Engine and Gearbox Suspension - Repair - e92/93 BMW M3 E90

Mechanical 7 illustrations ~651 words

22 11 001 Replacing right engine mount (S65)

Necessary preliminary tasks

  1. Remove «right engine support arm»(/bmw/m3/e90-2007-2013/remont/mechanical/#engine-and-gearbox-suspension-repair-e9293__22-11-100-replacing-right-engine)

Slacken nut (1).

Tightening torque 22 11 1AZ , see 22 11 ENGINE SUSPENSION .

Installation

Replace nuts.

Scheme 344

Scheme 344
Scheme 344

Installation

Installation position of engine mount determined by locating pin.

22 11 011 Replacing left engine mount (S65)

Necessary preliminary tasks

  1. Secure engine in installation position . See «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (S65)»(/bmw/m3/e90-2007-2013/remont/mechanical/#engine-repair-e9293__11-00-670-securing-engine-in) .
  2. Lower front axle support . See «31 11 506 LOWERING/RAISING FRONT AXLE CARRIER (M3, UNIVERSAL LIFTER)»(/bmw/m3/e90-2007-2013/remont/axle-shafts/#front-axle-repair-e92e93__31-11-506-loweringraising-front-axle) .

Slacken nut (1).

Tightening torque 22 11 1AZ , see 22 11 ENGINE SUSPENSION .

Installation

Replace nuts.

Scheme 345

Scheme 345
Scheme 345

Installation

Installation position of engine mount determined by locating pin.

22 11 100 Replacing right engine support arm (S65)

Necessary preliminary tasks

  1. Secure engine in installation position . See «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (S65)»(/bmw/m3/e90-2007-2013/remont/mechanical/#engine-repair-e9293__11-00-670-securing-engine-in) .
  2. Release tie rod on steering gear . See «32 21 231 REPLACING (REMOVING AND INSTALLING) LEFT OR RIGHT TIE ROD»(/bmw/m3/e90-2007-2013/remont/manual-power-steering/#steering-and-wheel-alignment-repair-e92e93__32-21-231-replacing-removing-and) .

Observe safety instructions on raising the vehicle. See 00 ... ... LIFTING VEHICLE WITH A LIFTING PLATFORM .

Release screws (1).

Remove engine support arm (2).

Tightening torque 22 11 3AZ , see 22 11 ENGINE SUSPENSION .

Note. Illustration similar

Scheme 346

Scheme 346
Scheme 346

22 11 110 Replacing left engine support arm (S65)

Necessary preliminary tasks

  1. Remove left exhaust manifold . See «18 40 010 REMOVING AND INSTALLING/REPLACING LEFT EXHAUST MANIFOLD (S65)»(/bmw/m3/e90-2007-2013/remont/exhaust/#exhaust-system-repair-e9293__18-40-010-removing-and-installingreplacing) .

Observe safety instructions on raising the vehicle. See 00 ... ... LIFTING VEHICLE WITH A LIFTING PLATFORM .

Release screws (2).

Remove engine support arm.

Tightening torque 22 11 3AZ , see 22 11 ENGINE SUSPENSION .

Note. Illustration similar

Scheme 347

Scheme 347
Scheme 347

22 31 001 Replacing rubber mount for transmission mounting

Necessary preliminary tasks

  1. Remove rear underbody protection. See «51 47 491 REMOVING AND INSTALLING/REPLACING REAR UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-47-491-removing-and-installingreplacing) .
  2. Support transmission with lifter.

Remove screws and nuts.

Remove transmission cross-member (1).

Remove rubber mount from transmission cross-member.

Tightening torque 22 32 3AZ/4AZ , see 22 32 TRANSMISSION MOUNTS .

Scheme 348

Scheme 348
Scheme 348

22 31 001 Replacing rubber mount for transmission mounting (S65)

Necessary preliminary tasks

  1. Remove rear underbody protection . See «51 47 491 REMOVING AND INSTALLING/REPLACING REAR UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-47-491-removing-and-installingreplacing) .
  2. Support transmission with hydraulic lifter.

Release screws (1) and nuts (2) and remove transmission cross-member.

Remove rubber mount from transmission cross-member.

Tightening torque 23 71 2AZ/5AZ , see 23 71 TRANSMISSION MOUNTS .

Note. Illustration similar

Scheme 349

Scheme 349
Scheme 349

22 31 050 Replacing cross-member for transmission mounting

Note. Operations are identical to Replacing rubber mount for transmission mounting.

Necessary preliminary tasks

  1. Remove rear underbody protection. See «51 47 491 REMOVING AND INSTALLING/REPLACING REAR UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-47-491-removing-and-installingreplacing) .
  2. Support transmission with lifter.

Remove screws and nuts.

Remove transmission cross-member (1).

Remove rubber mount from transmission cross-member.

Tightening torque 22 32 3AZ/4AZ , see 22 32 TRANSMISSION MOUNTS .

Note. Operations are identical to Replacing rubber mount for transmission mounting.

22 32 050 Replacing cross-member for transmission mounting (S65)

Necessary preliminary tasks

  1. Remove rear underbody protection . See «51 47 491 REMOVING AND INSTALLING/REPLACING REAR UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-47-491-removing-and-installingreplacing) .

Support transmission with hydraulic jack.

Release screws (1).

Tightening torque: 22 32 4AZ , see 22 32 TRANSMISSION MOUNTS .

Unscrew nuts (2).

Tightening torque: 22 32 3AZ , see 22 32 TRANSMISSION MOUNTS .

Remove cross-member.

Scheme 350

Scheme 350
Scheme 350
