Power Seats (4-cyl) Acura TSX II

Seats 17 illustrations ~612 words

Driver's Seat without DPMS

For the driver's seat with DPMS, refer to DRIVER POSITION MEMORY SYSTEM (DPMS) (4-CYL) .

Scheme 409

Scheme 409: Driver's Seat without DPMS
Scheme 409: Driver's Seat without DPMS

Scheme 410

Scheme 410: Front Passenger's Seat
Scheme 410: Front Passenger's Seat

Scheme 411

Scheme 411: Without DPMS
Scheme 411: Without DPMS

Scheme 412

Scheme 412: Circuit Diagram - Front Passenger's Power Seat
Scheme 412: Circuit Diagram - Front Passenger's Power Seat

Driver's Seat

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 413

Scheme 413: Driver's Seat
Scheme 413: Driver's Seat

Scheme 414

Scheme 414
Scheme 414
  1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
  2. Remove the power seat adjustment switch knobs (A) and the recline cover from the driver's seat (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-recline-cover-removalinstallation) ), then remove the two screws and the power seat adjustment switch (B).
  3. Disconnect the 12P connector from the power seat adjustment switch.
  4. Reinstall the adjustment switch knobs to the switch.
  5. Check for continuity between the terminals in each switch position according to the table. *: There is continuity without operating a switch.
  6. If the continuity is not as specified, replace the switch.

Front Passenger's Seat

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 415

Scheme 415: Front Passenger's Seat
Scheme 415: Front Passenger's Seat

Scheme 416

Scheme 416
Scheme 416
  1. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
  2. Remove the power seat adjustment switch knobs (A) and the recline cover from the front passenger's seat (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-recline-cover-removalinstallation) ), then remove the two screws and the power seat adjustment switch (B).
  3. Disconnect the 12P connector from the power seat adjustment switch.
  4. Reinstall the adjustment switch knobs to the switch.
  5. Check for continuity between the terminals in each switch position according to the table. *: There is continuity without operating a switch.
  6. If the continuity is not as specified, replace the switch.

Driver's Power Seat Motor Test

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 417

Scheme 417: Driver's Power Seat Motor Test
Scheme 417: Driver's Power Seat Motor Test

Scheme 418

Scheme 418
Scheme 418

Scheme 419

Scheme 419
Scheme 419

Scheme 420

Scheme 420
Scheme 420

Scheme 421

Scheme 421
Scheme 421

Scheme 422

Scheme 422
Scheme 422
  1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
  2. Disconnect the connector from each power seat motor. NOTE: All connectors are terminal side of male terminals.
  3. Test each motor by connecting power and ground according to the table. When the motor stops running, disconnect battery power immediately.
  4. If the motor does not run or fails to run smoothly, replace the motor: Slide motor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-slide-motor-replacement) ) Front up-down motor (see «FRONT SEAT UP-DOWN MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Rear up-down motor (see «REAR UP-DOWN MOTOR»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__rear-up-down-motor) ) Recline motor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-recline-motor-replacement) )

Front Passenger's Power Seat Motor Test

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 423

Scheme 423: Front Passenger's Power Seat Motor Test
Scheme 423: Front Passenger's Power Seat Motor Test

Scheme 424

Scheme 424
Scheme 424

Scheme 425

Scheme 425
Scheme 425
  1. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
  2. Disconnect the connector from each power seat motor. NOTE: All connectors are terminal side of male terminals.
  3. Test each motor by connecting power and ground according to the table. When the motor stops running, disconnect battery power immediately.
  4. If the motor does not run or fails to run smoothly, replace the motor: Slide motor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-slide-motor-replacement) ) Recline motor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-recline-motor-replacement) )
