Under-Hood Fuse/relay Box Acura TL IV

Removal and Installation

Special Tools Required

Relay puller 07AAC-000A1A0

Note. The under-hood fuse/relay box is a part of the left engine compartment wire harness, and it cannot be replaced by itself

Scheme 26

1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tl/iv-2008-2011/remont/body-electrical/#battery) )
2. Open the cover (A), then remove the screws (B) for the alternator and battery cable terminals
3. Remove the nut (C) and release the tab (D), then remove the bottom cover (E) from the under-hood fuse/relay box
4. Disconnect the connectors (F) from the under-hood fuse/relay box
5. Remove the relay circuit board (G) from the under-hood fuse/relay box
6. Carefully remove the relays using the relay puller (see «POWER RELAY TEST»(/acura/tl/iv-2008-2011/remont/body-electrical/#relays__power-relay-test) )

Note. Do not use pliers.Pliers will damage the relays, which could cause the engine to stall or not start or cause other functions to fail

Installation

1. Install the relays and connect the connectors to the under-hood fuse/relay box, then install the under-hood fuse/relay box in the reverse order of removal
2. Install the removed parts in the reverse order of removal
3. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tl/iv-2008-2011/remont/body-electrical/#battery) )
4. Confirm that all systems work properly
