Continuously Variable Transmission (cvt) 01j - Removal & Installation Audi A4 B6

APPLICATION

TRANSAXLE APPLICATION

This transmission can be identified by code letters stamped on case. (Scheme 162)

Scheme 162

BATTERY DISCONNECT PROCEDURES

Note. When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle.

Before beginning repairs on the electrical system

1. Obtain the anti-theft radio security code.
2. Switch off all electrical consumers.
3. Switch ignition off and remove ignition key.
4. On vehicles equipped with Audi Telematics by OnStar, switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. See «Back-Up Battery For Telematic/Telephone Control Module»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__back-up-battery-for-telematictelephone-control-module) .
5. Disconnect negative ( - ) battery terminal.

After reconnecting vehicle battery

1. Re-code and check operation of anti-theft radio
2. Check operation of clock and power windows. See «Power Window Control Module»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__power-window-control-module) .
3. On vehicles equipped with Audi Telematics by OnStar, switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. See «Back-Up Battery For Telematic/Telephone Control Module»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__back-up-battery-for-telematictelephone-control-module) .

Power Window Control Module

If the battery is disconnected, the window control module loses its memory of current position and the automatic up/down function. To reset

1. Switch ignition on.
2. Lift window switch up to run power windows up to stop.
3. Operate all window lifters again for at least 1 second in "close" position to activate automatic up/down function.
4. Press window switch briefly.
5. The selected side window must automatically run to the bottom stop.

Back-Up Battery For Telematic/Telephone Control Module

Switching back-up battery on or off requires using factor scan tool VAG 1551 or VAS 5051 Scan Tool (ST), or equivalent aftermarket scan tool.

Under "Rapid data transfer" operating mode 1, select "Telematics" address word 75. Then select function "10 - Adaptation".

Emergency (back-up) battery, switch on/off, reset time register can be selected from this mode. Consult scan tool operator's manual for instructions.

Removal (1.8L)

Secure counterhold VW 558 to driver plate using hex bolt M8 x 45. Place two M10 hex nuts between counterhold and drive plate.

Mark position of drive plate relative to engine. Unbolt drive plate.

1. Locate drive plate with shim -2- and packing plate -1-. (Scheme 163) Lug -arrow- must face toward torque converter.
2. Insert at least 3 old securing bolts and tighten to 30 Nm.
3. Perform measurement by passing sliding calliper with depth gauge through hole used for securing converter. (Scheme 164) Specification: 18.9-20.5 mm.
4. If measured value exceeds specification, remove drive plate again and correct value by installing with/without shim -2-. Tighten bolts to 30 Nm again.
5. Measure distance again.
6. If measured value matches specification, install new bolts and tighten. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__torque-specifications).

Removal (3.0L)

Note. Transmission is removed.

1. Turn crankshaft via center bolt of toothed belt gear in direction of engine rotation to TDC Cyl. 3 marking.
2. If installed, disconnect electrical harness connector at after-run coolant pump.
3. Unscrew sealing plug of TDC mark at cylinder block.
4. Thread T40026 locking pin into the hole of the removed sealing plug and tighten.
5. Mark drive plate to engine. Remove drive plate.

1. Installation is reverse of removal, noting the following: Drive plate is bolted to the crankshaft with a centering bushing (arrow). (Scheme 165)
2. Replace bolts and tighten. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__torque-specifications). Remove T10026 alignment bolt and thread sealing plug of TDC marking with new O-ring into cylinder block.

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

1. Move selector lever to "P" position. Slide battery cover to right, and lift off. Disconnect negative battery cable. See «BATTERY DISCONNECT PROCEDURES»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__battery-disconnect-procedures).
2. Remove engine cover. Set up support bar (10-222 A) on wing panel flanges, with spindle facing towards rear of vehicle. (Scheme 166) Uncover lifting eye at back of engine. Connect hook on spindle with lifting eye on back of engine. Tighten spindle of support bar without lifting, and take up some engine weight.
3. Remove front wheels. On vehicle equipped with auxiliary heater, remove bolts (arrows) securing exhaust pipe of auxiliary/additional heater to sound insulation. (Scheme 167)
4. Loosen bolts and release quick-fasteners (1-3). (Scheme 168) Remove front and rear sound insulation panels. Unbolt bracket for sound insulation. (Scheme 169)
5. Remove inner cover plates (1 and 2) on underside of vehicle. (Scheme 170)
6. Remove front crossmember on underside of vehicle (1-6). (Scheme 171)
7. Remove rear crossmember on underside of vehicle (1-4). (Scheme 172)
8. Loosen clamp (arrows) on exhaust system, and disconnect exhaust pipe. (Scheme 173) Remove heat shield for exhaust system.
9. Remove universal support plate (V.A.G. 1359/2) from engine and transmission jack (V.A.G. 1383 A), and place a square block of wood (1) control piston arm. (Scheme 174) Support tunnel crossmember using engine/transmission jack (V.A.G. 1383 A).
10. Unscrew bolts (1 and 2). (Scheme 175) Unscrew bolts (3 and 4). Slowly lower tunnel crossmember using engine/transmission jack (V.A.G. 1383 A).
11. Remove nuts (arrows) and disconnect tunnel crossmember. (Scheme 176)
12. Remove heat shield (1) for right axle shaft. (Scheme 177) Unbolt left and right axle shafts from transmission flange.
13. Unbolt and remove support bracket (1) for front exhaust pipe. (Scheme 178) Loosen bolts (arrows) securing front exhaust pipe to catalytic converter. Remove front exhaust pipe.
14. Place drip tray underneath transmission. Unscrew union nuts (1 and 2), and disconnect ATF lines. (Scheme 179) Unbolt ATF filter from transmission (arrows). (Scheme 180)
15. Unscrew union nuts (1 and 2), and disconnect ATF lines from radiator. (Scheme 181) Unbolt bracket from ATF lines (arrow). Remove bolt (arrow) and disconnect ATF lines from transmission. (Scheme 182) Take off ATF lines.
16. Release harness connector (A) in direction of arrow, and disconnect from transmission. (Scheme 183) Move wiring harness clear.
17. Remove bolt (2), and bracket (3) for selector lever cable. (Scheme 184) Press off selector lever cable (A) from shift rod lever using pry (80-200). (Scheme 185)
18. Remove transmission support (arrows). (Scheme 186) Remove bolts (1-5 and 11) on engine/transmission flange. (Scheme 187) Only loosen the bolt (item 6). The bolt remains in the bore tightened slightly (hand-tight). The starter does not have to be removed.
19. Install transmission support 3282 on to engine/transmission jack (V.A.G. 1383A). Set template (3282/30) on to transmission support (3282). (Scheme 188) Align transmission support arms to correspond with holes in template. Bolt attachments as labeled on template.
20. Position transmission jack (V.A.G. 1383 A) with transmission support (3282) under transmission, and take up transmission weight. Align adjustment plate parallel to transmission, and secure support to transmission with bolt M10X20 (arrow). (Scheme 189) Use engine and transmission jack (V.A.G. 1383 A) to lift transmission up slightly.
21. On Audi Cabriolet vehicles only, unbolt torque reaction support (arrows). (Scheme 190) Loosen nuts (1) on left and right sides, and swivel stabilizer bar (2) downward. (Scheme 191) Unscrew nuts (3) on left and right engine mounts until bottom of nuts is flush with studs (arrows). Using support bar (10-222 A) lift engine until two nuts (3) on left and right sides, come in contact with bottom mount.
22. On all vehicles, remove bolts (7-10) on engine-to-transmission flange. (Scheme 187) On Cabriolet models, lower engine to original position. On all models, lower transmission slowly. Tie up axle shafts. Remove last bolt securing transmission to engine. Press transmission off dowel sleeves and lower carefully.

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

1. Move selector lever to "P" position. Slide battery cover to right, and lift off. Disconnect negative battery cable. See «BATTERY DISCONNECT PROCEDURES»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__battery-disconnect-procedures).
2. Remove rear engine cover (arrows). (Scheme 192)
3. Remove front engine cover (arrows). (Scheme 193)
4. Remove engine cover at left of compartment. (Scheme 194)
5. Remove coolant reservoir (arrow). (Scheme 195) Disconnect electrical wiring to engine coolant level warning switch (F66) at bottom of expansion tank. Wire aside coolant expansion tank with connected coolant hoses (1-3).
6. Remove harness connectors heat shield at left of bulkhead. Remove harness connectors (1-4) from bracket at left of bulkhead. (Scheme 196) Disconnect electrical harness connector (1 and 4). Guide wires to oxygen sensor downward.
7. Remove nut (2) from left exhaust pipe/exhaust manifold, which is accessible from top. (Scheme 197)
8. Remove cover (1) located at right of engine compartment. (Scheme 198)
9. Remove bolts (arrows). (Scheme 199) Disconnect EVAP canister purge regulator valve (1) from air duct. Remove air duct (2).
10. Remove air cleaner housing (arrows). (Scheme 200)
11. Remove bolts (arrows) from solenoid valve mounting plate (3). (Scheme 201) Disconnect electrical connector from mass air flow sensor. Disconnect crankcase breather hose (4) from air duct (2).
12. Remove bolt (arrow) and disconnect air duct (2) at throttle valve control module. (Scheme 202) If installed, disconnect hose (1) from air guide.
13. Remove harness connectors (1-4) from bracket on right side of bulkhead. (Scheme 203) Disconnect electrical harness connectors (1 and 4). Guide wires to oxygen sensors downward. Remove bracket for harness connectors.
14. Unscrew nut (2), accessible from above, connecting right front exhaust pipe with exhaust manifold. (Scheme 197)
15. Set engine support bridge (10-222A) with engine brackets (10-222A/1) on fender mounting edges. (Scheme 166) Pre-tension engine slightly using spindle on engine support bridge. Remove both front wheels.
16. On vehicle equipped with auxiliary heater, remove bolts (arrows) securing exhaust pipe of auxiliary/additional heater to sound insulation. (Scheme 167) Loosen bolts and release quick-fasteners (1-3), and take off front and rear sound insulation panels. (Scheme 168)
17. Unbolt bracket for sound insulation. (Scheme 169) Remove front crossmember on underside of vehicle (1-4). (Scheme 204)
18. Loosen clamps (arrows) on both exhaust pipes to disconnect exhaust system. (Scheme 205)
19. Remove universal mount (V.A.G. 1359/2) from engine/transmission jack (V.A.G. 1383A), and place a block of wood (1) onto piston arm. see scheme 45 Support transmission using engine/transmission jack (V.A.G. 1383A).
20. Unscrew bolts (1 and 2). (Scheme 175) Unscrew bolts (3 and 4). Slowly lower tunnel crossmember using engine/transmission jack (V.A.G. 1383 A). Remove nuts (arrows) and disconnect tunnel crossmember. (Scheme 176)
21. Loosen bolt (1) on sound insulation cover above left and right axle shafts. see scheme 46
22. Unbolt left and right hand axle shafts from transmission flange.
23. Unbolt front exhaust pipe bracket on left side (arrow). see scheme 47
24. Move oxygen sensor wiring clear. Access nuts (1 and 3) from below and unscrew nuts connecting front exhaust pipe to exhaust manifold on left side. (Scheme 197) Remove front exhaust pipe complete with primary and main catalytic converter.
25. Unbolt front exhaust pipe bracket on right side (arrow). see scheme 47 Move oxygen sensor wiring clear. Access nuts (1 and 3) from below and unscrew nuts connecting front exhaust pipe to exhaust manifold on right side. (Scheme 197) Remove front exhaust pipe complete with primary and main catalytic converter.
26. Disconnect engine speed sensor (G28) on left side of transmission (arrow), and move aside. see scheme 48 Unbolt ATF lines bracket (arrow). see scheme 49
27. Remove bolt (arrow), and disconnect ATF lines from transmission. (Scheme 182) Move ATF lines clear to side and secure in place. Release harness connector (A) in direction of arrow, and disconnect from transmission. (Scheme 183) Move wiring harness clear.
28. Remove bolt (2), and bracket (3) for selector lever cable. (Scheme 184) Press off selector lever cable (A) from shift rod lever using pry (80-200). (Scheme 185)
29. Remove transmission support (arrows). (Scheme 186) Remove bolts (2- 7) on engine/transmission flange. see scheme 50 Only loosen bolt (8). Leave bolt hand tight. It is not necessary to remove starter.
30. Install transmission support 3282 on to engine/transmission jack (V.A.G. 1383A). Set template (3282/30) on to transmission support (3282). (Scheme 188) Align transmission support arms to correspond with holes in template. Bolt attachments as labeled on template.
31. Position transmission jack (V.A.G. 1383 A) with transmission support (3282) under transmission, and take up transmission weight. Align adjustment plate parallel to transmission, and secure support to transmission with bolt M10x20 (arrow). (Scheme 189) Use engine and transmission jack (V.A.G. 1383 A) to lift transmission up slightly.
32. On Cabriolet models, unbolt torque reaction support (arrows). see scheme 51 Loosen nuts (1) on left and right sides, and swivel stabilizer bar (2) downward. (Scheme 191) Unscrew nuts (3) on left and right engine mounts until bottom of nuts is flush with studs (arrows). Using support bar (10-222 A), lift engine until two nuts (3), on left and right sides, come into contact with bottom of mount.
33. On all models, remove bolts (1,9,10 and 11) on engine-to-transmission flange. see scheme 50 On Cabriolet models, lower engine to original position. On all models, lower transmission slowly. Move axle shafts to rear. Remove last bolt securing transmission to engine. Press transmission off dowel sleeves and lower carefully.

Scheme 203

Scheme 204

1. Installation is reverse of removal procedure. Note the following: Secure all hose connection with correct hose clips (same as original equipment). Prior to installing replacement transmission, always blow through ATF cooler and ATF lines with compressed air (no more than 10 bar), and replace additional ATF filter. See «SERVICING - A/T (01J)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt) article. When performing repairs, replace self-locking nuts and bolts. Replace bolts which have specified tightening angle as well as seals and gaskets. All cable ties which are opened or cut open on removal must be replaced in same position when installing.
2. Before installing transmission, tie electrical wiring to one side so that it cannot be trapped between engine and transmission. Ensure dowel sleeves for centralizing engine/transmission are in cylinder block. Install, if necessary.
3. Install intermediate plate or spacer plate on dowel sleeves. Press selector shaft lever (A) at transmission to rear as far as possible, until parking lock engages. see scheme 52
4. Lift transmission carefully, and move into installation position with transmission support (3282). (Scheme 189) Secure transmission to engine.
5. On Cabriolet models, when installing bottom engine-to-transmission bolts, use support bar (10-222 A) to lift engine until two nuts (3), on left and right sides, contact bottom mount. (Scheme 191)
6. On all models, prior to inserting lower set of bolts connecting transmission-to-engine, lift transmission up slightly at rear. Tighten four bottom engine-to-transmission bolts to specification. See «TRANSMISSION MOUNTING BOLTS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__transmission-mounting-bolts) under TORQUE SPECIFICATION.
7. On Cabriolet models, lower engine to original position. Tighten nuts (3) on left and right engine mounts. (Scheme 191) Tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__torque-specifications).
8. Secure stabilizer bar (2). See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__torque-specifications). Secure torque reaction support-to-engine.
9. For transmission-to-engine flange tightening torque specifications, see «TRANSMISSION MOUNTING BOLTS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__transmission-mounting-bolts).
10. Ensure selector lever is in "P" position, and carefully press socket end of selector lever cable (5) onto selector shaft lever (7). (Scheme 184) Insert bolts (2) into mounting base (3) for selector lever cable and tighten to 17 ft. lbs. (23 N.m).
11. Bolt transmission support to transmission (arrows). (Scheme 186) Install ATF lines with new seals into transmission by hand, as far as possible. Bolt ATF lines on. Install exhaust system free of stress.
12. Install axle shafts to transmission flanges. Install axle shaft guards on left and right sides. see scheme 46
13. Install tunnel crossmember. see scheme 53
14. Check selector lever cable setting, ATF level and oil level in front final drive. See «SERVICING - A/T (01J)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt) article. Align exhaust system free of stress.
15. Check all electrical connections and routing.
16. After connecting battery, enter anti-theft code for radio. Fully close power windows to stop. Activate all power window switches for at least one second to activate automatic window raising/lowering. Set clock to correct time. See «BATTERY DISCONNECT PROCEDURES»(/audi/a4/b6-2000-2006/remont/automatic-trans/#continuously-variable-transmission-cvt-01j-removal-installation__battery-disconnect-procedures).

Note. Lower vehicle and final tighten bolts/nuts on suspension components with bonded rubber bushings.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

BOLT VERSIONS

Three different 8 mm bolt versions are used on Audi suspensions. see scheme 54 All bolts should only be used once. Bolts are as follows

1. Bolt "A" without ribbing. Tightening torque 18 ft. lbs. (25 N.m).
2. Bolt "B" with ribbing. Tightening torque 55 ft. lbs. (75 N.m).
3. Bolt "C" with screw head and washer ribbing. Tightening torque 22 ft. lbs. (30 N.m) plus an additional 90°.

Scheme 205

TRANSMISSION MOUNTING BOLTS

Note. Engine-to-transaxle tightening torques are valid only for nuts and bolts that are lightly greased, oiled, covered with a thin coat of phosphate or blackened. Other lubricants are permitted (e.g. engine oil or transaxle fluid); however, they may not contain graphite. Do not use any degreased parts. To install lower engine-to-transmission bolts, lift rear of transmission slightly. Tolerance for tightening torques is 15% more or less.

1.8L Engine

TRANSAXLE-TO-ENGINE BOLT TORQUE SPECIFICATIONS (1.8L ENGINE)

3.0L Engine

TRANSAXLE-TO-ENGINE BOLT TORQUE SPECIFICATIONS (3.0L ENGINE)
