Automatic Transmission External Controls - CD4E: Removal & Installation Ford Escape I рестайлинг

Installation

1. Lightly lubricate the shifter straw with multi-purpose grease, and install it into the shifter bore by pushing straight down.
2. Feed the overdrive cancel switch electrical connector wire harness into the opening in the bezel and install the knob.
3. Install the set screw.
4. Install the top finish panel.
5. Install the upper shift lever trim ring. To install the upper shift lever trim ring, orient the thick tab on the driver side front of the shifter and press into place.
6. Move the shifter through all gears from PARK to DRIVE several times, making sure that the shift knob set screw is not too tight.

Scheme 637

Scheme 638

Scheme 639

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-232183) .
2. Place the floor shift selector lever in the (D) position.
3. Gently pry up to remove the upper shift lever trim ring.
4. Remove the top finish panel.
5. Remove the set screw.
6. Remove the knob and wiring by pulling straight up on the knob.
7. Carefully pry up the 4 bezel clips and remove the bezel.
8. Remove the gearshift bezel.

1. Install the gearshift bezel.
2. Feed the overdrive cancel switch electrical connector wire harness into the opening in the bezel and install the knob.
3. Install the set screw.
4. Install the top finish panel.
5. Install the upper shift lever trim ring. To install the upper shift lever trim ring, orient the thick tab on the driver side front of the shifter and press into place.
6. Move the shifter through all gears from PARK to DRIVE several times making sure that the shift knob set screw is not too tight.

Scheme 640

1. Remove the loose selector lever button by carefully prying the button out with a screwdriver.

1. Install a new selector lever button by pressing the button into the selector lever until it clicks into place.
