Driveability - Gas - Non-Dtc Based Diagnostics: Other Dodge Dart PF

Testing & Diagnostics 6 illustrations ~1780 words

CHECKING THE ENGINE MECHANICAL SYSTEM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

CHECKING THE EXHAUST SYSTEM FOR LEAKS

A multimedia supplement to the instructions contained in this article is available. To the multimedia example of the condition described go to; http://www.youtube.com/user/Mitchell1Tips then type "A00646310.vid1" into the "Search Channel" box

Scheme 97

Scheme 97: CHECKING THE EXHAUST SYSTEM FOR LEAKS

CHECKING THE FUEL DELIVERY SYSTEM (HARD START)

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

POSSIBLE CAUSES

Possible Causes
FUEL DELIVERY SYSTEM LEAKING OR DAMAGED
RESTRICTED FUEL SUPPLY LINE
FUEL PUMP INLET STRAINER PLUGGED
FUEL PUMP CONTROL OUTPUT CIRCUIT OPEN
FUEL INJECTOR(S)
FUEL PUMP MODULE
WARNINGFollow these safety precautions to reduce the risk of fire and possible serious or fatal injury when performing this test procedure. Fuel or fuel vapors are highly flammable. A fire could occur if an ignition source is present. Do not expose the fuel or the test equipment used in this procedure to open flames or sparks. Inhalation of fuel vapors could lead to disorientation and personal injury. Keep the service area well ventilated, or perform this test procedure in an area where there is a building exhaust removal system. Relieve fuel system pressure before servicing fuel system components. Use extreme caution when connecting and disconnecting fuel lines. Considerable fuel leakage may occur when servicing the fuel system. Wear protective eye wear and clothing to protect from fuel splash, and take suitable fuel containment measures. Wrap a shop towel around the fuel pressure gauge connection to absorb fuel leakage that occurs when connecting the test equipment. Place the towel in an approved container when complete. Never store fuel in an open container due to the possibility of fire or explosion. Have a dry chemical (Class B) fire extinguisher nearby.

Scheme 98

Scheme 98: DIAGNOSTIC TEST

Scheme 99

Scheme 99

Scheme 100

Scheme 100

Scheme 101

Scheme 101

Scheme 102

Scheme 102
  1. CHECK THE FUEL DELIVERY SYSTEM FOR LEAKS AND DAMAGE WARNING: The fuel system is under a constant pressure (even with the engine off). Before testing or servicing any fuel system hose, fitting, or line, the fuel system pressure must be released. Failure to follow these instructions can result in possible serious or fatal injury. Visually and physically inspect the fuel delivery system for external leaks and damage. Is the system leaking or damaged? Yes Repair or replace as necessary. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . No Go To 2
  2. CHECK FUEL PUMP OPERATION Ignition on, engine not running. With a scan tool, actuate the Fuel System test. NOTE: It may be necessary to use a mechanics stethoscope in the next step. Listen for fuel pump operation at the Fuel Tank. Does the Fuel Pump operate? Yes Go To 3 No Check the power and ground circuits to the Fuel Pump Module assembly. If the circuits test good, replace the Fuel Pump Module assembly. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance .
  3. INSTALL APPROPRIATE FUEL LINE ADAPTERS/FITTING FROM THE GAS AND DIESEL FUEL PRESSURE/DECAY TESTER 8978A Turn the ignition off. WARNING: The fuel system is under a constant pressure (even with the engine off). Before testing or servicing any fuel system hose, fitting, or line, the fuel system pressure must be released. Failure to follow these instructions can result in possible serious or fatal injury. Release the fuel system pressure. Refer to «FUEL DELIVERY, GAS, STANDARD PROCEDURE»(ref-646230-S42658421212014072800000) . Disconnect the rail fuel supply line connector between the fuel supply line and the fuel rail. Refer to «FITTING, QUICK CONNECT, STANDARD PROCEDURE»(ref-646230-S25407444222014072800000) . Install the appropriate Fuel Line Adapters/Fitting from the Gas and Diesel Fuel Pressure/Decay Tester (special tool #8978A, Decay Tool, Fuel). Proceed Go To 4
  4. INSTALL THE FUEL PRESSURE GAUGE ASSEMBLY Connect the (special tool #8978A, Decay Tool, Fuel), with the Fuel Inlet Hose (1) toward the Fuel tank side and the Fuel Outlet Hose (2) toward the fuel rail side of the system using the Fuel Line Adapters/Fitting as needed. Connect special tool Drain Extension Hose 535680 (3) to the Fuel Pressure Gauge Assembly Drain Hose (5). Connect Reservoir Assembly 534960 (4) to Drain Extension Hose 535680 (3). WARNING: To reduce the risk of fire and possible serious or fatal injury, place Reservoir Assembly 534960 (4) on the floor and out of the way so that it is not a trip hazard. Proceed Go To 5
  5. CHECK THE FUEL PRESSURE Perform the following procedure to purge air from the system: Open the Fuel System Isolation Valve (1). Close the Flow Test Valve (2). Ignition on, engine not running. With the scan tool, actuate the Fuel Pump. Open the Flow Test Valve (2) for 10 seconds, then close the Valve. CAUTION: Stop All Actuations. Turn the ignition off. Disconnect, empty and then reconnect the Reservoir Assembly. Turn the ignition on. With the scan tool, actuate the Fuel Pump. NOTE: On vehicles equipped with a PWM Fuel Pump, actuate the Fuel Pump at or above 60%. Read the Fuel Pressure Gauge (3) and record the reading. NOTE: The fuel pressure specification for all engines, including a Non SRT-4 is 407 kPa +/- 34 kPa (59 psi +/- 5 psi). SRT-4 fuel pressure specification is 552 kPa +/- 34 kPa (80 psi +/- 5 psi). Choose a conclusion that best matches your fuel pressure reading. Below Specification Go To 10 Within Specification Go To 6 Above Specification Replace the fuel filter/fuel pressure regulator. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . CAUTION: Stop all actuations.
  6. CHECK THE FUEL DELIVERY SYSTEM OUTPUT WARNING: The fuel system is under a constant pressure (even with the engine off). Before testing or servicing any fuel system hose, fitting, or line, the fuel system pressure must be released. Failure to follow these instructions can result in possible serious or fatal injury. With the scan tool, continue to actuate the fuel pump. Open the Flow Test Valve (1) for 20 seconds, then close the Valve. CAUTION: Stop all actuation tests before proceeding. Turn the ignition off. Measure the amount of fuel in the Reservoir Assembly (2). The fuel output specification is ml/s X 20 seconds = fuel flow in ml. FUEL FLOW ENGINE ml/s ml per 20 Seconds 4 Cylinder and 6 Cylinder 20.8333 417 8 Cylinder 38.88889 778 SRT-4 50 1000 10 cylinder 55.5 1110 Does the amount of fuel in the reservoir meet or exceed the specification? Yes Go To 7 No Go To 8
  7. CHECK THE FUEL DELIVERY SYSTEM FOR LEAK DOWN WARNING: The fuel system is under a constant pressure (even with the engine off). Before testing or servicing any fuel system hose, fitting, or line, the fuel system pressure must be released. Failure to follow these instructions can result in possible serious or fatal injury. Ignition on, engine not running. With the scan tool, actuate the fuel pump. Close the Fuel System Isolation Valve (1). CAUTION: Stop all actuation tests before proceeding. Turn the ignition off and then wait five minutes before proceeding. Read the Fuel Inlet (2) and Fuel Outlet (3) Pressure Gauges. The pressure should not drop more than 10 psi on either gauge. Does the fuel pressure drop more than 10 psi? Yes - On Fuel Inlet Gauge (2) Replace the Fuel Pump Module. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . Yes - On Fuel Outlet Gauge (3) Replace the leaking Fuel Injector(s). Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . No If directed here by another test, return to that test. Otherwise, test complete.
  8. CHECK FOR RESTRICTED FUEL SUPPLY LINE WARNING: The fuel system is under a constant pressure even with the engine off. Before testing or servicing any fuel system hose, fitting or line, the fuel system pressure must be released. Turn the ignition off. Disconnect the Fuel Pressure Decay Tester. Raise the vehicle on a hoist, and disconnect the fuel pressure line at the Fuel Pump Module. Install the Fuel Pressure Decay Tester between the fuel supply line and the Fuel Pump Module. Again, purge air from the system. Ignition on, engine not running. With the scan tool, actuate the Fuel Pump. Open the Flow Test Valve (1) for 20 seconds, then close the Valve. CAUTION: Stop all actuation tests before proceeding. Turn the ignition off. Measure the amount of fuel in the Reservoir Assembly (2). The fuel output specification is ml/s X 20 seconds = fuel flow in ml. FUEL FLOW ENGINE ml/s ml per 20 Seconds 4 Cylinder and 6 Cylinder 20.8333 417 8 Cylinder 38.88889 778 SRT-4 50 1000 10 cylinder 55.5 1110 Does the amount of fuel in the reservoir meet or exceed the specification? Yes Repair/replace fuel supply line as necessary. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . No Go To 9 CAUTION: Stop all actuation tests before proceeding.
  9. CHECKING THE FUEL INLET STRAINER WARNING: The fuel system is under a constant pressure (even with the engine off). Before testing or servicing any fuel system hose, fitting or line, the fuel system pressure must be released. Failure to follow these instructions can result in possible serious or fatal injury. Turn the ignition off. Remove the Fuel Pump Module and inspect the Fuel Inlet Strainer. Is the Fuel Inlet Strainer plugged? Yes Replace the Fuel Pump Inlet Strainer. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . No Replace the Fuel Pump Module. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance .
  10. CHECK FOR RESTRICTED FUEL SUPPLY LINE WARNING: The fuel system is under a constant pressure even with the engine off. Before testing or servicing any fuel system hose, fitting or line, the fuel system pressure must be released. Turn the ignition off. Disconnect the Fuel Pressure Decay Tool. Raise the vehicle on a hoist, and disconnect the fuel pressure line at the fuel pump module. Install the Fuel Pressure Decay Tool between the fuel supply line and the fuel pump module. Again, purge air from the system. Turn the ignition on. With the scan tool, actuate the Fuel Pump. NOTE: On vehicles equipped with a PWM Fuel Pump, actuate the Fuel Pump at or above 60%. Read the Fuel Pressure Gauge (3) and record the reading. NOTE: The fuel pressure specification for all engines, including a Non SRT-4 is 407 kPa +/- 34 kPa (59 psi +/- 5 psi). SRT-4 fuel pressure specification is 552 kPa +/- 34 kPa (80 psi +/- 5 psi). Is the fuel pressure now within specification? Yes Repair/replace fuel supply line as necessary. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . No Go To 11 CAUTION: Stop all actuation tests before proceeding.
  11. CHECKING FUEL INLET STRAINER WARNING: The fuel system is under a constant pressure (even with the engine off). Before testing or servicing any fuel system hose, fitting or line, the fuel system pressure must be released. Failure to follow these instructions can result in possible serious or fatal injury. Turn the ignition off. Remove the Fuel Pump Module and inspect the Fuel Inlet Strainer. Is the Fuel Inlet Strainer plugged? Yes Replace the Fuel Pump Inlet Strainer. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance . No Replace the Fuel Pump Module. Perform the POWERTRAIN VERIFICATION TEST. Refer to appropriate Testing & Diagnostics article under Engine Performance .

CHECKING THE PCM POWER AND GROUND CIRCUITS

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

ENGINE CRANKS BUT DOES NOT START

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Possible Causes
5-VOLT SUPPLY CIRCUIT OPEN OR SHORTED
UNDERCHARGED BATTERY
SYSTEM DTCS PRESENT
POWERTRAIN POWER AND GROUND CIRCUIT(S) OPEN OR HIGH RESISTANCE
POWERTRAIN FUSES OPEN
FUEL DELIVERY SYSTEM
FUEL CONTAMINATION
INADEQUATE SPARK
ENGINE MECHANICAL PROBLEM

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to appropriate Testing & Diagnostics article under Engine Performance .
