Engine - Special Tools -- e90 BMW M3 E90

Mechanical 28 illustrations ~1763 words

Adapter MW

Replaced by: 0491003

Note. For pressure gauge for checking the oil pressure - Replaced by 11 4 030 (0 491 003)

Storage Location

B9

Compression tester Minimum set: Mechanical tools MW

Note. (Compression pressure testing set) For all gasoline and diesel engines.

SI number

01 09 92 (558)

Consisting of

4 = 0490620 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: S14, S38, S50 - Replaced by 11 0 235 (0 493 129)

4 = 0490616 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 221

4 = 0490622 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 224

2 = 0494517 Adapter

Note. Measuring "absolute compression" at all cylinders. Engine: W17

2 = 0493634 Case

Note. With foam material insert for recording compression tester

16 = 0495279 Adapter

Note. M67, M67TU engine

Scheme 372

Scheme 372: SI number

4 = 0490614 Compression tester

Note. (Compression tester) For diesel engines.

4 = 0490615 Probe

Note. (Test probe) For recording compression testers 11 0 221 and 11 0 160/engine: M21, M41, M47, M51, M57, M57T2

4 = 0490617 Compression tester

Note. (Compression tester) For gasoline engines.

4 = 0490618 Hose

Note. (Extension hose) For rubber tapered section with fitting 11 0 228

4 = 0490619 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, N62, S50US, S52US, S62

4 = 0490621 Tapered section

Note. (Rubber tapered section) For recording compression testers 11 0 224 and 11 0 160.

4 = 0490625 Valve

Note. (Non-return valve)

4 = 0490626 Filter

Note. (Filter) 3 x 3 mm

9 = 0493129 Probe

Note. (Test probe, screw-in) For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54, S85

2 = 0493387 Probe

Note. (Test probe) For recording compression tester 11 0 221 or DIS pressure sensor/engine: M47, M57, M57TU, M57T2

Compression tester MW

Replaced by: 0490613

Note. (Compression recorder) manufacturer VDO - Replaced by 11 0 220 (0 490 613)

Consisting of

1 = 0490594 Card

Note. (Cards) For compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613)

2 = 0490595 Pressure gauge

Note. Compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613)

3 = 0490596 Guard

Note. (Rubber protection) Still available as replacement Discontinuation and replaced by 11 0 220 (0 490 613)

4 = 0490597 Lines

Note. Discontinuation and replaced by 11 0 220 (0 490 613)

5 = 0490598 Adapter

Note. (test adapter for gasoline engine) Engine: all, except M70 Discontinuation and replaced by 11 0 220 (0 490 613)

6 = 0490599 Adapter

Note. (test adapter for gasoline engine) Engine: M70 Discontinuation and replaced by 11 0 220 (0 490 613)

7 = 0490600 Adapter

Note. (Test adapter extension) Discontinuation and replaced by 11 0 220 (0 490 613)

Scheme 373

Scheme 373: Compression tester MW

Device MW

Note. (Securing device) For securing engine when removing transmission (preventing engine tilting).

01 13 07 (387)

Scheme 374

Scheme 374: SI number

Note. For removing and installing valve cotters.

B18

01 21 07 (410)

Consisting of

1 = 0496347 Adapter

Note. (Adapter kit - dismantling tool)

2 = 0496348 Adapter

Note. (Adapter - mounting tool)

3 = 0496349 Fitting aid

Note. (Fitting aid for valve keys)

Scheme 375

Scheme 375: SI number

Replaced by: 0490504

Note. For retightening the connecting rod and cylinder head bolts - Replaced by 00 9 120 (0 490 504)

Consisting of

1 = 0490827 Extension

Note. (Extension 1/1") Replaced by 00 9 120 (0 490 504)

2 = 0490828 Washer

Note. (Graduated disc 180°) Replaced by 00 9 120 (0 490 504)

3 = 0490829 Sleeve

Note. (Guide sleeve) Replaced by 00 9 120 (0 490 504)

4 = 0490830 Nut

Note. (Knurled nut) Replaced by 00 9 120 (0 490 504)

5 = 0490831 Wrench socket

Note. (Socket wrench insert WAF 10) Replaced by 00 9 120 (0 490 504)

6 = 0490832 Washer

Note. (Graduated disc up to 270°) Replaced by 00 9 120 (0 490 504)

7 = 0490833 Tab

Scheme 376

Scheme 376: Device MW

Note. For counter-holding on the cylinder head Replaced by 00 9 120 (0 490 504)

8 = 0490834 Adapter

Note. (Adapter) Replaced by 00 9 120 (0 490 504)

Device Minimum set: Mechanical tools MW

Note. (Cylinder head expander tool)

Individual

01 03 02 (833)

Consisting of

17 = 0495028 Cage

Note. (Valve spring cage) Engine N52

1 = 0494366 Device

5 = 0494370 Quick fastener

7 = 0494372 Shaped part

Note. (Shaped part)

8 = 0494373 Shaped part

Note. (Shaped part) Shaped part made of plastic

9 = 0494374 Lever

2 = 0494367 Rod

3 = 0494368 Adapter

Note. (Sliding block)

4 = 0494369 Tab

6 = 0494371 Insert

Note. (Aluminum strip)

Scheme 377

Scheme 377: SI number

10 = 0494375 Hook

11 = 0494376 Cage

Note. (Valve spring cage) Engine M41, M51, S50

12 = 0494377 Cage

Note. (Valve spring cage) Engine M43, M73

13 = 0494378 Cage

Note. (Valve spring cage) Engine M44, M52, M54, M56, M62, S52, S54, S62

14 = 0494379 Cage

Note. (Valve spring cage) Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73

15 = 0494380 Cage

Note. (Valve spring cage) Engine M21, M40

Replaced by: 0491007

Note. For installation of the dipstick guide tube - Replaced by 11 4 070 (0 491 007)

Note. For removing and installing valve keys.

01 02 05 (173)

Consisting of

1 = 0495159 Tool

Note. (Dismantling tool)

2 = 0495160 Fitting aid

Note. (Mounting tool)

3 = 0495161 Fitting aid

Scheme 378

Scheme 378: SI number

Extractor MW

Note. For removing ignition coils.

C71

01 13 07 (387)

Scheme 379

Scheme 379: SI number

Fitting aid MW

Replaced by: 0494362

Note. (fitting accessories) For removing and fitting the valve springs. Replaced by 11 9 000 (0 494 362)

01 12 93 (701)

Consisting of

3 = 0490649 Hook

Note. (hook) Length 220 mm - Engine: all, except M10 Replaced by 11 9 000 (0 494 362)

5 = 0490651 Cage

Note. (Valve spring cage) Engine: M44, M52, M62, S62, S54 Replaced by 11 9 000 (0 494 362)

1 = 0490647 Cage

Note. (Valve spring cage) Engine: M43, M73

2 = 0490648 Lever

Note. (compression lever) Engine: all, except M10

6 = 0493285 Cage

Note. (Valve spring cage) Engine: M47, M47TU, M57, N40, N42, M67, M67TU

4 = 0490650 Cage

Scheme 380

Scheme 380: SI number

Note. (valve spring cage) Replaced by 11 0345, engine: M52

Gauge Minimum set: Mechanical tools MW

Note. For fixing the camshaft at the top dead center.

01 07 10 (634)

Scheme 381

Scheme 381: SI number

Gauge MW

Note. (set of gauges) For locking the camshafts at TDC. Two gauge sets are required to adjust the timing.

01 13 07 (387)

Consisting of

1 = 0496271 Gauge

Note. (gauge 1)

2 = 0496272 Gauge

Note. (gauge 2)

3 = 0496273 Screw

Note. (set of screws)

Scheme 382

Scheme 382: SI number

Holder Minimum set: Mechanical tools MW

Note. (Counter support with screw connection) For holding the flywheel when gearbox is removed

B43

01 01 01 (662)

Consisting of

1 = 0494034 Holder

Note. (Individual counter support)

2 = 0494035 Screw

Note. (Bolt (thread M10) with washer) For screwing counter support

3 = 0494129 Bush

Note. (Bush for counter support) For counter support, for retaining flywheel when gearbox is removed Engine: N62, N73

4 = 0494130 Screw

Note. (Bolt (thread M12)) For counter support for retaining flywheel when gearbox is removed

5 = 0494793 Bush

6 = 0495216 Bush

Scheme 383

Scheme 383: SI number

Note. For counter support, for retaining flywheel when gearbox is removed Engine: M57TU2

Scheme 384

Scheme 384: Holder

Holder MW

Replaced by: 0490855

Note. (Counter support) - Nov. 88 Replaced by 11 2 240 (0 490 855)

Note. (Installation bracket)

A51

Scheme 385

Scheme 385: Storage Location

Scheme 386

Scheme 386: Installation drift

Scheme 387

Scheme 387: Installation pliers

Lifting gear Minimum set: Mechanical tools MW

Note. (Hoist) For removing and installing engines.

01 13 94 (888)

Consisting of

1 = 0490562 Lifting gear

Note. (Cross-member)

2 = 0490563 Chain

Note. (Chain) Version: long

3 = 0490564 Chain

Note. (Chain) Version: short

4 = 0490565 Shackle

Note. (Shackle) 2 x

Scheme 388

Scheme 388: SI number

Mandrel MW

Note. (Drift) For driving needle bearing out of crankcase (M20) and pressing out propeller shaft centering mount

Scheme 389

Scheme 389: Mandrel MW

Mandrel Minimum set: Mechanical tools MW

Note. (drift) For driving guide bearing into crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving centering mount into propeller shaft

A15

Scheme 390

Scheme 390: Storage Location

Note. (Installation drift)

A51

Note. (Alignment pin) For locking crankshaft in TDC position when adjusting timing.

B19

A19

01 03 06 (245)

Scheme 391

Scheme 391: SI number

Note. (Mandrel) Replaced by 11 1 200

Note. (Drift) Replaced by 11 1 200

Replaced by: 0490724

Note. (Drift) Replaced by 11 1 200 (0 490 724)

Open-end spanner MW

Note. (open-end spanner WAF 27) For adjusting left track rod on rack

Y4

Scheme 392

Scheme 392: Storage Location

Plate MW

Note. (Fixture) For mounting engine on assembly stand.

01 02 05 (173)

Consisting of

1 = 0495157 Basic body

2 = 0495158 Screw

Note. (Set of screws (10 x))

Scheme 393

Scheme 393: SI number

Note. For testing cylinder heads for watertightness.

01 21 07 (410)

Consisting of

1 = 0496351 Plate

2 = 0496352 Seal

Note. (seal) (spare part))

Scheme 394

Scheme 394: SI number

Pliers MW

Replaced by: 0490796

Note. For removal of the valve stem seals - Replaced by 11 1 480 (0 490 796)

Scheme 395

Scheme 395: Pliers MW

Replaced by: 0490796

Note. For removing and installing the valve stem seal. Only free for motorcycle! Replaced by 11 1 480 (0 490 796)

Note. (Removal pliers)

A51

Scheme 396

Scheme 396: Storage Location

Note. (Installation pliers)

A51

Puller Minimum set: Mechanical tools MW

Note. For removing shaft sealing ring from gear case cover

B11

01 06 98 (306)

Consisting of

1 = 0493292 Bell housing

Note. (thread housing)

2 = 0493293 Spindle

Note. (spindle M12 x 100)

Scheme 397

Scheme 397: SI number

Sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve) For fitting the valve stem seal, diameter 7 mm

Scheme 398

Scheme 398: Sleeve Minimum set: Mechanical tools MW

Sleeve MW

Replaced by: 0490744

Note. (Assembly sleeves) For fitting the valve stem seal - Replaced by 11 1 360 (0 490 744)

Tool Minimum set: Mechanical tools MW

Note. (Puller tool) For pulling off the radial seal ring from the gear case cover

C25

A38

01 05 92 (507)

Consisting of

1 = 0490877 Bell housing

Note. (thread housing)

2 = 0490878 Spindle

3 = 0490879 Synchronizing key

Note. Engine: M41, M47, M50, M51, M52, M60, M62, PENT

Scheme 399

Scheme 399: SI number

3 = 0490880 Synchronizing key

Note. (Synchronizing key) Engine: S50, S54

3 = 0490881 Bush

Note. (Spacer bush) Engine: M41, M50, M51, M52

2 = 0493591 Synchronizing key

Note. Engine: S62, S65, S85
