WHEN MONITORED
Continuously after 15 seconds of engine runtime, no O2 Sensor Heater DTCs present and battery voltage greater than 10.4 volts.
SET CONDITION
The Oxygen Sensor reference voltage is below 0.9 volts for 60 seconds. It takes one trip of problem identification to set the MIL.
POSSIBLE CAUSES
| Possible Causes |
|---|
| O2 SENSOR RETURN CIRCUIT SHORTED TO GROUND |
| O2 SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Engine running for 15 seconds, O2 Sensors at operating temperature and battery voltage greater 10.4 volts.
The PCM detects that the (K902) Reference Signal voltage is greater than 3.7 volts for nine seconds. It takes one trip of problem identification to set the MIL.
| Possible Causes |
|---|
| O2 SENSOR RETURN CIRCUIT SHORTED TO VOLTAGE |
| O2 SENSOR RETURN CIRCUIT OPEN OR HIGH RESISTANCE |
| OXYGEN SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on.
The Powertrain Control Module (PCM) detects an excessive voltage variation on the 5-Volt supply circuit.
| Possible Causes |
|---|
| 5-VOLT SUPPLY CIRCUIT SHORTED TO VOLTAGE |
| 5-VOLT SUPPLY CIRCUIT SHORTED TO GROUND |
| 5-VOLT SUPPLY CIRCUIT OPEN OR HIGH RESISTANCE |
| ACCELERATOR PEDAL POSITION SENSOR |
| CAMSHAFT 1/2 POSITION SENSOR |
| MAP SENSOR |
| FUEL TANK PRESSURE SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Continuously with the ignition on.
An attempt to program/write to the internal EEPROM failed. Also checks at power down. One Trip Fault. Three good trips to turn off the MIL.
| POSSIBLE CAUSES |
|---|
| POWERTRAIN CONTROL MODULE |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Engine in Run mode with vehicle speed present. The Powertrain Control Module (PCM) updates the mileage every eight miles.
The PCM detects a failed attempt to update Service Reminder Indicator (SRI) Mileage in the Control Module EEPROM. One trip fault.
| POSSIBLE CAUSES |
|---|
| SRI MILEAGE NOT PROGRAMMED INTO THE PCM |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Continuously with the ignition on.
An attempt to program/write to the internal EEPROM failed, Also checks at power down. One Trip Fault. Three good trips to turn off the MIL.
| Possible Causes |
|---|
| POWERTRAIN CONTROL MODULE (PCM) SOFTWARE UPDATE |
| EXCESSIVE RESISTANCE IN THE PCM POWER OR GROUND CIRCUITS |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and battery voltage greater than 10.0 volts.
An active DTC is stored in the ABS/ESP Module. One Trip Fault. Three good trips to turn off the MIL.
| Possible Causes |
|---|
| DTC PRESENT IN THE ABS MODULE |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
P1D6D-AGS CIRCUIT OVER TEMPERATURE
For a complete wiring diagram refer to appropriate SYSTEM WIRING DIAGRAMS article
Scheme 201
With the engine running and battery voltage between 11.0 and 16.0 volts.
The Powertrain Control Module (PCM) receives a message from the Active Grill Shutter Actuator that the internal actuator temperature is above 165°C (329°F) for 15.0 seconds. Two trip fault.
| Possible Causes |
|---|
| ACTIVE GRILL SHUTTER OBSTRUCTED/BINDING |
| ACTIVE GRILL SHUTTER ACTUATOR |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
P1D73-AGS PERFORMANCE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the engine running and battery voltage between 11.0 and 16.0 volts. Ambient Air Temperature or Engine Coolant Temperature above -7°C (19.4°F).
The Powertrain Control Module (PCM) receives a message from the Active Grill Shutter Actuator that the open to close position travel is above 100 degrees or the mechanical stop was detected before the commanded position was reached.
| Possible Causes |
|---|
| ACTIVE GRILL SHUTTER ACTUATOR FUSED B+ CIRCUIT OPEN/HIGH RESISTANCE |
| ACTIVE GRILL SHUTTER ACTUATOR GROUND CIRCUIT OPEN/HIGH RESISTANCE |
| ACTIVE GRILL SHUTTER OBSTRUCTED/BINDING |
| ACTIVE GRILL SHUTTER ACTUATOR LINKAGE DISCONNECTED/BINDING/BROKEN |
| ACTIVE GRILL SHUTTER ACTUATOR MOUNTING HARDWARE LOOSE OR MISSING |
| ACTIVE GRILL SHUTTER ACTUATOR |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
P1D83-IMPLAUSIBLE ENGINE OIL TEMPERATURE SIGNAL RECEIVED
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Scheme 202
With engine off time greater than 480 minutes and ambient temperature greater than -7°C (19.4°F).
After a calibrated amount of cool down time, the Powertrain Control Module (PCM) compares the AAT, ECT and IAT Sensor values. If the general temperature rationality passes, the PCM compares the Engine Oil Temperature (EOT) Sensor value to a threshold based on the other temp sensor values. If the difference is greater than a calibrated value, the diagnostic fails.
| Possible Causes |
|---|
| EXCESSIVE RESISTANCE IN THE EOT SENSOR SIGNAL CIRCUIT |
| EXCESSIVE RESISTANCE IN THE EOT SENSOR GROUND CIRCUIT |
| ENGINE OIL TEMPERATURE (EOT) SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
P1E09-CLOSED LOOP FUELING NOT ACHIEVED - BANK 1 DOWNSTREAM
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With engine running between 1100 RPMs and 4000 RPMs, and the upstream O2 Sensor in closed loop mode.
The Powertrain Control Module (PCM) detects a condition where the downstream O2 Sensor has remained in open loop fuel control, from a start-up condition, longer than a calibrated amount of time, when conditions would have otherwise expected closed loop operation. Two trip fault. Three good trips to turn off the MIL.
| POSSIBLE CAUSES |
|---|
| FUEL DELIVERY SYSTEM |
| ECT SENSOR, WIRING, OR CONNECTORS |
| MAP SENSOR, WIRING, OR CONNECTORS |
| O2 SENSOR, WIRING, OR CONNECTORS |
| ENGINE MECHANICAL SYSTEM |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the throttle plate is stuck during extremely cold ambient temperature operation. The PCM will initiate a throttle de-icing procedure, and if the throttle blade still doesn't move, this DTC will set. The MIL will not illuminate. The vehicle will be in Limp home condition, limiting RPM and vehicle speed.
| POSSIBLE CAUSES |
|---|
| THROTTLE PLATE OBSTRUCTION |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running in closed loop fuel control for 9.92 seconds.
The conditions that cause this diagnostic monitor to fail is when the Upstream O2 Sensor becomes biased from an exhaust leak, O2 Sensor contamination, or some other extreme operating condition. The Downstream O2 Sensor is considered to be protected from extreme environments by the catalyst. The Powertrain Control Module (PCM) monitors the Downstream O2 Sensor feedback control, called downstream fuel trim, to detect any shift in the Upstream O2 Sensor target voltage from nominal target voltage. The value of the downstream fuel trim is compared with the lean thresholds. Every time the value exceeds the calibrated threshold, a fail timer is incremented and mass flow through the exhaust is accumulated. If the fail timer and accumulated mass flow exceed the fail thresholds, the test fails and the diagnostic stops running for that trip. If the test fails on consecutive trips, a DTC is set.
| POSSIBLE CAUSES |
|---|
| EXHAUST LEAK |
| FUEL DELIVERY SYSTEM |
| O2 SENSOR, WIRING, OR CONNECTORS |
| ENGINE MECHANICAL SYSTEM |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running in closed loop fuel control for 9.92 seconds.
The conditions that cause this diagnostic monitor to fail is when the Upstream O2 Sensor becomes biased from an exhaust leak, O2 Sensor contamination, or some other extreme operating condition. The Downstream O2 Sensor is considered to be protected from extreme environments by the catalyst. The Powertrain Control Module (PCM) monitors the Downstream O2 Sensor feedback control, called downstream fuel trim, to detect any shift in the Upstream O2 Sensor target voltage from nominal target voltage. The value of the downstream fuel trim is compared with the lean thresholds. Every time the value exceeds the calibrated threshold, a fail timer is incremented and mass flow through the exhaust is accumulated. If the fail timer and accumulated mass flow exceed the fail thresholds, the test fails and the diagnostic stops running for that trip. If the test fails on consecutive trips, a DTC is set.
| POSSIBLE CAUSES |
|---|
| EXHAUST LEAK |
| FUEL DELIVERY SYSTEM |
| O2 SENSOR, WIRING, OR CONNECTORS |
| ENGINE MECHANICAL SYSTEM |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on and the ETC Motor not in Limp Home Mode.
When the Powertrain Control Module (PCM) detects an internal error or short between the ETC Motor (-) and ETC Motor (+) circuits in the ETC Motor Driver. One trip fault. ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| LOW BATTERY VOLTAGE |
| ETC MOTOR (+) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (-) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (+) CIRCUIT SHORTED TO GROUND |
| ETC MOTOR (-) CIRCUIT SHORTED TO GROUND |
| ETC MOTOR (+) CIRCUIT SHORTED TO THE ETC MOTOR (-) CIRCUIT |
| ETC MOTOR (+) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR (-) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR/THROTTLE BODY |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running, ETC motor not in Limp Home Mode, and TPS adaptation complete.
The Powertrain Control Module (PCM) detects too large of an error between the actual position of the throttle plate and the desired set point. One trip fault. The DTC will set within 5 seconds. Three good trips to turn off the MIL ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| LOW SYSTEM VOLTAGE |
| THROTTLE BODY ASSEMBLY |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on.
Internal Powertrain Control Module (PCM) failure. Module will attempt to reset, so you will be able to hear the throttle relearning. If the condition is continuous, the vehicle may not be drivable. One trip fault. ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and ETC motor is working.
When the Powertrain Control Module (PCM) requests to limit engine speed, if Pulse Width Modulated (PWM) signal is too high for 20.5 seconds, and before P2118 sets. One trip fault and the code will set within 5 seconds. ETC light is illuminated.
| POSSIBLE CAUSES |
|---|
| THROTTLE PLATE STUCK OR OBSTRUCTED |
| ETC MOTOR (+) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (-) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (+) CIRCUIT SHORTED TO THE ETC MOTOR (-) CIRCUIT |
| ETC MOTOR (+) CIRCUIT SHORTED TO GROUND |
| ETC MOTOR (-) CIRCUIT SHORTED TO GROUND |
| ETC MOTOR (+) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR (-) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and battery voltage greater than 10.0 volts.
Just after key on, the throttle is opened and closed to test the system. If the Powertrain Control Module (PCM) detects that the Throttle Position Sensor does not return to Limp Home Position, this DTC will set. One trip fault. The DTC will set within five seconds. ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| THROTTLE PLATE STICKING OR OBSTRUCTED |
| THROTTLE POSITION SENSOR CIRCUIT(S) HIGH RESISTANCE OR SHORTED |
| ETC MOTOR (+) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (-) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (+) CIRCUIT SHORTED TO THE ETC MOTOR (-) CIRCUIT |
| ETC MOTOR (+) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR (-) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR (+) CIRCUIT SHORTED TO GROUND |
| ETC MOTOR (-) CIRCUIT SHORTED TO GROUND |
| THROTTLE BODY ASSEMBLY |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and battery voltage greater than 10 volts.
Just after key on, the throttle is opened and closed to test the system. If the Powertrain Control Module (PCM) detects that the Throttle Position Sensor does not move from Limp Home Position, this DTC will set. One trip fault. The DTC will set within five seconds. ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| THROTTLE PLATE STICKING OR OBSTRUCTED |
| THROTTLE POSITION SENSOR CIRCUIT(S) HIGH RESISTANCE OR SHORTED |
| ETC MOTOR (+) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (-) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (+) CIRCUIT SHORTED TO THE ETC MOTOR (-) CIRCUIT |
| ETC MOTOR (+) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR (-) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR (+) CIRCUIT SHORTED TO GROUND |
| ETC MOTOR (-) CIRCUIT SHORTED TO GROUND |
| THROTTLE BODY ASSEMBLY |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the igniting on. During in-plant testing, the APPS is checked to make sure the minimum and maximum values can be reached. The PCM performs the diagnostic test for this DTC after the diagnostic test for P2166 has passed.
APPS 1 has failed to achieve the required minimum value during In-Plant testing. One trip fault and the code will set within 5 seconds. Engine will only idle.
| POSSIBLE CAUSES |
|---|
| ETC RELEARN |
| ACCELERATOR PEDAL POSITION SENSOR |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the igniting on. During in-plant testing, the APPS is checked to make sure the minimum and maximum values can be reached. The PCM performs the diagnostic test for this DTC after the diagnostic test for P2167 has passed.
APPS 2 has failed to achieve the required minimum value during In-Plant testing. One trip fault and the code will be stored within 5 seconds. Engine will only idle.
| POSSIBLE CAUSES |
|---|
| ETC RELEARN |
| ACCELERATOR PEDAL POSITION SENSOR |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and ETC motor is not in the Limp Home Position.
When the Powertrain Control Module (PCM) detects an internal error or a short between the ETC Motor (-) and ETC Motor (+) circuits in the ETC Motor Driver. One trip fault. ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| THROTTLE PLATE STUCK OR OBSTRUCTED |
| ETC MOTOR (+) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (-) CIRCUIT SHORTED TO VOLTAGE |
| ETC MOTOR (+) CIRCUIT SHORTED TO THE ETC MOTOR (-) CIRCUIT |
| ETC POSITIVE CIRCUIT SHORTED TO GROUND |
| ETC NEGATIVE CIRCUIT SHORTED TO GROUND |
| ETC MOTOR (+) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR (-) CIRCUIT OPEN OR HIGH RESISTANCE |
| ETC MOTOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the APP Sensor 1 input voltage is below the minimum acceptable value. Acceleration rate and Engine output are limited. One trip fault and the code will set within 5 seconds. ETC light is flashing
| POSSIBLE CAUSES |
|---|
| 5-VOLT SUPPLY APP SENSOR 1 CIRCUIT OPEN OR SHORTED TO GROUND |
| APP SENSOR 1 SIGNAL CIRCUIT SHORTED TO GROUND |
| APP SENSOR 1 SIGNAL CIRCUIT SHORTED TO THE APP SENSOR 1 GROUND CIRCUIT |
| APP SENSOR 1 SIGNAL CIRCUIT SHORTED TO THE APP SENSOR 2 GROUND CIRCUIT |
| APP SENSOR 1 SIGNAL CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR 1 GROUND CIRCUIT OPEN OR HIGH RESISTANCE |
| ACCELERATOR PEDAL POSITION SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the Accelerator Pedal Position (APP) Sensor 1 input voltage is above 4.73 volts for 0.08 seconds.
| POSSIBLE CAUSES |
|---|
| 5-VOLT SUPPLY APP SENSOR 1 CIRCUIT SHORTED TO VOLTAGE |
| APP SENSOR SIGNAL 1 CIRCUIT SHORTED TO VOLTAGE |
| APP SENSOR SIGNAL 1 CIRCUIT SHORTED TO THE 5-VOLT SUPPLY APP SENSOR 2 CIRCUIT |
| APP SENSOR SIGNAL 1 CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR 1 GROUND CIRCUIT OPEN OR HIGH RESISTANCE |
| ACCELERATOR PEDAL POSITION SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the APP Sensor 2 input voltage is below the minimum acceptable value. Acceleration rate and Engine output are limited. One trip fault and the code will set within 5 seconds. ETC light is flashing.
| Possible Causes |
|---|
| 5-VOLT SUPPLY CIRCUIT OPEN OR SHORTED TO GROUND |
| APP SENSOR 2 SIGNAL CIRCUIT OPEN |
| APP SENSOR 2 SIGNAL CIRCUIT SHORTED TO GROUND |
| APP SENSOR 2 SIGNAL CIRCUIT SHORTED TO THE APP SENSOR 1 RETURN CIRCUIT |
| APP SENSOR 2 SIGNAL CIRCUIT SHORTED TO THE APP SENSOR 2 RETURN CIRCUIT |
| APP SENSOR 2 GROUND CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on, battery voltage greater than 10.4 volts, and no Accelerator Pedal Position (APP) Sensor 1 and Accelerator Pedal Position (APP) Sensor 2 DTCs present.
The Powertrain Control Module (PCM) detects that the correlation between APP Sensor 1 and APP Sensor 2 is not plausible. Idle may be affected when the brake pedal is pressed or if a brake switch circuit error is present. Acceleration rate and engine output are limited. One trip fault and the code will set within five seconds. ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| 5-VOLT SUPPLY APP SENSOR 2 CIRCUIT SHORTED TO VOLTAGE |
| APP SENSOR SIGNAL 2 CIRCUIT SHORTED TO VOLTAGE |
| APP SENSOR SIGNAL 2 CIRCUIT SHORTED TO THE 5-VOLT SUPPLY APP 1 CIRCUIT |
| APP SENSOR SIGNAL 2 CIRCUIT SHORTED TO THE 5-VOLT SUPPLY APP 2 CIRCUIT |
| APP SENSOR SIGNAL 2 CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR 2 GROUND CIRCUIT OPEN OR HIGH RESISTANCE |
| ACCELERATOR PEDAL POSITION SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on, battery voltage greater than 10.4 volts, and no other Throttle Position Sensor DTCs present (P0121, P0122, P0123, P0221, P0222, P0223).
The Powertrain Control Module (PCM) detects that the Throttle Position Sensor voltages are not plausible for 0.13 seconds. One trip fault and the code will set within five seconds. ETC light is illuminated.
| POSSIBLE CAUSES |
|---|
| 5-VOLT SUPPLY CIRCUIT OPEN OR HIGH RESISTANCE |
| THROTTLE POSITION SENSOR SIGNAL 1 CIRCUIT OPEN OR HIGH RESISTANCE |
| THROTTLE POSITION SENSOR SIGNAL 2 CIRCUIT OPEN OR HIGH RESISTANCE |
| THROTTLE POSITION SENSOR GROUND CIRCUIT OPEN OR HIGH RESISTANCE |
| THROTTLE BODY |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on, battery voltage greater than 10.4 volts, and no Accelerator Pedal Position (APP) Sensor 1 and Accelerator Pedal Position (APP) Sensor 2 DTCs present.
The Powertrain Control Module (PCM) detects that the correlation between APP Sensor 1 and APP Sensor 2 is not plausible. Idle may be affected when the brake pedal is pressed or if a brake switch circuit error is present. Acceleration rate and engine output are limited. One trip fault and the code will set within five seconds. ETC light is flashing.
| POSSIBLE CAUSES |
|---|
| 5-VOLT SUPPLY APP SENSOR 1 CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR SIGNAL 1 CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR 1 GROUND CIRCUIT OPEN OR HIGH RESISTANCE |
| 5-VOLT SUPPLY APP SENSOR 2 CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR SIGNAL 2 CIRCUIT OPEN OR HIGH RESISTANCE |
| APP SENSOR 2 GROUND CIRCUIT OPEN OR HIGH RESISTANCE |
| ACCELERATOR PEDAL POSITION SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the igniting on. During in-plant testing, the APP Sensor is checked to make sure the minimum and maximum values can be reached.
APPS 1 has failed to achieve the required maximum value during In-Plant testing. One trip fault and the code will set within five seconds. Engine will only idle.
| POSSIBLE CAUSES |
|---|
| ETC RELEARN |
| ACCELERATOR PEDAL POSITION SENSOR |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the igniting on. During in-plant testing, the APP Sensors need to be checked to make sure the minimum and maximum values can be reached.
APPS 2 has failed to achieve the required maximum value during In-Plant testing. One trip fault and the code will be stored within five seconds. Engine will only idle.
| POSSIBLE CAUSES |
|---|
| ETC RELEARN |
| ACCELERATOR PEDAL POSITION SENSOR |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and engine running with no active DTCs for MAP Sensor, Throttle Position Sensors, Cam or Crank Position Sensors, or a 5-Volt Reference circuit.
The Powertrain Control Module (PCM) detects that a large vacuum leak has been detected and calculated MAP is less than actual MAP minus an offset value for more than 0.28 seconds. One trip fault.
| POSSIBLE CAUSES |
|---|
| ENGINE OIL LEVEL LOW |
| ENGINE OIL OR FILTER INCORRECT |
| ENGINE OIL CONTAMINATED |
| VACUUM LEAK |
| MAP SENSOR CIRCUIT(S) OPEN, SHORTED, OR HIGH RESISTANCE |
| THROTTLE POSITION SENSOR CIRCUIT(S) OPEN, SHORTED, OR HIGH RESISTANCE |
| MAP SENSOR |
| THROTTLE POSITION SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and engine running with no active DTCs for MAP Sensor, Throttle Position Sensors, Cam or Crank Position Sensors, or a 5-Volt Reference circuit.
A large vacuum leak has been detected and calculated MAP is less than the Gas Flow Adaptation value for more than 0.28 seconds. One trip fault.
| POSSIBLE CAUSES |
|---|
| VACUUM LEAK |
| MAP SENSOR CIRCUIT(S) OPEN, SHORTED, OR HIGH RESISTANCE |
| MAP SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on and engine running with no active DTCs for MAP Sensor, Throttle Position Sensors, Cam or Crank Position Sensors, or a 5-Volt Reference circuit.
The Powertrain Control Module (PCM) detects that a large vacuum leak has been detected and calculated MAP is greater than actual MAP minus an offset value for more than 0.28 seconds. One trip fault.
| POSSIBLE CAUSES |
|---|
| AIR INTAKE SYSTEM OBSTRUCTION |
| VACUUM LEAK |
| MAP SENSOR CIRCUIT(S) OPEN, SHORTED, OR HIGH RESISTANCE |
| THROTTLE POSITION SENSOR CIRCUIT(S) OPEN, SHORTED, OR HIGH RESISTANCE |
| MAP SENSOR |
| THROTTLE POSITION SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on, engine running, and no Engine Coolant Temperature (ECT) Sensor DTCs present.
The coolant temperature should change at a specific rate. If this rate is too slow or too fast this fault will set. One trip fault. Three good trips to clear MIL.
| POSSIBLE CAUSES |
|---|
| LOW COOLANT LEVEL |
| THERMOSTAT |
| COOLING SYSTEM RESTRICTION OR POOR FLOW |
| HIGH RESISTANCE IN THE ECT 1 SENSOR SIGNAL CIRCUIT |
| HIGH RESISTANCE IN THE SENSOR GROUND CIRCUIT |
| ENGINE COOLANT TEMPERATURE SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
P219A-BANK 1 AIR-FUEL RATIO IMBALANCE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Engine Coolant Temperature (ECT) is greater than 70°C (158°F), Engine run time of 90 seconds, engine RPM 1000 - 2700, engine load 30 - 90% and in flex fuel vehicles the Fuel Adaptive Learned must be completed.
DTC P113D is not set and the high frequency content of the O2 sensor exceeds a calibrated amount. Two Trip Fault. Three good trips to turn off the MIL.
| Possible Causes |
|---|
| O2 SENSOR HEATER OPERATION |
| EVAP PURGE SOLENOID OPERATION |
| O2 SIGNAL CIRCUIT |
| O2 RETURN CIRCUIT |
| O2 SENSOR |
| MAP SENSOR |
| ECT SENSOR |
| ENGINE MECHANICAL |
| FUEL FILTER/PRESSURE REGULATOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running for more than 90 seconds, in closed loop fuel control, the odometer greater than the minimum mileage allowable for catalyst break-in (499.7 miles), and no global or monitor conflicts or disabling conditions present. The diagnostic monitor will only run during a decel fuel shutoff event, and will only run once during each ignition cycle.
If during the decel fuel shutoff event, the Powertrain Control Module (PCM) detects that the sensor does not transition from rich to lean, the fault will set. An active fault is matured on a second trip failure. Three good trips will turn off the MIL.
| POSSIBLE CAUSES |
|---|
| EXHAUST LEAK |
| OXYGEN SENSOR WIRING OR CONNECTORS |
| O2 SENSOR SIGNAL CIRCUIT |
| O2 SENSOR RETURN CIRCUIT |
| 1/2 OXYGEN SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on and no Brake Switch or Accelerator Pedal Position (APP) Sensor DTCs present.
The Powertrain Control Module (PCM) detects that the Brake Switch and the Accelerator Pedal are both pressed for a calculated amount of time. One trip fault and the code will be set within five seconds. ETC light will illuminate, the light will only stay illuminated while DTC is active.
| Possible Causes |
|---|
| CUSTOMER PRESSING ACCELERATOR PEDAL, THEN PRESSING BRAKE PEDAL, AND CONTINUES HOLDING THEM DOWN SIMULTANEOUSLY |
| BRAKE SWITCH |
| ACCELERATOR PEDAL POSITION SENSOR |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.
| Possible Causes |
|---|
| (F343) FUSED ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE |
| (K19) COIL 1 CONTROL CIRCUIT SHORTED TO GROUND |
| (K19) COIL 1 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE |
| IGNITION COIL 1 |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.
| Possible Causes |
|---|
| (F343) FUSED ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE |
| (K17) COIL 2 CONTROL CIRCUIT SHORTED TO GROUND |
| (K17) COIL 2 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE |
| IGNITION COIL 2 |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.
| Possible Causes |
|---|
| (F343) FUSED ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE |
| (K18) COIL 3 CONTROL CIRCUIT SHORTED TO GROUND |
| (K18) COIL 3 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE |
| IGNITION COIL 3 |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine running and battery voltage greater than 10.4 volts.
The Powertrain Control Module (PCM) detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.
| Possible Causes |
|---|
| (F343) FUSED ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE |
| (K15) COIL 4 CONTROL CIRCUIT SHORTED TO GROUND |
| (K15) COIL 4 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE |
| IGNITION COIL 4 |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine speed greater than 1157 RPM.
The Powertrain Control Module (PCM) detects that battery voltage is 1.0 volt below charging goal voltage. The PCM compares sensed battery voltage with the field driver on and off. If the voltages are the same, this code will set. One Trip Fault. Three good trips to turn off the MIL.
| POSSIBLE CAUSES |
|---|
| BATTERY (+) CIRCUIT HIGH RESISTANCE |
| BATTERY (-) CIRCUIT HIGH RESISTANCE |
| GENERATOR CASE GROUND HIGH RESISTANCE |
| FUSED B+ CIRCUIT HIGH RESISTANCE |
| GROUND CIRCUIT(S) HIGH RESISTANCE |
| BATTERY |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the engine speed greater than 1157 RPM.
The Powertrain Control Module (PCM) compares sensed battery voltage with the Generator Sense circuit voltage. If the Generator Sense circuit voltage is greater than sensed battery voltage, this DTC will set. One Trip Fault. Three good trips to turn off the MIL.
| POSSIBLE CAUSES |
|---|
| BATTERY (+) CIRCUIT HIGH RESISTANCE |
| BATTERY (-) CIRCUIT HIGH RESISTANCE |
| GENERATOR CASE GROUND HIGH RESISTANCE |
| FUSED B+ CIRCUIT HIGH RESISTANCE |
| GROUND CIRCUIT(S) HIGH RESISTANCE |
| BATTERY |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Continuously.
The Powertrain Control Module (PCM) has detected an interruption in the supplied battery voltage while the module is powered down. Two Trip Fault. Three good trips to turn off the MIL.
| Possible Causes |
|---|
| AMBIENT AIR TEMPERATURE SENSOR |
| COOLANT TEMPERATURE SENSOR |
| POWERTRAIN CONTROL MODULE (PCM) SOFTWARE UPDATE |
| EXCESSIVE RESISTANCE IN THE PCM POWER OR GROUND CIRCUITS |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition run time is greater than one second. Battery voltage between 9 and 16 volts. Engine run time greater than three seconds.
The Powertrain Control Module (PCM) loses communication over the CAN C Bus circuit. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS OPEN OR SHORTED CONDITION |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition run time is greater than one second. Battery voltage between 9.0 and 16.0 volts. Engine run time greater than three seconds.
The Powertrain Control Module (PCM) doesn't receive a Bus Message from the Transmission Control Module (TCM) for seven consecutive seconds. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS OPEN OR SHORTED CONDITION |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition run time is greater than one second. Battery voltage between 9.0 and 16.0 volts. Engine run time greater than three seconds.
The Powertrain Control Module (PCM) doesn't receive an ABS message over the CAN C circuit for seven consecutive seconds. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS OPEN OR SHORTED CONDITION |
| ANTI-LOCK BRAKE (ABS) MODULE |
| BODY CONTROL MODULE (BCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on.
The Powertrain Control Module (PCM) fails to receive CAN bus messages from the Dynamics Sensor.
Note. The Dynamics Sensor is internal to the Occupant Restraint Controller (ORC).
| Possible Causes |
|---|
| CAN B OR CAN C BUS CIRCUITS OPEN OR SHORTED |
| DTCS RELATED TO BATTERY VOLTAGE, IGNITION, OR VIN MESSAGES |
| OCCUPANT RESTRAINT CONTROLLER (ORC) |
| POWERTRAIN CONTROL MODULE (PCM) |
Continuously when the ignition is on.
The battery voltage between 10.0 and 16.0 Volts.
Bus messages not received from the Electric Power Steering Control Module.
| Possible Causes |
|---|
| CAN BUS CIRCUITS OPEN OR SHORTED |
| DTCS RELATED TO BATTERY VOLTAGE, IGNITION, OR VIN MESSAGES |
| BODY CONTROL MODULE POWER AND GROUND |
| BCM NOT CONFIGURED CORRECTLY |
| BODY CONTROL MODULE (BCM) |
| MODULE THAT SET THIS DTC |
Ignition run time is greater than one second. Battery voltage between 9.0 and 16.0 volts.
The Powertrain Control Module (PCM) doesn't receive a Body Control Module (BCM) message over the CAN C bus for seven consecutive seconds. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS OPEN OR SHORTED CONDITION |
| BODY CONTROL MODULE (BCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition run time is greater than one second. Battery voltage between 9.0 and 16.0 volts. Engine run time greater than three seconds.
The Powertrain Control Module (PCM) doesn't receive an Occupant Restraint Controller (ORC) message over the CAN C circuit for seven consecutive seconds. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS OPEN OR SHORTED CONDITION |
| OCCUPANT RESTRAINT CONTROLLER (ORC) |
| BODY CONTROL MODULE (BCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on.
Battery voltage between 10.0 and 17.0 Volts.
Body Control Module (BCM) is configured correctly.
This module has not received a Cluster Bus message over the CAN C circuit for approximately two to five seconds. The circuit is continuously monitored.
| Possible Causes |
|---|
| CAN B BUS CIRCUITS OPEN OR SHORTED |
| DTCS RELATED TO BATTERY VOLTAGE, IGNITION, OR VIN MESSAGES |
| CLUSTER (CCN) |
| BODY CONTROL MODULE (BCM) NOT CONFIGURED CORRECTLY |
| BODY CONTROL MODULE (BCM) |
| MODULE THAT SET THIS DTC |
Ignition run time is greater than one second. Battery voltage between 9.0 and 16.0 volts.
The Powertrain Control Module (PCM) doesn't receive a HVAC Control Module message over the CAN bus. The circuit is continuously monitored.
| Possible Causes |
|---|
| CAN IHS BUS (125K) CIRCUITS OPEN OR SHORTED CONDITION |
| HVAC CONTROL MODULE |
| MODULE THAT SET THE DTC |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on.
Battery voltage between 10.0 and 16.0 volts.
Body Control Module (BCM) is configured correctly.
The module has not received a Steering Column Control Module (SCCM) Bus message for approximately two to five seconds.
| Possible Causes |
|---|
| CAN BUS CIRCUITS OPEN OR SHORTED |
| DTCS RELATED TO BATTERY VOLTAGE, IGNITION, OR VIN MESSAGES |
| STEERING COLUMN CONTROL MODULE (SCCM) |
| BODY CONTROL MODULE (BCM) NOT CONFIGURED CORRECTLY |
| BODY CONTROL MODULE (BCM) |
| MODULE THAT SET THIS DTC |
Ignition on and battery voltage greater than 10.0 volts.
The Powertrain Control Module (PCM) software is incorrect.
| POSSIBLE CAUSES |
|---|
| PCM PROGRAMMED WITH INCORRECT SOFTWARE |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Continuously while the system is active.
Implausible data has been received over the bus from the Transmission Control Module (TCM).
| POSSIBLE CAUSES |
|---|
| CAN BUS OPEN OR SHORTED CONDITION |
| TRANSMISSION CONTROL MODULE (TCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Continuously while the system is active.
Implausible data has been received over the bus from the Electronic Stability Program (ESP) in the ABS Module.
| POSSIBLE CAUSES |
|---|
| CAN BUS OPEN OR SHORTED CONDITION |
| ELECTRONIC STABILITY PROGRAM (ESP)/ANTILOCK BRAKE MODULE (ABS) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Continuously while the system is active.
An error message has been received over the CAN C bus from the Steering Angle Sensor (SAS).
| Possible Causes |
|---|
| CAN BUS OPEN OR SHORTED CONDITION |
| STEERING ANGLE SENSOR (SAS) / STEERING COLUMN CONTROL MODULE (SCCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
U110A-LOST COMMUNICATION WITH SCM - CAN-C
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
Battery voltage between 10.0 and 16.0 volts.
Body Control Module (BCM) is configured correctly.
The module has not received a Steering Control Module (SCM) Bus message for approximately two to five seconds.
| Possible Causes |
|---|
| CAN BUS CIRCUITS OPEN OR SHORTED |
| DTCS RELATED TO BATTERY VOLTAGE, IGNITION, OR VIN MESSAGES |
| STEERING COLUMN MODULE (SCM) |
| BODY CONTROL MODULE (BCM) NOT CONFIGURED CORRECTLY |
| BODY CONTROL MODULE (BCM) |
| MODULE THAT SET THIS DTC |
U110C-LOST FUEL LEVEL MESSAGE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on, battery voltage above 10.38 volts.
The Powertrain Control Module (PCM) does not receive a fuel level signal over the CAN C BUS circuit for a duration of 4.8 seconds. The circuit is constantly monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS CIRCUIT OPEN OR SHORTED |
| BODY CONTROL MODULE (BCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
U110E-LOST AMBIENT TEMPERATURE MESSAGE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on, battery voltage above 10.38 volts.
The Powertrain Control Module (PCM) does not receive the ambient temperature signal over the CAN C BUS from the Body Control Module (BCM), or the signal is implausible for a duration of 4.8 seconds. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS CIRCUIT OPEN OR SHORTED |
| BODY CONTROL MODULE (BCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on, and battery voltage above 10.38 volts.
The PCM does not receive a vehicle speed signal from the Anti-Lock Brake Module over the CAN C bus for a duration of 4.8 seconds.
| POSSIBLE CAUSES |
|---|
| CAN C BUS CIRCUIT OPEN OR SHORTED |
| ANTI-LOCK BRAKE (ABS) MODULE |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on for more than 2.0 seconds, battery voltage between 6.98 volts and 15.75 volts.
The Powertrain Control module (PCM) does not receive a message for the wheel distance traveled from the Anti-Lock Brake Module over the CAN C bus for a duration of 0.4 seconds.
| POSSIBLE CAUSES |
|---|
| CAN C BUS CIRCUIT OPEN OR SHORTED |
| ANTI-LOCK BRAKE (ABS) MODULE |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Continuously while the system is active.
The Powertrain Control Module (PCM) has not received a torque request over the bus circuit from the Electronic Stability Program (ESP)/ABS Module.
| Possible Causes |
|---|
| CAN BUS OPEN OR SHORTED CONDITION |
| ELECTRONIC STABILITY PROGRAM (ESP)/ANTILOCK BRAKE MODULE (ABS) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
U11B9-LOST COMMUNICATION WITH RF HUB
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
Battery voltage between 10 and 16 volts.
Body Control Module (BCM) is configured correctly.
This module has not received a RF Hub CAN Bus message for approximately two to five seconds.
| Possible Causes |
|---|
| CAN BUS CIRCUITS OPEN OR SHORTED |
| DTCS RELATED TO BATTERY VOLTAGE, IGNITION, OR VIN MESSAGES |
| RF HUB |
| BCM NOT CONFIGURED CORRECTLY |
| BODY CONTROL MODULE (BCM) |
| MODULE THAT SET THE DTC |
U11BC-LOST BRAKE SWITCH MESSAGE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Ignition on.
The Powertrain Control Module (PCM) doesn't receive a brake switch signal from the Anti-lock brake Module over the CAN C bus. One Trip fault.
| Possible Causes |
|---|
| BRAKE PEDAL POSITION (BPP) SENSOR |
| CAN C BUS CIRCUIT OPEN OR SHORTED |
| ANTI-LOCK BRAKE MODULE |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
U11C2-IMPLAUSIBLE/MISSING TRANSMISSION MESSAGE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
- With the ignition on.
- Battery voltage between 10 and 16 volts.
- Body Control Module (BCM) is configured correctly.
The Powertrain Control Module (PCM) has not received a Bus message from the Transmission Control Module (TCM) for approximately 500ms.
| Possible Causes |
|---|
| CAN BUS CIRCUITS OPEN OR SHORTED |
| TRANSMISSION CONTROL MODULE (TCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
U11E9-LOST COMMUNICATION WITH AGS
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the engine running and battery voltage between 11.0 and 16.0 volts. Ambient Air Temperature or Engine Coolant Temperature above -7°C (19.4°F).
The Powertrain Control Module (PCM) does not receive a valid LIN BUS message from the Active Grill Shutter Assembly for 2.6 seconds.
| Possible Causes |
|---|
| LIN BUS CIRCUIT SHORTED TO GROUND |
| LIN BUS CIRCUIT OPEN/HIGH RESISTANCE |
| FUSED B+ CIRCUIT OPEN |
| FUSED B+ CIRCUIT SHORTED TO GROUND |
| ACTIVE GRILL SHUTTER GROUND CIRCUIT OPEN |
| ACTIVE GRILL SHUTTER ASSEMBLY |
| POWERTRAIN CONTROL MODULE |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on, battery voltage above 10.38 volts.
The fuel level message that the Powertrain Control Module (PCM) is receiving from the Body Control Module (BCM) is implausible for a duration of 4.8 seconds. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS CIRCUIT OPEN OR SHORTED |
| BODY CONTROL MODULE (BCM) |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
With the ignition on.
The Powertrain Control Module (PCM) gets an implausible signal over the CAN C circuit from the ABS Module. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| CAN C BUS CIRCUIT SHORTED |
| CAN C BUS CIRCUIT OPEN |
| ANTI-LOCK BRAKE (ABS) MODULE |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on.
The Powertrain Control Module (PCM) gets an implausible signal over the CAN C circuit from the ABS Module. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| VEHICLE SPEED SENSOR DTC ACTIVE IN ANTI-LOCK BRAKE MODULE |
| CAN C BUS CIRCUIT SHORTED |
| CAN C BUS CIRCUIT OPEN |
| ANTI-LOCK BRAKE (ABS) MODULE |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
Ignition on.
The Powertrain Control Module (PCM) gets an implausible signal over the CAN C circuit from the Anti-Lock Brake (ABS) Module. The circuit is continuously monitored.
| POSSIBLE CAUSES |
|---|
| VEHICLE SPEED SENSOR DTC ACTIVE IN ANTI-LOCK BRAKE MODULE |
| CAN C BUS CIRCUIT SHORTED |
| CAN C BUS CIRCUIT OPEN |
| ANTI-LOCK BRAKE (ABS) MODULE |
| POWERTRAIN CONTROL MODULE (PCM) |
Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .
