Engine Cooling - 2.0L Duratec-He: Maintenance Ford Focus III

Cooling System Flushing

MATERIALS SPECIFICATIONS

1. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S15073665342012120400000) .
2. Add Motorcraft Premium Cooling System Flush to the cooling system and follow the directions on the package. Material: Motorcraft® Premium Cooling System Flush / VC-1 (ESR-M14P7-A)
3. Remove the radiator. Refer to: «Radiator»(ref-515984-S03776411122012120400000) .
4. Position the radiator with the upper radiator hose connection facing down. Use a high pressure water hose to backflush the radiator through the lower radiator hose connection.
5. Remove the thermostat housing. Refer to: «Thermostat Housing»(ref-515984-S03620469072012120400000) .
6. Position a high pressure water hose into the upper radiator hose and backflush the engine.
7. Install the thermostat housing. Refer to: «Thermostat Housing»(ref-515984-S03620469072012120400000) .
8. Install the radiator. Refer to: «Radiator»(ref-515984-S03776411122012120400000) .
9. Fill and bleed the cooling system. Refer to: «Cooling System Draining and Vacuum Filling»(ref-515984-S15674360012012120400000) . Refer to: «Cooling System Draining, Filling and Bleeding»(ref-515984-S18220348442012120400000) .

Cooling System Draining, Filling and Bleeding

SPECIAL TOOL(S) / GENERAL EQUIPMENT ROB75240 Coolant/Battery Refractometer (Fahrenheit)

MATERIALS SPECIFICATIONS

Scheme 33

1. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S15073665342012120400000) .
2. With the vehicle in NEUTRAL, position it on a hoist. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .
3. Remove the 6 pushpins, the 7 screws and the radiator air deflector.
4. Release the pressure in the cooling system by slowly turning the pressure relief cap 1/2 turn counterclockwise. When the pressure is released, remove the pressure relief cap.
5. Open the radiator draincock and drain the cooling system.
6. Close the radiator draincock when finished.

Cooling System Draining and Vacuum Filling

SPECIAL TOOL(S)/GENERAL EQUIPMENT ROB75240 Coolant/Battery Refractometer (Fahrenheit) UVU550000 Airlift Cooling Tester

Scheme 34

MATERIALS SPECIFICATIONS

1. Refer to: «ENGINE COOLING SYSTEM HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S15073665342012120400000) .
2. With the vehicle in NEUTRAL, position it on a hoist. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-515942-S20089493392012120400000) .
3. Remove the 6 pushpins, the 7 screws and the radiator air deflector.
4. Release the pressure in the cooling system by slowly turning the pressure relief cap 1/2 turn counterclockwise. When the pressure is released, remove the pressure relief cap.
5. Open the radiator draincock and drain the cooling system.
6. Close the radiator draincock when finished.
