Scheme 68
Scheme 69
| Callout | Component Name |
|---|---|
| 1 | Turn Signal/Multifunction Switch C3 |
| 2 | C279 Inflatable Restraint Steering Wheel Module Coil to Steering Wheel Harness |
| 3 | Inflatable Restraint Steering Wheel Module Coil C1 Connector |
| 4 | Inflatable Restraint Steering Wheel Module Coil C2 Connector |
| 5 | Turn Signal/Multifunction Switch C2 |
| 6 | Turn Signal/Multifunction Switch C1 |
| 7 | Rear Wiper/Washer Switch |
| 8 | Turn Signal/Multifunction Switch |
| 9 | Turn Signal/Multifunction Switch C4 |
| 10 | S277 and S279 |
| 11 | C277 Inflatable Restraint Steering Wheel Module Coil to Steering Column Harness |
| 12 | C275 Inflatable Restraint Steering Wheel Module Coil to Body Harness |
| 13 | C201 Steering Column Harness to I/P Harness |
| 14 | Steering Wheel Speed Position Sensor (JL4) |
| 15 | Theft Deterrent Exciter Module Connector (Pigtail) |
| 16 | Inflatable Restraint Steering Wheel Module Coil |
| 17 | Theft Deterrent Exciter Module |
| 18 | Ignition Switch |
| 19 | A/T Shift Lock Control Solenoid Connector |
Scheme 70
| Connector Part Information OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal: 12064971/Tray 5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A |
Automatic Transmission Shift Lock Control Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | D-GN/WH | 1135 | A/T Shift Lock Control Solenoid Control |
| B | BK/WH | 1551 | Ground |
A/T Shift Lock Control Solenoid
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: Listen for an audible click when the A/T shift lock control solenoid operates. Command both the ON and OFF states. Repeat the commands as necessary.
- 3: This step tests for battery voltage at the control circuit of the A/T shift lock control solenoid.
- 4: This step tests for an open or short to ground at the control circuit of the A/T shift lock control solenoid.
- 5: This step tests for an open at the ground circuit of the A/T shift lock control solenoid.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Automatic Transmission Shift Lock Control Schematics Connector End View Reference: Automatic Transmission Shift Lock Control Connector End Views or Computer/Integrating Systems Connector End Views in Computer/Integrating Systems | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, command the brake to shift control output control ON and OFF. With a scan tool, observe the BTSI solenoid parameter in the body control module (BCM) data list. Does the A/T shift lock control solenoid turn ON and OFF with each command? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Turn OFF the ignition. Disconnect the A/T shift lock control solenoid. Connect a test lamp between the shift lock solenoid control circuit at the connector of the A/T shift lock solenoid and a good ground. Turn ON the ignition, with the engine OFF. With a scan tool, command the brake to shift control output control ON and OFF several times. Does the test lamp illuminate ON and OFF with each command? | Go to Step 5 | Go to Step 4 |
| 4 | Test the control circuit of the A/T shift lock control solenoid for an open or short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 7 |
| 5 | Test the A/T shift lock control solenoid ground circuit for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 6 |
| 6 | Inspect for poor connections at the harness connector of the A/T shift lock control solenoid. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 8 |
| 7 | Inspect for poor connections at the harness connector of the BCM. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 10 | Go to Step 9 |
| 8 | Replace the A/T shift lock control solenoid. Refer to Automatic Transmission Shift Lock Actuator Replacement . Did you complete the replacement? | Go to Step 10 | |
| 9 | IMPORTANT: Perform the set up procedures for the BCM. Replace the BCM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming.Did you complete the replacement? | Go to Step 10 | |
| 10 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
| IMPORTANT |
|---|
| Perform the set up procedures for the BCM. |
DTC B2705
Symptoms - Automatic Transmission Shift Lock Control
| IMPORTANT | The following steps must be completed before using the symptom tables. |
- Perform the «Diagnostic System Check - Vehicle»(ref-241670-S16610990062006081100000) in Vehicle DTC Information before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
- Review the system operation in order to familiarize yourself with the system functions. Refer to «Automatic Transmission Shift Lock Control Description and Operation»(ref-241731-S03304192092006081100000) .
Automatic Transmission Shift Lock Control Description and Operation
The automatic transmission shift lock control system is a safety device that prevents an inadvertent shift out of PARK when the engine is running. The driver must press the brake pedal before moving the shift lever out of the PARK position. The system consists of the following components
- The automatic transmission shift lock control solenoid
- The body control module (BCM)
- The powertrain control module (PCM) or the transmission control module (TCM).
The BCM controls the voltage to the shift lock control solenoid through the shift lock control solenoid controlled voltage circuit. The following conditions must be met before the BCM will supply voltage to the shift lock solenoid
- The ignition is in the ON position.
- The PCM/TCM sends an input to the BCM indicating the transmission is in the PARK position.
- The BCM determines the brake pedal is not applied according the brake pedal position.
Since the shift lock control solenoid is permanently grounded, the BCM supplies voltage to the automatic transmission shift lock control solenoid, mechanically locking the shift lever in the PARK position as the solenoid energizes. When the brake pedal is applied, the BCM turns the control voltage output of the shift lock control solenoid OFF, de-energizing the shift lock control solenoid. The de-energized solenoid releases the mechanical lock allowing the driver to move the shift lever out of the PARK position. When the transmission is out of the PARK position, the shift lock control solenoid remains de-energized.
During remote start operation, the BCM will energize the shift lock control circuit, locking the shift lever in the PARK position.
