Automatic Transmission - Servicing - A/t (01j, Multitronic Cvt) Audi A4 B6

APPLICATION

TRANSAXLE APPLICATION

This transmission can be identified by code letters stamped on case. (Scheme 95)

Scheme 95

Transaxle

Check fluid level at 20,000 mile intervals. See maintenance schedule for change interval.

Center Differential & Final Drives

Check fluid level at 20,000 mile intervals. Fluid is filled for life. No changing is required.

CHECKING FLUID LEVELS

Note. ATF level will vary according to temperature. If ATF level is checked when ATF temperature is too low, overfilling may result. If ATF level is checked when AFT is too high, under filling may result. Overfilling or under filling will impair function of transmission. ATF temperature appears in display of vehicle diagnostic, testing and information system VAS 5051.

01J Transaxle

1. Requirements for checking ATF level are as follows. Transmission not in emergency running mode. Vehicle in horizontal position. Vehicle diagnostic, testing and information system VAS 5051 connected, vehicle self-diagnosis mode activated and vehicle system "02 - transmission electronics" selected. Engine idling. Air conditioner and heating must be switched off. At start of test, ATF temperature must not be higher than 30 C; allow transmission to cool down if necessary.
2. Using VAS 5051, select diagnosis function "08-Read data block" from menu (1). (Scheme 96) Enter "010" into key block (2) to select "Display Group number 010" and confirm entry with "Q" key. (Scheme 97) Read ATF temperature in display zone (3). (Scheme 98)
3. With brake pedal depressed, shift through all selector lever positions (P, R, N and D) at idling speed, and remain in each position for approximately 2 seconds. Raise and support vehicle.
4. Release quick fasteners (2 and 3), and remove sound insulation. (Scheme 99) Place container under transmission. When ATF has reached 95° F (35° C), unscrew ATF inspection plug (B). (Scheme 100)
5. Approximately 0.1 pint will always drain initially from internal oil level pipe when plug is unscrewed. If transmission is filled with proper quantity of ATF, a small amount of fluid should drain out of inspection bore once ATF temperature reaches between 100° F (35° C) and 113° F (45° C). For warmer climates, maximum temperature may rise to 122° F (50° C).
6. If ATF fluid has not drained out of inspection bore when temperature reaches 104° F (40° C), top off ATF. See «FLUID CAPACITIES»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__fluid-capacities). Replace ATF inspection plug and tighten to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications).
7. Using VAS 5051, press left arrow button to exit from function "08 - Read data block". Select diagnosis function "06 - End output". Switch off ignition and disconnect DLC. Install sound insulation panel.

Front Final Drive

Scheme 96

1. Drive vehicle a short distance to warm up gear oil to approximately 140°F (60°C). Position vehicle on level surface (4-post hoist or over pit). Turn engine off and let gear oil settle for 5 minutes.
2. Release quick-fasteners (2 and 3) and remove rear sound insulation. (Scheme 99) If equipped, loosen bolt on sound insulation cover above left drive shaft. Disengage retainer and remove noise insulation cover. (Scheme 139)
3. Place drain pan under final drive. Remove fill plug (arrow) on side of final drive. (Scheme 101) Check oil level with locally manufactured tool (e.g. a piece of angled wire). Gear oil level should be at 0.335" (8.5) mm below lower edge of fill hole. Add appropriate fluid as required. See «RECOMMENDED FLUIDS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__recommended-fluids).
4. Install NEW fill plug. Tighten to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications). Install noise insulation

RECOMMENDED FLUIDS

RECOMMENDED FLUIDS

FLUID CAPACITIES

TRANSAXLE FLUID CAPACITIES

FINAL DRIVE & CENTER DIFFERENTIAL FLUID CAPACITIES

DRAINING & REFILLING

Scheme 97

Scheme 98

1. Connect ATF reservoir from VAS 5162 filling system at highest possible point on vehicle. (Scheme 102) Raise and support vehicle. Release quick fasteners (2 and 3), and remove noise insulation tray. (Scheme 99) Place drain pan under transaxle.
2. Using multi-point bit 3357, remove drain plug (A). (Scheme 100) Drain ATF. Screw connecting piece on flow valve on ATF charging device VAS 5162 into threaded hole for ATF inspection plug (B).
3. Turn flow valve in direction of filling hose (lower curved arrow) to allow ATF to flow into transmission. (Scheme 103) Fill transmission with at least 4.8-5.3 Qts. (4.5-5.0 L) of ATF. Move selector lever to position "P", start engine and idle. Check ATF level and top off as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__checking-fluid-levels).

Manufacturer does not provide specific procedures for ATF lines and ATF cooler flushing. Before fitting replacement transmission always blow through ATF cooler and ATF lines with no more than 145 psi compressed air, and replace additional ATF filter.

If ATF is dirty upon removal, lines and ATF cooler must additionally be flushed out with clean ATF. To install ATF lines, first insert lines into transmission cooler by hand as far as possible, then bolt on. As an aid for further servicing on vehicles equipped with 4-cylinder turbo engine (Scheme 104)and (Scheme 105). As an aid for further servicing on vehicles equipped with 6-cylinder engine (Scheme 106)

Scheme 99

Scheme 100

Scheme 101

ON-VEHICLE REPAIRS

Note. Various components may be serviced without transaxle removal. For servicing of these components, see appropriate component under ADJUSTMENTS and/or REMOVAL & INSTALLATION .

LOCKING CABLE

Note. Locking cable must always be adjusted in installation position.

1. Remove shift mechanism cover. See «SHIFT MECHANISM COVER»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt). Selector lever knob and cover can remain installed. Remove ash tray in center console.
2. Loosen locking cable support bracket bolt (1). Ensure support bracket (2) is movable by hand. (Scheme 107)
3. Position Setting Bar (3352) between pin on lever and locking cable eye. (Scheme 107) Pull locking cable away from selector lever (toward front of vehicle) and tighten locking cable support bracket bolt to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications).
4. Remove setting bar. Ensure ignition lock key can be easily removed after each adjustment of locking cable.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

1. To check cable, shift selector lever to "P" position. Raise and support vehicle. Remove noise insulation tray. (Scheme 99)
2. On vehicles equipped with 4-cylinder engine, remove inner left (2) and inner right (1) cover plates on underside of vehicle. (Scheme 108)
3. On all models, remove crossmember on underside of vehicle. (Scheme 109)
4. Remove front crossmember on underside of vehicle. (Scheme 110)
5. Taking care not to bend flexible pipe connection on front exhaust pipe more than 10°, loosen clamp (arrows) on exhaust system, and disconnect exhaust pipe. (Scheme 111) Remove heat shield below shift mechanism.
6. Unscrew nut (1) and push bracket (4) up and out of mounting base (3). (Scheme 112)
7. Grab selector lever cable and push selector shaft lever (1) forward to stop into position "D" (arrow). (Scheme 113) Tighten nut (1) to fasten support bracket (4) in this position to mounting base (3). (Scheme 112)
8. Remove shift mechanism cover. See «SHIFT MECHANISM COVER»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt).
9. To adjust cable, loosen rear clamping screw on selector lever cable about one turn through hole in shift mechanism using torque wrench and adapter. (Scheme 114) Clamping screw is only accessible in selector lever "D" position. Selector lever must remain in "D" position while clamping screw is loose.
10. Check exact position of selector lever in "D" position by pushing selector lever lightly toward driver's seat (arrow "A"). (Scheme 114) Tighten clamping screw to 115 INCH lbs. (13 N.m) in this position using torque wrench and adapter.
11. Install all components in reverse order. Tighten all nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications).

REMOVAL & INSTALLATION

BATTERY DISCONNECT PRECAUTIONS

Note. When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle.

Air Bag

ECM

If connector is disconnected from ECM or battery is disconnected, all adaptation values in control module are erased. To achieve optimal anti-theft protection for vehicle, an anti-theft immobilizer was installed. Anti-theft immobilizer is a system for enabling/locking Engine Control Module (ECM) through the W-wire.

This system cannot be circumvented, it is necessary to perform adaptation of anti-theft immobilizer using VAS 5052 in On Board Diagnostic function. The great availability of equipment options makes adaptation of ECM necessary (e.g. cruise control system). This "writing" function is not possible with a generic scan tool, therefore it is necessary to use VAS 5052 in On Board Diagnostic function for this purpose. DTC memory content will remain intact however. If engine is started after this, a rough, uneven idle can result. In this case, ECM readiness code must be regenerated.

ECM Readiness Code

While limited diagnostic information is available, vehicle manufacturer does not support diagnostic information using aftermarket scan tools. To properly diagnose vehicle, it is recommended to use VAS 5051 scan tool with VAS 5051/1 adapter cable or VAG 1551 scan tool with 1551/3A adapter cable and VAG 1598/31 test box.

Readiness code must be generated when Engine Control Module (ECM) memory is cleared, battery voltage is disconnected or ECM is disconnected. To generate readiness code, vehicle must be stationary, transmission in Park or Neutral, all electrical consumers off, A/C switched off and coolant temperature at least 176° F (80° C). If possible, it is best to warm-up vehicle by test driving. Connect scan tool to DLC. DLC is located behind cover under left side of steering column.

Power Windows

After connecting battery, completely open and close all power windows.

Radio & Clock

Vehicles are equipped with an anti-theft stereo system that requires a code to activate. Record stereo code BEFORE disconnecting negative battery cable. Disconnect negative battery cable. Turn ignition to ON position. Reconnect negative battery cable. Enter code into stereo and reset clock.

Telematics

Note. A4 and A4 Quattro are equipped with Audi Telematics by OnStar(R).

To avoid unnecessary discharge of emergency (back-up) battery, it must always be switched off, prior to disconnecting vehicle battery, and switched back on after vehicle battery is reconnected.

Use VAS 5051 in mode "Guided Fault Finding". Enter appropriate model, equipment and model year. Press ">" to confirm. After control modules have been registered, and DTC memories checked, press "Go To". Use the following prompts to switch off/on emergency (back-up) battery

1. Select "Function/Component Selection".
2. Select "Body".
3. Select "Electrical Equipment".
4. Select "01 - On-Board Diagnostic Systems".
5. Select "Telematic".
6. Select "J526 - Telephone/Telematic Ctrl. Module, Service Mode Disc. Battery". If necessary, press ">" to advance.
7. To switch OFF emergency (back-up) battery, select/press button "3" - Service Mode Activating (No Load On Emergency Battery).
8. Follow tester prompts.
9. To switch ON emergency (back-up) battery, select/press button "1" - Service Mode Deactivating (Normal Operating Condition).
10. Follow tester prompts.

ADDITIONAL ATF FILTER

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. Raise and support vehicle. On vehicles equipped with an auxiliary heater remove screws (arrows) securing exhaust pipe of auxiliary/additional heater to sound insulation. (Scheme 115)
2. Loosen bolts and release quick-fasteners and take off front and rear sound insulation. (Scheme 99)
3. Unbolt bracket for sound insulation (arrows). (Scheme 116)
4. Place a drip tray underneath vehicle. Unscrew union nuts (1 and 2) and disconnect ATF lines. (Scheme 117) Unbolt clamp for ATF lines (arrow).
5. Unbolt additional ATF filter from transmission (arrows). (Scheme 118)
6. Install in reverse sequence. Check and top off ATF level as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__checking-fluid-levels) under LUBRICATION.

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

1. Raise and support vehicle. On vehicles equipped with an auxiliary heater remove screws (arrows) securing exhaust pipe of auxiliary/additional heater to sound insulation. (Scheme 115)
2. Loosen bolts and release quick-fasteners and take off front and rear sound insulation. (Scheme 99)
3. Place a drip tray underneath vehicle. Unscrew union nut (arrow) and disconnect ATF line going to additional ATF filter. (Scheme 119)
4. Disconnect air hoses (1 and 2) at secondary air pump. The electrical connector (3) can remain in place. (Scheme 120)
5. Unscrew bolts (1) on bracket for additional ATF filter (2). (Scheme 121)
6. Remove cover (1) located at right of engine compartment. (Scheme 122)
7. Remove bolts (arrows). (Scheme 123) Disconnect EVAP canister purge regulator valve (1) from air duct. Remove air duct (2).
8. Remove air cleaner housing (arrows). (Scheme 124)
9. Disconnect ATF line from top of radiator (arrow). (Scheme 125) Take off additional ATF filter.
10. Install in reverse sequence; note the following points: Replace O-rings.
11. Check and top off ATF level as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__checking-fluid-levels) under LUBRICATION.

Scheme 120

Scheme 121

Scheme 122

1. On vehicles without Radio-Navigation system or radio with large control panel, reach from below in the center console and loosen A/C control head from center console. (Scheme 126) (If A/C control head is difficult to remove, proceed as on vehicles with Radio-Navigation system.) NOTE: The A/C control head is secured in the center console with 4 retaining clips (A).
2. On vehicles with Radio-Navigation system or radio with large control panel, remove radio or radio-navigation system. See «RADIO»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt). Reach through the opening and push the A/C control head toward the rear out of center console.
3. An A/C control head for vehicles without radio-navigation system (A) has an additional trim (B) with 2 screws (C) available. (Scheme 127)
4. On all vehicles, unlock connectors (A to D and F) and disconnect them by pressing the unlocking lugs. (Scheme 128)
5. Installation is in reverse order of removal.

END COVER

Special Tools

1. Engine support bracket 10-222 A
2. Removal lever 80-200
3. Multi-point bit 3357
4. Engine/transmission jack V.A.G 1383 A
5. Waste fluid container

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

1. Remove engine cover panel
2. Set up support bar 10-222 A on fender panel flanges. Spindle goes toward rear of vehicle. (Scheme 130) Connect hook on spindle with lifting eye on back of engine. Take up weight of engine on spindle of support bar, but do not lift.
3. Drain ATF. See «DRAINING & REFILLING»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__draining-refilling).
4. On vehicles with 4-cylinder engine, remove cover plates on underside of vehicle: inner left -2- and inner right -1-. (Scheme 108) Remove rear crossmember on underside of vehicle (bolts 1 to 4). (Scheme 109)
5. On all models, remove front crossmember on underside of vehicle. (Scheme 110)
6. On vehicles with 6-cylinder engine, remove one of two front exhaust pipes.
7. On all models, loosen clamp (arrows) on exhaust system and disconnect exhaust pipe. (Scheme 111) CAUTION: The flexible pipe connection (de-coupling element) in the front exhaust pipe must not be bent more than 10 degrees, otherwise it can be damaged.
8. Remove heat shield below shift mechanism.
9. Remove universal support plate V.A.G 1359/2 from engine and transmission jack V.A.G 1383 A and place a square block of wood -1- onto piston arm. (Scheme 131) Support tunnel crossmember using engine/transmission jack V.A.G 1383 A.
10. First remove bolts -1- and -2-, then bolts -3- and -4-. (Scheme 132) Slowly lower tunnel crossmember using engine/transmission jack V.A.G 1383 A.
11. Remove nuts (arrows) and disconnect tunnel crossmember. (Scheme 133)
12. Release connector -A- in direction of arrow and disconnect from transmission. (Scheme 134) Move wiring harness clear.
13. Unscrew bolts -2- and remove mounting base -3- for selector lever cable. (Scheme 112)
14. Use removal lever 80-200 to pry selector lever cable -A- from selector shaft lever (arrow). (Scheme 159)
15. Remove transmission support from transmission (arrows). (Scheme 135)
16. Loosen bolts (arrows) and take off end cover. (Scheme 136) NOTE: Use new bolts when installing.

Scheme 131

Scheme 132

1. Install in reverse sequence. Replace gaskets and seals.
2. Slide new twin-lip oil seal -A- onto connector of Transmission Control Module (TCM) -J217- with twin lips facing outward. (Scheme 137)
3. Clean sealing surfaces of transmission housing and end cover. Install a new paper gasket -A- for end cover. (Scheme 138)
4. Install end cover and take care that paper gasket does not slip. Install new bolts (arrows). (Scheme 136) Tighten in crosswise pattern hand-tight to start with. Tighten to 11 ft. lbs. (15 N.m), then final tighten NEW bolts an additional 90 degree turn.
5. Carefully check installation position of twin-lip oil seal -A-. It must be flush (twin lips must not fold over). (Scheme 136)
6. Check whether selector lever is in position "P" and carefully press socket end of selector lever cable -5- onto selector shaft lever -7-. (Scheme 112) Insert bolts -2- into mounting base -3- for selector lever cable and tighten to 17 ft. lbs. (23 N.m) in transmission. NOTE: Take care not to bend selector shaft lever when pressing it on; support it if necessary as otherwise selector mechanism can no longer be adjusted properly.
7. Bolt transmission support onto transmission (arrows). (Scheme 135) Tighten to 15 ft. lbs. (20 N.m).
8. Install tunnel crossmember. For installation procedures, see «TUNNEL CROSSMEMBER»(/audi/a4/b6-2000-2006/remont/suspension-front/#suspension-front) in SUSPENSION - FRONT article.
9. Check selector lever cable setting. See «SELECTOR LEVER CABLE»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt) under ADJUSTMENTS.
10. Install exhaust system and align it to be free of stress.
11. Fill up with fresh ATF. See «DRAINING & REFILLING»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__draining-refilling).

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

1. Remove wheel trim. Pull trim cap off light-alloy wheels, (puller in vehicle tool kit). With wheels on ground, loosen bolt for drive axle shaft outer joint by a maximum of 90 degrees. Only loosen drive axle shaft hub bolt with vehicle standing on wheels to prevent danger of accident.
2. Remove left front wheel. Loosen bolts and quick-release fasteners (1, 2 and 3). (Scheme 99)
3. Remove front and rear sound insulation. If equipped, loosen bolt (1) on sound insulation cover above left drive shaft. (Scheme 139) Disengage retainer (2) and remove sound insulation over. If equipped, unbolt heat shield from left drive shaft.
4. Remove left drive shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b6-2000-2006/remont/axle-shafts/#axle-shafts-front-rear) article under DRIVELINE/AXLES.
5. Place container under transmission. Screw lower support of puller (T10037) into housing (arrow) and remove flange shaft. (Scheme 140)
6. Clamp flange shaft in vice. (Scheme 141) Use NEW circlip (A) to press old circlip out of groove in flange shaft.
7. Taking care not to damage oil seal seating surface, use special tool (VW 681) to pull out flange shaft oil seal. (Scheme 142)
8. If polygon bearings do not run smoothly with flange shaft removed, bearings are faulty. (Scheme 143) A test for noisy bearings can only be performed with bearings installed. Inspect for signs of damage to polygon bearings (such as cracking in outer race). Polygon bearings can only be replaced together with flange shaft.
9. To install, reverse removal procedure. Lightly lubricate outer circumference and sealing lip of oil seal with gear oil. Keep NEW oil seal for left-hand flange shaft straight when installing.
10. Drive NEW oil seal to a depth of 5.5 mm below outer surface of cover using special tool (2062). (Scheme 144) If old flange shaft is reinstalled after repair, oil seal must be driven in 6.5 mm so that NEW seal does not run on same contact surface as old seal.
11. Using drive (VW 295), knock flange shaft in.
12. Install drive axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b6-2000-2006/remont/axle-shafts/#axle-shafts-front-rear) article under DRIVELINE/AXLES.
13. Check oil level in front final drive. See «CHECKING FLUID LEVELS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__checking-fluid-levels) under LUBRICATION. Tighten all nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications).

Scheme 138

1. Turn ignition switch off. Disconnect negative battery cable.
2. Remove storage compartment on driver's side. (Scheme 145)
3. Remove steering column cover. Remove air conditioning operating unit and radio. See «A/C CONTROL HEAD»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt) and «RADIO»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt).
4. Remove ash tray in center console. Remove shift mechanism cover. See «SHIFT MECHANISM COVER»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt).
5. Turn ignition key to "ignition on" position. Move selector lever to "P" position. Lift retaining clip (2) from interlock lever and pull locking cable (1) out from ignition switch. (Scheme 146)
6. Lift securing spring (4) for locking cable and pull locking cable support bracket (5) on shift mechanism sideways and disengage locking cable eye. (Scheme 146)
7. To install cable, route locking cable free of kinks. Turn ignition key to "ignition on" position. Install locking cable (1) to ignition switch. Ensure interlock lever (2) is locked. Turn ignition switch to LOCK position (ignition off). Move selector lever to "P" position. Engage locking cable eye in pin (3).
8. Slightly lift securing spring (4). Push locking cable support bracket (5) into shift mechanism from right side until securing spring (4) engages. (Scheme 146)
9. Adjust locking cable. See «LOCKING CABLE»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__locking-cable) under ADJUSTMENTS.
10. Install shift mechanism cover and ash tray.

Scheme 139

Scheme 140

Scheme 141

1. Push the two clips of radio removal tool T10057 into the front of the radio. (Scheme 147)and (Scheme 148).
2. Pull the radio out of the instrument panel. Unplug the connectors and the antenna wire. Pull out the release tool from the radio. To do this, press in the locking tabs on the radio.
3. To install radio, plug in the connectors and the antenna wire. Carefully insert the radio into the instrument panel and let it engage in the installation slot.

Scheme 142

1. Push the four clips of radio removal tool T10057 into the front. (Scheme 147)and (Scheme 149).
2. Pull the radio out of the instrument panel. Unplug the connectors and the antenna wire. Pull out the release tool from the radio. To do this, press in the locking tabs at the top and bottom on the radio.
3. To install the radio, plug in the connectors and the antenna wire. Carefully insert the radio into the instrument panel and let it engage in the installation slot.

Scheme 143

1. Open glove compartment. Insert two hooks of T10057 radio removal tool into the front of the CD changer. (Scheme 147)and (Scheme 150).
2. Pull the CD changer out of its installation slot. Detach connector. Pull out the release tool from the CD changer. To do this, press in the locking tabs on the CD changer.
3. To install CD changer, plug in the connector. Slide the CD changer into the installation slot until it engages. After installation, it is essential that the wiring is checked to ensure that the system functions properly.
4. Check wire connection between radio and CD changer. Switch off radio.
5. On Concert II radio (Scheme 148), press the CD button on the radio and switch on the radio at the same time. On symphony II" radio (Scheme 149), press the "4" button on the radio and switch on the radio at the same time, keeping the ON button pressed in.
6. On both types of radio, indication on radio display should be: "CONNECT". If indication on radio display: "NO CDC". Check electrical harness connector at CD changer. Repeat wiring check and if not OK, check wiring connector according to wiring diagram.

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

1. Remove wheel trim. Pull trim cap off light-alloy wheels, (puller in vehicle tool kit). With wheels on ground, loosen bolt for drive axle shaft outer joint by a maximum of 90 degrees. Only loosen drive axle shaft hub bolt with vehicle standing on wheels to prevent danger of accident.
2. Remove left front wheel. Loosen bolts and quick-release fasteners (1, 2 and 3). (Scheme 99)
3. Remove front and rear sound insulation. If equipped, loosen bolt (1) on sound insulation cover above left drive shaft. (Scheme 139) Disengage retainer (2) and remove sound insulation cover.
4. If equipped, unbolt heat shield from left drive shaft. Remove left drive axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b6-2000-2006/remont/axle-shafts/#axle-shafts-front-rear) article under DRIVELINE/AXLES.
5. Unbolt flange shaft bearing bracket (arrows). (Scheme 151) Place container under transmission. Pull out flange shaft together with bearing bracket. Remove circlip (arrow A) for grooved ball bearing. (Scheme 152)
6. Press flange shaft out of flange shaft bearing bracket. (Scheme 153) Using special tool (VW 681), pull flange shaft oil seal out of bearing bracket. Press grooved ball bearing out of bearing bracket. (Scheme 154)
7. Press NEW grooved ball bearing into bearing bracket. (Scheme 155) Lightly lubricate outer circumference and sealing lip of oil seal with axle oil. Ensure seal is straight while driving NEW oil seal for right-hand flange shaft on. Using special tool (2062) drive to a depth of 5.5 mm below outer surface of bearing bracket. (Scheme 156) If old flange shaft is reinstalled after repair, oil seal must be driven in 6.5 mm so that NEW seal does not run on same contact surface as old seal.
8. Press bearing bracket with grooved ball bearing onto flange shaft. (Scheme 157) Insert circlip (arrow A). (Scheme 152)
9. Replace O-ring (arrow A) in flange shaft bearing bracket. (Scheme 158) Push spring (C) with cap facing outward into drilling at end of flange shaft (arrow). Insert flanges shaft into transmission. Bolt on flange shaft bearing bracket (arrows). Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications).
10. Install drive axle shaft. See «AXLE SHAFTS - FRONT & REAR»(/audi/a4/b6-2000-2006/remont/axle-shafts/#axle-shafts-front-rear) article under DRIVELINE/AXLES. Install heat shield for drive shaft.
11. Check oil level in front final drive. See «CHECKING FLUID LEVELS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__checking-fluid-levels) under LUBRICATION.

Scheme 151

Scheme 152

Scheme 153

Scheme 154

1. To check cable, shift selector lever to "P" position. Raise and support vehicle. Remove noise insulation tray. (Scheme 99)
2. On vehicles equipped with 4-cylinder engine, remove inner left (2) and inner right (1) cover plates on underside of vehicle. (Scheme 108)
3. On all models, remove crossmember on underside of vehicle. (Scheme 109) Remove front crossmember on underside of vehicle. (Scheme 110)
4. Taking care not to bend flexible pipe connection on front exhaust pipe more than 10°, loosen clamp (arrows) on exhaust system, and disconnect exhaust pipe. (Scheme 111) Remove heat shield below shift mechanism.
5. Unscrew bolts (2) and remove mounting base (3) for selector lever cable. (Scheme 112) Using removal lever (80-200), pry selector lever cable (A) from selector shaft level (arrow). (Scheme 159)
6. Remove bottom cover from shift mechanism (arrows). (Scheme 160)
7. Disconnect selector lever cable sleeve from bottom cover and slide back sleeve. Pull retaining clip (1) for selector lever cable down off shift mechanism. (Scheme 161) Pull plastic locking spring (2) forward slightly, and push pin (3) up as far as required (arrow), but no further. Ensure pin is not pushed out completely. Pull selector lever cable (4) out of shift mechanism. DO NOT bend or kink selector cable.
8. Loosen lock nuts (6), and disconnect selector lever cable from support bracket (4). (Scheme 112) To install, reverse removal procedure. DO NOT bend or kink selector lever cable. Apply a thin coat of polyurea grease (No. G 052 142 A2), to selector lever cable eyelet and ball socket.
9. Push selector lever cable into shift mechanism and secure cable with retaining clip (1). see scheme 68 Insert end of selector lever cable (4) into joint on selector lever. Push down (arrow) pin (3). Check plastic locking spring (2) has secured pin.
10. Button sealing sleeve for selector lever cable into shift mechanism bottom cover. Attach bottom cover to shift mechanism and tighten nuts (arrows). (Scheme 160)
11. Attach selector lever cable (5) to support bracket (4) and tighten lock nuts (6). (Scheme 112) Tighten lock nuts to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications).
12. Press selector shaft lever (A) at transmission to rear as far as it will go (arrow) until parking lock engages. see scheme 69 Ensure selector lever is in position "P". Carefully press socket end of selector lever cable (5) onto selector shaft lever (7). (Scheme 112)
13. Adjust selector lever cable. See «SELECTOR LEVER CABLE»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt) under ADJUSTMENTS. Install exhaust system and align to be free of stress.

Scheme 155

1. Shift selector lever into position "D". Turn sleeve (1) to left and push downward as far as stop. see scheme 70 Carefully pull switch (2) just enough out of selector lever knob (3) until a cable tie can be inserted between button and selector lever. CAUTION: Do not remove button further under any circumstances, otherwise the selector lever knob will be damaged.
2. Secure button in pulled-out position using cable tie (arrow) see scheme 70 Remove selector lever knob upward.
3. Installation is reverse of removal, noting the following: Shift selector lever into position "D".
4. To install new selector lever knob (3), button (2) must be pulled out as far as stop and secured with a cable tie (arrow) or using assembly aid included with new knob. see scheme 70 If the button was accidentally not secured, then it must not be pulled from selector lever knob using mechanical tools. Apply compressed air gun to bottom of knob and carefully press button out with compressed air.
5. Position complete selector lever knob (3) on selector lever (button 2) faces driver. see scheme 70 During this, the knob must engage into ring groove of the selector lever. Remove cable tie (arrow) or assembly aid, then button actuation engages in vertical groove of selector lever. If necessary press button into selector lever knob. Pull sleeve (1) upward and engage by turning clockwise.

1. Remove transmission. See appropriate REMOVAL & INSTALLATION article in AUTOMATIC TRANSMISSION.
2. Remove bolt (B), and lift off selector shaft lever (A). see scheme 69 Carefully pry out selector shaft oil seal using a screwdriver or flat chisel. Take care not to damage sealing surface and selector shaft.
3. To install, reverse removal procedure. Lightly lubricate outer circumference of NEW oil seal with ATF. Slide NEW oil seal onto selector shaft as far as possible. Drive oil seal home onto seat using thrust piece (VW 418 A). Install selector shaft lever (A) onto selector shaft. see scheme 69 Tighten bolt (B) to specification. See «TORQUE SPECIFICATIONS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__torque-specifications).
4. After transmission has been installed, check and top off ATF level as necessary. See «CHECKING FLUID LEVELS»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__checking-fluid-levels) under LUBRICATION.

Scheme 156

Scheme 157

1. Remove selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt).
2. Open ashtray in center console, and remove trim panel (arrows). see scheme 71 Remove 2 retaining screws for ashtray and lift rear of ashtray.
3. Pry out retainer lugs (arrows), and lift off shift mechanism cover (1) complete with guide plate. see scheme 72
4. Install in reverse sequence. Install selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt).

Scheme 158

Scheme 159

Scheme 160

Scheme 161

1. Remove end cover. See «END COVER»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__end-cover).
2. Unscrew bolts (arrows) and pull out automatic transmission control module (J217) without tilting it. (Scheme 137) Remove double-lip sealing ring (A) from automatic transmission control module (J217).
3. Install in reverse order. Remove any dirt and metal particles from senders (A), (C) and (D). see scheme 73
4. Clean selector shaft detent (arrow). see scheme 74 Do NOT use fluffy cloths. Take special care to remove all metal particles and any other dirt from contact surfaces of solenoids. NOTE: Make sure that the spring (A) and roller (B) are fitted correctly. see scheme 74
5. Remove any dirt and metal particles from senders (A), (C) and (D). see scheme 73
6. Before installing automatic transmission control module (J217), replace O-rings (A) on hydraulic control assembly. Coat the O-rings with ATF before inserting them. see scheme 75
7. Insert automatic transmission control module (J217) without tilting it. Connections (A), (B) and (C) on rear side of control module must engage in hydraulic control assembly. see scheme 76
8. Tighten transmission control module bolts (arrows) to 89 INCH lbs. (10 N.m). (Scheme 137)
9. Install end cover. See «END COVER»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-servicing-at-01j-multitronic-cvt__end-cover).
10. The following steps must be performed after a new automatic transmission control module has been installed: Encode new automatic transmission control module (J217). Adapt automatic transmission control module (J217).

Note. Use the vehicle diagnostic, testing and information system VAS 5051. See appropriate automatic transmission DIAGNOSIS article.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

See also:
• TUNNEL CROSSMEMBER
• AXLE SHAFTS - FRONT & REAR
• FLUID CAPACITIES
• TORQUE SPECIFICATIONS
• RECOMMENDED FLUIDS
• CHECKING FLUID LEVELS
• ADJUSTMENTS
• REMOVAL & INSTALLATION
• DRAINING & REFILLING
• BATTERY DISCONNECT PRECAUTIONS
• LOCKING CABLE
• END COVER
