Scheme 171
- Remove the cowl cover (see «COWL COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#exterior-trim-4-cyl__cowl-cover-replacement) ).
- Disconnect the brake booster vacuum hose (A) from the strut brace (B).
- Remove the nuts from the top of the damper, and remove the strut brace.
- Install the strut brace in the reverse order of removal.
Rear Wheelhouse Gusset Replacement
Note. Put on gloves to protect your hands. Take care not to scratch the body or the related parts. Sedan is shown; Sport Wagon is similar. The left side is shown; the right side is similar.
Scheme 172
- Remove these items: Rear seat-back Sedan (see «REAR SEAT REMOVAL/INSTALLATION - SEDAN»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Sport Wagon (see «REAR SEAT REMOVAL/INSTALLATION - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Rear seat side bolster Sedan (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-side-bolster) ) Sport Wagon (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Rear wheelhouse insulator Sedan (see «REAR WHEELHOUSE INSULATOR»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl) ) Sport Wagon (see «REAR WHEELHOUSE INSULATOR»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-wheelhouse-insulator) )
- Detach the wire harness clips (A), and remove the mounting bolts (B), then remove the rear wheelhouse gusset (C).
- Install the gusset in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.
Rear Panel Gusset Replacement
Note. Put on gloves to protect your hands. Take care not to scratch the body or the related parts. The left side is shown; the right side is similar.
Scheme 173
- Remove these items: Cargo area side trim panel (see «CARGO AREA SIDE TRIM PANEL»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__cargo-area-side-trim-panel) ) Rear lid support (see step 10 on «CARGO AREA SIDE TRIM PANEL»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__cargo-area-side-trim-panel) )
- Detach the wire harness clips (A), and remove the bolts (B), then remove the rear panel gusset (C).
- Install the gusset in the reverse order of removal.
Subframe Replacement
Special Tools Required
Subframe Alignment Pin 070AG-SJAA10S
Front Subframe Torque
After removing the front subframe mounting bolts, the front subframe middle rubber mount mounting bolts, the front subframe rear stiffener mounting bolts, the rear engine mounting base bracket mounting bolts, and the rear engine mounting upper base bracket mounting bolt, be sure to replace them with new ones.
Scheme 174
Front Subframe Alignment
Note. Align the front subframe alignment with the subframe alignment pin.
Scheme 175
- Align the front subframe (A) in the following sequence. 1. Lift the front subframe up to the body, and loosely install the new subframe mounting bolts (B), the front stiffener mounting bolts (C), the new rear stiffener mounting bolts (D) and the stiffeners (E). 2. Loosely install the new subframe middle mounting bolts (F, G) securing the subframe middle mounts (H). 3. Insert the subframe alignment pin (I) through the positioning slot (J) on the right rear stiffener, through the positioning hole (K) on the subframe, and into the positioning hole (L) on the body, then loosely tighten the subframe right rear mounting bolt. 4. Insert the subframe alignment pin through the positioning slot on the left rear stiffener, through the positioning hole on the subframe, and into the positioning hole on the body, then loosely tighten the subframe left rear mounting bolt. 5. Tighten the subframe mounting bolts to the specified torque values starting with the right rear subframe mounting bolt. Use the subframe alignment pin when tightening the rear side subframe mounting bolts. 6. Check all of the subframe mounting bolts, and retighten if necessary. NOTE: Tighten the bolts in the sequence shown.
- Tighten the bolts securing the subframe middle mounts to the specified torque.
- After reinstalling all removed parts, check and adjust the front wheel alignment (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__wheel-alignment) ).
Rear Subframe Torque
Note. Install the rear subframe by aligning the installation positioning holes and positioning holes with the subframe alignment pin. Always replace any removed subframe mounting bolts with new ones.
