5-speed Automatic Transmission 01v on Board Diagnostic (OBD) Audi A4 B6

On Board Diagnostic (OBD) system, operation

The automatic transmission controls are electronic/hydraulic.

The Transmission Control Module (TCM) -J217- receives information from components which influence the shifts. Based on this information, the control module activates the applicable solenoid valves in the valve body. The solenoids route the fluid pressure generated by the ATF pump to the clutches or brakes to be closed.

Transmission Control Module (TCM) DTC recognition

The term "On Board Diagnostic system" refers to the electrical/electronic part of the controls.

The control module is equipped with a DTC memory so that in the event of the failure of an electrical/electronic component, or in the event of an open circuit, the cause of the fault can be determined quickly.

DTCs are recognized by means of electrical signals. If malfunctions occur in the sensors or components being monitored, they are stored in the DTC memory indicating the type and location of the DTC.

If a DTC is present, it is initially saved as a statistical DTC. If the DTC is no longer present, it first of all becomes a sporadic DTC (SP).

DTCs that are saved in the DTC memory as sporadically present are displayed as "sporadically occurring DTCs" during a DTC scan. "SP" appears on the right side of the display. With the printer switched on, "sporadically occurring DTCs" are printed out following the DTC scan.

DTCs that are saved in the DTC memory as sporadically occurring DTCs are automatically deleted after 40 engine cold starts (and subsequent transmission warm up).

The potential of the On Board Diagnostic system can only be fully realized by using the Vehicle Diagnosis, Measurement and Information System VAS 5051.

Functions which the VAS 5051 Vehicle Diagnosis, Measurement and Information system can detect. Refer to List of Selectable Functions , Table of Selectable Functions.

Safety functions of the Transmission Control Module (TCM)

In the event of a failure of individual or multiple components or sensors, the Transmission Control Module -J217- activates replacement functions or limp-home programs. This ensures non-destructive operation of the automatic transmission with the concomitant effect on the function and quality of the shifts.

If critical DTCs occur and with the Transmission Control Module (TCM) J217 activated, the gear currently engaged is initially held. As soon as the situation with respect to the transmission and vehicle safety permits, the Transmission Control Module -J217- activates "Mechanical Limp Home with Active Control Module".

Mechanical Limp Home with Active Control Module

1. Transmission shifts out of all forward gears into the hydraulic 4th gear. Converter clutch is open. All solenoids have no power.
2. Maximum shift pressure on the powertrain elements.
3. Reverse gear can be engaged. Shift lock (in "P" and "N") is active.

Scheme 522

1. All segments of the gear selector display are fully illuminated.

In the event of a Transmission Control Module (TCM) -J217- failure (e.g power supply failure or harness connector disconnected) the transmission immediately continues to operate in "Mechanical Limp Home with Non-Active Control Module".

Mechanical Limp Home with Non-Active Control Module

1. Transmission shifts out of all forward gears into the hydraulic 4th gear. Converter clutch is open. All solenoids have no power.
2. Maximum shift pressure on the powertrain elements.
3. Reverse gear can be engaged. Shift lock (in "P" and "N") is active.

Scheme 523

1. All segments of the gear selector display are dark.
2. The Transmission Control Module (TCM) -J217- is completely inoperative, which means that On Board Diagnostic (OBD) is not possible.

Technical data for the On Board Diagnostic (OBD) system

1) Resetting adaptation values for Transmission Control Module (TCM). Refer to Adaptation values for Transmission Control Module (TCM), basic setting

Scheme 524

1 - Transmission Control Module (TCM) -J217

1. Component location and removal and installation. Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing)
2. Loosening multiple connector. Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing)
3. Control module is tested by On Board Diagnostic (OBD)

2 - Data Link Connector (DLC)

1. Component location. (Scheme 525)

3 - Shift Lock Solenoid -N110

1. Component location. (Scheme 526)
2. Can be tested in Measured Value Block. Refer to «Test procedure»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__test-procedure) and «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
3. Removal and installation

Refer to

1. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

4 - Internal transmission wiring harness with integrated Transmission Fluid Temperature Sensor (ATF) -G93

1. Component location. (Scheme 528)
2. G93- is tested by On Board Diagnostic
3. Removing and installing wiring harness or Transmission Fluid Temperature Sensor -G93

Refer to

1. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

5 - Valve body

1. Component location. (Scheme 527)
2. Solenoid Valves -N88-, -N89-, -N90- and Pressure Control Valves -N215-, -N216-, -N217- and -N218- are attached to the valve body.
3. Components are tested by On Board Diagnostic
4. Removal and installation

Refer to

1. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

6 - Multi-function Transmission Range (TR) Switch -F125

1. Component location. (Scheme 529)
2. Is tested by On Board Diagnostic
3. Removal and installation

Refer to

1. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

7 - Shift control mechanism cover

1. Removal and installation

Refer to

1. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

8 - Tiptronic Switch -F189

1. Component location. (Scheme 530)
2. Can be tested in Measured Value Block. Refer to «Test procedure»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__test-procedure)
3. Removal and installation

Refer to

1. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

9 - Starter Interlock Alarm System Relay -J60

1. Component location. (Scheme 532)
2. Testing. Refer to «Starter Interlock Alarm System Relay -J60-, checking»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__starter-interlock-alarm-system-relay-j60)

10 - Sensor for transmission RPM -G182

1. Component location. (Scheme 534)
2. Is tested by On Board Diagnostic
3. Removal and installation

Refer to

1. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

11 - Sender for transmission output RPM -G195

1. Measures transmission output RPM
2. Component location. (Scheme 533)
3. Is tested by On Board Diagnostic
4. Removal and installation

Refer to

1. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

12 - Transmission Range (TR) Selector Lever Display -Y6

1. Component location. see scheme 14
2. Gear display not illuminated indicates limp home operation with non-active Transmission Control Module (TCM).
3. Completely illuminated gear display indicates limp home operation with active Transmission Control Module (TCM).
4. Removal and installation

Refer to

1. «90 INSTRUMENTS»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment)
2. «90 INSTRUMENTS»(ref-278931-S12002884242008020700000) for ELECTRICAL EQUIPMENT, CABRIOLET

13 - Kickdown Switch -F8

1. Component location. See. (Scheme 535)
2. No mechanical switch; a specific value from Throttle Position Sensor and Sender for accelerator pedal position -G79-/-G185- is stored in Engine Control Module (ECM)
3. Signal transmission from ECM to TCM over CAN-bus
4. Can be tested in Measured Value Block. Refer to «Test procedure»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__test-procedure)

1. Accelerator pedal module removal and installation

Refer to 20 - FUEL SUPPLY SYSTEM

14 - Brake light switch -F

1. Component location. (Scheme 536)
2. Signal transmission from Engine Control Module (ECM) to Transmission Control Module (TCM) over CAN-bus
3. Can be tested in Measured Value Block. Refer to «Test procedure»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__test-procedure)
4. Removal and installation

Refer to 46 - BRAKES - MECHANICAL COMPONENTS

15 - Cruise Control Switch -E45

1. Component location. (Scheme 537)
2. Removal and installation

Refer to

1. «94 LIGHTS, SWITCHES - EXTERIOR»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment)
2. «94 LIGHTS, SWITCHES - EXTERIOR»(ref-278931-S06915746392008020700000) for ELECTRICAL EQUIPMENT, CABRIOLET

Scheme 525

Component location: The DLC is located under the knee bolster to the left of the steering wheel.

Scheme 526

Component location: The Shift Lock Solenoid is located in the shift control mechanism -arrow-.

Scheme 527

Component location: The valve body is bolted underneath the transmission housing and is covered by the transmission oil pan.

Solenoid Valves -N88-, -N89-, -N90- and Pressure Control Valves 1 -N215-, 2 -N216-, 3 -N217- and 4 -N218- are attached to the valve body.

Scheme 528

Component location: The wiring harness is attached to the valve body.

The wiring harness can be replaced with the transmission installed and the valve body removed.

Scheme 529

Component location: The Multi-Function Transmission Range (TR) Switch is located on the left side of the transmission, harness connector for Multi-Function Transmission Range (TR) Switch -arrow

Scheme 530

Component location: The Tiptronic Switch is integrated into the circuit board for the icon insert which is located in the cover for the shift control mechanism.

It consists of 3 Hall sensors (A, B, C), which are energized by a solenoid on the transverse slide on the roll cover

A - Downshift switch sensor

B - Tiptronic recognition sensor

C - Upshift switch sensor

1. If malfunctions occur test Tiptronic Switch in the Measured Value Block. Refer to «Test procedure»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__test-procedure) for malfunctions.

Scheme 531

In the event of malfunctions, first check whether the solenoid is properly attached to the roll cover -C- transverse slide, if necessary replace transverse slide. The icon insert with the integrated circuit board must not be replaced until the wiring connections have been inspected. In the case of vehicles with multi-function steering wheel, the buttons on the steering wheel and their wiring must also be inspected.

Scheme 532

Component location: On the relay carrier in the E-Box plenum.

4 - Starter Interlock Alarm System Relay -J60

Scheme 533

Component location: The Sender for transmission RPM is located in the transmission at the right rear

Scheme 534

Component location: The sensor -A- is a Hall sensor and is attached behind the valve body to the transmission housing.

Transmission Range Selector Lever Display -Y6

Component location: Integrated in the instrument cluster

Note. The Transmission Range (TR) Selector Lever Display can only be replaced together with the instrument cluster.

Scheme 535

1. No mechanical switch; a specific value from the Throttle Position Sensor and the Sender for accelerator pedal position -G79-/-G185- is stored in the Engine Control Module (ECM)

Scheme 536

Component location: The brake light switch -arrow- is located on the pedal cluster.

Note. In order to ensure adequately tight fit the switch must be installed only one time.

Scheme 537

Component location: The Cruise Control Switch is located at the steering column switch.

Transmission Control Module (TCM) -J217-, removing and installing

1. Switch ignition OFF.
2. Remove rubber seal from the plenum panel cover.

Scheme 538

1. Remove plenum panel cover toward front -1- -arrows-.

Scheme 539

1. Pry off two cover caps -3- with a screwdriver.
2. Loosen hex head nuts -4- a few turns.
3. Remove wiper arms -2- from wiper shaft by tilting them slightly.
4. Remove hex head nuts completely and remove wiper arms.

1. Remove safety clips -1- and remove cowl grille -5-.

Scheme 540

1. Remove cover for plenum panel E-box -arrows-.

Scheme 541

1. Pry off retaining bracket with a screwdriver -arrows-.
2. Place Engine Control Module (ECM) with harness connectors attached to one side.
3. Unclip retaining bracket for Transmission Control Module (TCM).

Note. The harness connector for the control module must not removed or connected for 30 seconds after the ignition has been switched OFF.

Scheme 542

1. Unlock harness connector -arrow- and pull it off Transmission Control Module (TCM).

Note. When the harness connector is removed, the adaptation values in the Transmission Control Module (TCM) are reset. The control module has to relearn these values after resumption of operation. During this "learning process" shift quality may be worse than normal.

Installation is carried out in the reverse order.

Safety Precautions

If the use of test and measuring equipment is required during test drives, the following precautions must be observed

In order to prevent injuries to persons and/or destruction of electrical and electronic components, the following precautions must be observed

1. Attach measurement and test equipment terminals only with the ignition switched OFF.
2. With some tests it may happen that the control module detects and saves a trouble code. For this reason, the DTC memory must be scanned and if necessary deleted after completing all tests and repairs.
3. Disconnecting and attaching battery terminals must only be carried out with the ignition switched OFF, otherwise the Transmission Control Module (TCM) can be damaged.

Notes on towing

Note. It is not possible to tow the vehicle in order to start the engine, for example when the battery is too weak or the starter is not working.

VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions

Test requirements

1. Parking brake applied.
2. Vehicle voltage supply O.K.
3. Voltage supply and fuses for particular system O.K.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. Ground connections for transmission O.K.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. Check ground connections for corrosion and damaged connection, repair as needed.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. Check battery ground strap and ground strap between battery and transmission.

Test procedure

1. Switch ignition OFF.

Scheme 543

1. Connect VAS 5051 Vehicle Diagnosis, Measurement and Information System with diagnostic lead VAS 5051/1.

Note. The Data Link Connector (DLC) is located in the left side knee bolster.

Note. If an error message appears in the display

Refer to Users Manual for VAS 5051 Vehicle Diagnosis, Measurement and Information System VAS 5051

Scheme 544

Display on VAS 5051

1. Touch "Vehicle On Board Diagnostic System" button.

Scheme 545

Display on VAS 5051

Note. By touching "00 - Scan DTC Memory - Complete System" in the selection -1- the automatic test sequence is performed, i.e. a scan is performed of the DTC memory for all systems in the vehicle capable of On Board Diagnostic (OBD).

Depending on the desired function

1. Switch ignition ON.

Or

1. Start engine.
2. In selection -1- touch vehicle system "02 - Transmission Electronics".
3. Wait until next display appears on screen.

Scheme 546

Display on VAS 5051

1 - Control module identification number of the Transmission Control Module (TCM).

List of Selectable Functions

Diagnostic Trouble Code (DTC) memory, scanning

1. Connect VAS 5051 Vehicle Diagnosis, Measurement and Information System. Refer to «VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__vas-5051-vehicle-diagnosis-measurement-and) and in selection touch vehicle system "02 - Transmission Electronics". Ignition must be switched ON.

Scheme 547

Display on VAS 5051

1. In selection touch -1- diagnostic function "02 - Scan DTC memory".

Scheme 548

Display on VAS 5051

1 - Contents of the DTC memory

0 DTCs detected

Or

X DTCs detected

2 - DTC

DTC number

Location of DTC

Type of DTC

A - If DTCs were recognized

1. Print out contents of screen or OBD protocol.
2. End function "02 - Scan DTC memory" by touching <-- button.

Display on VAS 5051

1. Repair malfunction(s) using the Test Chart. Refer to «Diagnostic Trouble Code (DTC) table»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2) .
2. In selection touch diagnostic function "02 - Scan DTC memory" again and delete DTC memory. Refer to «Diagnostic Trouble Code (DTC) memory, erasing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2) .
3. Touch "06 - End output".

B - If no DTC was detected

1. Touch "06 - End output".

Diagnostic Trouble Code (DTC) table

Note. In the following all the possible DTCs are listed by ascending order of DTC numbers. These trouble codes can be recognized by the Transmission Control Module -J217-. Then they are displayed on the Vehicle Diagnosis, Measurement and Information System VAS 5051 during scanning of the DTC memory content. If faults occur only occasionally or if the DTC memory was not deleted after the fault was corrected, these faults will be displayed for a predetermined time as "intermittently occurring faults". Refer to Transmission Control Module (TCM) DTC recognition . If faulty components are displayed when the DTC memory is read, make an additional check of wiring connections to the components for a short circuit and open circuit.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

DTC Chart Part 1, up to Diagnostic Trouble Code 18112/P1704

Notes on Diagnostic Trouble Codes 16987/P 0603 and 16989/P0605

Only after determining the possible fault cause and correcting the following faults

1. Mechanical faults
2. Hydraulic faults
3. Electrical/electronic components and wiring connections

Notes on DTC 17087/P0703

1. The signal from the brake light switch -F- is transmitted by the Engine Control Module (ECM) over the CAN-bus circuit to the Transmission Control Module (TCM).
2. Conditions for DTC recognition: The signals from the brake light switch and the brake test switch are transmitted over the CAN-bus circuit to the Transmission Control Module (TCM) and evaluated there. In the event of an implausibility this DTC is displayed in the Transmission Control Module (TCM).

2) First check 8-pin harness connectors for corroded terminals or water entry and replace if necessary.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

4) The Transmission Fluid Temperature Sensor -G93- is integrated in the transmission wiring harness and can only be replaced as a unit with the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

4) The Transmission Fluid Temperature Sensor G93 is integrated in the transmission wiring harness and can only be replaced as a unit with the wiring harness.

Note on DTC 17095/P0711

1. Condition for DTC recognition: Transmission fluid temperature does not increase after the engine is started or makes erratic changes in temperature.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

4) The Transmission Fluid Temperature Sensor -G93- is integrated in the transmission wiring harness and can only be replaced as a unit with the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

4) The Transmission Fluid Temperature Sensor -G93- is integrated in the transmission wiring harness and can only be replaced as a unit with the wiring harness.

5) First check harness connectors for corroded terminals or water entry and replace if necessary.

Note on DTC 17100/P0716

1. Condition for DTC recognition: One transmission position (D or S) has been positively engaged, not an intermediate position. Engine RPM while driving is higher than 608 RPM. Transmission output RPM while driving is higher than 416 RPM.
2. The DTC is displayed when the conditions for DTC recognition are met and transmission input RPM is equal 0 RPM or higher than 8000 RPM.

5) First check harness connectors for corroded terminals or water entry and replace if necessary.

Notes on DTC 17114/P0730

1. The gear monitoring function of the Transmission Control Module checks the gear ratios by comparing transmission input and transmission output RPM, taking into consideration the gear currently engaged. This DTC is displayed when a detected, unacceptable gear ratio (implausibility) is found.
2. When testing full braking RPM, transmission input RPM in the converter with the vehicle stationary and gear engaged must be almost zero. If this is not the case, this DTC is also displayed because clutch damage may be present (Read Measured Value Block. Refer to «Test procedure»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__test-procedure) ; display group number 001).

Note on DTC 17115/P0731

1. The gear monitoring function of the Transmission Control Module checks the gear ratios by comparing transmission input and transmission output RPM, taking into consideration the gear currently engaged. This DTC is displayed in addition to DTC 17114/P0730 when a detected, unacceptable gear ratio (implausibility) is found.

Note on DTC 17116/P0732

1. The gear monitoring function of the Transmission Control Module checks the gear ratios by comparing transmission input and transmission output RPM, taking into consideration the gear currently engaged. This DTC is displayed in addition to DTC 17114/P0730 when a detected, unacceptable gear ratio (implausibility) is found.

Note on DTC 17117/P0733

1. The gear monitoring function of the Transmission Control Module checks the gear ratios by comparing transmission input and transmission output RPM, taking into consideration the gear currently engaged. This DTC is displayed in addition to DTC 17114/P0730 when a detected, unacceptable gear ratio (implausibility) is found.

Note on DTC 17118/P0734

1. The gear monitoring function of the Transmission Control Module checks the gear ratios by comparing transmission input and transmission output RPM, taking into consideration the gear currently engaged. This DTC is displayed in addition to DTC 17114/P0730 when a detected, unacceptable gear ratio (implausibility) is found.

Note on DTC 17119/P0735

1. The gear monitoring function of the Transmission Control Module checks the gear ratios by comparing transmission input and transmission output RPM, taking into consideration the gear currently engaged. This DTC is displayed in addition to DTC 17114/P0730 when a detected, unacceptable gear ratio (implausibility) is found

Note on DTC 17125/P0741

1. The ratio of transmission input RPM -G182- to engine RPM with the torque converter clutch closed does not match (implausibility).

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Note on DTC 17135/P0751

1. Short circuit to B+ is already checked with the ignition switched ON. All types of DTCs are recognized during operation.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Note on DTC 17136/P0752

1. Short circuit to B+ is already checked with the ignition switched ON. All types of DTCs are recognized during operation.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Notes on DTC 17140/P0756

1. Short circuit to B+ is already checked with the ignition switched ON. All types of DTCs are recognized during operation.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Notes on DTC 17141/P0757

1. Short circuit to B+ is already checked with the ignition switched ON. All types of DTCs are recognized during operation.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Note on DTC 17145/P0761

1. Short circuit to B+ is already checked with the ignition switched ON. All types of DTCs are recognized during operation.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Note on DTC 17146/P0762

1. Short circuit to B+ is already checked with the ignition switched ON. All types of DTCs are recognized during operation.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Note on DTC 17968/P1560

1. Condition for DTC recognition: Engine speed higher than 7400 RPM.

6) No mechanical switch; a specific value from the throttle and accelerator position sensors -G79-/-G185- is set in the Engine Control Module (ECM). Signal transmission from Engine Control Module (ECM) to Transmission Control Module takes place over CAN-bus.

Note on DTC 18112/P1704

1. With the brake pedal depressed and simultaneous full depression of the accelerator pedal as far as Kickdown (wide-open throttle) this fault can be displayed erroneously.

DTC Chart Part 2, up to Diagnostic Trouble Code 18269/P1861

7) The Tiptronic Switch -F189- consists of switches for recognition, upshift and downshift. It is integrated in the shift mechanism printed circuit board, i.e. if the Tiptronic Switch -F189- is faulty, the printed circuit board has to be replaced.

8) The Tiptronic Switch -F189- receives its Tiptronic gate recognition or upshift/downshift information through the solenoid on the transverse slide on the roll cover. If the solenoid has become detached, the roll cover must be replaced.

Note on DTC 18141/P1733

1. DTC is displayed if the downshift switch 7) was detected shifting outside selector lever position D.

7) The Tiptronic Switch -F189- consists of switches for recognition, upshift and downshift. It is integrated in the shift mechanism printed circuit board, i.e. if the Tiptronic Switch -F189- is faulty, the printed circuit board has to be replaced.

8) The Tiptronic Switch -F189- receives its Tiptronic gate recognition or upshift/downshift information through the solenoid on the transverse slide on the roll cover. If the solenoid has become detached, the roll cover must be replaced.

Note on DTC 18147/P1739

1. DTC is displayed if the upshift switch7) was detected shifting outside selector lever position D.

7) The Tiptronic Switch -F189- consists of switches for recognition, upshift and downshift. It is integrated in the shift mechanism printed circuit board, i.e. if the Tiptronic Switch -F189- is faulty, the printed circuit board has to be replaced.

8) The Tiptronic Switch -F189- receives its Tiptronic gate recognition or upshift/downshift information through the solenoid on the transverse slide on the roll cover. If the solenoid has become detached, the roll cover must be replaced.

9) If the transmission is shifted into the Tiptronic gate with the selector lever in D this shift procedure is recognized by the Tiptronic recognition switch -F189- and transmitted to the Transmission Control Module (TCM).

Note on DTC 18152/P1744

1. DTC is displayed if Tiptronic recognition was detected, although the selector lever is not in the Tiptronic gate.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

Notes on DTC 18156/P1748

Only after determining the possible fault cause and correcting the following faults

1. Mechanical faults
2. Hydraulic faults
3. Electrical/electronic components and wiring connections

Notes on DTC 18158/P1750

1. Condition for DTC recognition: Battery voltage 9 volts or less. Refer to transmission goes into limp home mode. Refer to «Safety functions of the Transmission Control Module (TCM)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__safety-functions-of-the-transmission-control) .
2. With a loss of electrical system voltage (terminal 30) the adaptation values in the Transmission Control Module (TCM) are reset. The control module has to relearn these values after resumption of operation. During this "learning process" shift quality may be worse than normal.

Notes on DTC 18159/P1751

1. Condition for DTC recognition: Battery voltage above 16 volts
2. This DTC was also displayed, for example, when jump starting with a 24 volt battery.
3. Battery monitoring distinguishes four ranges (U = battery voltage)

1) U less than 7 volts. Refer to transmission goes into limp home mode. Refer to Safety functions of the Transmission Control Module (TCM)

2) U 7...9 volts. Refer to gear is held for about 2.5 seconds, if U is still in this range afterward, transmission goes into limp home mode. Refer to Safety functions of the Transmission Control Module (TCM)

3) U 9...16 volts. Refer to voltage is O.K.

4) U higher than 16 volts. Refer to transmission goes into limp home mode. Refer to Safety functions of the Transmission Control Module (TCM)

7) The Tiptronic Switch -F189- consists of switches for recognition, upshift and downshift. It is integrated in the shift mechanism printed circuit board, i.e. if the Tiptronic Switch -F189- is faulty, the printed circuit board has to be replaced.

11) Shift Lock Solenoid -N110- cannot be switched OFF, i.e. the selector lever cannot be shifted out of selector lever positions P or D, even by actuating the brake pedal.

12) Shift Lock Solenoid -N110- cannot be activated in selector lever position P and N, i.e. it cannot be shifted out of P and N without actuating the brake pedal.

12) Shift Lock Solenoid -N110- for shift lever lock cannot be activated in selector lever position P and N, i.e. it cannot be shifted out of P and N without actuating the brake pedal.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

3) First check harness connectors for corroded terminals or water entry and replace if necessary. If DTCs are displayed, pay particular attention to the 16-pin harness connector at the transmission between the valve body and the wiring harness.

13) The data bus is also described as a CAN-bus.

Notes on DTC 18258/P1850

1. Condition for DTC recognition: The Transmission Control Module (TCM) is not receiving a message from the Engine Control Module (ECM). However, communication with the ABS control module and the instrument cluster is working.
2. The exchange of data and information between the Engine Control Module (ECM), ABS control module, Transmission Control Module (TCM) and instrument cluster is carried out over what is called a CAN-bus. All information signals are transmitted over 2 lines.

13) The data bus is also described as a CAN-bus.

Notes on DTC 18259/P1851

1. Condition for DTC recognition: The Transmission Control Module (TCM) is not receiving a signal from the ABS control module. However, communication with the Engine Control Module (ECM) and the instrument cluster is functioning.
2. The exchange of data and information between the Engine Control Module (ECM), ABS control module, Transmission Control Module (TCM) and instrument cluster is carried out over what is called a CAN-bus. All information signals are transmitted over 2 lines.

13) The data bus is also described as a CAN-bus.

Note on DTCs 18262/P1854 and 18263/P1855

1. The exchange of data and information between the Engine Control Module (ECM), ABS control module, Transmission Control Module (TCM) and instrument cluster is carried out over what is called a CAN-bus. All information signals are transmitted over 2 lines.

Notes on DTC 18265/P1857

1. The signal for actual engine torque is transmitted by the Engine Control Module (ECM) over the CAN-bus circuit to the Transmission Control Module (TCM).
2. Conditions for DTC recognition: The Engine Control Module (ECM) diagnoses the fault in the particular component. This fault diagnosis is transmitted over the CAN-bus circuit to the Transmission Control Module (TCM).

5) First check harness connectors for corroded terminals or water entry and replace if necessary.

14) The Throttle Position Sensor and sender for accelerator pedal position -G79-/-G185- are present.

Notes on DTC 18269/P1861

1. The signal for throttle position and accelerator pedal position sensors is transmitted by the Engine Control Module (ECM) over the CAN-bus circuit to the Transmission Control Module (TCM).
2. Conditions for DTC recognition: The Engine Control Module (ECM) diagnoses the fault in the particular component. This fault diagnosis is transmitted over the CAN-bus circuit to the Transmission Control Module (TCM).

Control element diagnosis/Output Diagnostic Test Mode (DTM)

Note. Control element diagnosis can only be performed if the ignition is ON, the selector lever is in position "P", the engine is not running and the vehicle is stationary. Control element diagnosis is terminated if the engine is started. Solenoid Valve 1 -N88-, Solenoid Valve 2 -N89-, Solenoid Valve 3 -N90-, Pressure Control Valve 1 -N215- and Shift Lock Solenoid -N110- are tested acoustically during control element diagnosis. Ambient noises must be avoided during the acoustical test. Pressure Control Valve 2 -N216-, Pressure Control Valve 3 -N217- and Pressure Control Valve 4 -N218- are energized through control element diagnosis. Acoustical testing is made more difficult by the fact that these valves click very quietly, which can be heard only in the area of the ATF oil pan. However, any electrical faults that occur when the valves are energized are saved in the DTC memory by the On Board Diagnostic (OBD) system. During control element diagnosis the individual actuators are energized for approximately 45 seconds, unless the test is automatically advanced to the next actuator by pressing the delta button. To repeat control element diagnosis, switch the ignition OFF and ON again.

Test sequence

1. Connect VAS 5051 Vehicle Diagnosis, Measurement- and Information System. Refer to «VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__vas-5051-vehicle-diagnosis-measurement-and) and in selection touch vehicle system "02 - Transmission Electronics". Ignition must be switched ON.

Display on VAS 5051

1. In selection touch -1- diagnostic function "03 - Control element diagnosis".
2. Touch delta button.

Scheme 549

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

1 - Shift Valve 1. Refer to Solenoid Valve 1 -N88

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. This valve is energized (clicks) for approximately 45 seconds , unless the test is automatically advanced to the next actuator by touching the delta button.

Note. Any electrical malfunctions are saved in the DTC memory. Refer to Diagnostic Trouble Code (DTC) table .

If the valve is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 550

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

2 - Shift Valve 2. Refer to Solenoid Valve 2 -N89

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. This valve is energized (clicks) for approximately 45 seconds , unless the test is automatically advanced to the next actuator by touching the delta button.

Note. Any electrical malfunctions are saved in the DTC memory. Refer to Diagnostic Trouble Code (DTC) table .

If the valve is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 551

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

3 - Shift Valve 3. Refer to Solenoid Valve 3 -N90

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. This valve is energized (clicks) for approximately 45 seconds, unless the test is automatically advanced to the next actuator by touching the delta button.

Note. Any electrical malfunctions are saved in the DTC memory. Refer to Diagnostic Trouble Code (DTC) table .

If the valve is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 552

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

4 - Shift Lock Solenoid -N110

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. The Shift Lock Solenoid -N110- is triggered at intervals for about 45 seconds (clicks), unless control element diagnosis is terminated by touching the delta button.

Note. In addition, the brake symbol on the shift mechanism cover must illuminate at intervals.

If the solenoid is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 553

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

5 - Pressure Control Valve 1 -N215

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. This valve is energized (clicks) for approximately 45 seconds , unless the test is automatically advanced to the next actuator by touching the delta button.

Note. Any electrical malfunctions are saved in the DTC memory. Refer to Diagnostic Trouble Code (DTC) table .

If the valve is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 554

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

6 - Pressure Control Valve 2 -N216

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. This valve is energized (clicks) for approximately 45 seconds , unless the test is automatically advanced to the next actuator by touching the delta button.

Note. The valve can be heard clicking very faintly only in the area of the ATF oil pan. Any electrical malfunctions are saved in the DTC memory. Refer to Diagnostic Trouble Code (DTC) table .

If the valve is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 555

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

7 - Pressure Control Valve 3 -N217

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. This valve is energized (clicks) for approximately 45 seconds , unless the test is automatically advanced to the next actuator by touching the delta button.

Note. The valve can be heard clicking very faintly only in the area of the ATF oil pan. Any electrical malfunctions are saved in the DTC memory. Refer to Diagnostic Trouble Code (DTC) table .

If the valve is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 556

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

8 - Pressure Control Valve 4 -N218

1. Touch delta button.

A - Actuator test is running - Test may be advanced

1. This valve is energized (clicks) for approximately 45 seconds , unless the test is automatically advanced to the next actuator by touching the delta button.

Note. The valve can be heard clicking very faintly only in the area of the ATF oil pan. Any electrical malfunctions are saved in the DTC memory. Refer to Diagnostic Trouble Code (DTC) table .

If the valve is not energized (does not click)

1. Perform electrical test. Refer to «Electrical Testing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2)
2. Touch delta button.

Scheme 557

Display on VAS 5051

A - Actuator test is pending - Test must be advanced

9 - Power supply for solenoid valves

1. Touch delta button.

A - Actuator test is running - Test may be advanced

Note. This actuator can be ignored. To continue control element diagnosis, touch the delta button.

Scheme 558

Display on VAS 5051

A - Actuator test is concluded

1. End function "03 - Control element diagnosis" by touching <-- button.

Diagnostic Trouble Code (DTC) memory, erasing

Requirements

1. DTC memory scanned. Refer to «Diagnostic Trouble Code (DTC) memory, scanning»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2) .
2. All malfunctions corrected.

After DTC scan has been checked

Display on VAS 5051

1. In selection touch -1- diagnostic function "05 - Delete DTC memory".

Scheme 559

Display on VAS 5051

1 - No display (before deletion)

Or

DTC memory deleted

Note. If the message appears in display field -1-: "DTC memory has not been scanned yet", the test procedure was not followed exactly. The DTC memory can only be deleted if the DTC memory was scanned previously.

2 - you sure you want to do this? will be deleted!

1. Touch "OK" button in display -2-.
2. End function "05 - Delete DTC memory" by touching <-- button.
3. After repair scan DTC memory again.

Note. This deletes DTCs which were stored during repair of the fault, for example by removing harness connectors.

1. After scanning and deleting DTC memory, test drive vehicle and scan DTC memory again.

The scan of the DTC memory must display

"No DTC recognized"

Adaptation values for Transmission Control Module (TCM), basic setting

Note. Following repairs to the valve body (e.g. replacing solenoid valves), if the valve body, the torque converter or the transmission is replaced, the adaptation values in the Transmission Control Module (TCM) should be reset. This allows the adaptation values for normal operation in the Transmission Control Module (TCM) to be learned more quickly following resumption of operation. Adaptation values in the Transmission Control Module (TCM) are reset if

1. Multiple connector is removed from Transmission Control Module (TCM) for at least 15 minutes. Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing)
2. Battery is disconnected for at least 15 minutes

Refer to

1. «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment)
2. «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(ref-278931-S05223151852008020700000) for ELECTRICAL EQUIPMENT, CABRIOLET

Transmission Control Module (TCM), coding

The Transmission Control Module (TCM) can be coded.

Note. Coding can only be performed with the ignition ON and with the selector lever in position "P" or "N". Accelerator pedal must remain in idle position. Vehicle must be stationary and the engine must not be started.

Test procedure

1. Connect VAS 5051 Vehicle Diagnosis, Measurement and Information System. Refer to «VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__vas-5051-vehicle-diagnosis-measurement-and) and in selection, touch vehicle system "02 - Transmission Electronics". Ignition must be switched ON.

Display on VAS 5051

1. In selection, touch -1- diagnostic function "07 - Coding control module".

Scheme 560

Display on VAS 5051

1 - Enter code word

1. On keypad -2- enter control module coding.

1. Confirm entry by pressing Q button.

Note. After coding, the Transmission Control Module DTC memory is automatically deleted.

Display on VAS 5051

1 - Coding is being carried out

1. Wait until next display appears on screen.

Scheme 561

Display on VAS 5051

1 - Coding in the vehicle system completed

2 - Control module identification number with new coding

(previous coding in parentheses)

1. Terminate function "07 - Coding Control Module" by pressing <-- button.

Measured Value Block, reading

Test procedure

1. Connect VAS 5051 Vehicle Diagnosis, Measurement- and Information System. Refer to «VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__vas-5051-vehicle-diagnosis-measurement-and) and in selection touch vehicle system "02 - Transmission Electronics". Ignition must be switched ON.

or, depending on the desired operation

1. Start engine.

Display on VAS 5051

1. In selection touch -1- diagnostic function "08 - Read Measured Value Block".

Display on VAS 5051

1 - Enter display group

1. On key pad -2- enter desired 3-digit display group number. Refer to «List of Selectable Display Group Numbers»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__list-of-selectable-display-group-numbers) and confirm entry by touching Q-button.

Example

1. Entry "001" for "Display group number 001" and confirm by touching Q button.

Scheme 562

Display on VAS 5051

1 - Read Measured Value Block

2 - Display field 1

Display field 2

Display field 3

Display field 4

3 - Display Group X

Note. If a display field is not being used, there will be no display. To switch to another display field, proceed as follows

1. End function "08 - Read Measured Value Block" by touching <-- button.

List of Selectable Display Group Numbers

Test table

1) While driving: A second technician is needed to read the specified values.

1) While driving: A second technician is needed to read the specified values.

Note on display group number 001, display fields 2 and 3

1. Test condition: Shifting must be completed. Vehicle not decelerating (not driving downhill or engine braking).

1) While driving: A second technician is needed to read the specified values.

2) The Transmission Control Module (TCM) is equipped with automatic gear slaving. The forward gear, which the Transmission Control Module (TCM) would activate during a driving mode change with the selector lever in "D", is displayed.

Notes on display group number 001, display field 4

1. Faulty solenoid valves or other diagnosed faults can prevent a specific gear from being engaged.

1) While driving: A second technician is needed to read the specified values.

1) While driving: A second technician is needed to read the specified values.

Notes on ATF temperature

1. A detected temperature of -50°C indicates a short circuit to ground.
2. A detected temperature of 180°C indicates a short circuit to B+ or an open circuit.

Notes on the intermediate positions

If the selector lever is shifted into one of the intermediate positions mentioned, "Z1", "Z2" or "Z3" is shown on the display. No selected gear must be shown in the display in the instrument cluster , that is to say, only PRNDS is displayed, without a gear being lit up.

Notes on display field 3 in display group number 004

1. The input signals for Multi-function Transmission Range (TR) Switch -F125- can be checked at the Transmission Control Module (TCM).

1) While driving: A second technician is needed to read the specified values.

1) While driving: A second technician is needed to read the specified values.

Note on the solenoid valves

1. Non-switched (inactive) solenoid valves are shown with "0", switched (active) solenoid valves are shown with "X".

1) While driving: A second technician is needed to read the specified values.

5) Solenoid Valve 3 -N90- is actuated only briefly during certain shift operations.

Note on the solenoid valves

1. Non-switched (inactive) solenoid valves are shown with "0", switched (active) solenoid valves are shown with "X".

1) While driving: A second technician is needed to read the specified values.

Note on specified current for pressure control valves

1. Faulty solenoid or pressure control valves, clutches or other faults can prevent a specific gear from being engaged.

1) While driving: A second technician is needed to read the specified values.

Note on specified current for pressure control valves

1. Faulty solenoid or pressure control valves, clutches or other faults can prevent a specific gear from being engaged.

1) While driving: A second technician is needed to read the specified values.

Test conditions for torque converter slip RPM

1. "Converter clutch closed" The shift must be completed (wait at least 1 second), the torque converter lockup clutch (WK) must be closed and accelerator pedal value must be constant.
2. "Converter clutch control": The values given apply to the "adjusted condition" of the converter clutch. Under unfavorable conditions (for example, accelerating on a hill) this condition will not be reached until 20 seconds after the completion of the shift. During this adjustment phase, slip values up to 350 RPM can be reached.
3. Excessive converter slip RPM figures can also indicate slipping clutches or servos not activated.

1) While driving: A second technician is needed to read the specified values.

6) Kickdown point passed at throttle pedal.

1) While driving: A second technician is needed to read the specified values.

Note on display field 1

The signal for actual engine torque is transmitted by the Engine Control Module (ECM) over the CAN-bus circuit to the Transmission Control Module (TCM)

1) While driving: A second technician is needed to read the specified values.

7) You must activate the upshift switch (+) by tapping the selector lever forward. On vehicles with multi-function steering wheel the upshift switch has to be activated by additionally tapping the upper left or right button (+) on the steering wheel.

8) You must activate the downshift switch (-) by tapping the selector lever to the rear. On vehicles with multi-function steering wheel the downshift switch has to be activated by additionally tapping the lower left or right button (-) on the steering wheel.

Note on display group number 013

1. Display field 2 and 4: When the Engine Control Module (ECM) is replaced, the same display as on the old control module must appear after installing the new control module. If this is not the case, the wrong Engine Control Module (ECM) has been installed, or it has been incorrectly coded.

Notes on display group number 125

1. If "1" is displayed, communication from the corresponding control module to the Transmission Control Module (TCM) is O.K.
2. If "0" is displayed and no fault has been set in the DTC memory, the corresponding control module does not have CAN capability (or is faulty).

Scheme 563

Special tools and equipment

1. V.A.G 1526 A
2. V.A.G 1527 B
3. V.A.G 1594 A
4. V.A.G 1598/20

Note. For testing, use Multimeter V.A.G 1526 A or Vehicle Diagnosis, Measurement and Information System VAS 5051. The charts contain the specific measurement methods which have to be set up before the corresponding measurements. The specified values given are valid for an ambient temperature of 0°C to 40°C. If the values measured deviate from the specified values, determine malfunctions following the wiring diagram. If the values measured show only a minor deviation from the specified values, clean cavities and connectors on the test equipment and test leads, repeat test. Before replacing the components in question, check their wires and connectors. In particular, with specified values under 10 ohms , repeat the resistance measurement on the component. The terminal numbers of the connector and the cavity numbers on the V.A.G 1598/20 test box match. Refer to Multiple harness connector (88-pin connector) of Transmission Control Module (TCM) -J217- (cavities on V.A.G 1598/20) .

Test requirements

1. Vehicle voltage supply O.K.
2. Voltage supply and fuses for particular system O.K.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. Ground connections for transmission O.K.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. Check ground connections for corrosion and damaged connection, repair as needed.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. Check battery ground strap and ground strap between battery and transmission.

Test procedure

1. Switch ignition OFF.
2. Remove Transmission Control Module (TCM). Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing) and separate multiple connector. Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing) .

Scheme 564

1. Connect V.A.G 1598/20 test box to control module wiring harness.
2. If values measured deviate from specifications, perform "Steps in event of deviations from specified value" in right-hand column of test table. Refer to «Test table»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2) .
3. Perform all steps in column "Steps in the event of deviations from specified value"
4. Perform only test steps recommended in Test table ("selective troubleshooting")

Multiple harness connector (88-pin connector) of Transmission Control Module (TCM) -J217- (cavities on V.A.G 1598/20)

1) Signal is transmitted over the Engine Control Module (ECM) to the Transmission Control Module (TCM) and can only be checked in the Measured Value Block. Refer to Test procedure .

Chart of Test Steps (88-pin multiple connector)

1. Perform only the test steps listed by component in the DTC Chart and the Measured Value Block.

1) Permissible tolerance: ± 0.1 k ohms

Harness connectors between the Transmission Control Module (TCM) and transmission, checking

Perform this test if the control element diagnosis or the electrical test points to problems between the transmission and Transmission Control Module (TCM) -J217-.

Test procedure

1. Remove Transmission Control Module (TCM). Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing) and separate multiple connector. Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing) .

1. Connect V.A.G 1598/20 test box to control module wiring harness.

Scheme 565

1. Remove sound deadening -arrows-.

Checking harness connectors to the 16-pin connector at the transmission

Scheme 566

1. Unscrew retainer -1- for sound deadening.
2. Rotate locking lever -3- and remove connector for transmission wiring harness.

Scheme 567

1. Connect Multimeter to make a resistance measurement between terminals of 16-pin connector and cavities of test box V.A.G 1598/20, as described in following chart.

1. Specified value always less than 1.5 ohms

Note. In the event of deviations from the specified value, repair open circuit following wiring diagram and check connector for corroded terminals, water entry and leakage. If this test revealed no unacceptable deviations, the wiring harness in the transmission must be tested.

Refer to

1. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

Removing and Installing Valve Body

1. Only if the wiring harness in the transmission is O.K. should the appropriate solenoids or pressure control valves be replaced.

Refer to

1. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

Removing and Installing Valve Body

Multi-function Transmission Range (TR) Switch -F125-, checking

Note. Before performing the electrical test on the Multi-function Transmission Range (TR) Switch, you must first check the Measured Value Block for the multifunction switch. Refer to Test procedure , display ground number 004 Make sure that the selector lever cable is correctly adjusted.

Refer to

1. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

Functional Test

1. Disconnect connector -arrow- for Multi-function Transmission Range (TR) Switch -F125- at front left of transmission.

Scheme 568

Terminal pinout at the connector for Multi-function Transmission Range (TR) Switch -F125-.

1) Terminal pinout at the connector for Multi-function TR switch

1) Terminal pinout at the connector for Multi-function TR switch

Scheme 569

1. Attach Multimeter for a voltage measurement between following terminals of 10-pin connector.
2. Switch ignition ON.

If a specified value is not reached

1. Repair open circuit or short circuit as necessary.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

Check wiring connection between 10-pin connector for multi-function switch and Transmission Control Module (TCM)

1. Remove Transmission Control Module (TCM). Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing) and separate multiple connector. Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing) .

1. Connector V.A.G 1598/20 test box to control module wiring harness.

1. Connect multimeter to make a resistance measurement between terminals of 10-pin connector and cavities of test box V.A.G 1598/20, as described in following chart

Note. In the event of deviations from the specified value, repair open circuit following wiring diagram and check connector for corroded terminals, water entry and leakage. If this test revealed no unacceptable deviations, Multi-function Transmission Range Switch -F125- must be replaced.

Refer to

1. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

Starter Interlock Alarm System Relay -J60-, checking

1. Remove Transmission Control Module (TCM). Refer to «Transmission Control Module (TCM) -J217-, removing and installing»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__transmission-control-module-tcm-j217-removing) and place it to one side with connector still attached.
2. Turn ignition key to "Start" position.
3. Move selector lever from "S" to "P" and back.

1. It must be possible both to hear and feel the Starter Interlock Alarm System Relay -J60- (in the relay carrier plenum panel E-box, pin location 4) engage
2. As long as no malfunction is present, the starter can be operated with the selector lever in position "N" or "P"

If the relay does not engage

1. Check Starter Interlock Alarm System Relay -J60-. Refer to «Check power supply to Starter Interlock Alarm System Relay -J60»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__check-power-supply-to-starter-interlock) .

If the relay engages but the starter does not turn

1. Check wiring connections from Starter Interlock Alarm System Relay -J60- to starter terminal 50 following wiring diagram, or check starter respectively.

Check power supply to Starter Interlock Alarm System Relay -J60

1. Disconnect Starter Interlock Alarm System Relay -J60-.

Scheme 570

1. Connect V.A.G 1527 B voltage tester as follows

1. Turn ignition key to "Start" position.

1. LED must illuminate each time

If the LED does not illuminate

1. Repair open circuit or short circuit as necessary.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

Check activation of Starter Interlock Alarm System Relay -J60

1. Connect V.A.G 1527 B voltage tester as follows

1. Move selector lever from "S" to "P" and back.

1. With the selector lever in "N" or "P" the LED must illuminate, but not in other selector lever positions

If the LED does not illuminate

1. Check adjustment of selector lever cable.

Refer to

1. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) for 5 SPD. AUTOMATIC TRANSMISSION 01V
2. «37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v-front-and-all-wheel-drive-internal-components-servicing) for 5 SPD. AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE - INTERNAL COMPONENTS, SERVICING

1. Check Multi-function Transmission Range (TR) Switch -F125-. Refer to «Multi-function Transmission Range (TR) Switch -F125-, checking»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__multi-function-transmission-range-tr-switch-f125) .
2. Repair open circuit or short circuit as necessary.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

Data Exchange between Transmission Control Module (TCM) and CAN-Capable Control Modules, checking

Note. The exchange of data between the individual control modules is carried out by means of a bus system. "CAN-bus" describes a system to carry and distribute data. The wiring connections between the control modules, over which the data are transmitted, are described as data lines. Data are transmitted serially, that means in sequence, over these data lines to the attached control modules (e.g. engine RPM, accelerator pedal position).

Checking bus system

In the DTC Chart you were instructed to verify the exchange of data between the Transmission Control Module (TCM) and CAN-capable control modules.

1. Connect VAS 5051 Vehicle Diagnosis, Measurement and Information System. Refer to «VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__vas-5051-vehicle-diagnosis-measurement-and) and in selection touch vehicle system "02 - Transmission Electronics". Ignition must be switched ON.

Display on VAS 5051

1. In selection touch -1- diagnostic function "08 - Read Measured Value Block".

Display on VAS 5051

1 - Enter display group

Note. Measured Value Block 125 shows the participants on the data BUS drive.

1. On keypad enter -2- "125" for "Display Group Number 125" and confirm by touching Q button.

Scheme 571

Display on VAS 5051

1. Check display in display fields -1- to -3-.

The display shows the control modules which are CAN-capable with the Engine Control Module (ECM)

1. Display 1: CAN capable control module is participant on the data bus
2. Display 0 or no display: CAN-capable control module is not participant on the data bus or not CAN-capable

1. End function "08 - Read Measured Value Block" by touching <-- button.
2. Touch "06 - End output".

Display on VAS 5051

1. In selection -1- touch diagnostic function "00 - Scan DTC memory - complete system".

1. Now the DTC memory of all systems in the vehicle capable of self-diagnosis is scanned.

If a control module responds and identifies itself, the number of stored trouble codes or "No trouble code" is displayed.

Any stored DTCs in a system are shown in sequence. Then the VAS 5051 sends the next address word.

If a DTC referring to "Data bus drive..." Or "...CAN-bus" is displayed

1. Check whether correct Engine Control Module (ECM) and other CAN-capable control modules have been installed (Part No. and Code).

If the correct control modules have been installed

1. Check whether multiple connectors for control modules are fully seated.

If the multiple connectors are fully seated.

1. Check CAN-bus system.

Checking a "Dual-Wire-Bus System"

Communication takes place between two or more control modules over a "Dual-Wire-Bus System".

1. Analyze DTCs stored in control modules.

Note. The analysis helps you to pinpoint the wiring fault.

Example 1

Based on the DTCs entered in the DTC memories, you can see that control module 1 is not connected to control modules 2 and 3.

1. Switch ignition OFF.
2. Disconnect control modules connected by bus wiring and check whether one bus wiring connection has an open circuit.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. If no malfunction is found in bus wiring, replace control module 1.

Example 2

Based on the DTCs entered in the DTC memories, you can see that control module 2 is not connected to control modules 1 and 3.

1. Switch ignition OFF.
2. Disconnect control modules connected by bus wiring and check whether one of bus wiring connections has an open circuit.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

1. If no malfunction is found in bus wiring, replace control module 2.

Example 3

Based on the DTCs entered in the DTC memory, you see that no transmission or reception activity is possible in any of the control modules.

1. Switch ignition OFF.

Scheme 572

1. Disconnect control modules connected by bus wiring and inspect bus wiring for a short circuit to B+ and to ground.

Refer to Wiring Diagrams, Electrical Troubleshooting and Component Locations binder

If you are unable to determine any cause in the bus wiring for the DTC "Data bus drive faulty", check to see whether one of the control modules is responsible for this DTC.

Test requirement

1. VAS 5051 Vehicle Diagnosis, Measurement and Information System connected and Vehicle Self Diagnosis selected. Refer to «VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#5-speed-automatic-transmission-01v-on-board-diagnostic-obd-2__vas-5051-vehicle-diagnosis-measurement-and) .

All the control modules which use the CAN-bus for communication are disconnected. The ignition is switched OFF.

1. Connect one control module.

Display on VAS 5051

1. Switch ignition ON.
2. Touch appropriate vehicle system in Display -1-.
3. Read DTC memory of control module just connected and delete it.
4. Touch delta button.

1. In display touch -1- diagnostic function "06 - End output".
2. Switch ignition OFF and ON again.
3. Leave ignition switched ON for 10 seconds. Then, using scan tool, read DTC memory of control module just connected.
4. If DTC "Data bus drive faulty" is read, control module just connected must be replaced.

1. If DTC "Data bus drive not faulty" is not read, connect next control module and repeat procedure.

See also:
• 37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING
• 37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING
• 90 INSTRUMENTS
• 20 - FUEL SUPPLY SYSTEM
• 46 - BRAKES - MECHANICAL COMPONENTS
• List of Selectable Functions
• Transmission Control Module (TCM) -J217-, removing and installing
• Test procedure
• Starter Interlock Alarm System Relay -J60-, checking
• Safety Precautions
• VAS 5051 Vehicle Diagnosis, Measurement and Information System, connecting and selecting functions
• Transmission Control Module (TCM) DTC recognition
• Data Exchange between Transmission Control Module (TCM) and CAN-Capable Control Modules, checking
• Safety functions of the Transmission Control Module (TCM)
• List of Selectable Display Group Numbers
• Multiple harness connector (88-pin connector) of Transmission Control Module (TCM) -J217- (cavities on V.A.G 1598/20)
• Multi-function Transmission Range (TR) Switch -F125-, checking
• Harness connectors between the Transmission Control Module (TCM) and transmission, checking
• Check power supply to Starter Interlock Alarm System Relay -J60
