Removal & Installation - A/t (01L): Specifications Audi A6 C5 facelift

Automatic Trans 1 illustration

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Axle Shaft Flange-To-Transmission Flange Bolt
M8 x 4830 (40)
M10 x 4852 (70)
Drive Shaft Flange-To-Transmission Flange Bolt (1)41 (55)
Drive Plate-To-Torque Converter (1)63 (85)
Drive Plate-To-Crankshaft (Engine Codes BCY & BAS) (1)
Step 122 (30)
Step 2Turn Additional 90 Degrees
Drive Plate-To-Crankshaft (Engine Codes ART, AWN & BBD) (1)
Step 144 (60)
Step 2Turn Additional 90 Degrees
Front Crossmember Below Exhaust System-To-Body18 (25)
Guide Link-To-Subframe Bolt/Nut (1) , (2)
Step 166 (90)
Step 2Turn Additional 90 Degrees
Heat Shield (Axle Shaft)17 (23)
Heat Shield (Driveshaft At Transmission Flange)18 (25)
Lower Track Control Link-To-Subframe Bolt/Nut (1) , (2)
Step 159 (80)
Step 2Turn Additional 90 Degrees
Oxygen Sensor37 (50)
Stabilizer Bar Link-To-Stabilizer Bar Link Nut
With Ball Joint74 (100)
With Rubber Bushings44 (60)
Subframe Bolts(3)
Suspension Strut-To-Track Control Unit (2)66 (90)
Torque Converter-To-Drive Plate Nut63 (85)
Transmission Support-To-Transmission Bolt30 (40)
Transmission Support-To-Transmission Mount Bolt37 (50)
Transaxle Mount-To-Engine/Transaxle Carrier Bolt (M8)17 (23)
Wheel Lug Nut89 (120)
INCH Lbs. (N.m)
Multi-Function Transmission Range Switch-To-Transmission71 (8)
(1) Always replace with NEW fastener. Always replace self-locking nuts. (2) Always final tighten suspension parts with bonded rubber bushings with vehicle on ground (normal ride height). (3) For installation procedures and tightening torques see INSTALLATION under SUBFRAME.
(1)Always replace with NEW fastener. Always replace self-locking nuts.
(2)Always final tighten suspension parts with bonded rubber bushings with vehicle on ground (normal ride height).
(3)For installation procedures and tightening torques see INSTALLATION under SUBFRAME.

TORQUE SPECIFICATIONS

Note. Engine-to-transaxle tightening torques are valid only for nuts and bolts that are lightly greased, oiled, covered with a thin coat of phosphate or blackened. Other lubricants are permitted (e.g. engine oil or transaxle fluid); however, they may not contain graphite. Do not use any degreased parts.

Bolt No.Bolt SizeFt. Lbs. (N.m)
01L (1)
1M 12 X 7548 (65)
2M 12 X 9048 (65)
3M 10 X 6033 (45)
4M 10 X 4533 (45)
5M 10 X 4533 (45)
6M 10 X 8048 (65)
7M 12 X 10048 (65)
8M 12 X 7548 (65)
9M 12 X 7548 (65)
(1) For bolt locations see scheme 35 Dowel sleeves for alignment are at locations "A".
(1)For bolt locations see scheme 35 Dowel sleeves for alignment are at locations "A".

TRANSAXLE-TO-ENGINE BOLT TORQUE SPECIFICATIONS

Scheme 1

Scheme 1
