Power Seats (v6) Acura TSX II

Seats 6 illustrations ~310 words

Front Passenger's Seat

For the driver's seat, refer to Driving Position Memory System (DPMS), COMPONENT LOCATION INDEX

Scheme 183

Scheme 183: Front Passenger's Seat
Scheme 183: Front Passenger's Seat

Scheme 184

Scheme 184: Circuit Diagram - Front Passenger's Power Seat
Scheme 184: Circuit Diagram - Front Passenger's Power Seat

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 185

Scheme 185: Front Passenger's Seat
Scheme 185: Front Passenger's Seat

Scheme 186

Scheme 186
Scheme 186
  1. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
  2. Remove the power seat adjustment switch knobs (A) and the recline cover from the front passenger's seat (see «FRONT SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-cushion-cover-replacement) ).
  3. Remove the two screws and the power seat adjustment switch (B).
  4. Disconnect the 12P connector from the power seat adjustment switch.
  5. Reinstall the adjustment switch knobs to the switch.
  6. Check for continuity between the terminals in each switch position according to the table.
  7. If the continuity is not as specified, replace the switch.
  8. Install the switch in the reverse order of removal.

Front Passenger's Power Seat Motor Test

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 187

Scheme 187: Front Passenger's Power Seat Motor Test
Scheme 187: Front Passenger's Power Seat Motor Test

Scheme 188

Scheme 188
Scheme 188
  1. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
  2. Disconnect the connector from each power seat motor. NOTE: All connectors are terminal side of male terminals.
  3. Test each motor by connecting power and ground according to the table. When the motor stops running, disconnect battery power immediately.
  4. If the motor does not run or fails to run smoothly, replace the motor. Slide motor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-slide-motor-replacement) ) Recline motor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-motor-replacement) )
