Automatic Transaxle - 4T65-E - Overhaul: Specifications Chevrolet Uplander I

Automatic Trans 2 illustrations ~1037 words

Fastener Tightening Specifications

Description of UsageRef. No.QtySizeSpecification
MetricEnglish
2-1 Servo to Case1033M8x1.25x2525 N.m18 lb ft
Accumulator Cover to Case13111M6x1.0x2812 N.m106 lb in
Case Cover to Case4343M6x1.0x4012 N.m106 lb in
Case Cover to Case4363M6x1.0x3012 N.m106 lb in
Case Cover to Driven Sprocket Support4353M8x1.25x5025 N.m18 lb ft
Case Cover to Driven Sprocket Support (TORX®)4331M6x1.0x3212 N.m106 lb in
Case to Drive Sprocket Support5244M8x1.25x2325 N.m18 lb ft
Case Extension to Case54M10x1.5x3536 N.m26 lb ft
Case Side Cover to Case569M8x1.25x2525 N.m18 lb ft
Case Side Cover to Case (Stud)584M8x1.25x2525 N.m18 lb ft
Case Side Cover to Case (TORX® Special)574M8x1.25x2125 N.m18 lb ft
Detent Spring to Case Cover8051M6x1.0x1612 N.m106 lb in
Forward Band Servo Cover to Case123M6x1.0x2012 N.m106 lb in
Oil Cooler Quick Connector6219/16-18 UNF32 N.m23 lb ft
Oil Cooler Quick Connector6119/16-18 UNF32 N.m23 lb ft
Oil Pan to Case2320M6x1.0x1814 N.m10 lb ft
Oil Pressure Test Hole Plug3811/8-27 NPTF12 N.m106 lb in
Pump Body to Case2062M6x1.0x9516 N.m11 lb ft
Pump Body to Case2319M6x1.0x87.512 N.m106 lb in
Pump Cover to Case Cover2079M6x1.0x8512 N.m106 lb in
Pump Cover to Case Cover2302M6x1.0x9512 N.m106 lb in
Pump Cover to Pump Body2051M6x1.0x208 N.m70 lb in
Speed Sensor to Case91M8x1.25x1212 N.m106 lb in
TFP Switch to Case3791M6x1.0x87.516 N.m11 lb ft
TFP Switch to Case Cover3752M6x1.0x6012 N.m106 lb in
TFP Switch to Valve Body3811M6x1.0x208 N.m70 lb in
Transfer Case Lower Brace to Transfer Case9032M8x10.9x2531 N.m23 lb ft
Transfer Case Side Brace to Transfer Case9033M8x10.9x2531 N.m23 lb ft
Transfer Case Side Brace to Transmission9032M8x10.9x2531 N.m23 lb ft
Transmission to Transfer Case Lower Brace9041M10x9.8x3556 N.m41 lb ft
Transfer Case to Transmission9072M10x9.8x3540 N.m30 lb ft
Transfer Case to Transmission
First Pass9092M10x10.9x12035 N.m26 lb ft
Final Pass160 degrees
Transfer Case to Transmission
First Pass9101M10x9.8x3535 N.m26 lb ft
Final Pass70 degrees
Valve Body to Case3743M6x1.0x6512 N.m106 lb in
Valve Body to Case3841M6x1.0x8512 N.m106 lb in
Valve Body to Case Cover3761M6x1.0x3012 N.m106 lb in
Valve Body to Case Cover3784M6x1.0x5512 N.m106 lb in
Valve Body to Case Cover (TORX®)3772M6x1.0x4512 N.m106 lb in
Valve Body to Driven Sprocket Support3801M8x1.25x9025 N.m18 lb ft
Reference Number refers to the callout number on the disassembled view.

Fastener Tightening Specifications

End Play Specifications

ID NumberDimension (mm)Dimension (in)Color
Differential Carrier/Case Thrust Washer (714) Selection Guide
11.40-1.500.055-0.059Orange
21.50-1.600.059-0.062White
31.60-1.700.062-0.066Blue
41.70-1.800.066-0.070Pink
51.80-1.900.070-0.074Brown
61.90-2.000.074-0.078Green
72.00-2.100.078-0.082Black
82.10-2.200.082-0.086Purple
92.20-2.300.086-0.091Purple/White
102.30-2.400.091-0.095Purple/Blue
Bearing/Input Clutch Hub Selective Thrust Washer (630) Selection Guide
12.90-3.000.114-0.118Orange/Green
23.05-3.150.120-0.124Orange/Black
33.20-3.300.126-0.130No Color
43.35-3.450.132-0.136White
53.50-3.600.138-0.142Blue
63.65-3.750.144-0.148Pink
73.80-3.900.150-0.154Brown
83.95-4.050.156-0.159Green
94.10-4.200.161-0.165Black
104.25-4.350.167-0.171Purple
114.40-4.500.173-0.177Purple/White

End Play Specifications

Transfer Case Selective Washer Specifications

Dimension ADimension BEnd Play without Selective WasherSelective Washer ColorSelective Washer Size
MetricEnglishMetricEnglishMetricEnglishMetricEnglish
23.23-23.12 mm.914-.910 in19.98-20.23 mm.786-.796 in3.25-2.89 mm.128-.114 inLight Blue2.67 mm.105 in
23.12-23.01 mm.910-.906 in19.98-20.23 mm.786-.796 in3.14-2.78 mm.124-.109 inLight Green2.56 mm.100 in
23.01-22.90 mm.906-.901 in19.98-20.23 mm.786-.796 in3.03-2.67 mm.119-.105 inWhite2.45 mm.096 in
22.90-22.79 mm.901-.897 in19.98-20.23 mm.786-.796 in2.92-2.56 mm.115-.101 inOrange2.34 mm.092 in
22.79-22.68 mm.897-.892 in19.98-20.23 mm.786-.796 in2.81-2.45 mm.110-.096 inPink2.23 mm.088 in
22.68-22.57 mm.892-.888 in19.98-20.23 mm.786-.796 in2.70-2.34 mm.106-.092 inNo Color2.12 mm.083 in
22.57-22.46 mm.888-.884 in19.98-20.23 mm.786-.796 in2.59-2.23 mm.102-.087 inBlack2.01 mm.079 in
23.23-23.12 mm.914-.910 in20.23-20.48 mm.796-.806 in3.00-2.64 mm.118-.103 inWhite2.45 mm.096 in
23.12-23.01 mm.910-.906 in20.23-20.48 mm.796-.806 in2.89-2.53 mm.114-.099 inOrange2.34 mm.092 in
23.01-22.90 mm.906-.901 in20.23-20.48 mm.796-.806 in2.78-2.42 mm.110-.095 inPink2.23 mm.088 in
22.90-22.79 mm.901-.897 in20.23-20.48 mm.796-.806 in2.67-2.31 mm.105-.090 inNo Color2.12 mm.083 in
22.79-22.68 mm.897-.892 in20.23-20.48 mm.796-.806 in2.56-2.20 mm.101-.086 inBlack2.01 mm.079 in
22.68-22.57 mm.892-.888 in20.23-20.48 mm.796-.806 in2.45-2.09 mm.096-.082 inPurple1.90 mm.074 in
22.57-22.46 mm.888-.884 in20.23-20.48 mm.796-.806 in2.34-1.98 mm.092-.077 inBrown1.79 mm.070 in
23.23-23.12 mm.914-.910 in20.48-20.72 mm.806-.816 in2.75-2.40 mm.108-.094 inPink2.23 mm.088 in
23.12-23.01 mm.910-.906 in20.48-20.72 mm.806-.816 in2.64-2.29 mm.104-.090 inNo Color2.12 mm.083 in
23.01-22.90 mm.906-.901 in20.48-20.72 mm.806-.816 in2.53-2.18 mm.100-.085 inBlack2.01 mm.079 in
22.90-22.79 mm.901-.897 in20.48-20.72 mm.806-.816 in2.42-2.07 mm.095-.081 inPurple1.90 mm.074 in
22.79-22.68 mm.897-.892 in20.48-20.72 mm.806-.816 in2.31-1.96 mm.091-.077 inBrown1.79 mm.070 in
22.68-22.57 mm.892-.888 in20.48-20.72 mm.806-.816 in2.20-1.85 mm.087-.072 inDark Blue1.68 mm.066 in
22.57-22.46 mm.888-.884 in20.48-20.72 mm.806-.816 in2.09-1.74 mm.082-.068 inDark Green1.57 mm.061 in

Transfer Case Selective Washer Specifications

Transmission General Specifications

NameHydra-matic 4T65-E
RPO CodesM15/MN7/M76
Production LocationWarren, MI
Vehicle Platform (Engine/Transmission) UsageH, W, U, B
Transaxle DriveTransverse Mounted Front Wheel Drive
1st Gear Ratio2.921:1
2nd Gear Ratio1.568:1
3rd Gear Ratio1.000:1
4th Gear Ratio0.705:1
Reverse2.385:1
Torque Converter Size (Diameter of Torque Converter Turbine)245 mm (M15) 258 mm (MN7) 245 mm, 258 mm (M76)
Pressure TapsLine Pressure
Transaxle Fluid TypeDexron™ III
Transaxle Fluid Capacity (Approximate)Bottom Pan Removal: 7.0 L (7.4 qts) Complete Overhaul: 9.5 L (10.0 qts) Dry: 12.7 L (13.4 qts)
Transaxle Type: 4Four Forward Gears
Transaxle Type: TTransverse Mount
Transaxle Type: 65Product Series
Transaxle Type: EElectronic Controls
Chain Ratios (Designates Number of Teeth on the Drive/Driven Sprockets)35/35 37/33
Final Drive Ratios2.86, 3.05, 3.29
Overall Final Drive Ratios2.86, 3.05, 2.93, 3.29
Position QuadrantP, R, N, D, 3, 2, 1 or P, R, N, OD, 2, 1
Case MaterialDie Cast Aluminum
Transaxle Weight Dry87.9 kg (194.2 lbs)
Transaxle Weight Wet97.0 kg (214.4 lbs)
Maximum Trailer Towing Capacity907 kg (2000 lbs)
Maximum Gross Vehicle Weight (GVW)2903 kg (6,400 lbs)

Transmission General Specifications

Fluid Capacity Specifications

ApplicationSpecification
MetricEnglish
Bottom Pan Removal (2WD)7.0 L7.4 qt
Bottom Pan Removal (AWD)7.4 L7.8 qt
Complete Overhaul (2WD)9.5 L10.0 qt
Complete Overhaul (AWD)9.9 L10.4 qt
Dry (2WD)12.7 L13.4 qt
Dry (AWD)13.1 L13.8 qt

Fluid Capacity Specifications

Torque Converter Assembly Removal

CAUTIONThe torque converter weighs approximately 65 lbs. Personal injury may result if you lift the torque converter improperly.
  1. Remove the torque converter assembly (1).
  2. Remove the turbine shaft O-ring seal (520).

Torque Signal Regulator Valve (321)

Regulates line pressure into the torque signal fluid circuit. This regulation is controlled by filtered actuator feed fluid pressure from the PC solenoid valve.

Pressure Regulator Valve (313) (Torque Converter/Cooler and Lube Circuits)

Line pressure at the valve enters the converter feed circuit which is then routed to the TCC control valve.

Regulates line pressure into the torque signal fluid circuit. This regulation is controlled by filtered actuator feed fluid pressure from the PC solenoid valve.

Line pressure at the valve enters the converter feed circuit which is then routed to the TCC control valve.

Line pressure at the valve enters the converter feed circuit which is then routed to the TCC control valve.

Line pressure at the valve enters the converter feed circuit which is then routed to the TCC control valve.

Line pressure at the valve enters the converter feed circuit which is then routed to the TCC control valve.

Line pressure at the valve enters the converter feed circuit which is then routed to the TCC control valve.

Torque Converter Clutch

With the TCC control PWM solenoid OFF the converter clutch is released in Second gear. Under normal operating conditions the TCC is released in Second gear. However, TCC apply could vary depending on vehicle application and may be calibrated to apply in Overdrive Range - Second Gear.

With the TCC control PWM solenoid OFF the converter clutch is released in Second gear. Under normal operating conditions the TCC is released in Second gear. However, TCC apply could vary depending on vehicle application and may be calibrated to apply in Overdrive Range - Second Gear.

Overdrive Range, Third Gear - Torque Converter Clutch Not Applied (Without Touch Activated Power)

As the speed of the vehicle increases, the powertrain control module (PCM) receives input signals from various engine and transmission sensors. The PCM uses this data to energize the 2-3 shift solenoid (SS) valve in order to shift the transmission into third gear at the appropriate time.

TCC apply could vary depending on vehicle application and may be calibrated to apply in Overdrive Range - Third Gear.

Overdrive Range, Third Gear - Torque Converter Clutch Not Applied (With Touch Activated Power)

As the speed of the vehicle increases, the powertrain control module (PCM) receives input signals from various engine and transmission sensors. The PCM uses this data to energize the 2-3 shift solenoid (SS) valve in order to shift the transmission into third gear at the appropriate time.

TCC apply could vary depending on vehicle application and may be calibrated to apply in Overdrive Range - Third Gear.

Overdrive Range, Fourth Gear - Torque Converter Clutch Not Applied (Without Touch Activated Power)

As the speed of the vehicle continues to increase, the powertrain control module (PCM) monitors the input signals from various engine and transmission sensors. The PCM uses this data to energize the 1-2, 3-4 shift solenoid (SS) valve in order to shift the transmission into fourth gear at the appropriate time.

TCC apply could vary depending on vehicle application and may be calibrated to apply in Overdrive Range - Fourth Gear.

Overdrive Range, Fourth Gear - Torque Converter Clutch Not Applied (With Touch Activated Power)

As the speed of the vehicle continues to increase, the powertrain control module (PCM) monitors the input signals from various engine and transmission sensors. The PCM uses this data to energize the 1-2, 3-4 shift solenoid (SS) valve in order to shift the transmission into fourth gear at the appropriate time.

TCC apply could vary depending on vehicle application and may be calibrated to apply in Overdrive Range - Fourth Gear.

Overdrive Range, Fourth Gear - Torque Converter Clutch Applied (Without Touch Activated Power)

The torque converter clutch applies during third or fourth gear operation after the powertrain control module (PCM) receives the appropriate input signals to energize the TCC control (PWM) solenoid. To apply the torque converter clutch, the following changes take place in the electrical and hydraulic systems

TCC apply fluid is routed to the torque converter clutch at the same time TCC release fluid exhausts from the torque converter clutch. TCC apply fluid pressure applies the TCC.

Overdrive Range, Fourth Gear - Torque Converter Clutch Applied (With Touch Activated Power)

The torque converter clutch applies during third or fourth gear operation after the powertrain control module (PCM) receives the appropriate input signals to energize the TCC control (PWM) solenoid. To apply the torque converter clutch, the following changes take place in the electrical and hydraulic systems

TCC apply fluid is routed to the torque converter clutch at the same time TCC release fluid exhausts from the torque converter clutch. TCC apply fluid pressure applies the TCC.

Overdrive Range, 4-3 Downshift - Torque Converter Clutch Not Applied (Without Touch Activated Power)

When the transmission is operating in Fourth gear, a 4-3 downshift will occur if there is a significant change (increase) in the throttle position or if the load on the engine is increased. When the 4-3 downshift occurs, the torque converter clutch will release prior to the shift occurring which results in the following changes in the hydraulic system

Overdrive Range, 4-3 Downshift - Torque Converter Clutch Not Applied (With Touch Activated Power)

When the transmission is operating in Fourth gear, a 4-3 downshift will occur if there is a significant change (increase) in the throttle position or if the load on the engine is increased. When the 4-3 downshift occurs, the torque converter clutch will release prior to the shift occurring which results in the following changes in the hydraulic system

The PCM will release the TCC before downshifting into Manual Second. The TCC will not re-apply in Second gear under normal operating conditions.

Scheme 92

Scheme 92: Torque Converter Clutch
Scheme 92: Torque Converter Clutch

The PCM will release the TCC before downshifting into Manual Second. The TCC will not re-apply in Second gear under normal operating conditions.

Scheme 93

Scheme 93: Torque Converter Clutch
Scheme 93: Torque Converter Clutch
