SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Vapor Canister to Vehicle - Nuts | 9 | 80 | |
| PCV Valve | 2.5 | 22 |
Scheme 1
- Disconnect the negative battery cable.
- Partially raise the vehicle.
- Remove the right rear wheel.
- Remove the inner wheel splash shield.
- Disconnect electrical connector (1) to the ESIM (Evaporative System Integrity Monitor).
- Disconnect the lines (4, 5) from the EVAP canister side (6).
- Remove the mounting fasteners (2).
- Remove EVAP canister assembly.
