Automatic Transaxle/transmission - FNR5: Specifications Ford Fusion I рестайлинг

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

a Specific tightening sequence is required. See the appropriate procedure.

Torque Converter Diagnosis

Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Prior to installing a new torque converter, all diagnostic procedures must be followed. This is to prevent the unnecessary installation of new or remanufactured torque converters. Only after a complete diagnostic evaluation can the decision be made to install a new torque converter.

Begin with the normal diagnostic procedures as follows

1. Preliminary Inspection.
2. Know and Understand the Customer Concern.
3. Verify the Concern - Carry out the Torque Converter Operations Test; refer to «Torque Converter Operations Test»(ref-291885-S09766915432008073000000) .
4. Carry out Diagnostic Procedures. Run On-Board Diagnostic (OBD); refer to «On-Board Diagnostic (OBD) with Scan Tool»(ref-291885-S03453998312008073000000) . Repair all non-transaxle related DTCs first. Repair all transaxle DTCs. Rerun OBD to verify repair. Carry out the Line Pressure Test. Refer to «Special Testing Procedures»(ref-291885-S37853139822008073000000) . Carry out the Stall Speed Test. Refer to «Special Testing Procedures»(ref-291885-S37853139822008073000000) . Carry out the Diagnosis by Symptom Index. Refer to «Diagnosis By Symptom»(ref-291885-S11416079262008073000000) . Use the index to locate the appropriate routine that best describes the symptom(s). The routine will list all possible components that may cause or contribute to the symptom. Check each component listed; diagnose and repair as necessary before installing a new or remanufactured torque converter.

Torque Converter Operations Test

This test verifies that the Torque Converter Clutch (TCC) control system and the torque converter are operating correctly.

1. Carry out the Self Test. Refer to «On-Board Diagnostic (OBD) with Scan Tool»(ref-291885-S03453998312008073000000) . Check for DTCs. Refer to «Diagnostic Trouble Code (DTC) Charts»(ref-291885-S19521950162008073000000) .
2. Connect a scan tool.
3. Bring the engine to normal operating temperature by driving the vehicle at highway speeds for approximately 15 minutes in D position.
4. After normal operating temperature is reached, maintain a constant vehicle speed of about 80 km/h (50 mph) and tap the brake pedal with the left foot.
5. The engine RPM should increase when brake pedal is tapped, and decrease about 5 seconds after pedal is released. If this does not occur, see Torque Converter Clutch (TCC) Operation Concerns. Refer to «Diagnosis By Symptom»(ref-291885-S11416079262008073000000) .
6. If the vehicle stalls in D at idle with vehicle at a stop, move the position selector lever to L position. If the vehicle stalls, refer to Torque Converter Clutch (TCC) Operation Concerns in the «Diagnosis By Symptom»(ref-291885-S11416079262008073000000) . Repair as necessary. If the vehicle does not stall in D position. Refer to «Diagnosis By Symptom»(ref-291885-S11416079262008073000000) .

Torque Converter Clutch (TCC) in Drive Mode

The Drive Mode allows the technician to turn the TCC off and on.

Drive Mode for TCC OFF operates only when

1. OSS and TR sensors are operational.
2. No OSS and TR sensor DTCs are set.
3. Engine is ON.
4. Selector lever is in D.
5. Vehicle speed is above 32 km/h (20 mph).

Drive Mode for TCC ON operates ONLY when

1. OSS and TR sensors are operational.
2. No OSS and TR sensor DTCs are set.
3. Engine is ON.
4. Selector lever is in D.
5. Vehicle speed is above 32 km/h (20 mph).
6. Transaxle in 2nd gear or higher.
7. Transmission Fluid Temperature (TFT) is between 16°C-135°C (60°F-275°F).
8. Brake is not applied below 32 km/h (20 mph).
9. Steady vehicle speed is maintained.

Transmission Fluid Leakage in Torque Converter Area

In diagnosing and correcting transmission fluid leaks in the pump support and gear and torque converter area, use the following procedures to locate the exact cause of the leakage. Leakage between the transaxle and engine, as evidenced by fluid around the torque converter housing, may have several sources. By careful observation it is possible, in many instances, to pinpoint the source of leakage before removing the transaxle from the vehicle. The paths which the fluid takes to reach the bottom of the torque converter housing are shown in the illustration. The 5 steps following correspond with the numbers in the illustration.

Scheme 393

1. Transmission fluid leaking by the pump seal lip will tend to move along the impeller hub and onto the back of the impeller housing. Except in the case of a total seal failure, transmission fluid leakage by the lip of the seal will be deposited on the inside of the torque converter housing only, near the outside diameter of the housing. Transmission fluid from the vent assembly may move along the impeller hub and onto the back of the impeller housing. Transmission fluid from a converter hub weld leak will move along a path on the inside of the converter housing.
2. Transmission fluid leakage by the outside diameter of the pump seal and pump body will follow the same path that leaks by the inside diameter of the pump seal follow. Transmission fluid from a converter hub weld leak will move along a path on the inside of the converter housing.
3. Transmission fluid that leaks by a pump-to-case screw or pump gasket will be deposited on the inside of the torque converter housing only. Transmission fluid will not be deposited on the back of the torque converter.
4. Transmission fluid leakage from the converter drain plug, (model-dependent) converter seal weld or converter-to-flexplate stud weld will appear at the outside diameter of the torque converter on the back face of the flexplate, and in the converter housing only near the flexplate. Transmission fluid leaks from the torque converter will leave a ring of transmission fluid around the inside of the torque converter housing.
5. Engine oil leaks are sometimes incorrectly diagnosed as transaxle pump gasket leaks. The following areas of possible leakage should also be checked to determine if engine oil leakage is causing the concern. Leakage at the valve cover gasket may allow oil to flow over the torque converter housing or seep down between the torque converter housing and cylinder block causing oil to be present in or at the bottom of the torque converter housing. Oil galley plug leaks will allow oil to flow down the rear face of the cylinder block to the bottom of the torque converter housing. Leakage at the crankshaft rear oil seal will work back to the flexplate, and then into the torque converter housing.

Torque Converter

1. A new or remanufactured torque converter must be installed if one or more of the following statements is true: A torque converter malfunction has been determined based on complete diagnostic procedures. Converter stud or studs, impeller hub or bushing are damaged. Discoloration (due to overheating). Evidence of transmission assembly or fluid contamination due to the following transmission or converter failure modes: Major metallic failure. Multiple clutches or clutch plate failures. Sufficient component wear which results in metallic contamination. Internal torque converter contamination present. For additional information refer to «Torque Converter Contamination Inspection»(ref-291885-S06293753322008073000000) .

Torque Converter Contamination Inspection

Material

Note. Do not use water-based cleaners or mineral spirits to clean or flush the torque converter or transaxle damage will occur. Use only clean transmission fluid designated for this transaxle.

1. If a new or remanufactured torque converter is not being installed, the following steps must be completed.
2. With the torque converter on a bench, pour a small amount of transmission fluid from the torque converter onto an absorbent white tissue or through a paper filter and examine the transmission fluid.
3. Observe the color and odor of the transmission fluid. The transmission fluid should be red, not brown or black. Odor may indicate an overheating condition such as clutch disc or band failure.
4. Examine the stain on the tissue for evidence of particles (spec of any kind). Examine the transmission fluid level indicator for signs of antifreeze (gum or varnish). If particles are present in the transmission fluid or there is evidence of engine coolant or water, a new torque converter must be installed.
5. If there are no particles or contamination present, drain the remainder of the transmission fluid from the torque converter.
6. Add 1.9L (2 qt) of clean transmission fluid into the converter and agitate by hand.
7. Thoroughly drain the transmission fluid.

Torque Converter Hub Seal

Special Tools Illustration Tool Name Tool Number Installer, Drive Pinion Oil Seal 205-115 (15058) Remover, Input Shaft Oil Seal 308-375 Slide Hammer 307-005 (T59L100-B)

Scheme 394

Scheme 395

Material

Material
