TORQUE CONVERTER

The torque converter is equipped with a lock-up clutch. The closing (application) of the lock-up clutch is determined by the engine load and speed, and produces very little vibration. The lock-up clutch drives 3rd, 4th and 5th gears mechanically, independent of slip.

CAUTIONBefore installing the transmission, check the installation dimension of the torque converter. See .
  1. Pay attention to the rules of cleanliness when working on the automatic transmission. See «Rules Of Cleanliness For Working On Automatic Transmissions»(ref-172633-S32196432842005030200000) .
  2. Repair instructions. See «GENERAL REPAIR INSTRUCTIONS»(ref-172633-S29762831402005030200000) .
  3. Apply a thin coat of ATF to the seals. Other lubricants result in operating problems of the hydraulic transmission controls.

Scheme 364

Scheme 364

TORQUE CONVERTER, IDENTIFICATION

Different torque converters exist. Identify by the code (arrow). (Scheme 365)

Scheme 365

Scheme 365: TORQUE CONVERTER, IDENTIFICATION

Allocation torque converter/transmission. See CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT .

TORQUE CONVERTER, CHECKING

Examine hub -arrow- of torque converter for traces of wear. (Scheme 366)

Scheme 366

Scheme 366: TORQUE CONVERTER, CHECKING

Note. The torque converter is welded and must be replaced complete if damaged or faulty.

Torque Converter Draining

If the ATF is soiled due to shavings or during fundamental reconditioning of the transmission, the torque converter must be emptied

Siphon ATF from torque converter using VAG1358A and VAG1358A/1. (Scheme 367)

Scheme 367

Scheme 367: Torque Converter Draining

Tightening Drive Pinion Nut And Adjusting Friction Torque

Thread in two hex head bolts M8 x 30 -A-. see scheme 58

When nut is tightened, final drive must be supported (e.g. using VAG 1359/2 universal mount together with VAG 1383A transmission hoist).

Note. Increase torque slowly and measure friction torque multiple times. If the specified friction torque is surpassed, replace spacer sleeve and repeat adjustment! Any spacer sleeve that has been pressed together too far one time must be replaced.

Measuring Friction Torque

With torque gauge, 0 to 600 Ncm, locally available. see scheme 72

Scheme 368

Scheme 368: Measuring Friction Torque

Note. If necessary use 3/4" to 1/2" reducing piece.

Adjust to following friction torque. see scheme 73

Scheme 369

Scheme 369

Measuring Friction Torque (Check Measurement, Ring Gear)

  1. Drive pinion removed
  2. Differential installed with shims "S1*" and "S2*"

Torque gauge 0 to 600 Ncm -A- installed on differential. see scheme 92

Scheme 370

Scheme 370

Read friction torque.

Friction torque specified values. See RING GEAR FRICTION TORQUE table.

Bearing ApplicationNcm
New Bearing13.3-26.6 (150-300)
Run-In Bearing (1)2.66-5.31 (30-60)
(1) At least 50 km.
(1)At least 50 km.

RING GEAR FRICTION TORQUE

  1. Tapered roller bearings for differential are low-friction bearings. Therefore friction torque can only be used for check measurement in a limited way. A correct adjustment is only possible by determining the total thickness "S total ".
  2. Do not grease new tapered roller bearings additionally for friction torque measurement. The bearings are already greased with a special oil from the factory.
  3. For a new adjustment of the gear set, the drive pinion adjustment must now be performed with checks. See «DRIVE PINION, ADJUSTING»(ref-172633-S00793257452005030200000) .
