Engine Cooling - 2.0L Ecoboost: Removal & Installation Ford Focus III

Cooling System (Mechanical) 25 illustrations ~393 words

Removal

Note. Removal steps in this procedure may contain installation details.

Scheme 51

Scheme 51: Removal

Scheme 52

Scheme 52
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
  2. Refer to: «Cooling System Draining and Vacuum Filling»(ref-515994-S34655776092012120400000) .
  3. Be prepared to capture escaping fluid. General Equipment: Hose Clamp Remover/Installer
  4. Torque: 10 Nm

Installation

  1. To install, reverse the removal procedure.
  1. To install, reverse the removal procedure.
  2. Fill the degas bottle. Material: Motorcraft® - Orange Antifreeze/Coolant Prediluted / VC-3DIL-B (WSS-M97B44-D2)

Note. Removal steps in this procedure may contain installation details.

Scheme 53

Scheme 53: Removal

Scheme 54

Scheme 54

Scheme 55

Scheme 55

Scheme 56

Scheme 56
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
  2. Refer to: «Cooling System Draining and Vacuum Filling»(ref-515994-S34655776092012120400000) .
  3. Loosen: 2 turn(s)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. Torque: 20 Nm

Note. Removal steps in this procedure may contain installation details.

Scheme 57

Scheme 57: Removal

Scheme 58

Scheme 58
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
  2. Refer to: «Cooling System Draining and Vacuum Filling»(ref-515994-S34655776092012120400000) .
  3. NOTE: Make sure the block heater wiring is routed and secured away from rotating or hot components.
  4. Torque: 40 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 59

Scheme 59

Scheme 60

Scheme 60

Scheme 61

Scheme 61

Scheme 62

Scheme 62

Scheme 63

Scheme 63

Scheme 64

Scheme 64

Scheme 65

Scheme 65

Scheme 66

Scheme 66
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
  2. Torque: 8 Nm
  3. Refer to: «Cooling System Draining and Vacuum Filling»(ref-515994-S34655776092012120400000) .
  4. Refer to: «CHARGE AIR COOLER (CAC)»(ref-515993-S24877701142012120400000) .
  5. On both sides. General Equipment: Transmission Jack Torque: 25 Nm
  6. General Equipment: Knife
  7. General Equipment: Transmission Jack
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 67

Scheme 67

Scheme 68

Scheme 68

Scheme 69

Scheme 69

Scheme 70

Scheme 70
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
  2. Refer to: «AIR CLEANER»(ref-515993-S21705096842012120400000) .
  3. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .
  4. If equipped.
  5. Loosen: 3 turn(s)
  1. To install, reverse the removal procedure.
  2. Torque: 25 Nm

Note. Removal steps in this procedure may contain installation details.

Scheme 71

Scheme 71

Scheme 72

Scheme 72

Scheme 73

Scheme 73

Scheme 74

Scheme 74

Scheme 75

Scheme 75
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
  2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-515934-S32792027622012120400000) .
  3. Refer to: «AIR CLEANER»(ref-515993-S21705096842012120400000) .
  4. Install new gaskets and O-ring seals. Torque: 15 Nm
  5. Refer to: «Cooling System Draining and Vacuum Filling»(ref-515994-S34655776092012120400000) .
  6. Torque: 5 Nm
  7. This procedure step requires the specified number of technicians. Torque: 25 Nm
  1. To install, reverse the removal procedure.
