Overhaul - 01V: Component Locations Audi A6 C5 facelift

Special Tools & Equipment

1. VAG1358A
2. VAG1358A/1

Scheme 383

1. VW 681 extractor lever
2. 3295 thrust piece

Scheme 384

1. Depth caliper gauge

Special Tools And Equipment

1. VAG 1383 A Engine/transmission hoist with VAG 1359/2 transmission support.

1. VAG 1306 Drip tray

Scheme 385

Scheme 386

Scheme 387

1. VW401 Thrust plate
2. VW402 Thrust plate
3. VW407 Punch
4. VW412 Punch
5. VW295 Needle bearing drift
6. VW408A Punch
7. VW442 Thrust pad
8. 40-21 Sleeve
9. 40-105 Thrust piece
10. 2050 Thrust plate
11. 3138 Drift
12. Kukko 44/2 Two-arm puller
13. VAG 1582 Taper roller bearing puller
14. VAG 1582/6

Scheme 388

Scheme 389

Scheme 390

Scheme 391

Scheme 392

Check adjustment shims for damage after removing.

Scheme 393

Scheme 394

1. VAG 1383A Engine/transmission hoist
2. VAG 1359/2 Universal mount
3. VW391 Puller
4. VW401 Thrust plate
5. VW402 Thrust plate
6. VW408A Punch
7. VW412 Punch
8. VW457 Support channels
9. VW460/2 Drift
10. VW470/1 Thrust shell for drive pinion bearing
11. VW540 Holding fixture
12. VW771 Slide hammer-complete set with 771/37
13. 30-205 Thrust pad
14. 2003/3 Seal installer
15. 3005 Thrust pad
16. 3026 Mandrel
17. 3028 Retainer
18. 3062 Thrust pad
19. 3138 Drift
20. 3143 Seal driver
21. 3253 Wheel bearing assembly set with 3253/3 and 3253/4
22. Kukko 17/2 Separator
23. Kukko21/7 Extractor
24. Kukko 22/2 Support
25. Torque gauge (0-600 Ncm)
26. 36 mm long socket

Scheme 395

1. VAG 1383A Engine/transmission hoist
2. VAG 1359/2 Universal mount
3. VW385/1 Measuring bar
4. VW385/2 Plastic piece
5. VW385/3 Plastic piece
6. VW385/14 Measuring rod
7. VW385/15 Extension pin
8. VW385/17 Magnetic plate
9. VW385/30 Master gauge-adjustable
10. VW385/33 End gauge
11. VW387 Dial gauge holder
12. VW388 Measuring lever
13. VW401 Thrust plate
14. VW402 Thrust plate
15. VW408A Punch
16. VW457 Support channels
17. VW521/4 Locking sleeve
18. VW521/4 Locking sleeve
19. VW540 Holding fixture
20. 30-205 Thrust pad
21. 2003/3 Seal installer
22. 3005 Thrust pad
23. 3028 Retainer
24. 3062 Thrust pad
25. 3253 Wheel bearing assembly set with 3253/3 and 3253/4
26. Dial gauge extension 30 mm
27. Dial gauge
28. Torque gauge (0-600 Ncm)

1. VW 382/10 extension pin 6mm
2. VW 385/17 magnetic plate
3. VW 387 dial gauge holder
4. VW 388 measuring lever
5. VW 521/4 locking sleeve
6. VW 521/8 bushing
7. Dial gauge
8. Torque wrench 0 - 600 Ncm

Note. Tapered roller bearings for differential are low-friction bearings. Therefore friction torque can only be used for check measurement in a limited way. A correct adjustment is only possible by determining the total thickness "S total ". Do not grease new tapered roller bearings additionally for friction torque measurement. The bearings are already greased with a special oil from the factory.
