Seats (4-cyl) Acura TSX II

Scheme 200

Scheme 201

Front Seat Active Head Restraint Inspection

Note. If the vehicle has been in a collision, always inspect the active head restraint, even if they appear reusable, by doing the following procedure.

Scheme 202

1. Move the seat-back to the fully upright position. Raise the head restraint to the highest position.
2. Apply masking tape on the top of the head restraint.
3. Apply the masking tape (A) on the top of the head restraint (B).
4. Make the mark (C) at the center point of the head restraint. Use the mark for the measurements in step 3 .
5. Push the head restraint (A) forward, and measure the horizontal head restraint movement. The head restraint should move more than 50 mm (2.0 in) without resistance. If it is less than 50 mm (2.0 in), or the head restraint does not move smoothly, replace the seat frame assembly: Driver's seat (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-frame-replacement) ) Passenger's seat (see «PASSENGER'S SEAT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__passengers-seat) )

Scheme 203

Front Seat Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Do the ODS unit initialization (see ODS UNIT INITIALIZATION ) after front passenger's seat replacement.

Note. Put on gloves to protect your hands. Take care not to scratch the body or tear the seat covers. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

1. Adjust the steering column to the full tilt up position, and to the full telescopic in position. Adjust the seat-back recline to a middle position.
2. Slide the front seat all the way forward and lower it all the way down.
3. Carefully pry up on the bottom of the anchor cover (A) at the pry point (B) with the appropriate trim tool to release the hooks (C) and the tab (D), then remove the cover by pulling it upward.
4. Remove the lower anchor bolt (A).
5. Remove the seat track end covers (A) from the back of both seat tracks.
6. Remove the seat mounting bolts from the rear side of the front seat.
7. Slide the front seat all the way back, and remove the front seat mounting bolts.
8. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl) ), then wait at least 3 minutes before removing the seat.
9. Lift up the front seat, then detach the harness clips (A). Disconnect the side airbag connector (B) and the seat wire harness connector (C). Disconnect the ODS unit harness connector (D) (passenger's seat). Driver's seat (Without driving position memory system) Driver's seat (With driving position memory system) Passenger's seat
10. Remove the head restraint.
11. With the help of an assistant, carefully remove the front seat through the front door opening.
12. Install the seat in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly. Apply medium strength liquid thread lock to the seat mounting bolts before reinstallation. Tighten the seat mounting bolts to the specified torque in the sequence shown. Slide the seat all the way back and tighten (1) and (2), then slide it forward and tighten (3) and (4). Tighten the bolts by hand first, then tighten them to the specified torque. Do the battery terminal reconnection procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl__battery-removal-and-installation) ).

Driver's seat

Scheme 211

Passenger's seat

Scheme 212

Front Seat Recline Motor Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. The driver's seat is shown; the passenger's seat is similar.

Scheme 213

Scheme 214

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove these items: Seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-back-cover-replacement) ) Front seat recline cover (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-recline-cover-removalinstallation) )
3. Release the push nut (A) from the motor side end of the connecting rod (B), gently tap on the motor side of the connecting rod to remove it from the recline motor (C) and both recline adjusters (D).
4. Remove the mounting bolt, then remove the recline motor (A).
5. Install the motor in the reverse order of removal, and note these items: Replace the push nut with a new one and make sure the push nut is installed correctly. Make sure the recline motor harness is routed properly. Apply medium strength liquid thread lock to the mounting bolt before reinstallation. Make sure the motor connector is plugged in properly. Check the front seat recline operation.

Front Seat Lumbar Support Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to kink the cable. Take care not to tear or damage the seat covers.

Scheme 215

Scheme 216

Scheme 217

Scheme 218

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove the seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-back-cover-replacement) ).
3. Remove the cable clamp (A) fastening the lumbar support cable (B).
4. Remove the screws securing the lumbar support actuator (A).
5. Remove the lumbar support (A). 1. While pulling the lower part of the lumbar support to one side of the seat back frame, release it from the lower wire (B). 2. Release an opposite side of the lumbar support from the other lower wire. 3. Release the upper part of the lumbar support from both upper springs (C).
6. Release the lower wires (A) from both active head restraint links (B).
7. Install the lumbar support in the reverse order of removal.

Front Seat Slide Motor Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers. The driver's seat is shown; the passenger's seat is similar.

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove the seat cushion cover/pad (see «FRONT SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-cushion-cover-replacement) ).
3. Remove the flex cable (A) and the cable housing (B). 1. Release the housing from the hooks (C). 2. Disconnect the cable from the worm gear (D) in the inner seat track by pulling out the housing. 3. Disconnect the cable from the slide motor (E). NOTE: Take care not to kink the cable.
4. Disconnect the slide motor connector (A), and detach the harness clip (B). Remove the bolts securing the slide motor bracket (C) with a TORX T30 bit.
5. Disconnect the slide motor (A) from the short flex cable (B), and remove the slide motor bracket (C) from the slide gearbox bracket (D).
6. Pull out the short flex cable (A) from the worm gear (B).
7. Remove the screws, then remove the slide motor (A) from the slide motor bracket (B).
8. Install the motor in the reverse order of removal, and note these items: Apply multipurpose grease to the worm gear areas in both seat tracks. Install the short flex cable to the slide motor before installing the slide motor to the slide motor bracket. Make sure both seat tracks are all the way forward before installing the slide motor bracket on the tracks. Make sure each cable is connected properly. Make sure the motor connector is plugged in properly. Check the front seat slide operation.

Front Up-Down Motor

Note. Put on gloves to protect your hands.

Scheme 224

Scheme 225

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove the seat cushion cover/pad (see «FRONT SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-cushion-cover-replacement) ).
3. Remove the front up-down motor (A) and the front up-down motor bracket (B) as an assembly. 1. Disconnect the motor connector (C). 2. Remove the motor bracket mounting bolts (D) with a TORX T30 bit. 3. Remove the motor bracket mounting bolt (E) with a TORX T40 bit.
4. Detach the motor connector clip (A). Remove the bolts with a TORX T30 bit, then remove the front up-down motor (B) from the front up-down motor bracket (C).
5. Install the motor in the reverse order of removal, and note these items: Apply multipurpose grease to the pivot areas of the up-down adjuster and the motor pinion. When installing the front up-down motor (A), adjust the gear (B) to the motor pinion (C) by slightly rotating the brake (D) with an 8 mm hex wrench. Make sure the motor connector is plugged in properly. Check the front seat up-down operation.

Scheme 226

Rear Up-Down Motor

Note. Put on gloves to protect your hands.

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove these items: Seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-back-cover-replacement) ) Seat cushion cover/pad (see «FRONT SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-cushion-cover-replacement) )
3. Remove the rear brake (A) and the rear brake bracket (B) as an assembly. 1. Remove the brake bracket mounting bolts (C) with a TORX T30 bit. 2. Remove the brake bracket mounting bolt (D) with a TORX T40 bit. 3. Pull back the brake bracket to remove the gear (E) from the brake gear axle.
4. Remove the gear (A).
5. Manually lower the seat frame down fully to access the rear bolt securing the rear up-down motor.
6. Disconnect and detach the motor connector (A). Remove the bolts with a TORX T30 bit, then remove the rear up-down motor (B). Installation
7. Remove the bolts with a TORX T30 bit, then remove the rear brake (A) from the rear brake bracket (B).
8. Install the rear up-down motor (A). 1. Apply multipurpose grease to the motor pinion. 2. Tighten the bolts with a TORX T30 bit. 3. Connect the motor connector (B) and fasten the connector clip (C) to the seat frame. NOTE: Make sure the connector is plugged in properly.
9. Manually raise the seat frame fully upward.
10. Install the gear (A) facing the seat frame.
11. Install the rear brake bracket (A) without the rear brake to the seat frame. Lightly tighten all of the mounting bolts (B, C) with a TORX T40 and T30 bit.
12. Carefully position the seat frame on its rear up-down motor side down.
13. Align the pinion (A) of the rear brake (B). 1. Engage the gear (C) with the motor pinion by hand, and center it. 2. Check the positions of the sector gear (D) and the cross-shaped hole (E) in the gear. 3. Align the pinion with an 8 mm hex wrench of the rear brake to the sector gear and also fingers (F) around the axle to the cross-shaped hole in the gear.
14. While holding the gear (A) perpendicular to the axle of the rear brake (B) by hand, install the rear brake onto the rear brake bracket (C). NOTE: If you feel any interference between inside gears, remove the rear brake, and repeat step 13 . If the rear brake seats fully on the rear brake bracket with no interference, go to step 15.
15. Install the rear brake mounting bolts (A), and tighten them to their specified torque with a TORX T30 bit. Install the rear brake bracket mounting bolts (B, C), then tighten them to their specified torque with a TORX T40 and T30 bit.
16. Reinstall all of removed parts to the seat frame: Seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-back-cover-replacement) ) Seat cushion cover/pad (see «FRONT SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-cushion-cover-replacement) )
17. Reinstall the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
18. Check the front seat up-down operation.

Front Seat Rail Replacement - Driver's Seat

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Check the operation of the driver's seat position sensor (see DRIVER'S SEAT POSITION SENSOR OPERATION CHECK ) after driver's seat position sensor replacement.

Note. Put on gloves to protect your hands. Take care not to tear the seat covers. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 237

Scheme 238

Scheme 239

Scheme 240

1. Adjust the steering column to the full tilt up position, and to the full telescopic in position. Adjust the seat-back recline to a middle position.
2. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
3. Remove these items: Front seat recline cover (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-recline-cover-removalinstallation) ) Seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl__front-seat-belt-buckle) ) Seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) )
4. Detach the clips (A, B), then remove the upper rail outer cover (C).
5. Detach the clip, then remove the upper rail inner cover (A).
6. Disconnect the slide motor connector (A), then detach the harness clip (B).
7. Remove the bolts with a TORX T30 bit, then remove the front seat rail (A).
8. Install the seat rail in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely. Check the seat slide operation.

Front Seat Frame Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Driver's Seat

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Check the operation of the driver's seat position sensor (see DRIVER'S SEAT POSITION SENSOR OPERATION CHECK ) after driver's seat position sensor replacement.

Note. If the side airbag has deployed, replace the seat frame and related parts, along with the other parts listed for side airbag deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 241

Scheme 242

Scheme 243

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove these items: Front seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-back-cover-replacement) ) Front seat cushion cover/pad (see «FRONT SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-cushion-cover-replacement) ) Seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl__front-seat-belt-buckle) ) Seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ) Side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__side-airbag-replacement) )
3. Detach the clips (A, B), then remove the upper rail outer cover (C).
4. Detach the clip, then remove the upper rail inner cover (A).
5. Remove the recline inner cover (A) and the center inner cover (B) from the seat frame (C).
6. Install the seat frame in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Passenger's Seat

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Do the front passenger's weight sensor initialization (see FRONT PASSENGER'S WEIGHT SENSOR OUTPUT CHECK AFTER A VEHICLE COLLISION ) after front passenger's seat frame replacement.

Note. If the side airbag has deployed, replace the seat frame and related parts, along with the other parts listed for side airbag deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 244

Scheme 245

Scheme 246

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove these items: Front seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-back-cover-replacement) ) Front seat cushion cover/pad (see «FRONT SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-cushion-cover-replacement) ) ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ) Seat belt buckle (see «FRONT SEAT BELT BUCKLE»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl__front-seat-belt-buckle) ) Side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__side-airbag-replacement) )
3. Detach the clip, then remove the upper rail outer cover (A).
4. Detach the clip, then remove the upper rail inner cover (A).
5. Remove the recline inner cover (A) and the center inner cover (B) from the seat frame (C).
6. Install the seat frame in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Front Seat-Back Cover Replacement

Special Tools Required

1. KTC Trim Tool Set SOJATP2014*
2. Trim Pad Remover, Snap-on A 177A or equivalent, commercially available

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Do the OPDS sensor initialization (see ODS UNIT INITIALIZATION ) after front passenger's seat-back cover replacement.

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers. Passenger's seat: Do not touch the OPDS sensor in the seat-back pad, and keep it away from oil. Oil can corrode the sensor causing it to fail. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The driver's seat is shown; the passenger's seat is similar.

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Driver's seat: Remove the retainer clip (A), then remove the lumbar support handle (B).
3. From under the seat cushion, release the hooks of the elastic strap (A) from the seat cushion frame springs (B), then pull out the back panel undercover (C).
4. From under the seat cushion, disconnect and/or detach the connectors: Driver's seat: Side airbag connector (A) Recline motor harness connector (B) Seat-back heater connector (C) Passenger's seat: Side airbag connector (A) Recline motor harness connector (B) Driver's seat (Without driving position memory system) Driver's seat (With driving position memory system) Passenger's seat
5. Detach the harness clips (D), and remove the harness clamps (E).
6. Remove the back panel (A). 1. Remove the screws. 2. Release the hooks (B) by pulling back the bottom of the back panel. 3. Gently pull down the back panel to release the hooks (C) from the seat-back frame.
7. Pull the side airbag harness (A), and the recline motor harness (B) out through the loop (C). Pull the seat-back heater harness (D) out through the loop (E) (driver's seat). Release the hooks (F), then detach the clips. Release the hook strip (G), and pull back the bottom of the seat-back cover (H), then pull the harnesses out through the harness holes (I). Driver's seat Passenger's seat
8. Release the hook strips (A), then loosen the seat-back cover (B).
9. Remove the nut, then release the bracket (A) of airbag attachment wire C from the seat-back frame (B).
10. Release airbag attachment wire A and airbag attachment wire B from the seat-back frame (C).
11. Passenger's seat: Remove the ODS unit cover (A). 1. Turn over the seat-back cover (B) and the pad (C) as needed. 2. Release the cover from the lower hooks (D). 3. Pull the cover upward to release it from the upper hook (E).
12. Passenger's seat: Disconnect the ODS unit harness connector (F) and the ODS sensor connectors (G).
13. Passenger's seat: Detach the harness clips (A) fastening the OPDS sensor harnesses (B), and release the wire tie (C).
14. Passenger's seat: Detach the harness clip (A). Pull the ODS unit harness (B) in through a hole in the seat frame, and pull it out through the harness hole (C) in the seat-back cover (D).
15. Pinch the tabs on the ends of the head restraint guides (A), and remove them from the seat-back.
16. Remove the seat-back cover/pad (A) from the seat-back frame (B).
17. Pull back the edge of the seat-back cover all the way around, and release the upholstery rings (A), then remove the seat-back cover (B).
18. Remove airbag attachment wire B from the outside reinforcing cloths (D). Pull airbag attachment wire A out through the loops (E) of the inside reinforcing cloths (F) and through loop (G) of airbag attachment wire C. Remove airbag attachment wires A and C.
19. Install the seat-back cover in the reverse order of removal, and note these items: To prevent wrinkles when installing the seat-back cover, make sure the material is stretched evenly over the pad before securing the upholstery rings, the hooks, and the hook strips. Before installing the seat-back cover, make sure airbag attachment wires A, B, and C are installed in the reinforcing cloths (D) correctly, and that wire A and wire C are securely assembled. Reinstall airbag attachment wires A, B, and the bracket (E) of airbag attachment wire C to the seat-back frame as shown. Replace all of the upholstery rings (F) fastening the seat-back cover (G) to the pad wires (H) with new ones using commercially available upholstery ring pliers (I). Use only original Acura replacement seat-back covers. Make sure the side airbag harness and the seat wire harness are routed properly.

Scheme 265

Front Seat Recline Cover Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The driver's seat is shown; the passenger's seat is similar.

Scheme 266

Scheme 267

Scheme 268

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove the screw, and release the hook (A), the tabs (B), and the pin (C), then remove the front cover (D).
3. Remove the recline cover (A). 1. Remove the screw, and detach the clip. 2. Release the tabs (B). 3. Pull up the cover, then release the hook (C) and the tab (D). 4. Disconnect the power seat adjustment switch connector (E). 5. If necessary, release the tabs (F), then remove the upper recline inner cover (G) from the recline cover.
4. Remove the center cover (A). 1. Remove the screw. 2. Release the tabs (B). 3. Pull up the cover, then release the tab (C). 4. Release the tabs (D), then remove the upper recline inner cover (E) from the center cover.
5. Install the recline cover in the reverse order of removal, and push the clips, the hooks, and the tabs into place securely.

Front Seat Cushion Cover Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers. Passenger's seat: Do not touch the OPDS sensor in the seat-back pad, and keep it away from oil. Oil can corrode the sensor causing it to fail. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The driver's seat is shown; the passenger's seat is similar.

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ).
2. Remove the front seat recline cover (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-recline-cover-removalinstallation) ).
3. From under the seat cushion, release the hooks on the elastic strap (A) for the seat cushion frame springs (B), then pull out the back panel undercover (C).
4. From under the seat cushion, disconnect and/or detach the connectors: Driver's seat: Side airbag connector (A) Recline motor harness connector (B) Seat-back heater connector (C) Seat cushion heater connector (D) Passenger's seat: Side airbag connector (A) Recline motor harness connector (B) Seat cushion heater connector (D) Driver's seat (Without driving position memory system) Driver's seat (With driving position memory system) Passenger's seat
5. Detach the harness clips (E), and remove the harness clamps (F).
6. Passenger's seat: Remove the back panel (A). 1. Remove the screws. 2. Release the hooks (B) by pulling back the bottom of the back panel. 3. Gently pull down the back panel to release the hooks (C) from the seat-back frame.
7. Passenger's seat: Release the hooks (A), then detach the clips from under the seat-back cover (B). Release the hook strips (C), then pull the bottom of the seat-back cover back.
8. Passenger's seat: Remove the ODS unit cover (A). 1. Turn over the seat-back cover (B) and the pad (C) as needed. 2. Release the cover from the lower hooks (D). 3. Pull the cover upward to release it from the upper hook (E).
9. Passenger's seat: Disconnect the ODS unit harness connector (F).
10. Passenger's seat: Detach the harness clip (A), then pull the ODS unit harness (B) in through a hole in the seat frame, and pull it out through the harness hole (C) in the seat-back cover (D).
11. Pull the side airbag harness (A) and the recline motor harness (B) on either of the seats, the seat-back heater harness (C) on the driver's seat, and the ODS unit harness (D) on the passenger's seat out through the loops (E). Driver's seat Passenger's seat
12. Release the hook strips (A) from both sides of the seat cushion frame.
13. With driving position memory system: Disconnect the power seat control unit connectors (A), and remove the screws, then remove the power seat control unit (B).
14. Release the hook strips (A) from under the seat cushion.
15. Remove the seat cushion cover/pad (A) from the seat frame (B).
16. Release the upholstery rings (A) fastening the seat cushion cover (B) and the undercover (C) on the seat cushion pad.
17. Pull back the edge of the seat cushion cover all the way around, and release the upholstery rings (A), then remove the seat cushion cover (B).
18. Install the cover in the reverse order of removal, and note these items: To prevent wrinkles when installing the seat cushion cover, make sure the material is stretched evenly over the pad before securing the upholstery rings and hook strips. Replace all of the upholstery rings (A) fastening the seat cushion cover (B) to the pad wire (C) with new ones using commercially available upholstery ring pliers (D). If the clips are damaged or stress-whitened, replace them with new ones.

Seat-Back

Note. Take care not to scratch the body or tear the seat covers.

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

1. Remove the right seat-back (A). 1. Fold down the right seat-back. 2. Release the Velcro fasteners (B), and pull back the seat-back cover (C), then remove the bolts. 3. Release the hooks (D) of both pivot brackets (E).
2. Remove the bolt, then remove the center pivot bracket (A).
3. If necessary, remove the bushing (B).
4. Remove the left seat-back (A). 1. Fold down the left seat-back. 2. Pull the center seat belt (B) out through the slit (C) in the seat belt guide (D). 3. Release the Velcro fastener (E), and pull back the seat-back cover (F), then remove the bolt. 4. Release the hooks (G) of the pivot bracket (H).
5. Extend the center seat belt (A) to remove the left seat-back (B), then release the pivot shaft (C) from the center pivot bracket (D).
6. If necessary, remove the bushing (A) from the center pivot bracket (B).
7. If necessary, release the hook (A) and remove the center pivot cover (B) from the center pivot bracket (C).
8. Remove the seat side bolster.
9. Detach the harness clip (A), and remove the bolt, then remove the pivot bracket (B).
10. Install the seat-back in the reverse order of removal, and note these items: If the clip is damaged or stress-whitened, replace it with a new one. Push the clip and the hooks into place securely. Guide the center seat belt over the front of the seat-back as you install the seat-back. Make sure there are no twists or kinks in the center seat belt before attaching the rear seat-back.

Seat Cushion

Note. Take care not to scratch the body or tear the seat covers.

Scheme 293

Scheme 294

1. Fold down both seat-backs.
2. Pull back the front area of the trunk floor (see step 2 on «TRIM REMOVAL/INSTALLATION - TRUNK AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-trunk-area) ).
3. Remove the bolt securing the seat cushion (A) from behind the left seat-back (B).
4. Raise both seat-backs.
5. While pushing down on the seat cushion (A), pull the seat hook handles (B) to release the hooks (C).
6. Pull back the seat cushion to pull out the seat belt buckles (D) from the holes in the seat cushion. Release the center seat belt (E) and the center seat belt buckle (F) from their slits (G), and remove seat cushion.
7. Install the seat cushion (A) in the reverse order of removal. When installing the seat cushion, first install the seat belt buckles (B) into the holes (C). Slip the center seat belt buckle (D) and the center seat belt (E) through the slits (F) in the seat cushion.

Note. Make sure there are no twists or kinks in the seat belts before the seat cushion is installed.

Scheme 295

Seat Side Bolster

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Take care not to scratch the body or tear the seat covers.

Scheme 296

Scheme 297

1. Remove the seat cushion.
2. Remove the bolt securing the seat side bolster (A).
3. Fold down the seat-back.
4. Lift up the seat side bolster (A) to release the hooks (B), then remove the seat side bolster.
5. Install the seat side bolster in the reverse order of removal, and note these items: Guide the belts over the front of the seat side bolster as you install the bolster. Make sure there are no twists or kinks in the seat belts before attaching the seat side bolster.

Note. Take care not to scratch the body or tear the seat covers.

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

1. Remove the right seat-back (A). 1. Fold the right seat-back forward. 2. Release the Velcro fastener (B), and turn over the rear floor mat (C). 3. Release the Velcro fasteners (D), and pull back the seat-back cover (E), then remove the bolts. 4. Release the hooks (F) of both pivot brackets (G).
2. Remove the bolt, then remove the center pivot bracket (A).
3. If necessary, remove the bushing (B).
4. Remove the left seat-back (A). 1. Fold down the left seat-back. 2. Release the Velcro fastener (B), and turn over the rear floor mat (C). 3. Release the Velcro fastener (D), and pull back the seat-back cover (E), then remove the bolt. 4. Release the hooks (F) of the pivot bracket (G).
5. Release the pivot shaft (A) and the bushing (B) together from the center pivot bracket (C), then remove the left seat-back (D).
6. If necessary, remove the bushing (A) from the pivot shaft (B) of the left seat-back (C).
7. Remove the seat side bolster.
8. Detach the harness clip (A), and remove the bolt, then remove the pivot bracket (B).
9. Install the seat-back in the reverse order of removal, and note these items: If the clip is damaged or stress-whitened, replace it with a new one. Push the clip and the hooks into place securely.

Note. Take care not to scratch the body or tear the seat covers.

Scheme 304

Scheme 305

1. Fold down both seat-backs.
2. Release the Velcro fasteners from both seat-backs. Pull back the Velcro fasteners, then attach them on the rear floor mat. Pull back the front area of the rear floor lid, and detach the clips, then turn the front section upside down to release the hooks from both front lid supports (see step 3 on «TRIM REMOVAL/INSTALLATION - CARGO AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-cargo-area) ).
3. Remove the bolt securing the seat cushion (A) from behind the left seat-back (B).
4. Raise both seat-backs.
5. While pushing down on the seat cushion (A), pull the seat hook handles (B) to release the hooks (C).
6. Pull back the seat cushion to pull out the seat belt buckles (D) from the holes in the seat cushion. Release the center seat belt buckle (E) and the center seat belt detachable anchor (F) from their slits (G), and remove it.
7. Install the seat cushion (A) in the reverse order of removal. When installing the seat cushion, first install the seat belt buckles (B) into the holes (C). Slip the center seat belt buckle (D) and the center seat belt detachable anchor (E) through the slits (F) in the seat cushion.

Scheme 306

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Take care not to scratch the body or tear the seat covers.

Scheme 307

Scheme 308

Scheme 309

1. Remove the seat cushion.
2. Remove the rear seat belt lower anchor from the body (see step 2 on «REAR SEAT BELT REPLACEMENT - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl) ).
3. Detach the clips and release the hook (A), then remove the seat belt side cover (B). Slip the rear seat belt (C) out through the slit (D) in the cover.
4. Remove the bolt securing the seat side bolster (A).
5. Fold down the seat-back.
6. Remove the seat side bolster (A). 1. Lift the seat side bolster up to release the hooks (B). 2. Pass the rear seat belt (C) entirely in through a hole in the seat side bolster.
7. Install the seat side bolster in the reverse order of removal, and note these items: Guide the belts over the front of the seat side bolster as you install the bolster. Make sure there are no twists or kinks in the seat belts before attaching the seat side bolster.

Rear Seat-Back Release Lever Replacement

Note. Take care not to bend or scratch the interior trim. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage. The left seat-back release lever is shown; the right seat-back release lever is similar.

Scheme 310

Scheme 311

1. From the trunk compartment, detach the clips, and release the hook (A), then remove the seat-back release lever (B). NOTE: To release the clips, pry up on the center pin at the notch (C).
2. Disconnect the rear seat-back release cable (A). NOTE: Take care not to kink the cable.
3. Install the release lever in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the rear seat-back release cable is connected securely. Push the clips and the hook into place securely. Make sure the seat-back locks securely and unlocks properly.

Rear Seat-Back Latch/Release Cable Removal/Installation

Note. Take care not to bend or scratch the interior trim. The left rear seat-back latch/release cable is shown; the right rear seat-back latch/release cable is similar.

Scheme 312

Scheme 313

Scheme 314

1. Remove the rear seat-back release lever (see «REAR SEAT-BACK RELEASE LEVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__rear-seat-back-release-lever-replacement) ).
2. From the trunk compartment, detach the cable clip fastening the seat-back release cable (A).
3. Remove the rear bulkhead cover (see «TRIM REMOVAL/INSTALLATION - REAR SHELF AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-rear-shelf-area) ).
4. Detach the cable fastener (A) and disconnect the seat-back release cable (B) from the seat-back latch (C). Detach the cable clip fastening the seat-back release cable on the trunk lid key cylinder bracket (D).
5. Remove the bolts, then remove the latch (A).
6. Install the latch/release cable in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the release cable is connected securely. Push the clips into place securely. Make sure the seat-back locks securely and unlocks properly.

Rear Seat-Back Latch Removal/Installation

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers.

Scheme 315

Scheme 316

Scheme 317

1. Remove the rear seat-back (see «REAR SEAT REMOVAL/INSTALLATION - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ).
2. Remove the seat-back cover/pad from the seat-back frame (see «REAR SEAT-BACK COVER REPLACEMENT - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__rear-seat-back-cover-replacement-sport) ).
3. Remove the bolts (A, B). Left rear seat-back Right rear seat-back
4. Left rear seat-back: Remove the seat-back latch patch (C) from the seat-back frame (D).
5. Release the pivot pins (A) of the latch knob (B) from the seat-back frame (C). NOTE: The left rear seat-back is shown; the right rear seat-back is similar.
6. Remove the seat-back latch (A) from the seat-back frame (B). NOTE: The left rear seat-back is shown; the right rear seat-back is similar.
7. Install the latch in the reverse order of removal, and make sure the seat-back locks securely and unlocks properly.

Rear Seat Armrest Replacement

Note. Take care not to tear or damage the seat covers.

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

1. Fold down the left seat-back.
2. Unzip the left seat-back cover (A), then pull back the seat-back cover/pad (B) as needed. Remove the armrest mounting bolt from the armrest pivot shaft.
3. Raise the left seat-back.
4. Remove the clip (A) from the armrest pivot shaft (B).
5. Slide the armrest (A) toward the driver's side, and remove the pivot shaft (B) from the collar (C).
6. Remove the pivot shaft (A) from the collar (B), then remove the armrest (C).
7. Remove the collars (A) from the seat-back (B).
8. Install the armrest in the reverse order of removal, and apply medium strength liquid thread lock to the armrest mounting bolt before reinstallation.

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers. The left rear seat-back is shown; the right rear seat-back is similar.

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

1. Remove the seat-back (see «REAR SEAT REMOVAL/INSTALLATION - SEDAN»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ).
2. Remove these items: All of the head restraints Rear seat armrest (see «REAR SEAT ARMREST REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__rear-seat-armrest-replacement) )
3. Left seat-back: Remove the screw, then remove the center belt guide (A).
4. Left seat-back: Pull out the center area of the armrest back panel (A) to release the upper edge of the armrest back panel.
5. Left seat-back: Pull out the armrest back panel (A) to release the hook (B) on the seat-back frame and the hook strip (C) on the seat-back cover.
6. Release the lower hook strip (A), and unzip the seat-back cover (B).
7. Pull out the seat-back frame (A) from the seat-back cover/pad (B), then remove the head restraint guides (C) and the center head restraint guides (D) while pinching the end of the guides.
8. Remove the seat-back cover/pad from the seat-back frame.
9. Pull back the edge of the seat-back cover (A) all the way around, and release the upholstery rings (B), then remove the seat-back cover.
10. Install the cover in the reverse order of removal, and note these items: To prevent wrinkles when installing a seat-back cover, make sure the material is stretched evenly over the pad before securing the upholstery rings and the hook strips. Replace all of the upholstery rings (A) fastening the seat-back cover (B) to the pad wires (C) with new ones using commercially available upholstery ring pliers (D).

Scheme 329

Rear Seat-Back Cover Replacement - Sport Wagon

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to tear the seams or damage the seat covers. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The left rear seat-back is shown; the right rear seat-back is similar.

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

1. Remove the seat-back (see «REAR SEAT REMOVAL/INSTALLATION - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ).
2. Remove these items: All of the head restraints Rear seat armrest (see «REAR SEAT ARMREST REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__rear-seat-armrest-replacement) )
3. Remove the screw, and detach the clip by pulling up the lower edge of the latch knob trim (A), then remove the trim while pulling off the hooks (B) from the holes (C) in the seat-back cover.
4. Left seat-back: Pull out the center area of the armrest back panel (A) to release the upper edge of the armrest back panel.
5. Left seat-back: Pull out the armrest back panel (A) to release the hook (B) on the seat-back frame and the hook strip (C) on the seat-back cover.
6. Release the hooks (A), then remove the tether anchor cover (B).
7. Release the lower hook strip (A), and unzip the seat-back cover (B).
8. Pull the cover (C) out the tether anchor hole.
9. Pull back the seat-back cover (A), and remove the clips.
10. Pull out the seat-back frame (A) from the seat-back cover/pad (B), then remove the head restraint guides (C) and the center head restraint guides (D) while pinching the end of the guides.
11. Remove the seat-back cover/pad from the seat-back frame.
12. Pull back the edge of the seat-back cover (A) all the way around, and release the upholstery rings (B), then remove the seat-back cover.
13. Install the cover in the reverse order of removal, and note these items: To prevent wrinkles when installing a seat-back cover, make sure the material is stretched evenly over the pad before securing the upholstery rings and the hook strips. Replace all of the upholstery rings (A) fastening the seat-back cover (B) to the pad wires (C) with new ones using commercially available upholstery ring pliers (D).

Rear Seat Cushion Cover Replacement

Note. Put on gloves to protect your hands. Take care not to tear or damage the seat covers.

Scheme 338

Scheme 339

Scheme 340

1. Remove the seat cushion: Sedan (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-cushion) ) Sport Wagon (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) )
2. From under the seat cushion, release all the upholstery rings (A), and fold back the seat cushion cover (B).
3. Pull back the edge of the seat cushion cover (A) all the way around, and release the upholstery rings (B), then remove the seat cushion cover.
4. Install the cover in the reverse order of removal, and note these items: To prevent wrinkles when installing a seat cushion cover, make sure the material is stretched evenly over the pad before securing the upholstery rings. Replace all of the upholstery rings (A) fastening the seat cushion cover (B) to the pad wires (C) with new ones using commercially available upholstery ring pliers (D).

See also:
• COMPONENT LOCATION INDEX
• ODS UNIT INITIALIZATION
• BATTERY TERMINAL DISCONNECTION AND RECONNECTION
• BATTERY REMOVAL AND INSTALLATION
• DRIVER'S SEAT POSITION SENSOR OPERATION CHECK
• FRONT SEAT BELT BUCKLE
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• SIDE AIRBAG REPLACEMENT
• FRONT PASSENGER'S WEIGHT SENSOR OUTPUT CHECK AFTER A VEHICLE COLLISION
• TRIM REMOVAL/INSTALLATION - TRUNK AREA
• TRIM REMOVAL/INSTALLATION - CARGO AREA
• REAR SEAT BELT REPLACEMENT - SPORT WAGON
• TRIM REMOVAL/INSTALLATION - REAR SHELF AREA
• FRONT SEAT FRAME REPLACEMENT
• PASSENGER'S SEAT
• FRONT SEAT REMOVAL/INSTALLATION
• FRONT SEAT-BACK COVER REPLACEMENT
• FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION
• FRONT SEAT CUSHION COVER REPLACEMENT
• REAR SEAT-BACK RELEASE LEVER REPLACEMENT
• REAR SEAT REMOVAL/INSTALLATION - SPORT WAGON
• REAR SEAT-BACK COVER REPLACEMENT - SPORT WAGON
• REAR SEAT ARMREST REPLACEMENT
• SEAT CUSHION
