Drain and Fill
| CAUTION | Use only clean automatic transmission fluid specific for this transmission. Do not use any supplemental transmission fluid additives or cleaning agents. The use of these products can cause internal transmission components to fail, which will affect the operation of the transmission. |
Scheme 522
Scheme 523
- With the vehicle in DRIVE, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-232183) .
- Turn the ignition to the OFF position.
- Remove the splash shield retainers and remove the LH splash shield.
- Place a suitable container under the transaxle drain plug.
- Remove the drain plug and drain the fluid.
- Remove the fill plug on the side of the transaxle.
- Install the drain plug. Tighten to 40 Nm (30 lb-ft). After the fluid has been drained, clean the drain plug threads and apply a small amount of pipe sealant.
- Fill the transaxle with clean automatic transmission fluid as specified until the level reaches the bottom of the fill plug hole.
- Install the fill plug. Tighten to 40 Nm (30 lb-ft).
- Install the LH splash shield and the retainers.
