11 0 240 Copuling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note. For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240
Coupling
Scheme 351
11 0 480 Plug mandrel
Note. For locking crankshaft in TDC position when adjusting timing.
Engine: S54, S65
Storage location: A19, B19
SI number: 1 03 06 (245)
Order number: 11 0 480
Plug mandrel
Scheme 352
11 1 310 Drift
Note. For driving needle bearing out of crankcase (M20) and pressing out propeller shaft centring mount
Series: E28, E30, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E91, E92, F01, F02, RR1
Order number: 11 1 310
Drift
Scheme 353
11 2 030 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note. For driving the guide bearing into the crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving the centring support into the propeller shaft
Series: E28, E30, E32, E34, E36, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E92, F01, F02, RR1
Scheme 354
Storage location: A15
Order number: 11 2 030
Drift
11 2 380 Puller
Minimum set: Mechanical tools
Note. For removing rotary shaft seal from timing case cover
Engine: M41, M47, M50, M51, M52, M52TU, M54, M56, M60, M62, S50B30, S50B32, S54, S62, S65, S85, W10, W11
Storage location: A38, C25
SI number: 1 05 92 (507)
Order number: 11 2 380
Puller
Scheme 355
Consisting of
1 = 11 2 381 Threaded bell housing
2 = 11 2 382 Spindle
3 = 11 2 383 Thrust piece
Note. Engine: M41, M47, M50, M51, M52, M60, M62, PENT
11 2 384 Thrust piece
Note. Engine: S50, S54
11 2 385 Spacer bushing
Note. Engine: M41, M50, M51, M52
11 2 386 Thrust piece
Note. Engine: S62, S65, S85
11 4 190 1/4" extension piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note. M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
SI number: 1 06 94(801)
Order 11 number: 4 190
1/4" extension piece
Scheme 356
11 5 260 Engine support plate
In conjunction with: 00 2 300
Note. For accommodating engine on assembly stand.
Engine: S65, S85
SI number: 1 02 05 (173)
Order number: 11 5 260
Engine support plate
Scheme 357
Consisting of
1 = 11 5 261 Basic body
2 = 11 5 262 Set of screws (10 x)
11 5 280 Fixture
In conjunction with: 11 9 000
Note. For removing and installing valve cotters.
Engine: S65, S85
SI number: 1 02 05 (173)
Order number: 11 5 280
Fixture
Scheme 358
Consisting of
1 = 11 5 281 Removal tool
2 = 11 5 282 Installation tool
3 = 11 5 283 Installation aid
11 5 461 Installation holder
Order number: 11 5 461
Installation holder
Scheme 359
11 5 462 Installation pliers
Order number: 11 5 462
Installation pliers
11 5 463 Installation drift
Order number: 11 5 463
Installation drift
11 5 464 Removal pliers
Order number: 11 5 464
Removal pliers
11 6 360 Extractor
Minimum set: Mechanical tools
In conjunction with: 11 2 383, 11 2 386
Note. For removing rotary shaft seal from timing case cover
Engine: M47, M47TU, S65, S85
Storage location: B11
SI number: 1 06 98 (306)
Order number: 11 6 360
Extractor
Scheme 360
Consisting of
1 = 11 6 361 Threaded bell housing
2 = 11 6 362 Spindle M12 x 100
11 9 260 Counter support with screw connection
Minimum set: Mechanical tools
Note. For locking flywheel with transmission removed
Engine: M47TU, M54, M57T2, M57TU, N40, N42, N43, N45, N45T, N46, N46T, N47, N47S, N51, N52, N53, N54, N62, N63, N73, S65, S85, W17
Scheme 361
Storage location: B43
SI number: 1 01 01 (662)
Order number: 11 9 260
Counter support with screw connection
Consisting of
1 = 11 9 261 Counterholder, individual
2 = 11 9 262 Bolt (M10 thread) with washer
Note. For bolting down counterholder
3 = 11 9 263 Sleeve for counterholder
Note. For counterholder for locking flywheel with transmission removed engine: N62, N73
4 = 11 9 264 Bolt (M12 thread)
Note. For counterholder for locking flywheel with transmission removed
5 = 11 9 265 Sleeve
6 = 11 9 266 Sleeve
Note. For counterholder for locking flywheel with transmission removed Engine: M57TU2
11 9 811 Holder
Order number: 11 9 811
Holder
Scheme 362
11 9 812 Screw
Order number: 11 9 812
Screw
11 9 950 Fixture
In conjunction with: 11 5 280
Note. For removing and installing valve cotters.
Engine: S65
SI number: 01 21 07 (410)
Order number: 11 9 950
Fixture
Scheme 363
Consisting of
1 = 11 9 951 Adapter kit - removal tool
In conjunction with: 11 5 281
2 = 11 9 952 Adapter - installation tool
In conjunction with: 11 5 282
3 = 11 9 953 Installation aid for valve cotters
11 9 960 Plate
In conjunction with: 11 5 230
Note. For testing cylinder heads for leaks.
Engine: S65
SI number: 01 21 07 (410)
Order number: 11 9 960
Plate
Scheme 364
11 9 970 Set of gauges
Note. For locating camshafts at TDC. 2 gauge sets are required to adjust the timing.
Engine: S65
SI number: 01 13 07 (387)
Order number: 11 9 970
Set of gauges
Scheme 365
Consisting of
1 = 11 9 971 Gauge 1
2 = 11 9 972 Gauge 2
3 = 11 9 973 Set of screws
11 9 980 Puller
Note. For removing ignition coils.
Engine: S65
SI number: 01 13 07 (387)
Order number: 11 9 980
Puller
Scheme 366
11 9 990 Locating fixture
Note. For securing engine when removing transmission (preventing engine tilting).
Engine: S65
SI number: 01 13 07 (387)
Order number: 11 9 990
Locating fixture
