- Release air pressure from cylinder 3.
- Remove the EN-6086-15 pneumatic adapter.
- Remove all parts of EN-50716 spring and wedge replacer.
- Shift to neutral gear and release the park brake.
- Adjust the engine to TDC of cylinder 1 and fix the crankshaft with EN-952 fixing pin.
- Install the spark plugs. Refer to «Spark Plug Replacement»(ref-614588-S19230835352014050700000) .
- Install the hydraulic valve lash adjuster arms. Refer to «Hydraulic Valve Lash Adjuster Arm Replacement»(ref-614552-S27440584062014050700000) .
- Raise the vehicle.
- Remove the EN-952 fixing pin and install the crankshaft bearing cap tie plate hole plug. Refer to «Camshaft Timing Chain Adjustment»(ref-614552-S13762395502014050700000) .
- Install the front wheelhouse liner . Refer to «Front Wheelhouse Liner Replacement (Trax)»(ref-614566-S03953499412014050700000) , «Front Wheelhouse Liner Replacement (Encore)»(ref-614566-S35749267182014050700000) .
- Lower the vehicle.
Scheme 23
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the radiator opening upper cover. Refer to Front Bumper Fascia Opening Upper Cover Replacement . Special Tools EN-28467-300 Engine Support Fixture Adapter J-28467-518 Main Support Beam J-28467-1A Cross Bracket J-28467-5A Strut Tower Support Assembly J-28467-2A Radiator Tube Shelf Assembly J-36857 Engine Lift Bracket J-28467-8A Hook Assembly For equivalent regional tools, refer to Special Tools . | |
| 1 | Engine Support Fixture Adapter Leg (Qty: 2) Procedure Install the bracket to fender frame. Do not install on top of fender lip. |
| 2 | Main Support Beam |
| 3 | Cross Bracket |
| 4 | Strut Tower Support Assembly Procedure Adjust the length of the strut tower support assembly. |
| 5 | Radiator Tube Shelf Assembly |
| 6 | Hook Assembly Procedure Use a grade 10.9 bolt to install the engine lift bracket. NOTE: If the engine is not equipped with engine lift bracket, install J-36857 in place. |
| NOTE |
|---|
| If the engine is not equipped with engine lift bracket, install J-36857 in place. |
Engine Support Fixture
