Automatic Transmission - Overhaul - 01v Audi A4 B6

IDENTIFICATION

TRANSMISSION APPLICATION

Transmission code letters are located on the data plate under the transmission (arrow). (Scheme 206)

There is another identical data plate on side of transmission which is not accessible with the transmission installed.

Scheme 206

Transmission serial number (arrow 1), Transmission identification (arrow 2), Code letter (arrow 3). (Scheme 207)

Scheme 207

The transmission code letters are also listed on the vehicle data plates.

Scheme 208

Scheme 209

TORQUE CONVERTER

The torque converter is equipped with a lock-up clutch. The lock-up clutch is closed load- and speed-dependent with minimum pulsations and mechanically drives all forward gears independent of slip.

The 5-speed automatic transmission 01V is equipped with 5 hydraulically activated forward gears. By passing the torque converter slip, these forward gears become mechanically driven gears if the lock-up clutch is closed.

ON BOARD DIAGNOSTIC (OBD)

Before performing service work on the automatic transmission, cause of damage must be exactly determined via "Guided Fault Finding".

"Guided Fault Finding" is performed using the VAS5051 tester.

TRANSMISSION CONTROL MODULE (TCM) -J217- WITH DRIVING SITUATION SHIFTING (FUZZY LOGIC)

Driving situation- and driving resistance dependent shift point determination is performed automatically.

Advantages

1. it is shifted depending on consumption.
2. highest engine performance is always available.
3. individual adaptation of shift points in all driving situations.
4. Arbitrarily changed shift points.

SHIFT POINT CHANGE WHEN DRIVING UP- OR DOWNHILL RANGES

At uphill or downhill ranges, the shifts are automatically selected dependent on the accelerator pedal position and vehicle speed via additional shift characteristics maps.

1. Shift characteristics map for extreme uphill driving is adapted to the engine performance.
2. Shift characteristics map for extreme downhill driving is adapted to the braking effect of the engine.

LUBRICATION & ADJUSTMENTS

For lubrication and adjustments, see SERVICING - A/T (01V - WITH 1.8L & 3.0L) article.

AXLE SHAFTS

For information on axle shafts, see AXLE SHAFTS - FRONT & REAR article.

TRANSMISSION COMPONENTS

For information on components serviceable while transmission is installed in vehicle, see SERVICING - A/T (01V - WITH 1.8L & 3.0L) article.

SERVICING NOTES

The maximum possible care, cleanliness and proper tools are essential to ensure satisfactory and successful transmission repairs. The usual basic safety precautions also apply when carrying out vehicle repairs.

1. Rules of cleanliness for working on automatic transmissions. See «Rules Of Cleanliness For Working On Automatic Transmissions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-overhaul-01v__rules-of-cleanliness-for-working-on) .
2. Do not run engine with the oil pan removed or without ATF filling and do not tow vehicle.
3. Clean ATF lines and ATF cooler when replacing automatic transmission. See «SERVICING - A/T (01V - WITH 1.8L & 3.0L)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#servicing-at-01v-with-18l-30l) article.
4. Secure torque converter on removed transmission to keep it from falling out.
5. Thoroughly clean all connections and the surrounding area before disconnecting.
6. Check installation dimension of torque converter before installing transmission. See «TORQUE CONVERTER, INSTALLING»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-overhaul-01v) .
7. When installing transmission, make sure centering sleeves are correctly seated in engine.
8. Place parts that have been removed on a clean surface and cover. Use foils and paper. Use lint-free cloths only!
9. Carefully cover over opened components or seal, if repairs are not carried out immediately.
10. Only install clean components: Only unpack replacement parts immediately prior to installation.
11. Check, and if necessary correct amount of the following fluids when replacing the automatic transmission. ATF in planetary gear, gear oil in front final drive, gear oil in center differential, and capacities and specifications. See «SERVICING - A/T (01V - WITH 1.8L & 3.0L)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#servicing-at-01v-with-18l-30l) article.
12. When replacing the rear final drive, check and if necessary, correct oil level in rear final drive. See «SERVICING - A/T (01V - WITH 1.8L & 3.0L)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#servicing-at-01v-with-18l-30l) article.

O-RINGS, GASKETS, SEALS

1. Always replace O-rings, gaskets and sealing rings.
2. After removing gaskets and seals, always inspect the contact surfaces at housing or shaft for burrs resulting from removal or for other signs of damage.
3. Thoroughly clean housing sealing surfaces before assembling.
4. Lightly lubricate O-rings before installing, this prevents the rings from being pinched when inserting.
5. Before installing, fill gap between sealing lips of radial-shaft seals half way with sealing grease 052 128 A1.
6. The open side of the seals face toward the fluid to be sealed in.
7. For installation, lightly coat outer circumference and sealing lip with ATF or transmission oil, depending on the installation location.
8. Use only ATF in areas near ATF. Other lubricating substances cause functional problems in the hydraulic transmission control.
9. When pressing in new seals, make sure the sealing lip does not run on the same point as the sealing lip of the old seal (use insertion depth tolerances).
10. After installing, check and if necessary correct fluid levels in the affected area. ATF in planetary gear, gear oil in front final drive, gear oil in center differential, and gear oil in rear final drive. See «SERVICING - A/T (01V - WITH 1.8L & 3.0L)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#servicing-at-01v-with-18l-30l) article.

NUTS, BOLTS

1. Loosen bolts in reverse order of tightening sequence.
2. Tighten and loosen bolts or nuts for securing covers and housings without tightening sequence in diagonal sequence in stages.
3. Do not cant, and loosen and tighten especially sensitive parts - e.g. valve body - in diagonal manner in stages.
4. The tightening torques stated apply to non-oiled nuts and bolts.
5. Always replace self-locking nuts and bolts.
6. Using a wire brush, clean threads of bolts which are secured with locking compound. Next, insert bolts using AMV 185 101 A1.
7. Threaded bores into which self-locking bolts or bolts with locking compound are threaded in, must be cleaned (e.g. using threaded tap). Otherwise there is danger that the bolts may shear when removed again.

CIRCLIPS

1. Do not over-stretch circlips.
2. Always replace damaged or over-stretched circlips.
3. Circlips must be fully seated in groove.

MOUNT

1. Install needle bearings with the lettering on the bearing (the side with thicker metal) facing the drift.
2. Insert bearing with transmission oil or ATF, depending on installation location.

VALVE BODY

1. Replace transmission if shift members are burnt.
2. The valve body is allocated to the transmission code letters. See «CODE LETTERS, TRANSMISSION ALLOCATIONS, RATIOS, EQUIPMENT»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-overhaul-01v) .

GUIDED TROUBLESHOOTING, VEHICLE ON BOARD DIAGNOSTIC (OBD) & TEST INSTRUMENTS

1. Before performing repairs on the automatic transmission, the malfunction cause must be determined as exact as possible via the VAS5051 tester in the operating modes ""Guided Fault Finding", "Vehicle Self-Diagnosis" and "Test Instruments."

1. Rules of cleanliness for working on automatic transmissions. See «Rules Of Cleanliness For Working On Automatic Transmissions»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-overhaul-01v__rules-of-cleanliness-for-working-on) .
2. General repair notes. See «SERVICING NOTES»(/audi/a4/b6-2000-2006/remont/automatic-trans/#automatic-transmission-overhaul-01v__servicing-notes) .
3. Lightly coat sealing ring with ATF. Other lubricating substances lead to functional problems in the hydraulic transmission control.

Scheme 210

TORQUE CONVERTER, IDENTIFICATION

Different types of torque converters exist. Identification is performed via code letters (arrow). (Scheme 211)

Scheme 211

Allocation of torque converter/transmission. See CODE LETTERS, TRANSMISSION ALLOCATIONS, RATIOS, EQUIPMENT .

TORQUE CONVERTER, CHECKING

Checking converter hub for wear grooves (arrow). (Scheme 212)

Scheme 212

Note. The torque converter is welded in and must be completely replaced if damaged or in case of malfunctions.

Scheme 213

1. VAG1358A - oil siphoning unit
2. VAG 1358 A/1 oil syphoning probe (Scheme 213)

Draining

In case of soiling of the ATF via shavings, torque converter must be drained.

Drain ATF from torque converter using VAG1358A and oil syphoning probe VAG1358A/1. (Scheme 214)

Scheme 214

Scheme 215

1. VW681 extractor lever
2. 3295 thrust piece

Removing

Remove transmission. See REMOVAL & INSTALLATION - A/T (01V - WITH 1.8L & 3.0L) article.

Secure transmission to assembly stand.

Insert VW681 extractor lever directly behind the sealing lip of the sealing ring, so that the contact ring which is behind it is not damaged. (Scheme 216)

Scheme 216

Installing

Insert contact ring.

Coat outer circumference and sealing lips of sealing ring with ATF.

1. Installation position: The open side of the sealing ring faces the transmission.

Using 3295 thrust piece, drive in sealing ring for torque converter up to thrust piece stop. (Scheme 217)

Scheme 217

Special Tools & Equipment

1. Depth gauge

Installation Dimension For Torque Converter, Checking

Slide in converter hub through the sealing ring up to the first stop.

Rotate torque converter inward with light pressure, until the groove of the torque converter hub engages in the coupling plate of the pump wheel and the torque converter slides inward noticeably.

When torque converter is installed correctly, distance between lower contact surface of threaded holes at torque converter and contact surface of converter housing on Automatic Transmission 01V is approx. 23 mm. (Scheme 218)

Scheme 218

If the torque converter is NOT inserted completely, this distance will be approx. 11 mm.

Pay particular attention to the following when installing the transmission.

Scheme 219

SHIFT ELEMENT POSITIONS

1. When dealing with problems relating to poor acceleration and performance or general malfunctions, the following chart indicates which selector elements are actuated in the various gears. This should help to identify the selector elements that are not working properly.

Scheme 220

TRANSMISSION, DISASSEMBLING & ASSEMBLING

Observe general repair instructions. See SERVICING NOTES .

Rules Of Cleanliness For Working On Automatic Transmissions

1. Thoroughly clean all connections and the surrounding area before disconnecting.
2. Place parts that have been removed on a clean surface and cover. Use foils and paper. Use lint-free cloths only!
3. Carefully cover over opened components or seal, if repairs are not carried out immediately.
4. Only install clean components: Only unpack replacement parts immediately prior to installation.
5. Always replace O-rings, gaskets and sealing rings.
6. Lightly lubricate O-rings before installing, this prevents the rings from being pinched when inserting.
7. Use only ATF in areas near ATF. Other lubricating substances cause functional problems in the hydraulic transmission control.
8. Check the following fluid levels after installing, top off if necessary. ATF in planetary gear, gear oil in front final drive, gear oil in center differential, and Capacities and specifications. See «SERVICING - A/T (01V - WITH 1.8L & 3.0L)»(/audi/a4/b6-2000-2006/remont/automatic-trans/#servicing-at-01v-with-18l-30l) article.

TRANSMISSION, OVERHAUL

Manufacturer does not provide overhaul information on this transmission.

TRANSMISSION, REMOVING AND INSTALLING

For information on removing and installing transmission, see REMOVAL & INSTALLATION - A/T (01V - WITH 1.8L article.

Removal & Installation

If transmission is installed in vehicle, raise and support vehicle. Remove noise insulation tray. (Scheme 221)

Scheme 221

Place drain pan under transaxle. Remove drain plug. (Scheme 222)

Scheme 222

Drain ATF. Unscrew bolts on oil pan in diagonal sequence and remove oil pan. Unscrew 2 bolts on ATF screen. (Scheme 223)

Scheme 223

Pull ATF screen off valve body. Pry securing clip (arrow) off wiring harness connector. (Scheme 224)

Scheme 224

Pull connector ("A") off transaxle vehicle speed sensor. Pull connector "B" off transaxle RPM sensor. (Scheme 225)

Scheme 225

Only remove the bolts from the valve body which are marked with an arrow. (Scheme 226)

Scheme 226

Note. The bolt (arrow A) is not installed on transmissions with hydraulic control E18/2 and can therefore be disregarded.

Do not remove any other bolts as this could influence the function of the valve body. Detach valve body from transaxle and guide out connector on wiring harness.

To install, reverse removal procedure. To ensure wiring harness does not become trapped when installing the valve body, route the wire with connector (C) according to the illustration. (Scheme 227)

Scheme 227

Lubricate NEW "O" rings for connector on wiring harness with ATF. Install connector in transaxle housing with flat part (A) facing toward oil pan. (Scheme 228) Align dowel pin on valve body (B) with hole in transaxle housing (C).

Scheme 228

Place valve body in position so that pin of detent plate (1) engages in slot on selector slide (2). (Scheme 229)

Scheme 229

Tighten bolts (arrows) hand tight, securing valve body. Bolt (A) does not apply and should be ignored. (Scheme 226) Tighten bolts to 71 INCH lbs. (8 N.m), working from the inside of valve body outward. Connect transaxle vehicle speed sensor connector. Pull up wire to transaxle RPM sensor between valve body and wiring harness.

Press in securing clip for wiring harness connector until retaining tab engages. Moisten seal on intake neck of ATF screen with ATF. Carefully push intake neck of ATF screen in opening of valve body. Install ATF screen and tighten bolts to 53 INCH lbs. (6 N.m).

Install oil pan with NEW gasket. Tighten oil pan bolts to 89 INCH lbs. (10 N.m), in several stages and in diagonal sequence. Install drain plug and tighten to 30 ft. lbs. (40 N.m).

Fill transaxle with ATF, check ATF level and top off. See SERVICING - A/T (01V - WITH 1.8L & 3.0L) article.

Scheme 230
