Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Front Door Panel Removal/Installation

Special Tools Required

1. KTC Trim Tool Set SOJATP2014*
2. Trim Pad Remover, Snap-on A 177A or equivalent, commercially available

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the door or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

1. Remove the tweeter cover (see «POWER MIRROR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-4-cyl__power-mirror-replacement) ).
2. Push on the upper hook (A) with the appropriate trim tool, then pull back the inner handle cap (B) to remove it.
3. Remove the screws securing the inner handle (A).
4. Remove the front seat memory switch panel (A). 1. Insert the appropriate trim tool into the notch (B), and pry up on the lower edge of the panel to detach the clip. 2. Pull out along the edge of the panel to release the hooks (C). 3. Driver's side with front seat memory switch: Disconnect the front seat memory switch connector (D).
5. Remove the screw.
6. Release the hooks (A), and remove the pull pocket cap (B), then remove the screw.
7. Remove the power window switch panel (A). 1. Pry up at the notch (B), then release the hook (C). 2. Pull out along the edge of the panel to release all of the hooks (D). 3. Detach the clip. 4. Disconnect the power window switch connector (E).
8. Remove the screw.
9. Remove the door panel (A) with as little bending as possible to avoid creasing or breaking it. 1 Start at the bottom edge of the door panel, detach the clips (B) that are just above the marks (C) on the edge of the door panel with a commercially available trim pad remover, and detach the clip (D). 2. Detach the remaining clips (E, F, G). 3. Starting at the rear, pull the door panel upward. NOTE: The inner handle cable (H) and the latch cable (I) are connected to the inner handle (J). Do not pull the door panel up too far, or these cables will be damaged.
10. While holding the door panel (A) away from the door, remove the inner handle (B). 1. Detach the clips by pulling out the handle. 2. Slide the handle to release the projections (C) of the handle from the grooves (D) in the door panel.
11. While holding the door panel (A) away from the door, disconnect each connector. 1. Disconnect the courtesy light subharness connector (B). 2. Driver's door: Disconnect the door subharness connector (C). 3. Driver's door (Sedan): Disconnect the trunk lid opener switch connector (D). 4. Driver's door (Sport Wagon): Disconnect the power tailgate switch connector (E). 5. Driver's door: Detach the harness clips (F). Inner Handle Removal
12. Remove the inner handle (A). 1. Release the inner handle cable fasteners (B, C), then disconnect the inner handle cable (D). 2. Release the latch cable fastener (E), and remove the latch cable fastener (F), from the inner handle by pinching is tabs together. Then disconnect the latch cable (G). NOTE: If the cable fasteners are damaged or stress-whitened, replace them with new ones. Door End Trim Removal
13. Detach the clips (A, B), then remove the door end trim (C). NOTE: If the clips are damaged or stress-whitened, replace them with new ones. Armrest Removal
14. Remove the screws (A), and loosen the screws (B) from back of the door panel. Release the hooks (C), then remove the armrest assembly (D).
15. Remove the screw, then remove the grip bracket B. Release the hook (A), then remove the front door pull pocket (C) from the armrest (D). Grip Cover Removal
16. Remove the grip cover (B) from the door panel (C). 1. Remove the screws from the back of the door panel, then remove the grip bracket A. 2. Remove the screws securing the grip cover from the back of the door panel. 3. Driver's door: Disconnect the front door subharness connector (D), and release the front door subharness (E) from the harness holder (F). 4. Release the hooks (G).
17. Remove the screw, and release the tabs (A), then remove the grip base (B) from the grip cover (C).
18. Driver's door: Release the tabs (A), then remove the power mirror switch bracket (B) by releasing it from the projections (C) of the grip cover (D).
19. Install the door panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Replace any damaged cable fasteners with new ones. Check the end of the inner handle cable for damage, and replace the cable if needed. The latch cable (A) should be fixed to the cable fastener (B) with the latch in the unlocked position as shown. Make sure each connector is plugged in properly, and each cable is connected securely. Make sure the power window and power door lock operate properly. When reinstalling the door panel, make sure the plastic cover on the door is installed properly. Push the clips and the hooks into place securely. Passenger's side: Do the power window control unit reset procedure (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-4-cyl__resetting-the-power-window-control-unit) ).

Scheme 254

Front Door Outer Handle Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the door.

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

1. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ) Door end trim (see «FRONT DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-outer-handle-replacement) )
2. Raise the glass fully.
3. Remove the plastic cover (A) as needed. 1. Disconnect the power door lock actuator connector (B). 2. Remove the rear plug cap (C). NOTE: If the plastic cover is damaged or torn, replace it with a new one.
4. Driver's door: Pull both side flanges (A) of the retainer (B) outward, and pull out the middle flange area (C) of the outer casing cover (D), then disconnect the lock cylinder cable (E) from the latch.
5. Remove the plug cap (A).
6. While holding the outer handle cover (A) from outside of the door, loosen the bolt (driver's door) until it can be pulled out half-way by hand, or remove the bolt (passenger's door), release the hooks (B) of the outer handle cover, then remove the cover. Driver's door Passenger's door
7. Release the hooks (A), then remove the lock cylinder (B) (driver's door) or the outer handle holder (C) (passenger's door) from the outer handle base (D). Driver's door Passenger's door
8. Driver's door: If the retainer (A) of the lock cylinder cable (B) is damaged, release the hooks (C), then replace it with a new one.
9. Pull back the outer handle (A) out as shown to remove it from the door.
10. Release the hooks (A, B), then remove the outer handle front seal (C) and the outer handle rear seal (D).
11. Remove the outer handle base (A). 1. Release the rod fastener (B). 2. Disconnect the outer handle rod (C) with a clip remover. 3. Loosen the nut. 4. Release the hook (D), and slide the base forward to release the special bolt (E) from the door.
12. Remove the rod fastener (A) from the outer handle base (B), then replace it with a new one.
13. Install the handle in the reverse order of removal, and note these items: Reinstall the lock cylinder (driver's door) or the outer handle holder (passenger's door) before installing the outer handle cover. Make sure the connector is plugged in properly, and the cable and the rod are connected securely. Make sure the door key cylinder/door lock and the door handle operate properly. When reinstalling the door panel, make sure the plastic cover on the door is installed properly. Push the clips and the hooks into place securely.

Front Door Latch Replacement

Note. Put on gloves to protect your hands.

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

1. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ) Inner handle (see «FRONT DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-outer-handle-replacement) ) Door end trim (see «FRONT DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-outer-handle-replacement) )
2. Raise the glass fully.
3. Remove the plastic cover as needed (see «FRONT DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-outer-handle-replacement) ).
4. Driver's door: Disconnect the lock cylinder cable from the latch (see «FRONT DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-outer-handle-replacement) ).
5. Disconnect the outer handle rod from the outer handle base (see «FRONT DOOR LATCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-latch-replacement) ).
6. Pull the glass run channel (A) away as needed, and remove the bolt, then remove the center lower channel (B) by pulling it downward.
7. Remove the screws (A, B) securing the latch (C), then remove the latch through the hole in the door. NOTE: Take care not to bend the outer handle rod (D), the latch cable (E), or the inner handle cable (F).
8. Remove the foam seals (A, B, C) from the latch protector (D) and the latch (E).
9. Remove the screw, then remove the latch protector (A) from the latch (B).
10. Disconnect the latch cable (A) and the inner handle cable (B) from the latch (C).
11. Install the latch in the reverse order of removal, and note these items: Before reinstalling the latch protector, clean the latch and latch protector surfaces with isopropyl alcohol where the new foam seals will be attached. After reinstalling the latch protector to the latch, attach the new foam seals to the protector and the latch. If the clips are damaged or stress-whitened, replace them with new ones. Make sure the connector is plugged in properly and each rod is connected securely. Make sure the door lock operates properly. When reinstalling the door panel, make sure the plastic cover on the door is installed properly. Push the clips into place securely.

Front Door Glass and Regulator Replacement

Note. Put on gloves to protect your hands.

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

1. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ).
2. Raise the glass fully.
3. Remove the screws, then remove the door panel bracket (A).
4. Remove the plastic cover (A). 1. Disconnect the power door lock actuator connector (B). 2. Disconnect the power mirror connector (C), and detach the harness clip (D). 3. Remove the plug caps (E). 4. Pass the wire harnesses (F) through the slits (G) in the plastic cover. NOTE: If the plastic cover is damaged or torn, replace it with a new one.
5. Carefully lower the glass (A) until you can see the bolts, then remove them. Carefully pull out the glass through the window slot. NOTE: Take care not to drop the glass inside the door.
6. Disconnect the connector (A) from the regulator (B).
7. Remove the bolts and the nuts, then remove the regulator through the hole in the door.
8. Apply multipurpose grease to all the sliding surfaces of the regulator (A) where shown.
9. Install the glass and the regulator in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Roll the glass up and down to make sure it moves freely without binding. Make sure that there is no clearance between the glass and the glass run channel when the glass is closed. Make sure the connector is plugged in properly. Adjust the position of the glass as necessary (see «GLASS POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/sun-rooft-topconvertible-top/#moonroof-4-cyl__glass-position-adjustment) ). Do the power window control unit reset procedure (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/tsx/ii-2008-2014/remont/windows/#power-windows-4-cyl__resetting-the-power-window-control-unit) ). Make sure the power door locks, the power windows, and the power mirror operate properly. Make sure the plastic cover on the door is installed properly and sealed around its outside perimeter to seal out water. Push the clips into place securely. Check for water leaks (see «DOOR POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__door-position-adjustment) ). Test-drive the vehicle, and check for wind noise and rattles.

Front Door Sash Inner Trim Replacement

Note. Take care not to scratch the door.

Scheme 277

1. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ).
2. Remove the front door sash inner trim (A). 1. Pull back along the outside edge of the trim to release the hooks (B) from the door glass opening flange at the B-pillar area of the door sash. 2. Release the hook (C) from the glass run channel (D) at the rear corner area of the door sash. 3. Pull back along the outside edge of the trim to release the hooks (E) from the door glass opening flange at the roof area and the A-pillar area of the door sash.
3. Hold the trim up, and align the corner area of the trim with the rear corner area of the door sash, then set the hook of the trim to the glass run channel. Set the hooks of the trim along the trim at the B-pillar area, the roof area, and the A-pillar area of the door sash.

Front Door Sash Outer Trim Replacement

Note. Take care not to scratch the door. Take care not to damage the rear hook in the weatherstrip because it is not available separately.

Scheme 278

1. Remove the door outer molding (see «FRONT DOOR OUTER MOLDING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-outer-molding-replacement) ).
2. Pull up the door sash outer trim (A) to release the hooks (B) from the door, and release the trim from between the door glass outer weatherstrip (C) and the door, then remove the trim.
3. Install the trim in the reverse order of removal.

Front Door Glass Outer Weatherstrip Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the rear hook in the weatherstrip because it is not available separately.

Scheme 279

Scheme 280

1. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ) Door panel bracket (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-glass-and-regulator-replacement) ) Plastic cover, as needed (see «FRONT DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-outer-handle-replacement) ) Power mirror (see «POWER MIRROR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-4-cyl__power-mirror-replacement) )
2. From the inside of the door, slide the clips (A) on the door glass outer weatherstrip (B) to release the hooks (C) from the flanges (D) on the door.
3. Push the rear hook (A) with a flat-tip screwdriver from inside of the door, and pull up the door glass outer weatherstrip (B), then remove the weatherstrip.
4. Before installing the weatherstrip, slide the clips to the released position as in step 2 .
5. Install the weatherstrip, and slide the clips securely on to the flanges.
6. Reinstall all removed parts, and note these items: When reinstalling the door panel, make sure the plastic cover on the door is installed properly and sealed around its outside perimeter to seal out water. Check for water leaks (see step 9 on page 20-57).

Front Door Outer Molding Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. If you remove the door outer molding, replace it with a new one because it will bend during removal. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the rear upper corner hook or the rear upper corner clip (black) because they are not available separately. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 281

Scheme 282

1. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ) Power mirror (see «POWER MIRROR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-4-cyl__power-mirror-replacement) )
2. Detach the clip with a clip remover, then pull back the door weatherstrip (A), and remove the screw securing the door outer molding (B).
3. Pull out the upper edge of the molding (A) from the edge of the sash, and cut the double-sided adhesive tape (B) with a utility knife, then remove the molding from the sash.
4. Scrape off the remaining double-sided adhesive tape from the sash, then clean the sash surface with a shop towel dampened with isopropyl alcohol.
5. Install the molding in the reverse order of removal, and note these items: Push the adhesive areas into place securely. Make sure the upper and lower sides of the molding are catching the edges of the sash properly. Push the clip into place securely.

Front Door Weatherstrip Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the front upper corner hook or the rear upper corner clip (black) because they are not available separately. Use a clip remover to remove the clips.

Scheme 283

1. Remove the door weatherstrip (A). 1. Remove the door checker mounting bolt (B) at the A-pillar. 2. Detach the clips (C, D, E) and release the hook (F). 3. Release the door weatherstrip from the holder (G) on the door sash, then remove the weatherstrip. Fastener Locations
2. Install the weatherstrip in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely. Make sure the weatherstrip is installed in the holder securely. Apply medium strength liquid thread lock to the door checker mounting bolt before installation. Check for water leaks (see «DOOR POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__door-position-adjustment) ).

Rear Door Panel Removal/Installation

Special Tools Required

1. KTC Trim Tool Set SOJATP2014*
2. Trim Pad Remover, Snap-on A 177A or equivalent, commercially available

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the door or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Sedan is shown; Sport Wagon is similar.

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

1. Lower the glass fully.
2. Push on the upper hook (A) with the appropriate trim tool, then pull back the inner handle cap (B) to remove it.
3. Remove the screws (A, B) securing the inner handle (C).
4. Release the hooks (A), and remove the pull pocket cap (B), then remove the screw.
5. Remove the power window switch panel (A). 1. Pry up at the notch (B), then release the hook (C). 2. Pull out along the edge of the panel to release all of the hooks (D). 3. Detach the clip. 4. Disconnect the power window switch connector (E).
6. Remove the screw.
7. Remove the door panel (A) with as little bending as possible to avoid creasing or breaking it. 1. Start at the bottom edge of the door panel, release the clips that are just above the marks (B) on the edge of the door panel with a commercially available trim pad remover. 2. Detach the remaining clips. 3. Starting at the rear, pull the door panel upward. NOTE: The inner handle cable (C) and the latch cable (D) are connected to the inner handle (E). Do not pull the door panel up too far, or these cables will be damaged.
8. While holding the door panel (A) away from the door, remove the inner handle (B). 1. Detach the clips, and release the hook (C) by pulling out the handle. 2. Slide the handle to release the projections (D) of the handle from the grooves (E) in the door panel.
9. While holding the door panel (A) away from the door, disconnect the courtesy light bulb socket (B). NOTE: If you are only removing the door panel, go to step 16 . If you are doing further disassembly of the door panel, continue to step 10. Inner Handle Removal
10. Remove the inner handle (A). 1. Release the inner handle cable fasteners (B, C), the disconnect the inner handle cable (D). 2. Release the latch cable fastener (E), and remove the latch cable fastener (F), from the inner handle by pinching is tabs together. Then disconnect the latch cable (G). NOTE: If the cable fasteners are damaged or stress-whitened, replace them with new ones. Door End Trim Removal
11. Detach the harness clip (A) and the clips (B, C, D), then remove the door end trim (E). NOTE: If the clips are damaged or stress-whitened, replace them with new ones. Armrest Removal
12. Remove the screws (A), and loosen the screws (B) from back of the door panel (C). Release the hooks (D), then remove the armrest assembly (E).
13. Remove the screw, then remove the grip bracket B. Release the hook (A), then remove the door pull pocket (C) from the armrest (D). Grip Cover Removal
14. Remove the grip cover (B) from the door panel (C). 1. Remove the screws from the back of the door panel, then remove the grip bracket A. 2. Remove the screws securing the grip cover from the back of the door panel. 3. Release the hook (D).
15. Remove the screw, and release the tabs (A), then remove the grip base (B) from the grip cover (C).
16. Install the door panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Replace any damaged cable fasteners with new ones. Check the end of the inner handle cable for damage, and replace the cable if needed. The latch cable (A) should be fixed to the cable fastener (B) with the latch in the unlocked position as shown. Make sure the connector is plugged in properly, and each cable is connected securely. Make sure the power window and power door lock operate properly. When reinstalling the door panel, make sure the plastic cover on the door is installed properly. Push the clips and the hooks into place securely.

Scheme 298

Rear Door Outer Handle Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the door. Sedan is shown; Sport Wagon is similar.

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door end trim (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) )
2. Raise the glass fully.
3. Remove the plastic cover (A) as needed. 1. Disconnect the power door lock actuator connector (B). 2. Remove the rear plug cap (C). NOTE: If the plastic cover is damaged or torn, replace it with a new one.
4. Remove the door pad (see «REAR DOOR PAD REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-pad-replacement) ).
5. Remove the plug cap (A).
6. While holding the outer handle cover (A), remove the bolt and release the hooks (B), then remove the cover.
7. Release the hooks (A), then remove the outer handle holder (B) from the outer handle base (C).
8. Pull back the outer handle (A) out as shown to remove it from the door.
9. Release the hooks (A, B), then remove the outer handle front seal (C) and the outer handle rear seal (D).
10. Remove the outer handle base (A). 1. Release the rod fastener (B). 2. Disconnect the outer handle rod (C) with a clip remover. 3. Loosen the nut. 4. Release the hook (D), and slide the base forward to release the special bolt (E) from the door.
11. Remove the rod fastener (A) from the outer handle base (B), then replace it with a new one.
12. Install the handle in the reverse order of removal, and note these items: Reinstall the outer handle holder before installing the outer handle cover. Make sure the connector is plugged in properly, and the outer handle rod is connected securely. Make sure the door lock and the door handle operate properly. When reinstalling the door panel, make sure the plastic cover on the door is installed properly. Push the hooks into place securely.

Rear Door Latch Replacement

Note. Put on gloves to protect your hands. Sedan is shown; Sport Wagon is similar.

Scheme 307

Scheme 308

Scheme 309

Scheme 310

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Inner handle (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) ) Door end trim (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) )
2. Raise the glass fully.
3. Remove the plastic cover as needed (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) ).
4. Sedan: Remove the door pad (see «REAR DOOR PAD REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-pad-replacement) ).
5. Disconnect the outer handle rod from the outer handle base (see «REAR DOOR LATCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-latch-replacement) ).
6. Remove the screws (A, B) securing the latch (C), then remove latch through the hole in the door. NOTE: Take care not to bend the outer handle rod (D), the latch cable (E), or the inner handle cable (F).
7. Remove the foam seals (A, B) from the latch protector (C) and the latch (D).
8. Remove the screw, then remove the latch protector (A) from the latch (B).
9. Disconnect the latch cable (A) and the inner handle cable (B) from the latch (C).
10. Install the latch in the reverse order of removal, and note these items: Before reinstalling the latch protector, clean the latch and the latch protector surfaces with isopropyl alcohol where the new foam seals will be attached. After reinstalling the latch protector to the latch, attach the new foam seals to the protector and the latch. If the clips are damaged or stress-whitened, replace them with new ones. Make sure the connector is plugged in properly, and the rod is connected securely. Make sure the door lock operates properly. When reinstalling the door panel, make sure the plastic cover on the door is installed properly. Push the clips into place securely.

Rear Door Glass and Regulator Replacement - Sedan

Note. Put on gloves to protect your hands.

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door end trim (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) )
2. Raise the glass fully.
3. Remove the screws, then remove the door panel bracket (A).
4. Remove the plastic cover (A). 1. Disconnect the power door lock actuator connector (B). 2. Detach the harness clips (C). 3. Remove the plug caps (D). 4. Pass the wire harnesses (E) through the slits (F) in the plastic cover. NOTE: If the plastic cover is damaged or torn, replace it with a new one.
5. Remove the door pad (see «REAR DOOR PAD REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-pad-replacement) ).
6. Carefully lower the glass (A) until you can see the bolts, then remove them. Release the glass from the holder (B), then remove the glass from the regulator (C), and carefully lower the glass. NOTE: Take care not to drop the glass inside the door.
7. Remove the bolt (A) from the rear lower channel (B). Pull the door weatherstrip (C) away as needed, and remove the screw (D).
8. Pull the glass run channel (A) away as needed. Pull the rear lower channel (B) forward from the quarter glass seal (C), then release the upper hook (D) from the door. Remove the rear lower channel from the rear door glass (E), then pull the rear lower channel up to remove it.
9. Remove the rear lower channel (A) from the glass run channel (B).
10. Carefully remove the glass (A) out through the window slot. NOTE: Take care not to drop the glass inside the door.
11. Remove the quarter glass (A). NOTE: Take care not to damage the door glass outer weatherstrip (B).
12. Disconnect the connector (A) from the regulator (B).
13. Remove the bolts (C), and loosen the bolt (D). Release the hook (E), then remove the regulator through the hole in the door.
14. Apply multipurpose grease to all the sliding surfaces of the regulator (A) where shown.
15. Install the glass and the regulator in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Roll the glass up and down to make sure it moves freely without binding. Make sure that there is no clearance between the glass and the glass run channel when the glass is closed. Make sure the connector is plugged in properly. Adjust the position of the glass as necessary (see «GLASS POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/sun-rooft-topconvertible-top/#moonroof-4-cyl__glass-position-adjustment) ). Make sure the power door lock, the power window, and the power mirror operate properly. Make sure the plastic cover on the door is installed properly and sealed around its outside perimeter to seal out water. Push the clips into place securely. Check for water leaks (see step 9 on page 20-57). Test-drive the vehicle, and check for wind noise and rattles.

Rear Door Glass and Regulator Replacement - Sport Wagon

Note. Put on gloves to protect your hands.

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door end trim (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) ) Door sash inner trim (see «REAR DOOR SASH INNER TRIM REPLACEMENT - SEDAN»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-sash-inner-trim-replacement) )
2. Raise the glass fully.
3. Remove the screws, then remove the door panel bracket (A).
4. Remove the plastic cover (A). 1. Disconnect the power door lock actuator connector (B). 2. Detach the harness clips (C). 3. Remove the plug caps (D). 4. Pass the wire harnesses (E) through the slits (F) in the plastic cover. NOTE: If the plastic cover is damaged or torn, replace it with a new one.
5. Carefully lower the glass (A) until you can see the bolts, then remove them. Release the glass from the holder (B), then remove the glass from the regulator (C), and carefully lower the glass. NOTE: Take care not to drop the glass inside the door.
6. Remove the bolt (A) from the rear lower channel (B). Pull the glass run channel (C) away as needed, and remove the screw (D).
7. Pull the glass run channel (A) away as needed. Pull the rear lower channel (B) forward and away from the quarter glass molding (C). Remove the rear lower channel from the rear door glass (D), then pull the rear lower channel up to remove it.
8. Remove the rear lower channel (A) from the glass run channel (B).
9. Carefully remove the glass (A) out through the window slot. NOTE: Take care not to drop the glass inside the door.
10. Remove the plug caps (A) and the screws securing the quarter glass (B).
11. With a flat-tip screwdriver wrapped with protective tape, carefully push out the clip (A), pull the top of the quarter glass (B) outward, then remove the glass by pulling it up. NOTE: Take care not to damage the clip and the glass outer weatherstrip (C).
12. Disconnect the connector (A) from the regulator (B).
13. Remove the bolts (C), and loosen the bolt (D). Release the hook (E), then remove the regulator through the hole in the door.
14. Apply multipurpose grease to all the sliding surfaces of the regulator (A) where shown.
15. Install the glass and the regulator in the reverse order of removal, and note these items; If the clips are damaged or stress-whitened, replace them with new ones. Roll the glass up and down to make sure it moves freely without binding. Make sure that there is no clearance between the glass and the glass run channel when the glass is closed. Make sure the connector is plugged in properly. Adjust the position of the glass as necessary (see «GLASS POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/sun-rooft-topconvertible-top/#moonroof-4-cyl__glass-position-adjustment) ). Make sure the power door lock, the power window, and the power mirror operate properly. Make sure the plastic cover on the door is installed properly and sealed around its outside perimeter to seal out water. Push the clips into place securely. Check for water leaks (see «DOOR POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__door-position-adjustment) ). Test-drive the vehicle, and check for wind noise and rattles.

Rear Door Pad Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the door.

Scheme 332

Scheme 333

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Plastic cover, as needed (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) )
2. Detach the clips with a clip remover, then remove the door pad (A) from the door.
3. Pull up the door skin pad (A) to release its hooks (B) from the edge of the pad holder (C), then remove the pad.
4. Install the pad in the reverse order of removal, and note these items: When reinstalling the door panel, make sure the plastic cover on the door is installed properly. Push the clips and the hooks into place securely.

Rear Door Sash Inner Trim Replacement - Sedan

Note. Take care not to scratch the door.

Scheme 334

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door end trim (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) )
2. Remove the rear door sash inner trim (A). 1. Pull back along the outside edge of the trim to release the hooks (B) from the door glass opening flange at the B-pillar area of the door sash. 2. Release the hook (C) from the glass run channel (D) at the front corner of the door sash. 3. Pull back along the outside edge of the trim to release the hooks (E) from the door glass opening flange at the roof area and the quarter glass area of the door sash.
3. Hold the trim up, and align the corner area of the trim with the front corner area of the door sash, then set the hook of the trim to the glass run channel. Set the hooks of the trim along the trim at the B-pillar area, roof area, and the quarter glass area of the door sash.

Rear Door Sash Inner Trim Replacement - Sport Wagon

Note. Take care not to scratch the door.

Scheme 335

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door end trim (see «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-handle-replacement) ).
2. Remove the rear door sash inner trim (A). 1. Pull back along the outside edge of the trim to release the hooks (B) from the door glass opening flange at the B-pillar area of the door sash. 2. Release the hook (C) from the glass run channel (D) at the front corner of the door sash. 3. Pull back along the outside edge of the trim to release the hooks (E) from the door glass opening flange at the roof area and the quarter glass area of the door sash.
3. Hold the trim up, and align the corner area of the trim with the front corner area of the door sash, then set the hook of the trim to the glass run channel. Set the hooks of the trim along the trim at the B-pillar area, roof area, and the quarter glass area of the door sash.

Rear Door Sash Outer Trim Replacement

Note. Take care not to scratch the door.

Scheme 336

1. Remove the door outer molding (see «REAR DOOR OUTER MOLDING REPLACEMENT - SEDAN»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-outer-molding-replacement) ).
2. Pull the door sash outer trim (A) up to release the hooks (B) from the door, then remove the trim.
3. Install the trim in the reverse order of removal.

Rear Door Glass Outer Weatherstrip Replacement - Sedan

Note. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the front hook in the weatherstrip because it is not available separately.

Scheme 337

Scheme 338

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door panel bracket (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT - SEDAN»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-glass-and-regulator-replacement) ) Plastic cover, as needed (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-glass-and-regulator-replacement) ) Door pad and door skin pad (see «REAR DOOR PAD REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-pad-replacement) )
2. From the inside of the door, slide the clips (A) on the door glass outer weatherstrip (B) to release the hooks (C) from the flanges (D) on the door.
3. Push the front hook (A) with a flat-tip screwdriver from inside of the door, then pull up the front area of the weatherstrip (B).
4. Release the weatherstrip from the door outer molding (C) by sliding the weatherstrip forward, then remove the weatherstrip.
5. Set the rear end of the weatherstrip to the molding. Before installing the weatherstrip, slide the clips to the released position as in step 2 .
6. Install the weatherstrip, and slide the clips securely on to the flanges.
7. Reinstall all removed parts, and note these items: When reinstalling the door panel, make sure the plastic cover on the door is installed properly and sealed around its outside perimeter to seal out water. Check for water leaks (see step 9 on page 20-57).

Rear Door Glass Outer Weatherstrip Replacement - Sport Wagon

Note. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the front hook in the weatherstrip because it is not available separately.

Scheme 339

Scheme 340

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door panel bracket (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-glass-and-regulator-replacement) ) Plastic cover, as needed (see step 3 on page 20-35)
2. From the inside of the door, slide the clips (A) on the door glass outer weatherstrip (B) to release the hooks (C) from the flanges (D) on the door panel.
3. Push the front hook (A) with a flat-tip screwdriver, from inside of the door, then pull up the front area of the rear door glass outer weatherstrip (B).
4. Pull up the weatherstrip to detach the rear hook (C), then remove the weatherstrip.
5. Before installing the new weatherstrip, align the clips of the weatherstrip to the flanges where the clips should be engaged by sliding them.
6. Push the clip and hook areas of the rear door glass outer weatherstrip into place securely.
7. Reinstall all removed parts, and note these items: When reinstalling the door panel, make sure the plastic cover is installed properly and sealed around its outside perimeter to seal out water. Check for water leaks (see «DOOR POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__door-position-adjustment) ).

Rear Door Outer Molding Replacement - Sedan

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. If you remove the door outer molding, replace it with a new one because it will bend during removal. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the front upper corner clip (black) and the rear corner clips (black) because they are not available separately. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 341

Scheme 342

1. Remove the door glass outer weatherstrip (see «REAR DOOR GLASS OUTER WEATHERSTRIP REPLACEMENT - SEDAN»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-glass-outer-weatherstrip-replacement) ).
2. Detach the clips (A) with a clip remover, then pull back the door weatherstrip (B), and remove the screws (C, D).
3. Pull out the upper edge of the door outer molding (A) from the edge of the sash, and cut the double-sided adhesive tape (B) with a utility knife, then remove the molding from the sash. Release the bottom hook (C), then remove the molding.
4. Scrape off the remaining double-sided adhesive tape from the sash, then clean the sash surface with a shop towel dampened with isopropyl alcohol.
5. Install the molding in the reverse order of removal, and note these items: The door outer molding must be replace with a new one when the molding is reinstalled. Make sure that there is no clearance between the door outer molding and the rear edge of the door glass outer weatherstrip. Push the adhesive areas and, the bottom hook area into place securely. Make sure the upper and lower sides of the molding are catching the edges of the sash properly. Push the clips into place securely. When reinstalling the door panel, make sure the plastic cover on the door is installed properly and sealed around its outside perimeter to seal out water. Check for water leaks (see step 9 on page 20-57).

Rear Door Outer Molding Replacement - Sport Wagon

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. If you remove the door outer molding, replace it with a new one because it will bend during removal. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the front upper corner clip (black) and the rear upper corner clips (black) because they are not available separately. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 343

Scheme 344

1. Detach the clips with a clip remover, then pull back the door weatherstrip (A), and remove the screws.
2. While removing the upper edge of the door outer molding (A) from the edge of the sash, cut the double-sided adhesive tape (B) with a utility knife, then remove the molding from the sash.
3. Scrape off the remaining double-sided adhesive tape from the sash, then clean the sash surface with a sponge dampened with isopropyl alcohol.
4. Install the new door outer molding in the reverse order of removal, and note these items: The door outer molding must be replace with a new one when the molding is reinstalled. Make sure the upper and lower sides of the molding are catching the edges of the sash properly. Push the adhesive areas into place securely. Push the door weatherstrip clips into place securely.

Rear Door Weatherstrip Replacement - Sedan

Note. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the front upper corner clip (black) and the rear corner clips (black) because they are not available separately. Use a clip remover to remove the clips.

Scheme 345

1. Remove the door checker mounting bolt (A) at the B-pillar.
2. Detach the clips (B, C, D). Release the door weatherstrip (E) from the holder (F) on the door sash, then remove the weatherstrip.
3. Install the weatherstrip in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely. Make sure the weatherstrip is installed in the holder securely. Apply medium strength liquid thread lock to the door checker mounting bolt before installation. Check for water leaks (see «DOOR POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__door-position-adjustment) ).

Rear Door Weatherstrip Replacement - Sport Wagon

Note. Put on gloves to protect your hands. Take care not to scratch the door. Take care not to damage the front upper comer clip (black) and the rear upper corner clips (black) because they are not available separately. Use a clip remover to remove the clips.

Scheme 346

1. Remove the door checker mounting bolt (A) at the B-pillar.
2. Detach the clips (B, C, D), and release the door weatherstrip (E) from the holder (F) on the door sash, then remove the weatherstrip.
3. Install the weatherstrip in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely. Make sure the weatherstrip is installed in the holder securely. Apply medium strength liquid thread lock to the door checker mounting bolt before installation. Check for water leaks (see step 9 on page 20-57).

Door Glass Adjustment

Note. Check the door weatherstrip and the glass run channel for damage or deterioration, and replace them if necessary. Sedan is shown; Sport Wagon is similar.

Scheme 347

Scheme 348

Scheme 349

Scheme 350

1. Place the vehicle on a firm, level surface when adjusting the door glass.
2. Remove these items: Door panel: Front door (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ) Rear door (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ) Door panel bracket: Front door (see step 3 on page 20-23) Rear door (see step 3 on page 20-39) Plastic cover: Front door (see step 4 on page 20-24) Rear door (see step 4 on page 20-40)
3. Carefully lower the glass (A) until you can see the glass mounting bolts (B), then loosen them. Front door Rear door
4. Push the glass against the glass run channel (C), then tighten the glass mounting bolts.
5. Check that the glass moves smoothly.
6. Raise the glass fully, and check for gaps. Also make sure that the glass (A) contacts the glass run channel (B) evenly.
7. Attach the plastic cover making sure it is sealed around its outside perimeter to seal out water.
8. Reinstall the door panel bracket: Front door (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-glass-and-regulator-replacement) ) Rear door (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT - SEDAN»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-glass-and-regulator-replacement) )
9. Check for water leaks. Run water over the roof and on the sealing area as shown, and note these items: Use a 12 mm (1/2 in) diameter hose (A). Adjust the rate of water flow as shown (B). Do not use a nozzle. Hold the hose about 300 mm (12 in) away from the door (C).
10. Reinstall the door panel: Front door (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ) Rear door (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) )

Door Position Adjustment

Note. Check for a flush fit with the body, then check for equal gaps between the front, rear, and bottom door edges and the body. Check that the door and body edges are parallel. Sedan is shown; Sport Wagon is similar.

Scheme 351

Scheme 352

Scheme 353

1. Place the vehicle on a firm, level surface when adjusting the doors.
2. Adjust at the hinges (A): Pad a floor jack (B) with shop towels (C), then use the jack to support the door while adjusting it. On the front door: Remove the front inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-inner-fender-replacement) ) and the front fender fairing (see «FRONT FENDER FAIRING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-fender-fairing-replacement) ). Loosen the hinge mounting bolts (D) slightly, and move the door backward or forward, up or down as necessary to equalize the gaps. On the rear door: Loosen the hinge mounting bolts (E) slightly, and move the door backward or forward, up or down as necessary to equalize the gaps. Front door Rear door
3. If necessary, replace the door mounting bolts with the adjusting bolts made specifically for door adjustment, then adjust at the door: Loosen the door mounting bolts (F) slightly, and move the door up or down as necessary to equalize the gaps, and move it in or out until it's flush with the body. NOTE: Refer to the Parts Catalog if you need to use an adjusting bolt.
4. Check that the door and body edges are parallel. If necessary, adjust the door cushions (A) to make the rear of the doors flush with the body.
5. Makes sure the door opens without popping or binding and latches securely without slamming. If not adjust the door striker (see «DOOR STRIKER ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__door-striker-adjustment) ).
6. Tighten the mounting bolts to the specified torque.
7. Apply touch-up paint to the hinge mounting bolts and around the hinges.
8. Check for water leaks (see «DOOR POSITION ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__door-position-adjustment) ).

Door Striker Adjustment

Make sure the door latches securely without slamming it. If necessary, adjust the striker (A): The striker screws are fixed, but the striker can be adjusted slightly up or down, and in or out.

Scheme 354

1. Loosen the screws (B).
2. Wrap the striker with a shop towel, then adjust the striker by tapping it with a plastic hammer (C). Do not tap the striker too hard.
3. Lightly tighten the screws.
4. Hold the outer handle out, and push the door against the body to be sure the striker allows a flush fit. If the door latches properly, tighten the screws and recheck.

See also:
• POWER MIRROR REPLACEMENT
• RESETTING THE POWER WINDOW CONTROL UNIT
• GLASS POSITION ADJUSTMENT
• FRONT INNER FENDER REPLACEMENT
• FRONT FENDER FAIRING REPLACEMENT
• FRONT DOOR PANEL REMOVAL/INSTALLATION
• FRONT DOOR OUTER HANDLE REPLACEMENT
• FRONT DOOR LATCH REPLACEMENT
• DOOR POSITION ADJUSTMENT
• FRONT DOOR OUTER MOLDING REPLACEMENT
• FRONT DOOR GLASS AND REGULATOR REPLACEMENT
• REAR DOOR PANEL REMOVAL/INSTALLATION
• REAR DOOR OUTER HANDLE REPLACEMENT
• REAR DOOR PAD REPLACEMENT
• REAR DOOR LATCH REPLACEMENT
• REAR DOOR SASH INNER TRIM REPLACEMENT - SEDAN
• REAR DOOR OUTER MOLDING REPLACEMENT - SEDAN
• REAR DOOR GLASS AND REGULATOR REPLACEMENT - SEDAN
• REAR DOOR GLASS OUTER WEATHERSTRIP REPLACEMENT - SEDAN
• DOOR STRIKER ADJUSTMENT
