Automatic Transmission - Electronically Controlled Continuously Variable Transmission (Ecvt) - (Hybrid): Component Locations Ford Escape I рестайлинг

Special Tool(s)

SPECIAL TOOL DESCRIPTION Remover, Input Shaft Oil Seal 308-375 Slide Hammer 100-001 (T50T-100-A) Installer, LH Halfshaft Fluid Seal 205-115

Scheme 524

SPECIAL TOOL DESCRIPTION Remover, Input Shaft Oil Seal 308-375 Slide Hammer 100-001 (T50T-100-A) Installer, RH Halfshaft Fluid Seal 308-382

Scheme 525

SPECIAL TOOL DESCRIPTION Adapter for 303-290A (Support Leg) 303-290A-03A Adapter for 303-290A (Lifting Hook) 303-290A-12 Support Bar, Engine 303-290A Adapters for 303-290A 303-290-01

Scheme 526

Scheme 527

Scheme 528

Scheme 529

Scheme 530

Scheme 531

Scheme 532

Scheme 533

Scheme 534

Scheme 535

Scheme 536

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-232183) .
2. Install the special tools.
3. Install the special tool.
4. Disconnect the heater hose retaining clip from the transaxle mount stud.
5. Remove insulator nut. To install, tighten to 90 Nm (66 lb-ft).
6. Remove the 3 bolts and the bracket. To install, tighten to 90 Nm (66 lb-ft).
7. Remove the nuts, heat shield, and insulator. To install, tighten to 90 Nm (66 lb-ft).
8. Remove the vacuum hose from the bottom of the insulator.
9. Remove and discard the vacuum hose from the vacuum solenoid.
10. Install the protective cap on the top port of the vacuum solenoid.
11. To install, reverse the removal procedure.
