Cooling System Draining and Vacuum Filling
SPECIAL TOOL(S) / GENERAL EQUIPMENT ROB75240 Coolant/Battery Refractometer (Fahrenheit) UVU550000 Airlift Cooling Tester Fluid Container
Scheme 76
| Name | Specification |
|---|---|
| Motorcraft® - Orange Antifreeze/Coolant Prediluted VC-3DIL-B | WSS-M97B44-D2 |
| Motorcraft® Orange Antifreeze/Coolant Concentrated VC-3-B | WSS-M97B44-D |
MATERIALS SPECIFICATIONS
Scheme 77
Scheme 78
Scheme 79
Scheme 80
Scheme 81
- Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .
- Use a hose to drain the coolant. General Equipment: Fluid Container Loosen: 4 turn(s)
- Torque: 4 turn(s)
Pinpoint Test C
C4
UVU550000 (Airlift Cooling Tester)
- Special Tool(s): UVU550000 (Airlift Cooling Tester)
C5
ROB75240 (Coolant/Battery Refractometer (Fahrenheit))
- Measure the coolant concentration in the vehicle. Special Tool(s): ROB75240 (Coolant/Battery Refractometer (Fahrenheit))
- Determine the concentration desired based on the vehicle duty cycle of extreme hot or cold operating conditions.
- Add/top off or adjust the coolant as follows: For concentrations measured 48/52 to 50/50 (freeze protection -31°C to -37°C [-30°F to -34°F]), use Motorcraft® Orange Antifreeze/Coolant Prediluted to maintain a coolant concentration in this same range. Material: Motorcraft® - Orange Antifreeze/Coolant Prediluted / VC-3DIL-B (WSS-M97B44-D2) For all other concentrations, use Motorcraft® Orange Antifreeze/Coolant Concentrated and/or distilled water to get to the desired concentration. Material: Motorcraft® Orange Antifreeze/Coolant Concentrated / VC-3-B (WSS-M97B44-D) When refilling the engine coolant after a flush procedure, use a mixture of Motorcraft® Orange Antifreeze/Coolant Concentrated and distilled water to get to the desired concentration.
