Connector Index
Identification numbers have been assigned to in-line connectors, junction connectors, and terminals. The number is preceded by the letter "C" for connectors, "G" for ground terminals, or "T" for non-ground terminals.
| Harness | Location |
|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Trunk, and Roof) | Notes |
| A/C wire harness | | C205, C301, C302, C403, C501 | | Connector to Harness (see A/C WIRE HARNESS ) |
| Audio wire harness | | C406, C407, C501 through C510 G501, G502 | | Connector to Harness (see AUDIO WIRE HARNESS ) |
| Battery ground cable | (-), G1 | | | M/T: (see BATTERY GROUND CABLE (M/T) ) A/T: (see BATTERY GROUND CABLE (A/T) ) |
| Cable reel subharness | | | T9 | Connector to Harness (see CABLE REEL SUBHARNESS ) |
| Console subharness | | | C405 | Connector to Harness (see CONSOLE SUBHARNESS ) |
| Dashboard wire harness (View of driver's side) | | C304, C305, C306, C401, C402, C751, C752 G401, G402 | | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| Dashboard wire harness (View of middle to passenger's side) | | C206, C207, C208, C403, C406 through C411, C761 G403, G405 | C404, C405 G404 | Connector to Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| Driver's door subharness | | | C753, C754, C756 | Connector to Harness (see DRIVER'S DOOR SUBHARNESS ) |
| Driver's door wire harness | | C751, C752 | C753, C754, C755 | Connector to Harness (see DRIVER'S DOOR WIRE HARNESS ) |
| Driver's seat wire harness | | | C701 | Connector to Harness (see DRIVER'S SEAT WIRE HARNESS ) |
| Engine ground cable | T1, G2 | | | M/T: (see ENGINE GROUND CABLE (M/T) ) A/T: (see ENGINE GROUND CABLE (A/T) ) |
| Engine wire harness (Transmission section) | C108(A/T) | | | M/T: (see ENGINE WIRE HARNESS (TRANSMISSION SECTION) (M/T) ) A/T: (see ENGINE WIRE HARNESS (TRANSMISSION SECTION) (A/T) ) |
| Engine wire harness (Engine section) | C101 through C107 T4, T102 G101 | | | M/T: (see ENGINE WIRE HARNESS (ENGINE SECTION) (M/T) ) A/T: (see ENGINE WIRE HARNESS (ENGINE SECTION) (A/T) ) |
| EPS subharness | C202, C203 T6, T7, T8 | | | Connector to Harness (see EPS SUBHARNESS ) |
| Front passenger's door wire harness | | C761 | C762 | Connector to Harness (see FRONT PASSENGER'S DOOR WIRE HARNESS ) |
| Front passenger's seat wire harness | | | C702 | Connector to Harness (see FRONT PASSENGER'S SEAT WIRE HARNESS ) |
| Knock sensor subharness | C104 | | | M/T: (see KNOCK SENSOR SUBHARNESS (M/T) ) A/T: (see KNOCK SENSOR SUBHARNESS (A/T) ) |
| Left engine compartment wire harness (Dashboard branch) | | C301 through C307 G302 | | Connector to Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) |
| Left engine compartment wire harness (Engine compartment branch) | C101, C102, C201 G301 | | | Connector to Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| Left rear door wire harness | | | C771 | Connector to Harness (see LEFT REAR DOOR WIRE HARNESS ) |
| Left side wire harness (Without SH-AWD) | | C303, C401 | C601, C771 G601, G602, G603 | Connector to Harness (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) ) |
| Left side wire harness (With SH-AWD) | | C303, C401 | C601, C602, C771 G601, G602, G603 | Connector to Harness (see LEFT SIDE WIRE HARNESS (WITH SH-AWD ) |
| Moonroof subharness | | | C451 | Connector to Harness (see MOONROOF SUBHARNESS ) |
| Rear differential subharness (With SH-AWD) | | | C652, C653 T10 | Connector to Harness (see REAR DIFFERENTIAL SUBHARNESS (WITH SH-AWD) ) |
| Rear window defogger ground wire | | | G801 | Without SH-AWD: (see REAR WINDOW DEFOGGER GROUND WIRE (WITHOUT SH-AWD) ) With SH-AWD: (see REAR WINDOW DEFOGGER GROUND WIRE (WITH SH-AWD) ) |
| Right engine compartment wire harness | C201, C202, C203 G201, G202 | C204 through C208 G203, G204 | | Connector to Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| Right rear door wire harness | | | C781 | Connector to Harness (see RIGHT REAR DOOR WIRE HARNESS ) |
| Right side wire harness (Without SH-AWD) | | C410, C411, C509, C510 | C601, C781, G651, G653 | Connector to Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) ) |
| Right side wire harness (With SH-AWD) | | C410, C411, C509, C510 | C601, C602, C651, C652, C653, C781 G651, G652, G653 | Connector to Harness (see RIGHT SIDE WIRE HARNESS (WITH SH-AWD) ) |
| Roof wire harness | | | C402, C451 | Connector to Harness (see ROOF WIRE HARNESS ) |
| Shift solenoid wire harness (A/T) | C108 | | | Connector to Harness (see SHIFT SOLENOID WIRE HARNESS (A/T) ) |
| SRS floor wire harness | | | C404, C701, C702 G701, G702 | Connector to Harness (see SRS FLOOR WIRE HARNESS ) |
| Starter cable | (+), T3, T101 | | | M/T: (see STARTER CABLE (M/T) ) A/T: (see STARTER CABLE (A/T) ) |
| Transmission ground cable | T2, G3 | | | M/T: (see TRANSMISSION GROUND CABLE (M/T ) A/T: (see TRANSMISSION GROUND CABLE (A/T) ) |
Battery Ground Cable (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| (-) | 3 | | Left side of engine compartment | Battery negative terminal | |
| G1 | 4 | | Left side of engine compartment | Body ground, via battery ground cable | |
BATTERY GROUND CABLE (M/T) CONNECTOR
Engine Ground Cable (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T1 | 8 | | Right side of engine compartment | Engine | |
| G2 | 9 | | Right side of engine compartment | Body ground, via engine ground cable | |
ENGINE GROUND CABLE (M/T) CONNECTOR
Transmission Ground Cable (M/T
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T2 | 7 | | Left side of engine compartment | Transmission housing | |
| G3 | 6 | | Left side of engine compartment | Body ground, via transmission ground cable | |
TRANSMISSION GROUND CABLE (M/T) CONNECTOR
Starter Cable (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T3 | 5 | | Left side of engine compartment | Starter motor | |
| T101 | 1 | | Left side of engine compartment | Under-hood fuse/relay box | |
| (+) | 2 | | Left side of engine compartment | Battery positive terminal | |
STARTER CABLE (M/T) CONNECTOR
Scheme 42
Battery Ground Cable (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| (-) | 4 | | Left side of engine compartment | Battery negative terminal | |
| G1 | 5 | | Left side of engine compartment | Body ground, via battery ground cable | |
BATTERY GROUND CABLE (A/T) CONNECTOR
Engine Ground Cable (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T1 | 8 | | Right side of engine compartment | Engine | |
| G2 | 9 | | Right side of engine compartment | Body ground, via engine ground cable | |
ENGINE GROUND CABLE (A/T) CONNECTOR
Transmission Ground Cable (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T2 | 7 | | Left side of engine compartment | Transmission housing | |
| G3 | 6 | | Left side of engine compartment | Body ground, via transmission ground cable | |
TRANSMISSION GROUND CABLE (A/T) CONNECTOR
Starter Cable (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T3 | 2 | | Left side of engine compartment | Starter motor | |
| T101 | 1 | | Left side of engine compartment | Under-hood fuse/relay box | |
| (+) | 3 | | Left side of engine compartment | Battery positive terminal | |
STARTER CABLE (A/T) CONNECTOR
Scheme 43
Engine Wire Harness (Engine section) (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C compressor clutch | 30 | 1 | Right side of engine compartment | | |
| Alternator | 31 | 4 | Middle of engine compartment | | |
| CKP sensor | 13 | 3 | Left side of engine | | |
| CMP sensor | 36 | 3 | Right side of engine | | |
| ECM connector B | 37 | 49 | Right side of engine compartment | | |
| ECM connector C | 38 | 49 | Right side of engine compartment | | |
| Engine coolant temperature (ECT) sensor 1 | 23 | 2 | Left side of engine | | |
| Engine mount control solenoid | 11 | 2 | Left side of engine compartment | | |
| Engine oil pressure switch | 41 | 1 | Right side of engine compartment | | |
| EVAP canister purge valve | 10 | 2 | Left side of engine compartment | | |
| Exhaust gas recirculation (EGR) valve and position sensor | 24 | 5 | Left side of engine compartment | | |
| Front A/F sensor (Bank 2, Sensor 1) | 28 | 6 | Exhaust manifold (front bank) | | |
| Ignition coil No. 1 | 3 | 3 | Middle of engine | | |
| Ignition coil No. 2 | 5 | 3 | Middle of engine | | |
| Ignition coil No. 3 | 8 | 3 | Middle of engine | | |
| Ignition coil No. 4 | 34 | 3 | Middle of engine | | |
| Ignition coil No. 5 | 29 | 3 | Middle of engine | | |
| Ignition coil No. 6 | 27 | 3 | Middle of engine | | |
| Injector No. 1 | 2 | 2 | Middle of engine | | |
| Injector No. 2 | 4 | 2 | Middle of engine | | |
| Injector No. 3 | 7 | 2 | Middle of engine | | |
| Injector No. 4 | 35 | 2 | Middle of engine | | |
| Injector No. 5 | 32 | 2 | Middle of engine | | |
| Injector No. 6 | 25 | 2 | Middle of engine | | |
| Intake manifold tuning (IMT) actuator | 1 | 5 | Middle of engine | | |
| Manifold absolute pressure (MAP) sensor | 14 | 3 | Left side of engine compartment | | |
| Mass air flow (MAF) sensor/Intake air temperature (IAT) sensor | 17 | 5 | Left side of engine compartment | | |
| Rear A/F sensor (Bank 1, Sensor 1) | 9 | 6 | Exhaust manifold (rear bank) | | |
| Rear secondary heated oxygen sensor (secondary HO2S) (Bank 1, Sensor 2) | 12 | 4 | Exhaust manifold (rear bank) | | |
| Reverse lockout solenoid | 22 | 2 | Left side of engine compartment | | |
| Rocker arm oil control solenoid | 40 | 1 | Right side of engine | | |
| Rocker arm oil pressure switch | 42 | 2 | Right side of engine | | |
| Throttle position sensor/Throttle actuator | 15 | 6 | Left side of engine compartment | | |
ENGINE WIRE HARNESS (M/T) CONNECTOR
Scheme 44
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C101 | 19 | 13 | Left side of engine compartment | Left engine compartment wire harness (Engine compartment branch) | |
| C102 | 18 | 1 | Left side of engine compartment | Left engine compartment wire harness (Engine compartment branch) | |
| C103 (junction connector) | 6 | 24 | Middle of engine compartment | | |
| C104 | 39 | 1 | Middle of engine | Knock sensor subharness | |
| C106 (junction connector) | 20 | 24 | Left side of engine compartment | | |
| C107 (junction connector) | 21 | 24 | Left side of engine compartment | | |
| T4 | 33 | | Right side of engine compartment | Alternator +B terminal | |
| T102 | 16 | | Left side of engine compartment | Under-hood fuse/relay box | |
| G101 | 43 | | Middle of engine compartment | Body ground, via engine wire harness | |
ENGINE WIRE HARNESS (M/T) CONNECTOR
Knock Sensor Subharness (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Knock sensor | 26 | 1 | Middle of engine | | |
| C104 | 39 | 1 | Middle of engine | Engine wire harness (Engine section) | |
KNOCK SENSOR SUBHARNESS (M/T) CONNECTOR
Scheme 45
Engine Wire Harness (Engine section) (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C compressor clutch | 33 | 1 | Right side of engine compartment | | |
| A/T clutch pressure control solenoid valve C | 24 | 2 | Transmission housing | | |
| Alternator | 34 | 4 | Middle of engine compartment | | |
| CKP sensor | 13 | 3 | Left side of engine | | |
| CMP sensor | 39 | 3 | Right side of engine | | |
| Engine coolant temperature (ECT) sensor 1 | 25 | 2 | Left side of engine | | |
| Engine mount control solenoid | 11 | 2 | Left side of engine compartment | | |
| Engine oil pressure switch | 44 | 1 | Right side of engine compartment | | |
| EVAP canister purge valve | 10 | 2 | Left side of engine compartment | | |
| Exhaust gas recirculation (EGR) valve and position sensor | 26 | 5 | Left side of engine compartment | | |
| Front A/F sensor (Bank 2, Sensor 1) | 31 | 6 | Exhaust manifold (front bank) | | |
| Front secondary heated oxygen sensor (secondary HO2S) (Bank 2, Sensor 2) | 30 | 4 | Exhaust manifold (front bank) | | |
| Ignition coil No. 1 | 3 | 3 | Middle of engine | | |
| Ignition coil No. 2 | 5 | 3 | Middle of engine | | |
| Ignition coil No. 3 | 8 | 3 | Middle of engine | | |
| Ignition coil No. 4 | 37 | 3 | Middle of engine | | |
| Ignition coil No. 5 | 32 | 3 | Middle of engine | | |
| Ignition coil No. 6 | 29 | 3 | Middle of engine | | |
| Injector No. 1 | 2 | 2 | Middle of engine | | |
| Injector No. 2 | 4 | 2 | Middle of engine | | |
| Injector No. 3 | 7 | 2 | Middle of engine | | |
| Injector No. 4 | 38 | 2 | Middle of engine | | |
| Injector No. 5 | 35 | 2 | Middle of engine | | |
| Injector No. 6 | 27 | 2 | Middle of engine | | |
| Intake manifold tuning (IMT) actuator | 1 | 5 | Middle of engine | | |
| Manifold absolute pressure (MAP) sensor | 15 | 3 | Left side of engine compartment | | |
| Mass air flow (MAF) sensor/Intake air temperature (IAT) sensor | 18 | 5 | Left side of engine compartment | | |
| PCM connector B | 40 | 49 | Right side of engine compartment | | |
| PCM connector C | 41 | 49 | Right side of engine compartment | | |
| Rear A/F sensor (Bank 1, Sensor 1) | 9 | 6 | Exhaust manifold (rear bank) | | |
| Rear secondary heated oxygen sensor (secondary HO2S) (Bank 1, Sensor 2) | 12 | 4 | Exhaust manifold (rear bank) | | |
| Rocker arm oil control solenoid | 43 | 1 | Right side of engine | | |
| Rocker arm oil pressure switch | 45 | 2 | Right side of engine | | |
| Throttle position sensor/Throttle actuator | 16 | 6 | Left side of engine compartment | | |
| Transmission fluid pressure switch A (2nd clutch) | 14 | 1 | Transmission housing | | |
ENGINE WIRE HARNESS (A/T) CONNECTOR
Scheme 46
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C101 | 20 | 13 | Left side of engine compartment | Left engine compartment wire harness (Engine compartment branch) | |
| C102 | 19 | 1 | Left side of engine compartment | Left engine compartment wire harness (Engine compartment branch) | |
| C103 (junction connector) | 6 | 24 | Middle of engine compartment | | |
| C104 | 42 | 1 | Middle of engine | Knock sensor subharness | |
| C105 (junction connector) | 23 | 12 | Left side of engine compartment | | |
| C106 (junction connector) | 21 | 24 | Left side of engine compartment | | |
| C107 (junction connector) | 22 | 24 | Left side of engine compartment | | |
| T4 | 36 | | Right side of engine compartment | Alternator +B terminal | |
| T102 | 17 | | Left side of engine compartment | Under-hood fuse/relay box | |
| G101 | 46 | | Middle of engine compartment | Body ground, via engine wire harness | |
ENGINE WIRE HARNESS (A/T) CONNECTOR
Knock Sensor Subharness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Knock sensor | 28 | 1 | Middle of engine | | |
| C104 | 42 | 1 | Middle of engine | Engine wire harness (Engine section) | |
KNOCK SENSOR SUBHARNESS (A/T) CONNECTOR
Scheme 47
Engine Wire Harness (Transmission section) (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Back-up lights switch | 3 | 2 | Transmission housing | | |
| Front secondary heated oxygen sensor (secondary HO2S) (Bank 2, Sensor 2) | 5 | 4 | Transmission housing | | |
| Input shaft (mainshaft) speed sensor | 4 | 3 | Transmission housing | | |
| Output shaft (countershaft) speed sensor | 1 | 3 | Transmission housing | | |
| Starter solenoid | 2 | 1 | Left side of engine compartment | | |
ENGINE WIRE HARNESS (M/T) CONNECTOR
Scheme 48
Engine Wire Harness (Transmission section) (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T clutch pressure control solenoid valve A | 7 | 2 | Transmission housing | | |
| A/T clutch pressure control solenoid valve B | 8 | 2 | Transmission housing | | |
| ATF temperature sensor | 9 | 2 | Transmission housing | | |
| Input shaft (mainshaft) speed sensor | 13 | 3 | Transmission housing | | |
| Output shaft (countershaft) speed sensor | 11 | 3 | Transmission housing | | |
| Starter solenoid | 1 | 1 | Left side of engine compartment | | |
| Transmission fluid pressure switch B (3rd clutch) | 12 | 1 | Transmission housing | | |
| Transmission range switch | 10 | 10 | Transmission housing | | |
| 4th clutch transmission fluid pressure switch | 6 | 1 | Transmission housing | | |
| C108 | 14 | 5 | Transmission housing | Shift solenoid wire harness | |
ENGINE WIRE HARNESS (A/T) CONNECTOR
Shift Solenoid Wire Harness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Shift solenoid valve A | 2 | 1 | In the transmission | | |
| Shift solenoid valve B | 5 | 1 | In the transmission | | |
| Shift solenoid valve C | 3 | 1 | In the transmission | | |
| Shift solenoid valve D | 4 | 1 | In the transmission | | |
| C108 | 14 | 5 | Transmission housing | Engine wire harness (Transmission section) | |
SHIFT SOLENOID WIRE HARNESS (A/T) CONNECTOR
Scheme 49
Left Engine Compartment Wire Harness (Engine compartment branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C condenser fan motor | 22 | 2 | Front of engine compartment | | |
| Brake fluid level switch | 10 | 2 | Left side of engine compartment | | |
| ECM/PCM connector A | 1 | 49 | Right side of engine compartment | | |
| Engine coolant temperature (ECT) sensor 2 | 19 | 2 | Front engine compartment | | |
| Horn (high) | 18 | 1 | Behind left side of front bumper | | |
| Horn (low) | 24 | 1 | Behind right side of front bumper | | |
| Left fog light | 16 | 2 | Behind left side of front bumper | | |
| Left front impact sensor | 15 | 2 | Behind left side of front bumper | | |
| Left front parking/turn signal light | 17 | 3 | Behind left side of front bumper | | |
| Left front side marker light | 13 | 2 | Behind left headlight | | |
| Left front wheel speed sensor | 12 | 2 | Left side of engine compartment | | |
| Left headlight (high) | 4 | 2 | Behind left headlight | | |
| Left headlight (low) | 3 | 2 | Behind left headlight | | |
| Outside air temperature sensor | 21 | 2 | Front of engine compartment | | |
| Radiator fan motor | 20 | 2 | Front of engine compartment | | |
| Security hood switch | 2 | 2 | Front of engine compartment | | |
| Under-hood fuse/relay box connector A (electrical load detector) (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 9 | 3 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 8 | 14 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 7 | 5 | Left side of engine compartment | | |
| Windshield Wiper motor | 11 | 4 | Left side of engine compartment | | |
| C101 | 5 | 13 | Left side of engine compartment Engine wire harness (Transmission section) | | |
| C102 | 6 | 1 | Left side of engine compartment | Engine wire harness (Transmission section) | |
| C201 | 23 | 2 | Right front of engine compartment | Right engine compartment wire harness | |
| G301 | 14 | | Behind left side of front bumper | Body ground, via left engine compartment wire harness | |
LEFT ENGINE COMPARTMENT WIRE HARNESS CONNECTOR
Scheme 50
Left Engine Compartment Wire Harness (Dashboard branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Accelerator pedal position sensor | 8 | 6 | Under left side of dash | | |
| Brake pedal position switch | 9 | 4 | Under left side of dash | | |
| Clutch pedal position switch A (for starter cut) | 4 | 2 | Under left side of dash | | M/T |
| Clutch pedal position switch B (for cruise control) | 10 | 3 | Under left side of dash | | M/T |
| Driver's under-dash fuse/relay box connector F (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 33 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector G (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 2 | 13 | Under left side of dash | | |
| Left front TPMS initiator | 15 | 3 | Left front of fenderwell | | |
| C301 | 6 | 2 | Under middle of dash | A/C wire harness | |
| C302 | 7 | 2 | Under middle of dash | A/C wire harness | |
| C303 | 14 | 12 | Under left side of dash | Left side wire harness: Without SH-AWD With SH-AWD | |
| C304 | 13 | 2 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C305 | 11 | 4 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C306 | 12 | 24 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C307 (junction connector) | 5 | 12 | Under left side of dash | | |
| G302 | 1 | | Under left side of dash | Body ground, via left engine compartment wire harness | |
LEFT ENGINE COMPARTMENT WIRE HARNESS CONNECTOR
Scheme 51
Right Engine Compartment Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C pressure sensor | 11 | 3 | Right front of engine compartment | | |
| EPS control unit connector A | 6 | 2 | Under right side of dash | | |
| EPS control unit connector B | 4 | 2 | Under right side of dash | | |
| EPS control unit connector C | 3 | 2 | Under right side of dash | | |
| EPS control unit connector D | 5 | 28 | Under right side of dash | | |
| Headlight washer motor | 22 | 2 | Behind right side of front bumper | | (1) |
| Passenger's under-dash fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 30 | 1 | Under right side of dash | | |
| Passenger's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 29 | 18 | Under right side of dash | | |
| Right fog light | 19 | 2 | Behind right side of front bumper | | |
| Right front impact sensor | 20 | 2 | Behind right side of front bumper | | |
| Right front parking/turn signal light | 18 | 3 | Behind right side of front bumper | | |
| Right front side marker light | 24 | 2 | Behind right headlight | | |
| Right front TPMS initiator | 26 | 3 | Right front of fenderwell | | |
| Right front wheel speed sensor | 25 | 2 | Right side of engine compartment | | |
| Right headlight (high) | 15 | 2 | Behind right headlight | | |
| Right headlight (low) | 14 | 2 | Behind right headlight | | |
| VSA modulator-control unit | 12 | 47 | Right side of engine compartment | | |
| Washer fluid level switch | 21 | 2 | Behind right side of front bumper | | (2) |
| Windshield washer motor | 23 | 2 | Behind right side of front bumper | | |
| C201 | 13 | 2 | Right side of engine compartment | Left engine compartment wire harness (Engine compartment branch) | |
| C202 | 10 | 3 | Right side of engine compartment | EPS subharness | |
| C203 | 9 | 12 | Right side of engine compartment | EPS subharness | |
| C204 (junction connector) | 8 | 12 | Under right side of dash | | |
| C205 | 27 | 2 | Under right side of dash | A/C wire harness | |
| C206 | 31 | 20 | Under right side of dash | Dash board wire harness (View of middle to passenger's side) | |
| C207 | 7 | 2 | Under right side of dash | Dash board wire harness (View of middle to passenger's side) | |
| C208 | 28 | 4 | Under right side of dash | Dash board wire harness (View of middle to passenger's side) | |
| G201 | 16 | | Behind right side of front bumper | Body ground, via right engine compartment wire harness | |
| G202 | 17 | | Behind right side of front bumper | Body ground, via right engine compartment wire harness | |
| G203 | 1 | | Under right side of dash | Body ground, via right engine compartment wire harness | |
| G204 | 2 | | Under right side of dash | Body ground, via right engine compartment wire harness | |
| (1) Canada models with SH-AWD (2) Canada models |
| (1) | Canada models with SH-AWD |
RIGHT ENGINE COMPARTMENT WIRE HARNESS CONNECTOR
Scheme 52
Dashboard Wire Harness (View of driver's side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ACC cut relay | 44 | 5 | Under left side of dash | | (1) |
| Auxiliary under-dash fuse holder | 68 | 2 | Under left side of dash | | (1) |
| Center junction box connector A | 37 | 4 | Behind gauge | | |
| Center junction box connector B | 38 | 4 | Behind gauge | | |
| Center junction box connector C | 39 | 4 | Behind gauge | | |
| Center junction box connector D | 40 | 6 | Behind gauge | | |
| Center junction box connector E | 36 | 6 | Behind gauge | | |
| Center junction box connector F | 31 | 6 | Behind gauge | | |
| Center junction box connector G | 32 | 6 | Behind gauge | | |
| Center junction box connector H | 35 | 4 | Behind gauge | | |
| Center junction box connector J | 34 | 8 | Behind gauge | | |
| Center junction box connector K | 33 | 10 | Behind gauge | | |
| Console accessory power socket relay | 41 | 4 | Under left side of dash | | |
| Dashlight brightness controller | 53 | 6 | Left side of dashboard | | |
| Data link connector (DLC) | 63 | 16 | Under left side of dash | | |
| Driver's footwell light | 58 | 2 | Under left side of dash | | |
| Driver's junction box 1 connector A | 29 | 6 | Behind gauge | | |
| Driver's junction box 1 connector B | 30 | 6 | Behind gauge | | |
| Driver's junction box 1 connector C | 23 | 8 | Behind gauge | | |
| Driver's junction box 1 connector D | 28 | 4 | Behind gauge | | |
| Driver's junction box 1 connector E | 24 | 10 | Behind gauge | | |
| Driver's junction box 1 connector F | 25 | 8 | Behind gauge | | |
| Driver's junction box 1 connector G | 27 | 10 | Behind gauge | | |
| Driver's junction box 1 connector H | 26 | 10 | Behind gauge | | |
| Driver's junction box 2 connector A | 21 | 6 | Behind gauge | | |
| Driver's junction box 2 connector B | 14 | 6 | Behind gauge | | |
| Driver's junction box 2 connector C | 15 | 8 | Behind gauge | | |
| Driver's junction box 2 connector D | 20 | 4 | Behind gauge | | |
| Driver's junction box 2 connector E | 16 | 10 | Behind gauge | | |
| Driver's junction box 2 connector F | 17 | 8 | Behind gauge | | |
| Driver's junction box 2 connector G | 19 | 10 | Behind gauge | | |
| Driver's junction box 2 connector H | 18 | 10 | Behind gauge | | |
| Driver's under-dash fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 52 | 2 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 51 | 5 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector M (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 48 | 4 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector N (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 49 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector P (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 50 | 20 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector Q (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 46 | 20 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector R (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 47 | 24 | Under left side of dash | | |
| Front accessory power socket relay | 42 | 4 | Under left side of dash | | (2) |
| Front accessory power socket relay | 44 | 4 | Under left side of dash | | (3) |
| Gauge control module | 22 | 32 | Behind gauge | | |
| Headlight washer motor relay | 42 | 4 | Under left side of dash | | (4) |
| Headlight washer switch | 56 | 6 | Left side of dashboard | | (4) |
| IG2 cut relay | 45 | 5 | Under left side of dash | | (1) |
| (1) Without keyless access system (2) With keyless access system except Canada models with SH-AWD (3) With keyless access system Canada models with SH-AWD (4) Canada models with SH-AWD |
| (1) | Without keyless access system |
| (2) | With keyless access system except Canada models with SH-AWD |
| (3) | With keyless access system Canada models with SH-AWD |
| (4) | Canada models with SH-AWD |
DASHBOARD WIRE HARNESS CONNECTOR
Scheme 53
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Keyless access control unit connector A | 62 | 36 | Under left side of dash | | |
| Keyless access control unit connector B | 61 | 32 | Under left side of dash | | |
| Keyless access control unit connector C | 60 | 5 | Under left side of dash | | |
| Keyless access junction box connector A | 3 | 6 | Under left side of dash | | (1) |
| Keyless access junction box connector B | 4 | 6 | Under left side of dash | | (1) |
| Keyless access junction box connector C | 5 | 8 | Under left side of dash | | (1) |
| Keyless access junction box connector D | 10 | 4 | Under left side of dash | | (1) |
| Keyless access junction box connector E | 6 | 10 | Under left side of dash | | (1) |
| Keyless access junction box connector F | 7 | 8 | Under left side of dash | | (1) |
| Keyless access junction box connector G | 9 | 10 | Under left side of dash | | (1) |
| Keyless access junction box connector H | 8 | 10 | Under left side of dash | | (1) |
| Optional connector (for remote engine start) | 69 | 2 | Under left side of dash | | |
| Power control unit connector A | 55 | 1 | Under left side of dash | | |
| Power control unit connector B | 54 | 4 | Under left side of dash | | |
| Power control unit connector C | 59 | 36 | Under left side of dash | | |
| TPMS control unit | 43 | 20 | Under left side of dash | | |
| VSA OFF switch | 57 | 5 | Left side of dashboard | | |
| + B cut relay | 45 | 4 | Under left side of dash | | M/T |
| C304 | 67 | 2 | Under left side of dash | Left engine compartment wire harness (Dashboard branch) | (2) |
| C305 | 64 | 4 | Under left side of dash | Left engine compartment wire harness (Dashboard branch) | |
| C306 | 65 | 24 | Under left side of dash | Left engine compartment wire harness (Dashboard branch) | |
| C401 | 66 | 18 | Under left side of dash | Left side wire harness: Without SH-AWD With SH-AWD | |
| C402 | 13 | 23 | Under left side of dash | Roof wire harness | |
| C751 | 2 | 23 | Under left side of dash | Driver's door wire harness | |
| C752 | 1 | 12 | Under left side of dash | Driver's door wire harness | |
| G401 | 12 | | Under left side of dash | Body ground, via dashboard wire harness | |
| G402 | 11 | | Under left side of dash | Body ground, via dashboard wire harness | |
| (1) With keyless access system (2) With headlight washer |
| (1) | With keyless access system |
DASHBOARD WIRE HARNESS CONNECTOR
Scheme 54
Dashboard Wire Harness (View of middle to passenger's side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T gear position indicator panel light | 45 | 2 | Under center console | | A/T |
| A/T shift lock solenoid/park pin switch | 43 | 4 | Under center console | | A/T |
| Automatic lighting sensor | 14 | 5 | Middle of dash | | |
| Cable reel | 4 | 20 | In steering column | | |
| Center speaker | 11 | 2 | Middle of dash | | |
| Combination light switch | 2 | 12 | In steering column | | |
| Driver's airbag inflator | 5 | 4 | In steering column | | |
| Driver's climate control switch | 12 | 16 | Middle of dash | | |
| Driver's seat heater switch | 44 | 6 | Under center console | | |
| Electric steering lock | 3 | 12 | In steering column | | (1) |
| Engine start/stop switch | 10 | 10 | Middle of dash | | (1) |
| Remote slot | 9 | 16 | Middle of dash | | (1) |
| Remote slot control unit | 23 | 40 | Under right side of dash | | |
| Front accessory power socket | 34 | 2 | Under center console | | |
| Front passenger's airbag inflator | 19 | 4 | Under right side of dash | | |
| Front passenger's seat heater switch | 35 | 7 | Under center console | | |
| Hazard warning switch/Passenger's airbag cutoff indicator | 15 | 6 | Middle of dash | | |
| Ignition key switch | 48 | 6 | In steering column | | (2) |
| Ignition switch | 49 | 5 | In steering column | | (2) |
| Immobilizer-keyless control unit | 7 | 7 | In steering column | | (2) |
| In-car temperature sensor | 8 | 4 | Middle of dash | | |
| Passenger's under-dash fuse/relay box connector A (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 27 | 38 | Under right side of dash | | |
| RF unit 1 | 41 | 3 | Under center console | | (1) |
| Right tweeter | 20 | 2 | Under right side of dash | | |
| SRS unit connector A | 32 | 39 | Middle of dash | | |
| Steering angle sensor | 1 | 5 | In steering column | | |
| Sunlight sensor | 13 | 2 | Middle of dash | | |
| USB adapter unit | 46 | 14 | Under center console | | (3) |
| Wiper/washer switch | 6 | 8 | In steering column | | |
| Yaw rate-lateral acceleration sensor | 33 | 4 | Under center console | | (4) |
| Yaw rate-lateral/longitudinal acceleration sensor | 33 | 4 | Under center console | | (5) |
| (1) With keyless access system (2) Without keyless access system (3) Without navigation system (4) Without SH-AWD (5) With SH-AWD |
| (1) | With keyless access system |
| (2) | Without keyless access system |
| (3) | Without navigation system |
DASHBOARD WIRE HARNESS CONNECTOR
Scheme 55
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C206 | 30 | 20 | Under right side of dash | Right engine compartment wire harness | |
| C207 | 29 | 2 | Under right side of dash | Right engine compartment wire harness | |
| C208 | 28 | 4 | Under right side of dash | Right engine compartment wire harness | |
| C403 | 47 | 20 | Middle of dash | A/C wire harness | |
| C404 | 37 | 18 | Under center console | SRS floor wire harness | |
| C405 | 36 | 20 | Under center console | Console subharness | |
| C406 | 17 | 34 | Under right side of dash | Audio wire harness | |
| C407 | 18 | 12 | Under right side of dash | Audio wire harness | |
| C408 (junction connector) | 16 | 12 | Under right side of dash | | |
| C409 (junction connector) | 21 | 20 | Under right side of dash | | |
| C410 | 25 | 12 | Under right side of dash | Right side wire harness: Without SH-AWD With SH-AWD | |
| C411 | 26 | 8 | Under right side of dash | Right side wire harness: Without SH-AWD With SH-AWD | |
| C761 | 24 | 28 | Under right side of dash | Front passenger's door wire harness | |
| G403 | 31 | | Middle of dash | Body ground, via dashboard wire harness | |
| G404 | 50 | | Under center console | Body ground, via dashboard wire harness | |
| G405 | 22 | | Under right side of dash | Body ground, via dashboard wire harness | |
DASHBOARD WIRE HARNESS CONNECTOR
Console Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Auxiliary jack | 38 | 5 | Rear of center console | | |
| Console accessory power socket | 39 | 2 | Rear of center console | | |
| Console box light | 40 | 2 | Rear of center console | | |
| Parking brake switch | 42 | 1 | Under center console | | |
| C405 | 36 | 20 | Under center console | Dashboard Wire Harness | |
CONSOLE SUBHARNESS CONNECTOR
Scheme 56
Audio Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| AcuraLink connector (Female connector) | 11 | 5 | Under right side of dash | | (1) |
| AcuraLink connector (Male connector) | 7 | 5 | Under right side of dash | | (1) |
| AcuraLink control unit A (XM receiver) | 28 | 32 | Under middle of dash | | (1) |
| Audio unit connector A | 32 | 24 | Under middle of dash | | (2) |
| Audio unit connector B | 31 | 14 | Under middle of dash | | (2) |
| Audio unit connector C | 29 | 14 | Under middle of dash | | (2) |
| Audio unit connector D | 22 | 20 | Under middle of dash | | (2) |
| Audio-navigation unit connector A | 32 | 24 | Under middle of dash | | (3) |
| Audio-navigation unit connector B | 31 | 24 | Under middle of dash | | (3) |
| Audio-navigation unit connector C | 29 | 14 | Under middle of dash | | (3) |
| Audio-navigation unit connector D | 22 | 20 | Under middle of dash | | (3) |
| Audio-navigation unit connector F | 33 | 12 | Under middle of dash | | (3) |
| Audio-navigation unit connector G | 34 | 16 | Under middle of dash | | (3) |
| Audio-navigation unit connector H | 35 | 28 | Under middle of dash | | (3) |
| Audio-navigation switch panel | 30 | 24 | Under middle of dash | | (3) |
| Audio-HVAC display unit | 2 | 12 | Under middle of dash | | (2) |
| Front interior LF antenna | 27 | 2 | Under middle of dash | | (4) |
| Glove box light | 12 | 2 | Glove box | | |
| HandsFreeLink control unit | 25 | 28 | Under middle of dash | | |
| Interface dial | 26 | 5 | Under middle of dash | | (3) |
| Keyless access system mode switch | 14 | 2 | Under right side of dash | | (4) |
| Navigation display unit | 2 | 32 | Under middle of dash | | (3) |
| Navigation service check connector | 17 | 2 | Under right side of dash | | (3) |
| Passenger's climate control switch | 13 | 16 | Under middle of dash | | |
| Passenger's under-dash fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 15 | 28 | Under right side of dash | | |
| Trunk lid opener main switch | 16 | 2 | Under right side of dash | | |
| XM receiver | 28 | 14 | Under middle of dash | | (5) |
| C406 | 5 | 34 | Under right side of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C407 | 6 | 12 | Under right side of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C501 | 21 | 20 | Under middle of dash | A/C wire harness | |
| C502 (junction connector) | 23 | 12 | Under middle of dash | | |
| C503 (junction connector) | 24 | 12 | Under middle of dash | | |
| C504 (junction connector) | 4 | 12 | Under right side of dash | | |
| C505 (junction connector) | 3 | 12 | Under right side of dash | | |
| C506 (junction connector) | 8 | 12 | Under right side of dash | | |
| C507 (junction connector) | 9 | 12 | Under right side of dash | | |
| C508 (junction connector) | 10 | 12 | Under right side of dash | | |
| C509 | 18 | 28 | Under right side of dash | Right side wire harness: Without SH-AWD With SH-AWD | |
| C510 | 19 | 12 | Under right side of dash | Right side wire harness: Without SH-AWD With SH-AWD | |
| G501 | 1 | | Under middle of dash | Body ground, via audio wire harness | |
| G502 | 20 | | Under middle of dash | Body ground, via audio wire harness | |
| (1) USA models with navigation system (2) Without navigation system (3) With navigation system (4) With keyless access system (5) Except USA models with navigation system |
| (1) | USA models with navigation system |
| (2) | Without navigation system |
| (3) | With navigation system |
| (4) | With keyless access system |
| (5) | Except USA models with navigation system |
AUDIO WIRE HARNESS CONNECTOR
Scheme 57
Left Side Wire Harness (Without SH-AWD)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Condenser (for rear window defogger) | 7 | 2 | Left C-pillar | | |
| Driver's door switch | 4 | 1 | Left B-pillar | | |
| Driver's under-dash fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 2 | 20 | Under left side of dash | | |
| EVAP canister vent shut valve | 30 | 2 | Under floor | | |
| Fuel fill door opener solenoid | 29 | 2 | Left side of trunk | | |
| Fuel tank pressure (FTP) sensor | 31 | 3 | Under floor | | |
| Fuel tank unit | 10 | 4 | Under left side of floor | | |
| Glass antenna coil connector A | 8 | 1 | Left C-pillar | | |
| Glass antenna coil connector B | 9 | 1 | Left C-pillar | | |
| Keyless buzzer | 22 | 2 | Behind rear bumper | | |
| Left back-up light | 25 | 2 | Left side of trunk | | |
| Left license plate light | 24 | 2 | Behind rear bumper | | |
| Left rear door switch | 6 | 1 | Left C-pillar | | |
| Left rear side marker light | 28 | 2 | Left side of trunk | | |
| Left rear speaker | 13 | 2 | Middle of rear shelf | | |
| Left rear TPMS initiator | 33 | 3 | Under floor | | |
| Left rear turn signal light | 26 | 2 | Left side of trunk | | |
| Left rear wheel speed sensor | 32 | 2 | Under floor | | |
| Left taillight/brake light | 14 | 3 | Left side of trunk | | |
| Rear bumper LF antenna | 21 | 2 | Behind rear bumper | | (1) |
| Rear interior LF antenna | 5 | 2 | Under rear seat | | (1) |
| Rear window defogger connector A (+) | 11 | 1 | Left side of rear shelf | | |
| Rearview camera | 15 | 12 | Middle of trunk | | (2) |
| Right back-up light | 19 | 2 | Right side of trunk | | |
| Right license plate light | 23 | 2 | Behind rear bumper | | |
| Right rear side marker light | 17 | 2 | Right side of trunk | | |
| Right rear turn signal light | 18 | 2 | Right side of trunk | | |
| Right taillight/brake light | 16 | 3 | Right side of trunk | | |
| Trunk lid release actuator/trunk lid latch switch | 20 | 3 | Middle of trunk | | |
| C303 | 1 | 12 | Under left side of dash | Left engine compartment wire harness (Dashboard branch) | |
| C401 | 37 | 18 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C601 | 12 | 20 | Under rear seat | Right side wire harness (Without SH-AWD) | (2) |
| C601 | 12 | 13 | Under rear seat | Right side wire harness (Without SH-AWD) | (3) |
| C771 | 35 | 13 | Left B-pillar | Left rear door wire harness | |
| G601 | 36 | | Under driver's seat | Body ground, via left side wire harness | |
| G602 | 34 | | Under rear seat | Body ground, via left side wire harness | |
| G603 | 27 | | Left side of rear | Body ground, via left side wire harness | |
| (1) With keyless access system (2) With navigation system (3) Without navigation system |
| (1) | With keyless access system |
| (2) | With navigation system |
| (3) | Without navigation system |
LEFT SIDE WIRE HARNESS CONNECTOR
Scheme 58
Left Side Wire Harness (With SH-AWD
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Condenser (for rear window defogger) | 31 | 2 | Left side of trunk | | |
| Driver's door switch | 4 | 1 | Left B-pillar | | |
| Driver's under-dash fuse/relay box connector D (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 16 | Under left side of dash | | |
| Driver's under-dash fuse/relay box connector E (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 2 | 20 | Under left side of dash | | |
| Fuel fill door opener solenoid | 32 | 2 | Left side of trunk | | |
| Fuel pump control module | 7 | 10 | Under left side of floor | | '09 model |
| Fuel pump/fuel gauge sending unit | 6 | 4 | Under left side of floor | | |
| Glass antenna coil connector A | 9 | 1 | Left C-pillar | | |
| Glass antenna coil connector B | 10 | 1 | Left C-pillar | | |
| Keyless buzzer | 24 | 2 | Behind rear bumper | | |
| Left back-up light | 27 | 2 | Left side of trunk | | |
| Left license plate light | 26 | 2 | Behind rear bumper | | |
| Left rear door switch | 5 | 1 | Left C-pillar | | |
| Left rear side marker light | 30 | 2 | Left side of trunk | | |
| Left rear speaker | 15 | 2 | Middle of rear shelf | | |
| Left rear TPMS initiator | 34 | 3 | Under floor | | |
| Left rear turn signal light | 28 | 2 | Left side of trunk | | |
| Left rear wheel speed sensor | 33 | 2 | Under floor | | |
| Left taillight/brake light | 16 | 3 | Left side of trunk | | |
| Rear bumper LF antenna | 23 | 2 | Behind rear bumper | | (1) |
| Rear interior LF antenna | 8 | 2 | Under rear seat | | (1) |
| Rear window defogger connector A (+) | 14 | 1 | Left side of rear shelf | | |
| Rearview camera | 17 | 12 | Middle of trunk | | (2) |
| Right back-up light | 21 | 2 | Right side of trunk | | |
| Right license plate light | 25 | 2 | Behind rear bumper | | |
| Right rear side marker light | 19 | 2 | Right side of trunk | | |
| Right rear turn signal light | 20 | 2 | Right side of trunk | | |
| Right taillight/brake light | 18 | 3 | Right side of trunk | | |
| Secondary fuel gauge sending unit | 11 | 4 | Under right side of floor | | |
| Trunk lid release actuator/trunk lid latch switch | 22 | 3 | Middle of trunk | | |
| C303 | 1 | 12 | Under left side of dash | Left engine compartment wire harness (Dashboard branch) | |
| C401 | 38 | 18 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C601 | 13 | 20 | Under rear seat | Right side wire harness (With SH-AWD) | |
| C602 | 12 | 2 | Under rear seat | Right side wire harness (With SH-AWD) | |
| C771 | 36 | 13 | Left B-pillar | Left rear door wire harness | |
| G601 | 37 | | Under driver's seat | Body ground, via left side wire harness | |
| G602 | 35 | | Under rear seat | Body ground, via left side wire harness | |
| G603 | 29 | | Left side of rear | Body ground, via left side wire harness | |
| (1) With keyless access system (2) With navigation system |
| (1) | With keyless access system |
| (2) | With navigation system |
LEFT SIDE WIRE HARNESS CONNECTOR
Scheme 59
SRS Floor Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt tensioner | 10 | 4 | Left B-pillar | | |
| Driver's side airbag inflator | 13 | 2 | Under driver's seat | | |
| Front passenger's seat belt tensioner | 3 | 4 | Right B-pillar | | |
| Front passenger's side airbag inflator | 17 | 2 | Under front passenger's seat | | |
| Left side curtain airbag inflator | 8 | 2 | Left C-pillar | | |
| Left side impact sensor (first) | 11 | 4 | Left B-pillar | | |
| Left side impact sensor (second) | 9 | 2 | Left C-pillar | | |
| Rear safing sensor | 7 | 4 | Under rear seat cushion | | |
| Right side curtain airbag inflator | 6 | 2 | Right C-pillar | | |
| Right side impact sensor (first) | 2 | 4 | Right B-pillar | | |
| Right side impact sensor (second) | 5 | 2 | Right C-pillar | | |
| SRS unit | 15 | 39 | Under middle of dash | | |
| C404 | 4 | 18 | Under center console | Dashboard wire harness (View of middle to passenger's side) | |
| C701 | 14 | 23 | Under driver's seat | Driver's seat wire harness | |
| C702 | 16 | 18 | Under front passenger's seat | Front passenger's seat wire harness | |
| G701 | 12 | | Under driver's seat | Body ground, via SRS floor wire harness | |
| G702 | 1 | | Under front passenger's seat | Body ground, via SRS floor wire harness | |
SRS FLOOR WIRE HARNESS CONNECTOR
Scheme 60
Right Side Wire Harness (Without SH-AWD)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Electrical compass unit | 3 | 6 | Under rear shelf | | (1) |
| Front passenger's door switch | 10 | 1 | Right B-pillar | | |
| Passenger's under-dash fuse/relay box connector G (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 15 | 16 | Under right side of dash | | |
| Rear shelf LF antenna | 1 | 2 | Under rear shelf | | (2) |
| RF unit 2 | 23 | 3 | Right C-pillar | | (2) |
| Right rear door switch | 8 | 1 | Right C-pillar | | |
| Right rear speaker | 5 | 2 | Under rear shelf | | |
| Right rear TPMS initiator | 17 | 3 | Under right side of floor | | |
| Right rear wheel speed sensor | 18 | 2 | Under right side of floor | | |
| Stereo amplifier A | 19 | 28 | Right side of trunk | | (3) |
| Stereo amplifier A | 19 | 20 | Right side of trunk | | (1) |
| Stereo amplifier B | 20 | 18 | Right side of trunk | | |
| Subwoofer | 4 | 2 | Under rear shelf | | |
| Trunk light | 2 | 2 | Under rear shelf | | |
| C410 | 11 | 8 | Under right side of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C411 | 12 | 12 | Under right side of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C509 | 13 | 28 | Under right side of dash | Audio wire harness | |
| C510 | 14 | 12 | Under right side of dash | Audio wire harness | |
| C601 | 7 | 20 | Under rear seat | Left side wire harness (Without SH-AWD) | (3) |
| C601 | 7 | 13 | Under rear seat | Left side wire harness (Without SH-AWD) | (4) |
| C781 | 9 | 13 | Right B-pillar | Right rear door wire harness | |
| G651 | 16 | | Under front passenger's seat | Body ground, via right side wire harness | |
| G653 | 21 | | Right side of rear | Body ground, via right side wire harness | |
| (1) Without navigation system (2) With keyless access system (3) With navigation system (4) Without navigation system |
| (1) | Without navigation system |
| (2) | With keyless access system |
| (3) | With navigation system |
| (4) | Without navigation system |
RIGHT SIDE WIRE HARNESS CONNECTOR
Rear Window Defogger Ground Wire (Without SH-AWD)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector B (-) | 6 | 1 | Right C-pillar | | |
| G801 | 22 | | Right C-pillar | Body ground, via rear window defogger ground | |
REAR WINDOW DEFOGGER GROUND WIRE CONNECTOR
Scheme 61
Right Side Wire Harness (With SH-AWD)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Electrical compass unit | 33 | 6 | Under rear shelf | | (1) |
| EVAP canister vent shut valve | 31 | 2 | Under right side of floor | | |
| Front passenger's door switch | 15 | 1 | Right B-pillar | | |
| Fuel tank pressure (FTP) sensor | 24 | 3 | Under right side of floor | | |
| Passenger's under-dash fuse/relay box connector H (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 19 | 38 | Under right side of dash | | |
| Rear shelf LF antenna | 1 | 2 | Under rear shelf | | (2) |
| RF unit 2 | 8 | 3 | Right C-pillar | | (2) |
| Right rear door switch | 13 | 1 | Right C-pillar | | |
| Right rear speaker | 4 | 2 | Under rear shelf | | |
| Right rear TPMS initiator | 23 | 3 | Under right side of floor | | |
| Right rear wheel speed sensor | 25 | 2 | Under right side of floor | | |
| SH-AWD control unit connector A | 10 | 8 | Under rear seat | | |
| SH-AWD control unit connector B | 9 | 20 | Under rear seat | | |
| SH-AWD relay | 11 | 4 | Under rear seat | | |
| Stereo amplifier connector A | 26 | 28 | Right side of trunk | | (3) |
| Stereo amplifier connector A | 26 | 20 | Right side of trunk | | (1) |
| Stereo amplifier connector B | 27 | 18 | Right side of trunk | | |
| Subwoofer | 3 | 2 | Under rear shelf | | |
| Trunk light | 2 | 2 | Under rear shelf | | |
| C410 | 16 | 8 | Under right side of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C411 | 20 | 12 | Under right side of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C509 | 17 | 28 | Under right side of dash | Audio wire harness | |
| C510 | 18 | 12 | Under right side of dash | Audio wire harness | |
| C601 | 5 | 20 | Under rear seat | Left side wire harness (With SH-AWD) | |
| C602 | 6 | 2 | Under rear seat | Left side wire harness (With SH-AWD) | |
| C651 (Junction connector) | 12 | 12 | Right C-pillar | | |
| C652 | 28 | 6 | Under right side of floor | Rear differential subharness | |
| C653 | 29 | 6 | Under right side of floor | Rear differential subharness | |
| C781 | 14 | 13 | Right B-pillar | Right rear door wire harness | |
| G651 | 21 | | Under front passenger's seat | Body ground, via right side wire harness | |
| G652 | 22 | | Right C-pillar | Body ground, via right side wire harness | |
| G653 | 30 | | Right side of rear | Body ground, via right side wire harness | |
| (1) Without navigation system (2) With keyless access system (3) With navigation system |
| (1) | Without navigation system |
| (2) | With keyless access system |
| (3) | With navigation system |
RIGHT SIDE WIRE HARNESS CONNECTOR
Rear Window Defogger Ground Wire (With SH-AWD)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector B (-) | 7 | 1 | Right C-pillar | | |
| G801 | 32 | | Right C-pillar | Body ground, via rear window defogger ground | |
REAR WINDOW DEFOGGER GROUND WIRE CONNECTOR
Scheme 62
Roof Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Automatic dimming inside mirror | 1 | 7 | Front of roof | | |
| Driver's vanity mirror light | 7 | 2 | Left front of roof | | |
| Front passenger's vanity mirror light | 2 | 2 | Right front of roof | | |
| HFL-navigation microphone | 6 | 7 | Front of roof | | (1) |
| Left tweeter | 12 | 2 | Front of roof | | |
| Moonroof switch | 5 | 7 | Front of roof | | |
| Roof console | 3 | 20 | Front of roof | | |
| C402 | 11 | 23 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C451 | 4 | 23 | Middle of roof | Moonroof subharness | |
| (1) With navigation system |
| (1) | With navigation system |
ROOF WIRE HARNESS CONNECTOR
Moonroof Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| High mount brake light | 9 | 2 | Rear of roof | | |
| Moonroof control unit/motor | 10 | 14 | Rear of roof | | |
| Rear individual map light | 8 | 10 | Rear of roof | | |
| C451 | 4 | 23 | Middle of roof | Roof wire harness | |
MOONROOF SUBHARNESS CONNECTOR
Scheme 63
Driver's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door lock actuator/knob switch/key cylinder switch | 17 | 10 | Driver's door | | |
| Driver's door outer handle/lock switch/touch sensor/LF antenna | 1 | 8 | Driver's door | | (1) |
| Driver's power window motor | 15 | 6 | Driver's door | | |
| Left front speaker | 14 | 2 | Driver's door | | |
| Left power mirror | 9 | 16 | Driver's door | | |
| C751 | 11 | 23 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C752 | 12 | 12 | Under left side of dash | Dashboard wire harness (View of driver's side) | |
| C753 | 6 | 28 | Driver's door | Driver's door subharness | |
| C754 | 7 | 16 | Driver's door | Driver's door subharness | |
| C755 (junction connector) | 8 | 12 | Driver's door | | |
| (1) With keyless access system |
| (1) | With keyless access system |
DRIVER'S DOOR WIRE HARNESS CONNECTOR
Driver's Door Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door courtesy light | 16 | 2 | Driver's door | | |
| Driving position memory switch | 3 | 7 | Driver's door | | |
| Power mirror control unit | 10 | 24 | Driver's door | | |
| Power mirror switch | 5 | 13 | Driver's door | | |
| Power window master switch (door multiplex control unit) | 2 | 37 | Driver's door | | |
| Trunk lid opener/fuel fill door opener switch | 13 | 6 | Driver's door | | |
| C753 | 6 | 28 | Driver's door | Driver's door wire harness | |
| C754 | 7 | 16 | Driver's door | Driver's door wire harness | |
| C756 (junction connector) | 4 | 12 | Driver's door | | |
DRIVER'S DOOR SUBHARNESS CONNECTOR
Scheme 64
Front Passenger's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door courtesy light | 6 | 2 | Front passenger's door | | |
| Front passenger's door lock actuator/knob switch | 5 | 10 | Front passenger's door | | |
| Front passenger's door outer handle/lock switch/touch sensor/LF antenna | 4 | 8 | Front passenger's door | | (1) |
| Front passenger's power window motor | 7 | 6 | Front passenger's door | | |
| Front passenger's power window switch | 3 | 37 | Front passenger's door | | |
| Right front speaker | 8 | 2 | Front passenger's door | | |
| Right power mirror | 1 | 16 | Front passenger's door | | |
| C761 | 9 | 28 | Under right side of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C762 (junction connector) | 2 | 12 | Front passenger's door | | |
| (1) With keyless access system |
| (1) | With keyless access system |
FRONT PASSENGER'S DOOR WIRE HARNESS CONNECTOR
Scheme 65
Left Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left rear door lock actuator/knob switch | 1 | 10 | Left rear door | | |
| Left rear power window motor | 5 | 2 | Left rear door | | |
| Left rear power window switch | 2 | 14 | Left rear door | | |
| Left rear speaker | 3 | 2 | Left rear door | | |
| C771 | 4 | 13 | Left B-pillar | Left side wire harness: Without SH-AWD With SH-AWD | |
LEFT REAR DOOR WIRE HARNESS CONNECTOR
Scheme 66
Right Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right rear door lock actuator/knob switch | 3 | 10 | Right rear door | | |
| Right rear power window motor | 4 | 2 | Right rear door | | |
| Right rear power window switch | 2 | 14 | Right rear door | | |
| Right rear speaker | 1 | 2 | Right rear door | | |
| C781 | 5 | 13 | Right B-pillar | Right side wire harness: Without SH-AWD With SH-AWD | |
RIGHT REAR DOOR WIRE HARNESS CONNECTOR
Scheme 67
Driver's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat rear up-down motor/position sensor | 3 | 5 | Driver's seat | | |
| Driver's power lumbar support motor | 16 | 2 | Right side of seat-back | | |
| Driver's power lumbar support switch | 5 | 5 | Left side of driver's seat | | |
| Driver's power seat adjustment switch | 6 | 12 | Left side of driver's seat | | |
| Driver's seat back heater | 1 | 2 | Driver's seat | | |
| Driver's seat belt buckle switch | 12 | 2 | Driver's seat | | |
| Driver's seat cushion heater | 11 | 3 | Driver's seat | | |
| Driver's seat front up-down motor/position sensor | 15 | 5 | Driver's seat | | |
| Driver's seat heater relay (high) | 14 | 4 | Driver's seat | | |
| Driver's seat heater relay (low) | 13 | 5 | Driver's seat | | |
| Driver's seat position sensor | 4 | 2 | Driver's seat | | |
| Driver's seat recline motor/position sensor | 2 | 5 | Bottom of seat back | | |
| Driver's seat slide motor/position sensor | 9 | 5 | Driver's seat | | |
| Power seat control unit connector A | 8 | 18 | Under driver's seat | | |
| Power seat control unit connector B | 10 | 40 | Under driver's seat | | |
| C701 | 7 | 23 | Under driver's seat | SRS floor wire harness | |
DRIVER'S SEAT WIRE HARNESS CONNECTOR
Scheme 68
Front Passenger's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's seat adjustment switch | 10 | 12 | Right side of front passenger's seat | | |
| Front passenger's seat belt buckle switch | 7 | 2 | Front passenger's seat | | |
| Front passenger's seat cushion heater | 6 | 4 | Front passenger's seat | | |
| Front passenger's seat front up-down motor | 2 | 2 | Front passenger's seat | | |
| Front passenger's seat heater relay (high) | 5 | 4 | Front passenger's seat | | |
| Front passenger's seat heater relay (low) | 4 | 5 | Front passenger's seat | | |
| Front passenger's seat rear up-down motor | 11 | 2 | Front passenger's seat | | |
| Front passenger's seat recline motor | 13 | 2 | Bottom of seat back | | |
| Front passenger's seat slide motor | 9 | 5 | Front passenger's seat | | |
| Front passenger's seat weight sensor (inner side) | 3 | 2 | Front passenger's seat | | |
| Front passenger's seat weight sensor (outer side) | 12 | 3 | Front passenger's seat | | |
| ODS unit | 1 | 18 | Left side of seat-back | | |
| C702 | 8 | 18 | Under front passenger's seat | SRS floor wire harness | |
FRONT PASSENGER'S SEAT WIRE HARNESS CONNECTOR
Scheme 69
Cable Reel Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Audio remote switch, HFL-navigation voice control switch | 1 | 12 | Steering wheel | | |
| Cable reel connector C | 3 | 20 | Steering wheel | | |
| Cruise control combination/select/reset/information switch | 6 | 12 | Steering wheel | | |
| Paddle shifter + (Upshift switch) | 5 | 4 | Steering wheel | | A/T |
| Paddle shifter - (Downshift switch) | 2 | 4 | Steering wheel | | A/T |
| Horn switch | 7 | 1 | Steering wheel | | |
| T9 | 4 | | Steering wheel | Steering wheel | |
CABLE REEL SUBHARNESS CONNECTOR
Scheme 70
A/C Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Blower motor | 7 | 2 | Under right side of dash | | |
| Climate control unit connector A | 12 | 32 | Under right side of dash | | |
| Climate control unit connector B | 11 | 24 | Under right side of dash | | |
| Climate control unit connector C | 9 | 20 | Under right side of dash | | |
| Driver's air mix control motor | 15 | 7 | Under middle of dash | | |
| Driver's mode control motor | 16 | 7 | Under middle of dash | | |
| Evaporator temperature sensor | 17 | 2 | Under middle of dash | | |
| Front passenger's footwell light | 8 | 2 | Under right side of dash | | |
| Passenger's air mix control motor | 13 | 7 | Under middle of dash | | |
| Passenger's mode control motor | 5 | 7 | Under middle of dash | | |
| Power transistor | 3 | 5 | Under middle of dash | | |
| Recirculation control motor | 4 | 7 | Under middle of dash | | |
| C205 | 6 | 2 | Under right side of dash | Right engine compartment wire harness | |
| C301 | 1 | 2 | Under middle of dash | Left engine compartment wire harness (Dashboard branch) | |
| C302 | 2 | 2 | Under middle of dash | Left engine compartment wire harness (Dashboard branch) | |
| C403 | 14 | 20 | Under middle of dash | Dashboard wire harness (View of middle to passenger's side) | |
| C501 | 10 | 20 | Under middle of dash | Audio wire harness | |
A/C WIRE HARNESS CONNECTOR
Scheme 71
EPS Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| EPS motor | 3 | 3 | Middle of engine compartment | | |
| EPS motor angle sensor | 8 | 6 | Middle of engine compartment | | |
| Torque sensor | 4 | 3 | Middle of engine compartment | | |
| C202 | 2 | 3 | Right of engine compartment | Right engine compartment wire harness | |
| C203 | 1 | 12 | Right of engine compartment | Right engine compartment wire harness | |
| T6 | 5 | | Middle of engine compartment | Steering gearbox | |
| T7 | 6 | | Middle of engine compartment | Steering gearbox | |
| T8 | 7 | | Middle of engine compartment | Steering gearbox | |
Scheme 72
Rear Differential Subharness (With SH-AWD)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Differential fluid temperature sensor | 6 | 2 | Rear differential | | |
| Left clutch electromagnetic coil/search coil | 1 | 4 | Rear differential | | |
| Right clutch electromagnetic coil/search coil | 3 | 4 | Rear differential | | |
| C652 | 5 | 6 | Rear differential | Right side wire harness (With SH-AWD) | |
| C653 | 4 | 6 | Rear differential | Right side wire harness (With SH-AWD) | |
| T10 | 2 | | Rear differential | | |
REAR DIFFERENTIAL SUBHARNESS CONNECTOR
Scheme 73
