Special tools and workshop equipment required
- Oil Collecting and Extracting Device V.A.G 1782
Removing
Drain the coolant. Refer to COOLING SYSTEM, DRAINING AND FILLING or, in countries with hot climates, remove the after-run coolant pump -V51- After-Run Coolant Pump -V51 .
Remove the bolt -1- and nut -3- and the lock carrier left brace -2-.
Scheme 9
Open the clamp and remove the coolant hose -1- and, if necessary, -2- from the oil cooler.
Scheme 10
Place the V.A.G 1782 under the engine.
Remove the bolts -arrows- and remove the engine oil cooler.
Installing
- Tightening specification; refer to «OIL PAN UPPER AND LOWER SECTIONS, OIL PUMP AND OIL COOLER OVERVIEW»(ref-515405-S05347042122012120300000) .
Install in reverse order, paying attention to the following
Note. Replace the gasket. Secure all hose connections with hose clamps of the same type as those equipped by the factory.
Install after-run coolant pump -V51-. Refer to After-Run Coolant Pump -V51 .
Install the lock carrier brace. Refer to Removal and Installation .
Check oil level.
Fill the engine with coolant COOLING SYSTEM, DRAINING AND FILLING => Filling .
