Starter Cable (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | T3 | | Left Side of Engine | Starter Motor | |
| 2 | T101 | Left Rear of Engine Compartment | Under-hood Fuse/Relay Box |
| 3 | (+) | Left Front of Engine Compartment | Positive Battery Terminal |
Battery Ground Cable (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 4 | (-) | | Left Front of Engine Compartment | Negative Battery Terminal | |
| 5 | G1 | Left Front of Engine Compartment | Body Ground via Battery Ground Cable |
Transmission Ground Cable (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 6 | G3 | | Under Left Front of Engine Compartment | Body Ground via Transmission Ground Cable | |
| 7 | T2 | Transmission Housing | Transmission Housing |
Engine Ground Cable (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 8 | T1 | | Right Side of Engine Compartment | Engine | |
| 9 | G2 | Right Side of Engine Compartment | Body Ground via Engine Ground Cable |
Identifying Engine Ground Cable, Starter Cable, Battery Ground Cable And Transmission Ground Cable (Page 203-1). Scheme 509
Scheme 509: Identifying Engine Ground Cable, Starter Cable, Battery Ground Cable And Transmission Ground Cable (Page 203-1)
Starter Cable (M/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | T101 | | Left Rear of Engine Compartment | Under-hood Fuse/Relay Box | |
| 2 | (+) | Left Front of Engine Compartment | Positive Battery Terminal |
| 5 | T3 | Left Side of Engine | Starter Motor |
Battery Ground Cable (M/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 3 | (-) | | Left Front of Engine Compartment | Negative Battery Terminal | |
| 4 | G1 | Left Front of Engine Compartment | Body Ground via Battery Ground Cable |
Transmission Ground Cable (M/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 6 | G3 | | Under Left Front of Engine Compartment | Body Ground via Transmission Ground Cable | |
| 7 | T2 | Transmission Housing | Transmission Housing |
Engine Ground Cable (M/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 8 | T1 | | Right Side of Engine Compartment | Engine | |
| 9 | G2 | Right Side of Engine Compartment | Body Ground via Engine Ground Cable |
Identifying Starter Cable (M/T), Transmission Ground Cable , Battery Ground Cable, Engine Wire Harness (Page 203-3). Scheme 510
Scheme 510: Identifying Starter Cable (M/T), Transmission Ground Cable , Battery Ground Cable, Engine Wire Harness (Page 203-3)
Engine Wire Harness (Engine Section) (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | IMT Actuator | 5-BLK | Right Side of Engine | | |
| 2 | Injector No. 1 | 2-GRY | Middle of Engine |
| 3 | Ignition Coil No. 1 | 3-BLU | Rear of Engine |
| 4 | Injector No. 2 | 2-GRY | Middle of Engine |
| 5 | Ignition Coil No. 2 | 3-BLU | Rear of Engine |
| 6 | C103 (Junction Connector) | 24-BLK/GRY | Rear of Engine |
| 7 | Injector No. 3 | 2-GRY | Middle of Engine |
| 8 | Ignition Coil No. 3 | 3-BLU | Rear of Engine |
| 9 | Rear A/F Sensor (B1, S1) | 6-BLK | Rear of Engine |
| 10 | EVAP Canister Purge Valve | 2-BLK | Left Side of Engine | LEV2 |
| 11 | Engine Mount Control Solenoid Valve | 2-GRY | Left Side of Engine |
| 12 | Rear Secondary HO2S (B1, S2) | 4-BLK | Rear of Engine |
| 13 | CKP Sensor | 3-BLK | Under Rear of Engine |
| 14 | 2nd Clutch Transmission Fluid Pressure Switch | 1-BLU | Under Rear of Transmission Housing |
| 15 | MAP Sensor | 3-BLK | Left Side of Engine |
| 16 | TP Sensor/Throttle Actuator | 6-BLK | Left Side of Engine |
| 17 | T102 | | Left Rear of Engine Compartment | Under-hood Fuse/Relay Box |
| 18 | MAF/IAT Sensor | 5-BLK | Left Side of Engine Compartment |
| 19 | C102 (Female) | 1-BLU | Left Side of Engine Compartment | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| 20 | C101 (Female) | 13-BLK/GRY | Left Side of Engine Compartment | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| 21 | C106 (Junction Connector) | 24-BLK/GRY | Transmission Housing |
| 22 | C107 (Junction Connector) | 24-BLK/GRY | Transmission Housing |
| 23 | C105 (Junction Connector) | 12-BLK/GRY | Transmission Housing |
| 24 | A/T Clutch Pressure Control Solenoid Valve C | 2-BLK | Transmission Housing |
| 25 | ECT Sensor 1 | 2-BLK | Left Side of Engine |
Identifying Engine Wire Harness And Knock Sensor Sub Harness (Page 203-5). Scheme 511
Scheme 511: Identifying Engine Wire Harness And Knock Sensor Sub Harness (Page 203-5)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 26 | EGR Valve and EGR Valve Position Sensor | 5-BLK | Left Side of Engine | | |
| 27 | Injector No. 6 | 2-GRY | Middle of Engine |
| 29 | Ignition Coil No. 6 | 3-BLU | Front of Engine |
| 30 | Front Secondary HO2S (B2, S2) | 4-BLK | Front of Engine |
| 31 | Front A/F Sensor (B2, S1) | 6-BLK | Front of Engine |
| 32 | Ignition Coil No. 5 | 3-BLU | Front of Engine |
| 33 | A/C Compressor Clutch | 1-BLU/BLK | Front of Engine |
| 34 | Alternator | 4-BLU | Front of Engine |
| 35 | Injector No. 5 | 2-GRY | Middle of Engine |
| 36 | T4 | | Front of Engine | Alternator |
| 37 | Ignition Coil No. 4 | 3-BLU | Front of Engine |
| 38 | Injector No. 4 | 2-GRY | Middle of Engine |
| 39 | CMP Sensor | 3-BLK | Right Side of Engine |
| 40 | ECM/PCM Connector B | 49-BLK/GRY | Right Side of Engine Compartment |
| 41 | ECM/PCM Connector C | 49-BLK/GRN | Right Side of Engine Compartment |
| 42 | C104 (Female) | 1-BLU | Right Side of Engine | KNOCK SENSOR SUB-HARNESS |
| 43 | Rocker Arm Oil Control Solenoid | 1-BLU/BLK | Under Right Side of Engine |
| 44 | Oil Pressure Switch | 1-BLK | Under Right Side of Engine |
| 45 | Rocker Arm Oil Pressure Switch | 2-GRY | Under Right Side of Engine |
| 46 | G101 | Right Side of Engine | Body Ground via Engine Wire Harness |
Knock Sensor Sub-harness (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 28 | Knock Sensor | 1-BLU | Middle of Engine | | |
| 42 | C104 (Male) | 1-BUK | Right Side of Engine | ENGINE WIRE HARNESS |
Identifying Engine Wire Harness And Knock Sensor Sub-Harness (Page 203-7). Scheme 512
Scheme 512: Identifying Engine Wire Harness And Knock Sensor Sub-Harness (Page 203-7)
Engine Wire Harness (Transmission Section) (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Starter Solenoid | 1-BLK | Left Side of Engine | | |
| 6 | 4th Clutch Transmission Fluid Pressure Switch | 1-BLU | Transmission Housing |
| 7 | A/T Clutch Pressure Control Solenoid Valve A | 2-BLK | Transmission Housing |
| 8 | A/T Clutch Pressure Control Solenoid Valve B | 2-BRN | Transmission Housing |
| 9 | ATF Temperature Sensor | 2-GRY | Under Transmission Housing |
| 10 | Transmission Range Switch | 10-BLK/GRY | Transmission Housing |
| 11 | Output Shaft (Countershaft) Speed Sensor | 3-BLK | Under Transmission Housing |
| 12 | 3rd Clutch Transmission Fluid Pressure Switch | 1-BLU | Under Transmission Housing |
| 13 | Input Shaft (Mainshaft) Speed Sensor | 3-BLU | Under Transmission Housing |
| 14 | C108 (Female) | 5-BLK | Transmission Housing | SHIFT SOLENOID WIRE HARNESS |
Shift Solenoid Wire Harness (A/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 2 | Shift Control Solenoid Valve A | 1-N/A | In Transmission | | |
| 3 | Shift Control Solenoid Valve C | 1-N/A | In Transmission |
| 4 | Shift Control Solenoid Valve D | 1-N/A | In Transmission |
| 5 | Shift Control Solenoid Valve B | 1-N/A | In Transmission |
| 14 | C108 (Male) | 5-GRY | Transmission Housing | ENGINE WIRE HARNESS |
Identifying Shift Solenoid Wire Harness And Engine Wire Harness (Page 203-9). Scheme 513
Scheme 513: Identifying Shift Solenoid Wire Harness And Engine Wire Harness (Page 203-9)
Engine Wire Harness (Engine Section) (M/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | IMT Actuator | 5-BLK | Right Side of Engine | | |
| 2 | Injector No. 1 | 2-GRY | Middle of Engine |
| 3 | Ignition Coil No. 1 | 3-BLU | Rear of Engine |
| 4 | Injector No. 2 | 2-GRY | Middle of Engine |
| 5 | Ignition Coil No. 2 | 3-BLU | Rear of Engine |
| 6 | C103 (Junction Connector) | 24-BLK/GRY | Rear of Engine |
| 7 | Injector No. 3 | 2-GRY | Middle of Engine |
| 8 | Ignition Coil No. 3 | 3-BLU | Rear of Engine |
| 9 | Rear A/F Sensor (B1, S1) | 6-BLK | Rear of Engine |
| 10 | EVAP Canister Purge Valve | 2-BLK | Left Side of Engine | LEV2 |
| 11 | Engine Mount Control Solenoid Valve | 2-GRY | Left Side of Engine |
| 12 | Rear Secondary HO2S (B1, S2) | 4-BLK | Rear of Engine |
| 13 | CKP Sensor | 3-BLK | Under Rear of Engine |
| 14 | MAP Sensor | 3-BLK | Left Side of Engine |
| 15 | TP Sensor/Throttle Actuator | 6-BLK | Left Side of Engine |
| 16 | T102 | | Left Rear of Engine Compartment | Under-hood Fuse/Relay Box |
| 17 | MAF/IAT Sensor | 5-BLK | Left Side of Engine Compartment |
| 18 | C102 (Female) | 1-BLU | Left Side of Engine Compartment | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| 19 | C101 (Female) | 13-BLK/GRY | Left Side of Engine Compartment | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| 20 | C106 (Junction Connector) | 24-BLK/GRY | Transmission Housing |
| 21 | C107 (Junction Connector) | 24-BLK/GRY | Transmission Housing |
| 22 | Reverse Lockout Solenoid | 2-BLK | Left Side of Engine Compartment |
| 23 | ECT Sensor 1 | 2-BLK | Left Side of Engine |
Identifying Wire Harness Knock Sensor Sub-Harness (Page 203-11). Scheme 514
Scheme 514: Identifying Wire Harness Knock Sensor Sub-Harness (Page 203-11)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 24 | EGR Valve and EGR Valve Position Sensor | 5-BLK | Left Side of Engine | | |
| 25 | Injector No. 6 | 2-GRY | Middle of Engine |
| 27 | Ignition Coil No. 6 | 3-BLU | Front of Engine |
| 28 | Front A/F Sensor (B2, S1) | 6-BLK | Front of Engine |
| 29 | Ignition Coil No. 5 | 3-BLU | Front of Engine |
| 30 | A/C Compressor Clutch | 1-BLU/BLK | Front of Engine |
| 31 | Alternator | 4-BLU | Front of Engine |
| 32 | Injector No. 5 | 2-GRY | Middle of Engine |
| 33 | T4 | | Front of Engine | Alternator |
| 34 | Ignition Coil No. 4 | 3-BLU | Front of Engine |
| 35 | Injector No. 4 | 2-GRY | Middle of Engine |
| 36 | CMP Sensor | 3-BLK | Right Side of Engine |
| 37 | ECM/PCM Connector B | 49-BLK/GRY | Right Side of Engine Compartment |
| 38 | ECM/PCM Connector C | 49-BLK/GRN | Right Side of Engine Compartment |
| 39 | C104 (Female) | 1-BLU | Right Side of Engine | KNOCK SENSOR SUB-HARNESS |
| 40 | Rocker Arm Oil Control Solenoid | 1-BLU/BLK | Under Right Side of Engine |
| 41 | Oil Pressure Switch | 1-BLK | Under Right Side of Engine |
| 42 | Rocker Arm Oil Pressure Switch | 2-GRY | Under Right Side of Engine |
| 43 | G101 | | Right Side of Engine | Body Ground via Engine Wire Harness |
Knock Sensor Sub-harness (M/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 26 | Knock Sensor | 1-BLU | Middle of Engine | | |
| 39 | C104 (Male) | 1-BLK | Right Side of Engine | ENGINE WIRE HARNESS |
Identifying Engine Wire Harness And Knock Sensor Sub-Harness (Page 203-13). Scheme 515
Scheme 515: Identifying Engine Wire Harness And Knock Sensor Sub-Harness (Page 203-13)
Engine Wire Harness (Transmission Section) (M/T)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Output Shaft (Countershaft) Speed Sensor | 3-BLK | Under Transmission Housing | | |
| 2 | Starter Solenoid | 1-BLK | Left Side of Engine |
| 3 | Back-up Light Switch | 2-GRY | Transmission Housing |
| 4 | Input Shaft (Mainshaft) Speed Sensor | 3-BLU | Under Transmission Housing |
| 5 | Front Secondary HO2S (B2, S2) Sensor | 4-BLK | Front of Engine |
Identifying Engine Wire Harness (Page 203-15). Scheme 516
Scheme 516: Identifying Engine Wire Harness (Page 203-15)
Left Engine Compartment Wire Harness (Engine Compartment Branch)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | ECM/PCM Connector A | 49-BLK/WHT | Right Side of Engine Compartment | | |
| 2 | Security Hood Switch | 2-BLK | Behind Middle of Front Grille |
| 3 | Left Headlight Connector A | 2-BLK | Left Front Wheelwell |
| 4 | Left Headlight Connector B | 2-BLU | Left Front of Engine Compartment |
| 5 | C101 (Female) | 13-BLK/GRY | Left Side of Engine Compartment | Engine Wire Harness (see ENGINE WIRE HARNESS (ENGINE SECTION) (A/T) or ENGINE WIRE HARNESS (ENGINE SECTION) (M/T) ) |
| 6 | C102 (Male) | 1-BLK | Left Side of Engine Compartment | Engine Wire Harness (see ENGINE WIRE HARNESS (ENGINE SECTION) (A/T) or ENGINE WIRE HARNESS (ENGINE SECTION) (M/T) ) |
| 7 | Under-hood Fuse/Relay Box Connector C (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 5-WHT | Left Rear of Engine Compartment |
| 8 | Under-hood Fuse/Relay Box Connector B (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 14-WHT | Left Rear of Engine Compartment |
| 9 | Under-hood Fuse/Relay Box Connector A (ELD Unit) (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 3-WHT | Left Rear of Engine Compartment |
| 10 | Brake Fluid Level Switch | 2-GRY | Left Rear of Engine Compartment |
| 11 | Windshield Wiper Motor | 4-BLK | Under Left Side of Cowl Cover |
| 12 | Left Front Wheel Speed Sensor | 2-BLK | Left Front Wheelwell |
| 13 | Left Front Side Marker Light | 2-BLK | Left Front Wheelwell |
| 14 | G301 | | Behind Left Side of Front Bumper | Body Ground, via Left Engine Compartment Wire Harness |
| 15 | Left Front Impact Sensor | 2-YEL | Behind Left Side of Front Bumper |
| 16 | Left Fog Light | 2-BLK | Behind Left Side of Front Bumper |
| 17 | Left Front Turn Signal/Parking Light | 3-WHT | Behind Left Side of Front Bumper |
| 18 | High Horn | 1-BLK | Behind Left Side of Front Bumper |
| 19 | ECT Sensor 2 | 2-BLK | Under Left Front of Engine Compartment |
| 20 | Radiator Fan Motor | 2-BLK | Under Left Front of Engine Compartment |
| 21 | Outside Air Temperature Sensor | 2-GRY | Behind Left Side of Front Bumper |
| 22 | A/C Condenser Fan Motor | 2-BLK | Under Middle Front Of Engine Compartment |
| 23 | C201 (Female) | 2-BLK | Behind Right Side of Front Bumper | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| 24 | Low Horn | 1-BLK | Behind Right Side of Front Bumper |
Identifying Left Engine Compartment Wire Harness (Page 203-17). Scheme 517
Scheme 517: Identifying Left Engine Compartment Wire Harness (Page 203-17)
Left Engine Compartment Wire Harness (Dashboard Branch)
Identifying Left Engine Compartment Wire Harness (Page 203-19). Scheme 518
Scheme 518: Identifying Left Engine Compartment Wire Harness (Page 203-19)
Right Engine Compartment Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | G203 | | Under Right Side of Dash | Body Ground via Right Engine Compartment Wire Harness | |
| 2 | G204 | | Under Right Side of Dash | Body Ground via Right Engine Compartment Wire Harness |
| 3 | EPS Control Unit Connector C | 2-BLK | Under Right Side of Dash |
| 4 | EPS Control Unit Connector B | 2-BLU | Under Right Side of Dash |
| 5 | EPS Control Unit Connector D | 28-GRY | Under Right Side of Dash |
| 6 | EPS Control Unit Connector A | 2-BLU | Under Right Side of Dash |
| 7 | C207 (Male) | 2-N/A | Under Right Side of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | Headlight Washer |
| 8 | C204 (Junction Connector) | 12-WHT | Under Right Side of Dash |
| 9 | C203 (Female) | 12-BLK | Right Rear of Engine Compartment | EPS Sub-harness (see EPS SUB-HARNESS ) |
| 10 | C202 (Male) | 3-BLK/WHT | Right Rear of Engine Compartment | EPS Sub-harness (see EPS SUB-HARNESS ) |
| 11 | A/C Pressure Sensor | 3-BLK | Right Rear of Engine Compartment |
| 12 | VSA Modulator-Control Unit | 47-BLK/WHT | Right Side of Engine Compartment |
| 13 | Right Headlight Connector A | 2-GRY | Right Front Wheelwell |
| 14 | Right Headlight Connector B | 2-BLU | Right Front of Engine Compartment |
| 15 | C201 (Male) | 2-BLK | Behind Right Side of Front Bumper | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) |
| 16 | G201 | Behind Right Side of Front Bumper | Body Ground via Right Engine Compartment Wire Harness |
Identifying Right Engine Compartment Wire Harness (Page 203-21). Scheme 519
Scheme 519: Identifying Right Engine Compartment Wire Harness (Page 203-21)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 17 | G202 | | Behind Right Side of Front Bumper | Body Ground via Right Engine Compartment Wire Harness | |
| 18 | Right Front Turn Signal/Parking Light | 3-WHT | Behind Right Side of Front Bumper |
| 19 | Right Fog Light | 2-BLK | Behind Right Side of Front Bumper |
| 20 | Right Front Impact Sensor | 2-YEL | Behind Right Side of Front Bumper |
| 21 | Washer Fluid Level Switch | 2-N/A | Behind Right Side of Front Bumper | Canada, Mexico |
| 22 | Headlight Washer Motor | 2-N/A | Behind Right Side of Front Bumper | Headlight Washer |
| 23 | Windshield Washer Motor | 2-BLK | Behind Right Side of Front Bumper |
| 24 | Right Front Side Marker Light | 2-BLK | Right Front Wheelwell |
| 25 | Right Front Wheel Speed Sensor | 2-BLK | Right Front Wheelwell |
| 26 | Right Front TPMS Initiator | 3-BLK | Right Front Wheelwell |
| 27 | C205 (Female) | 2-WHT | Under Right Side of Dash | A/C Harness (see A/C WIRE HARNESS ) |
| 28 | C208 (Male) | 4-YEL | Behind Right Kick Panel | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 29 | Passenger's Under-dash Fuse/Relay Box Connector E (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 18-LT GRN | Behind Right Kick Panel |
| 30 | Passenger's Under-dash Fuse/Relay Box Connector B (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 1-LT GRN | Behind Right Kick Panel |
| 31 | C206 (Male) | 20-WHT | Under Right Side of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
Identifying Right Engine Compartment Wire Harness (Page 203-23). Scheme 520
Scheme 520: Identifying Right Engine Compartment Wire Harness (Page 203-23)
Dashboard Wire Harness (View of Driver's Side)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C752 (Female) | 12-WHT | Left A-Pillar | Driver's Door Wire Harness (see DRIVER'S DOOR WIRE HARNESS ) | |
| 2 | C751 (Female) | 23-WHT | Left A-Pillar | Driver's Door Wire Harness (see DRIVER'S DOOR WIRE HARNESS ) |
| 3 | Keyless Access Junction Box Connector A | 6-BLU | Under Left Side of Dash | Keyless Access |
| 4 | Keyless Access Junction Box Connector B | 6-BRN | Under Left Side of Dash | Keyless Access |
| 5 | Keyless Access Junction Box Connector C | 8-BRN | Under Left Side of Dash | Keyless Access |
| 6 | Keyless Access Junction Box Connector E | 10-WHT | Under Left Side of Dash | Keyless Access |
| 7 | Keyless Access Junction Box Connector F | 8-WHT | Under Left Side of Dash | Keyless Access |
| 8 | Keyless Access Junction Box Connector H | 10-BLU | Under Left Side of Dash | Keyless Access |
| 9 | Keyless Access Junction Box Connector G | 10-LT GRN | Under Left Side of Dash | Keyless Access |
| 10 | Keyless Access Junction Box Connector D | 4-WHT | Under Left Side of Dash | Keyless Access |
| 11 | G402 | Under Left Side of Dash | Body Ground via Dashboard Wire Harness |
| 12 | G401 | Behind Left Side of Dash | Body Ground via Dashboard Wire Harness |
| 13 | C402 (Female) | 23-WHT | Under Middle of Dash | Roof Wire Harness (see ROOF WIRE HARNESS ) |
| 14 | Driver's Junction Box 2 Connector B | 6-BRN | Behind Left Side of Dash |
| 15 | Driver's Junction Box 2 Connector C | 8-BRN | Behind Left Side of Dash |
| 16 | Driver's Junction Box 2 Connector E | 10-WHT | Behind Left Side of Dash |
| 17 | Driver's Junction Box 2 Connector F | 8-WHT | Behind Left Side of Dash |
| 18 | Driver's Junction Box 2 Connector H | 10-BLU | Behind Left Side of Dash |
| 19 | Driver's Junction Box 2 Connector G | 10-LT GRN | Behind Left Side of Dash |
| 20 | Driver's Junction Box 2 Connector D | 4-WHT | Behind Left Side of Dash |
| 21 | Driver's Junction Box 2 Connector A | 6-BLU | Behind Left Side of Dash |
| 22 | Gauge Control Module | 32-GRY | Left Side of Dash |
Identifying Driver's Junction Box, Keyless Access Junction Box And Center Junction Box (Page 203-25). Scheme 521
Scheme 521: Identifying Driver's Junction Box, Keyless Access Junction Box And Center Junction Box (Page 203-25)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 23 | Driver's Junction Box 1 Connector C | 8-BRN | Behind Left Side of Dash | | |
| 24 | Driver's Junction Box 1 Connector E | 10-WHT | Behind Left Side of Dash |
| 25 | Driver's Junction Box 1 Connector F | 8-WHT | Behind Left Side of Dash |
| 26 | Driver's Junction Box 1 Connector H | 10-WHT | Behind Left Side of Dash |
| 27 | Driver's Junction Box 1 Connector G | 10-LT GRN | Behind Left Side of Dash |
| 28 | Driver's Junction Box 1 Connector D | 4-WHT | Behind Left Side of Dash |
| 29 | Driver's Junction Box 1 Connector A | 6-BLU | Behind Left Side of Dash |
| 30 | Driver's Junction Box 1 Connector B | 6-BRN | Behind Left Side of Dash |
| 31 | Center Junction Box Connector F | 6-BLU | Under Left Side of Dash |
| 32 | Center Junction Box Connector G | 6-BRN | Under Left Side of Dash |
| 33 | Center Junction Box Connector K | 10-WHT | Under Left Side of Dash |
| 34 | Center Junction Box Connector J | 8-WHT | Under Left Side of Dash |
| 35 | Center Junction Box Connector H | 4-WHT | Under Left Side of Dash |
| 36 | Center Junction Box Connector E | 6-GRY | Under Left Side of Dash |
| 37 | Center Junction Box Connector A | 4-GRY | Under Left Side of Dash |
| 38 | Center Junction Box Connector B | 4-BLU | Under Left Side of Dash |
| 39 | Center Junction Box Connector C | 4-BRN | Under Left Side of Dash |
| 40 | Center Junction Box Connector D | 6-WHT | Under Left Side of Dash |
| 41 | Console Accessory Power Socket Relay | 4-BLK | Under Left Side of Dash |
| 42 | Front Accessory Power Socket Relay | 4-N/A | Under Left Side of Dash | Keyless Access: without Headlight Washer |
| 42 | Headlight Washer Relay | 4-BLK | Under Left Side of Dash | Headlight Washer |
| 43 | TPMS Control Unit | 20-GRY | Under Left Side of Dash |
| 44 | Front Accessory Power Socket Relay | 4-N/A | Under Left Side of Dash | Keyless Access |
| 44 | ACC Cut Relay | 5-GRY | Under Left Side of Dash | Headlight Washer without Keyless Access |
| 45 | IG2 Cut Relay | 5-GRY | Under Left Side of Dash | Without Keyless Access |
| 45 | +B Cut Relay | 4-BLK | Under Left Side of Dash | M/T |
| 46 | Driver's Under Dash Fuse/Relay Box (Driver's MICU) Connector Q (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 20-LT GRN | Behind Left Kick Panel |
Identifying Driver's Junction Box, Keyless Access Junction Box And Center Junction Box (Page 203-27). Scheme 522
Scheme 522: Identifying Driver's Junction Box, Keyless Access Junction Box And Center Junction Box (Page 203-27)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 47 | Driver's Under-dash Fuse/Relay Box (Driver's MICU) Connector R (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 24-LT GRN | Behind Left Kick Panel | | |
| 48 | Driver's Under-dash Fuse/Relay Box Connector M (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 4-YEL | Behind Left Kick Panel |
| 49 | Driver's Under-dash Fuse/Relay Box Connector N (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 16-LT GRN | Behind Left Kick Panel |
| 50 | Driver's Under-dash Fuse/Relay Box Connector P (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 20-LT GRN | Behind Left Kick Panel |
| 51 | Driver's Under-dash Fuse/Relay Box Connector C (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 5-LT GRN | Behind Left Kick Panel |
| 52 | Driver's Under-dash Fuse/Relay Box Connector B (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 2-LT GRN | Behind Left Kick Panel |
| 53 | Dash Lights Brightness Controller | 6-GRN | Left Side of Dash |
| 54 | Power Control Unit Connector B | 4-WHT | Under Left Side of Dash | Keyless Access |
| 55 | Power Control Unit Connector A | 1-WHT | Under Left Side of Dash | Keyless Access |
| 56 | Headlight Washer Switch | 6-N/A | Left Side of Dash | Headlight Washer |
| 57 | VSA OFF Switch | 5-WHT | Left Side of Dash |
| 58 | Driver's Footwell Light | 2-GRY | Under Left Side of Dash |
| 59 | Power Control Unit Connector C | 36-LT BLU | Under Left Side of Dash | Keyless Access |
| 60 | Keyless Access Control Unit Connector C | 5-GRY | Under Left Side of Dash | Keyless Access |
| 61 | Keyless Access Control Unit Connector B | 32-GRY | Under Left Side of Dash | Keyless Access |
| 62 | Keyless Access Control Unit Connector A | 36-GRY | Under Left Side of Dash | Keyless Access |
| 63 | DLC | 16-GRY | Under Left Side of Dash |
| 64 | C305 (Male) | 4-YEL | Under Left Side of Dash | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) |
| 65 | C306 (Male) | 24-WHT | Under Left Side of Dash | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) |
| 66 | C401 (Male) | 18-WHT | Under Left Side of Dash | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (SH-AWD) or LEFT SIDE WIRE HARNESS (SH-AWD) ) |
| 67 | C304 (Male) | 2-N/A | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | Headlight Washer |
| 68 | Auxiliary Under-dash Fuse Holder | 2-NAT | Under Left Side of Dash | Without Keyless Access |
| 69 | Remote Engine Start Connector | 2-WHT | Under Left Side of Dash | Option Connector |
Identifying Driver's Junction Box, Keyless Access Junction Box And Center Junction Box (Page 203-29). Scheme 523
Scheme 523: Identifying Driver's Junction Box, Keyless Access Junction Box And Center Junction Box (Page 203-29)
Dashboard Wire Harness (View of Middle to Passenger's Side)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Steering Angle Sensor | 5-GRN | In Steering Column Cover | | |
| 2 | Combination Light Switch | 12-BLK/WHT | In Steering Column Cover |
| 3 | Electric Steering Lock Control Unit | 12-GRY | In Steering Column Cover | Keyless Access |
| 4 | Cable Reel Connector B | 20-WHT | In Steering Column Cover | Cable Reel Connector C (see CABLE REEL SUB-HARNESS ) |
| 5 | Cable Reel Connector A | 4-YEL | In Steering Column Cover |
| 6 | Wiper/Washer Switch | 8-BLK/WHT | In Steering Column Cover |
| 7 | Immobilizer-Keyless Control Unit | 7-WHT | In Steering Column Cover | Without Keyless Access |
| 8 | Humidity/In-car Temperature Sensor | 4-WHT | Left Side of Dash |
| 9 | Remote Slot | 16-GRY | Left Side of Dash | Keyless Access |
| 10 | Engine Start/Stop Switch | 10-WHT | Left Side of Dash | Keyless Access |
| 11 | Front Center Speaker | 2-GRY | Middle of Dash |
| 12 | Driver's Climate Control Switch | 16-GRY | Middle of Dash |
| 13 | Sunlight Sensor | 2-GRN | Middle of Dash |
| 14 | Automatic Lighting Sensor | 5-GRN | Middle of Dash |
| 15 | Hazard Warning Switch/Front Passenger's Airbag Cut-off Indicator | 6-WHT | Middle of Dash | USA, Canada |
| 16 | C408 (Junction Connector) | 12-BLU | Behind Glove Box |
| 17 | C406 (Female) | 34-WHT | Behind Glove Box | Audio Wire Harness (see AUDIO WIRE HARNESS ) |
| 18 | C407 (Female) | 12-WHT | Behind Glove Box | Audio Wire Harness (see AUDIO WIRE HARNESS ) | Keyless Access |
| 19 | Front Passenger's Airbag First and Second Inflators | 4-YEL | Behind Glove Box |
| 20 | Right Tweeter | 2-BLK | Right A-pillar |
| 21 | C409 (Junction Connector) | 20-ORN | Behind Glove Box |
| 22 | G405 | | Right Side of Dash | Body Ground via Dashboard Wire Harness |
| 23 | Remote Slot Control Unit | 40-GRY | Behind Glove Box | Keyless Access |
| 24 | C761 (Female) | 28-WHT | Right A-pillar | Front Passenger's Door Wire Harness (see FRONT PASSENGER'S DOOR WIRE HARNESS ) |
| 25 | C410 (Female) | 8-WHT | Under Right Side of Dash | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or RIGHT SIDE WIRE HARNESS (SH-AWD) ) |
Identifying Dashboard Wire Harness And Console Sub-Harness (Page 203-31). Scheme 524
Scheme 524: Identifying Dashboard Wire Harness And Console Sub-Harness (Page 203-31)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 26 | C411 (Female) | 12-WHT | Under Right Side of Dash | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or REAR WINDOW DEFOGGER GROUND WIRE (SH-AWD) ) | |
| 27 | Passenger's Under-dash Fuse/Relay Box Connector A (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 38-WHT/LT GRN | Behind Right Kick Panel |
| 28 | C208 (Female) | 4-YEL | Behind Right Kick Panel | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| 29 | C207 (Female) | 2-N/A | Under Right Side of Dash | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) | Headlight Washer |
| 30 | C206 (Female) | 20-WHT | Under Right Side of Dash | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| 31 | G403 | Behind Middle of Dash | Body Ground via Dashboard Wire Harness |
| 32 | SRS Unit Connector A | 39-YEL | Behind Middle of Dash |
| 33 | Yaw Rate-Lateral Acceleration Sensor | 4-BLK | Under Center Console | Without SH-AWD |
| 33 | Yaw Rate-Lateral/Longitudinal Acceleration Sensor | 4-BLK | Under Center Console | SH-AWD |
| 34 | Front Accessory Power Socket | 2-BLK | Middle of Dash | USA, Canada |
| 35 | Front Passenger's Seat Heater Switch | 7-WHT | Middle of Dash |
| 36 | C405 (Male) | 20-WHT | Under Center Console | CONSOLE SUB-HARNESS |
| 37 | C404 (Male) | 18-WHT | Under Center Console | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | A/T |
| 41 | RF Unit 1 | 3-BLK | Under Center Console | Keyless Access |
| 43 | A/T Shift Lock Solenoid/Park-Pin Switch | 4-BLK/GRY | Under Center Console | A/T |
| 44 | C404 (Female) | 18-WHT | Under Center Console | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) | M/T |
| 45 | Driver's Seat Heater Switch | 6-BLU | Middle of Dash |
| 46 | A/T Gear Position Indicator Panel Light | 2-GRN | Middle of Dash |
| 47 | USB Adapter Unit Connector A | 14-WHT | Under Center Console | Without Navigation |
| 48 | C403 (Female) | 20-WHT | Under Middle of Dash | A/C Wire Harness (see A/C WIRE HARNESS ) |
| 49 | Ignition Key Switch/Key Light | 6-GRN | In Steering Column Cover | Without Keyless Access |
| 50 | Ignition Switch | 5-WHT | In Steering Column Cover | Without Keyless Access |
| 51 | G404 | Under Center Console | Body Ground via Dashboard Wire Harness |
Console Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 36 | C405 (Female) | 20-WHT | Under Center Console | DASHBOARD WIRE HARNESS | |
| 38 | Auxiliary Jack Assembly | 5-GRN | Center Console |
| 39 | Console Accessory Power Socket | 2-BLK | Center Console |
| 40 | Console Box Light | 2-BLK | Center Console |
| 42 | Parking Brake Switch | 1-NAT | Under Center Console |
Identifying Dashboard Wire Harness And Console Sub-Harness (Page 203-33). Scheme 525
Scheme 525: Identifying Dashboard Wire Harness And Console Sub-Harness (Page 203-33)
Audio Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | G501 | | Behind Middle of Dash | Body Ground via Audio Wire Harness | |
| 2 | Navigation Display Unit | 32-GRY | Middle of Dash | Navigation |
| 2 | Audio-HVAC Display Unit | 12-GRY | Middle of Dash | Without Navigation |
| 3 | C505 (Junction Connector) | 12-BLU | Behind Middle of Dash |
| 4 | C504 (Junction Connector) | 12-BLU | Behind Middle of Dash |
| 5 | C406 (Male) | 34-WHT | Behind Glove Box | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 6 | C407 (Male) | 12-WHT | Behind Glove Box | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | Keyless Access |
| 7 | AcuraLink Reprogramming Connector (Male) | 5-WHT | Behind Glove Box | AcuraLink |
| 8 | C506 (Junction Connector) | 12-BLU | Behind Glove Box | Navigation |
| 9 | C507 (Junction Connector) | 12-GRY | Behind Glove Box |
| 10 | C508 (Junction Connector) | 12-BRN | Behind Glove Box |
| 11 | AcuraLink Reprogramming Connector (Female) | 5-WHT | Behind Glove Box | AcuraLink |
| 12 | Glove Box Light | 2-BLK | Glove Box |
| 13 | Front Passenger's Climate Control Switch | 16-GRY | Middle of Dash |
| 14 | Keyless Access System Mode Switch | 2-WHT | Glove Box | Keyless Access |
| 15 | Passenger's Under-dash Fuse/Relay Box Connector D (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 28-LT GRN | Behind Right Kick Panel |
| 16 | Trunk Lid Opener Main Switch | 2-WHT | Glove Box |
| 17 | Navigation Service Check Connector | 2-WHT | Behind Right Kick Panel | Navigation |
| 18 | C509 (Female) | 28-WHT | Behind Right Kick Panel | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or RIGHT SIDE WIRE HARNESS (SH-AWD) ) |
Identifying Audio Wire Harness (Page 203-35). Scheme 526
Scheme 526: Identifying Audio Wire Harness (Page 203-35)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 19 | C510 (Female) | 12-WHT | Behind Right Kick Panel | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or RIGHT SIDE WIRE HARNESS (SH-AWD) ) | Navigation |
| 20 | G502 | Behind Middle of Dash | Body Ground via Audio Wire Harness |
| 21 | C501 (Female) | 20-WHT | Under Middle of Dash | A/C Wire Harness (see A/C WIRE HARNESS ) |
| 22 | Audio Unit Connector D | 20-GRY | Behind Audio Unit | Without Navigation |
| 22 | Audio-Navigation Unit Connector D | 20-GRY | Behind Audio-Navigation Unit | Navigation |
| 23 | C502 (Junction Connector) | 12-BLU | Behind Middle of Dash |
| 24 | C503 (Junction Connector) | 12-WHT | Behind Middle of Dash |
| 25 | HandsFreeLink Control Unit | 28-GRY | Behind Middle of Dash |
| 26 | Interface Dial | 5-GRN | Middle of Dash | Navigation |
| 27 | Front Interior LF Antenna | 2-BLK | Behind Middle of Dash | Keyless Access |
| 28 | XM Receiver Connector A | 14-WHT | Behind Middle of Dash | USA: without AcuraLink; Canada |
| 28 | AcuraLink Control Unit (XM Receiver) Connector A | 32-GRY | Behind Middle of Dash | AcuraLink |
| 29 | Audio Unit Connector C | 14-WHT | Behind Audio Unit | Without Navigation |
| 29 | Audio-Navigation Unit Connector C | 14-WHT | Behind Audio-Navigation Unit | Navigation |
| 30 | Audio-Navigation Switch Panel | 24-GRY | Middle of Dash | Navigation |
| 31 | Audio Unit Connector B | 14-GRY | Behind Audio Unit | Without Navigation |
| 31 | Audio-Navigation Unit Connector B | 24-LT BLU | Behind Audio-Navigation Unit | Navigation |
| 32 | Audio Unit Connector A | 24-GRY | Behind Audio Unit | Without Navigation |
| 32 | Audio-Navigation Unit Connector A | 24-GRY | Behind Audio-Navigation Unit | Navigation |
| 33 | Audio-Navigation Unit Connector F | 12-GRY | Behind Audio-Navigation Unit | Navigation |
| 34 | Audio-Navigation Unit Connector G | 16-GRY | Behind Audio-Navigation Unit | Navigation |
| 35 | Audio-Navigation Unit Connector H | 28-GRY | Behind Audio-Navigation Unit | Navigation |
Identifying Audio Wire Harness (Page 203-37). Scheme 527
Scheme 527: Identifying Audio Wire Harness (Page 203-37)
Left Side Wire Harness (without SH-AWD)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C303 (Male) | 12-WHT | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 2 | Driver's Under-dash Fuse/Relay Box Connector E (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 20-LT GRN | Behind Left Kick Panel |
| 3 | Driver's Under-dash Fuse/Relay Box Connector D (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 16-LT GRN | Behind Left Kick Panel |
| 4 | Driver's Door Switch | 1-WHT | Left B-Pillar |
| 5 | Rear Interior LF Antenna | 2-BLK | Rear of Floor | Keyless Access |
| 6 | Left Rear Door Switch | 1-WHT | Left C-Pillar |
| 7 | Rear Window Defogger Noise Condenser | 2-WHT | Left C-Pillar |
| 8 | Rear Window Defogger Coil Connector A | 1-BRN | Left C-Pillar |
| 9 | Rear Window Defogger Coil Connector B | 1-BRN | Left C-Pillar |
| 10 | Fuel Tank Unit | 4-GRY | Rear of Floor |
| 11 | Rear Window Defogger Connector A(+) | 1-BLK | Left C-Pillar |
| 12 | C601 (Female) | 20-WHT | Rear of Floor | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or RIGHT SIDE WIRE HARNESS (SH-AWD) ) | Coupler Type 1 |
| 12 | C601 (Female) | 13-WHT | Rear of Floor | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or RIGHT SIDE WIRE HARNESS (SH-AWD) ) | Coupler Type 2 |
| 13 | Left Rear Speaker | 2-GRY | Left Side of Rear Shelf |
| 14 | Left Brake Light/Taillight | 3-BLK | Behind Left Taillight Assembly |
| 15 | C901 (Male) | 12-WHT | Left Side of Trunk Lid | Rear Spoiler Wire Harness | USA, Canada: Keyless Access |
| 16 | Right Brake Light/Taillight | 3-GRY | Behind Right Taillight Assembly |
| 17 | Right Rear Side Marker Light | 2-GRY | Behind Right Taillight Assembly |
| 18 | Right Rear Turn Signal Light | 2-GRY | Behind Right Taillight Assembly |
| 19 | Right Back-up Light | 2-BRN/NAT | Behind Right Taillight Assembly |
| 20 | Trunk Lid Opener Solenoid/Latch Switch | 3-GRY | Middle of Trunk Lid |
Identifying Left Side Wire Harness (Page 203-39). Scheme 528
Scheme 528: Identifying Left Side Wire Harness (Page 203-39)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 21 | Rear Bumper LF Antenna | 2-BLK | Behind Middle of Rear Bumper | | Keyless Access |
| 22 | Keyless Buzzer | 2-BLK/YEL | Behind Middle of Rear Bumper |
| 23 | Right License Plate Light | 2-GRY | Middle of Rear Bumper |
| 24 | Left License Plate Light | 2-GRY | Middle of Rear Bumper |
| 25 | Left Back-up Light | 2-BRN/NAT | Behind Left Taillight Assembly |
| 26 | Left Rear Turn Signal Light | 2-GRY | Behind Left Taillight Assembly |
| 27 | G603 | Left Side of Trunk | Body Ground via Left Side Wire Harness |
| 28 | Left Rear Side Marker Light | 2-GRY | Behind Left Taillight Assembly |
| 29 | Fuel Fill Door Opener Solenoid | 2-GRY | Left Side of Trunk |
| 30 | EVAP Canister Vent Shut Valve | 2-LT GRN | Under Middle Rear of Vehicle | LEV2 |
| 31 | FTP Sensor | 3-BLK | Under Middle Rear of Vehicle | LEV2 |
| 32 | Left Rear Wheel Speed Sensor | 2-BLK | Under Left Rear of Vehicle |
| 33 | Left Rear TPMS Initiator | 3-BLK | Left Rear Wheelwell |
| 34 | G602 | Left Rear of Floor | Body Ground via Left Side Wire Harness |
| 35 | C771 (Female) | 13-WHT | Left B-Pillar | Left Rear Door Harness (see LEFT REAR DOOR WIRE HARNESS ) |
| 36 | G601 | Left Side of Floor | Body Ground via Left Side Wire Harness |
| 37 | C401 (Female) | 18-WHT | Under Left Side of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
Identifying Left Side Wire Harness (Page 203-41). Scheme 529
Scheme 529: Identifying Left Side Wire Harness (Page 203-41)
Left Side Wire Harness (SH-AWD)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C303 (Male) | 12-WHT | Behind Left Kick Panel | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 2 | Driver's Under-dash Fuse/Relay Box Connector E (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 20-LT GRN | Behind Left Kick Panel |
| 3 | Driver's Under-dash Fuse/Relay Box Connector D (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 16-LT GRN | Behind Left Kick Panel |
| 4 | Driver's Door Switch | 1-WHT | Left B-Pillar |
| 5 | Left Rear Door Switch | 1-WHT | Left C-Pillar |
| 6 | Fuel Tank Unit | 4-GRY | Under Left Side of Floor |
| 7 | Fuel Pump Control Module | 10-WHT | Left C-Pillar | '09 |
| 8 | Rear Interior LF Antenna | 2-BLK | Left B-Pillar | Keyless Access |
| 9 | Rear Window Defogger Coil Connector A | 1-BRN | Left C-Pillar |
| 10 | Rear Window Defogger Coil Connector B | 1-BRN | Left C-Pillar |
| 11 | Secondary Fuel Gauge Sending Unit | 4-GRY | Right Rear of Floor |
| 12 | C602 (Female) | 2-WHT | Rear of Floor | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (SH-AWD) ) |
| 13 | C601 (Female) | 20-WHT | Rear of Floor | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or RIGHT SIDE WIRE HARNESS (SH-AWD) ) | Coupler Type 2 |
| 14 | Rear Window Defogger Connector A(+) | 1-BLK | Left C-Pillar |
| 15 | Left Rear Speaker | 2-GRY | Left Side of Rear Shelf |
| 16 | Left Brake Light/Taillight | 3-BLK | Behind Left Taillight Assembly |
| 17 | C901 (Male) | 12-WHT | Left Side of Trunk Lid | Rear Spoiler Wire Harness | USA, Canada: Keyless Access |
| 18 | Right Brake Light/Taillight | 3-GRY | Behind Right Taillight Assembly |
| 19 | Right Rear Side Marker Light | 2-GRY | Behind Right Taillight Assembly |
| 20 | Right Rear Turn Signal Light | 2-GRY | Behind Right Taillight Assembly |
| 21 | Right Back-up Light | 2-BRN/NAT | Behind Right Taillight Assembly |
| 22 | Trunk Lid Opener Solenoid/Latch Switch | 3-GRY | Middle of Trunk Lid |
Identifying Left Side Wire Harness (Page 203-43). Scheme 530
Scheme 530: Identifying Left Side Wire Harness (Page 203-43)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 23 | Rear Bumper LF Antenna | 2-BLK | Behind Middle of Rear Bumper | | Keyless Access |
| 24 | Keyless Buzzer | 2-BLK/YEL | Behind Middle of Rear Bumper |
| 25 | Right License Plate Light | 2-GRY | Middle of Rear Bumper |
| 26 | Left License Plate Light | 2-GRY | Middle of Rear Bumper |
| 27 | Left Back-up Light | 2-BRN/NAT | Behind Left Taillight Assembly |
| 28 | Left Rear Turn Signal Light | 2-GRY | Behind Left Taillight Assembly |
| 29 | G603 | Left Side of Trunk | Body Ground via Left Side Wire Harness |
| 30 | Left Rear Side Marker Light | 2-GRY | Behind Left Taillight Assembly |
| 31 | Rear Window Defogger Noise Condenser | 2-WHT | Left Side of Trunk |
| 32 | Fuel Fill Door Open Solenoid | 2-GRY | Left Side of Trunk |
| 33 | Left Rear Wheel Speed Sensor | 2-BLK | Under Left Rear of Vehicle |
| 34 | Left Rear TPMS Initiator | 3-BLK | Left Rear Wheelwell |
| 35 | G602 | Left Rear of Floor | Body Ground via Left Side Wire Harness |
| 36 | C771 (Female) | 13-WHT | Left B-Pillar | Left Rear Door Harness (see LEFT REAR DOOR WIRE HARNESS ) |
| 37 | G601 | Left Side of Floor | Body Ground via Left Side Wire Harness |
| 38 | C401 (Female) | 18-WHT | Under Left Side of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
Identifying Left Side Wire Harness (Page 203-45). Scheme 531
Scheme 531: Identifying Left Side Wire Harness (Page 203-45)
SRS Floor Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | G702 | | Right Side of Floor | Body Ground via SRS Floor Wire Harness | |
| 2 | Right Side Impact Sensor (1st) | 4-YEL | Right B-pillar |
| 3 | Front Passenger's Seat Belt Tensioner | 4-YEL | Right B-pillar |
| 4 | C404 (Female) | 18-WHT | Under Center Console | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | A/T |
| 5 | Right Side Impact Sensor (2nd) | 2-YEL | Right C-Pillar |
| 6 | Right Side Curtain Airbag Inflator | 2-YEL | Right C-Pillar |
| 7 | Rear Sating Sensor | 4-YEL | Rear of Floor |
| 8 | Left Side Curtain Airbag Inflator | 2-YEL | Left C-Pillar |
| 9 | Left Side Impact Sensor (2nd) | 2-YEL | Left C-Pillar |
| 10 | Driver's Seat Belt Tensioner | 4-YEL | Left B-Pillar |
| 11 | Left Side Impact Sensor (1st) | 4-YEL | Left B-Pillar |
| 12 | G701 | Left Side of Floor | Body Ground via SRS Floor Wire Harness |
| 13 | Driver's Side Airbag Inflator | 2-YEL | Under Driver's Seat |
| 14 | C701 (Female) | 23-WHT | Under Driver's Seat | Driver's Seat Wire Harness (see DRIVER'S SEAT WIRE HARNESS ) |
| 15 | C404 (Male) | 18-WHT | Under Center Console | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | M/T |
| 16 | SRS Unit Connector B | 39-YEL | Behind Middle of Dash |
| 17 | C702 (Female) | 18-WHT | Under Front Passenger's Seat | Front Passenger's Seat Wire Harness (see FRONT PASSENGER'S SEAT WIRE HARNESS ) |
| 18 | Front Passenger's Side Airbag Inflator | 2-YEL | Under Front Passenger's Seat |
Identifying SRS Floor Wire Harness (Page 203-47). Scheme 532
Scheme 532: Identifying SRS Floor Wire Harness (Page 203-47)
Right Side Wire Harness (without SH-AWD)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Rear Shelf LF Antenna | 2-BLK | Middle of Rear Shelf | | Keyless Access |
| 2 | Trunk Light | 2-GRY | Middle of Rear Shelf |
| 3 | Electrical Compass Unit | 6-BLU | Middle of Rear Shelf | Without Navigation |
| 4 | Subwoofer | 2-GRY | Middle of Rear Shelf |
| 5 | Right Rear Speaker | 2-GRY | Right Side of Rear Shelf |
| 7 | C601 (Male) | 20-WHT | Rear of Floor | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) or LEFT SIDE WIRE HARNESS (SH-AWD) ) | Coupler Type 1 |
| 7 | C601 (Male) | 13-WHT | Rear of Floor | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) or LEFT SIDE WIRE HARNESS (SH-AWD) ) | Coupler Type 2 |
| 8 | Right Rear Door Switch | 1-WHT | Right C-Pillar |
| 9 | C781 (Female) | 13-WHT | Right B-Pillar | Right Rear Door Wire Harness (see RIGHT REAR DOOR WIRE HARNESS ) |
| 10 | Front Passenger's Door Switch | 1-WHT | Right B-Pillar |
| 11 | C410(Male) | 8-WHT | Under Right Side of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 12 | C411 (Male) | 12-WHT | Under Right Side of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 13 | C509 (Male) | 28-WHT | Behind Right Kick Panel | Audio Wire Harness (see AUDIO WIRE HARNESS ) |
| 14 | C510(Male) | 12-WHT | Behind Right Kick Panel | Audio Wire Harness (see AUDIO WIRE HARNESS ) |
| 15 | Passenger's Under-dash Fuse/Relay Box Connector G (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 16-LT GRN | Behind Right Kick Panel |
| 16 | G651 | Right Side of Floor | Body Ground via Right Side Wire Harness |
| 17 | Right Rear TPMS Initiator | 3-BLK | Right Rear Wheelwell |
| 18 | Right Rear Wheel Speed Sensor | 2-BLK | Under Right Rear of Vehicle |
| 19 | Stereo Amplifier Connector B | 28-GRY | Right Side of Trunk | Navigation |
| 19 | Stereo Amplifier Connector B | 20-GRY | Right Side of Trunk | Without Navigation |
| 20 | Stereo Amplifier Connector A | 18-GRY | Right Side of Trunk |
| 21 | G653 | Right Side of Trunk | Body Ground via Right Side Wire Harness |
| 23 | RF Unit 2 | 3-BLK | Right C-Pillar | Keyless Access |
Rear Window Defogger Ground Wire (without SH-AWD)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 6 | Rear Window Defogger Connector B(-) | 1-BLK | Right C-Pillar | | |
| 22 | G801 | Right C-Pillar | Body Ground via Rear Window Defogger Ground |
Identifying Rear Window Defogger Ground Wire (Page 203-49). Scheme 533
Scheme 533: Identifying Rear Window Defogger Ground Wire (Page 203-49)
Right Side Wire Harness (SH-AWD)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Rear Shelf LF Antenna | 2-BLK | Middle of Rear Shelf | | Keyless Access |
| 2 | Trunk Light | 2-GRY | Middle of Rear Shelf |
| 3 | Subwoofer | 2-GRY | Middle of Rear Shelf |
| 4 | Right Rear Speaker | 2-GRY | Right Side of Rear Shelf |
| 5 | C601 (Male) | 20-WHT | Rear of Floor | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) or LEFT SIDE WIRE HARNESS (SH-AWD) ) |
| 6 | C602 (Male) | 2-WHT | Rear of Floor | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (SH-AWD) ) |
| 8 | RF Unit 2 | 3-BLK | Right C-Pillar | Keyless Access |
| 9 | SH-AWD Control Unit Connector A | 20-GRY | Right Side of Trunk |
| 10 | SH-AWD Control Unit Connector B | 8-WHT | Right Side of Trunk |
| 11 | SH-AWD Relay | 4-BLK | Right Side of Trunk |
| 12 | C651 (Junction Connector) | 12-WHT/BLU | Right Rear of Floor |
| 13 | Right Rear Door Switch | 1-WHT | Right C-Pillar |
| 14 | C781 (Male) | 13-WHT | Right B-Pillar | Right Rear Door Wire Harness (see RIGHT REAR DOOR WIRE HARNESS ) |
| 15 | Front Passenger's Door Switch | 1-WHT | Right B-Pillar |
| 16 | C410(Male) | 8-WHT | Under Right Side of Dash | Dashboard Wiring Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 17 | C509 (Male) | 28-WHT | Behind Right Kick Panel | Audio Wire Harness (see AUDIO WIRE HARNESS ) |
| 18 | C510 (Male) | 12-WHT | Behind Right Kick Panel | Audio Wire Harness (see AUDIO WIRE HARNESS ) |
Identifying Right Side Wire Harness And Rear Window Defogger Ground Wire (Page 203-49). Scheme 534
Scheme 534: Identifying Right Side Wire Harness And Rear Window Defogger Ground Wire (Page 203-49)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 19 | Passenger's Under-dash Fuse/Relay Box Connector H (see CONNECTOR-TO-FUSE/RELAY BOX INDEX ) | 38-LT GRN | Behind Right Kick Panel | | |
| 20 | C411 (Male) | 12-WHT | Under Right Side of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 21 | G651 | Right Side of Floor | Body Ground via Right Side Wire Harness |
| 22 | G652 | Body Ground via Right Side Wire Harness |
| 23 | Right Rear TPMS Initiator | 3-BLK | Right Rear Wheelwell |
| 24 | FTP Sensor | 3-BLK | Under Right Rear of Vehicle | LEV2 |
| 25 | Right Rear Wheel Speed Sensor | 2-BLK | Under Right Rear of Vehicle |
| 26 | Stereo Amplifier Connector A | 18-GRY | Right Side of Trunk |
| 27 | Stereo Amplifier Connector B | 28-GRY | Right Side of Trunk | Navigation |
| 27 | Stereo Amplifier Connector B | 20-GRY | Right Side of Trunk | Without Navigation |
| 28 | C652 (Female) | 6-GRY | Middle of Rear Differential | Rear Differential Sub-harness (see REAR DIFFERENTIAL SUB-HARNESS (SH-AWD) ) |
| 29 | C653 (Female) | 6-BLK | Middle of Rear Differential | Rear Differential Sub-harness (see REAR DIFFERENTIAL SUB-HARNESS (SH-AWD) ) |
| 30 | G653 | Right Side of Trunk | Body Ground via Right Side Wire Harness |
| 31 | EVAP Canister Vent Shut Valve | 2-BLK | Under Right Rear of Vehicle | LEV2 |
| 33 | Electrical Compass Unit | 6-BLU | Middle of Rear Shelf | Without Navigation |
Rear Window Defogger Ground Wire (SH-AWD)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 7 | Rear Window Defogger Connector B(-) | 1-BLK | Right C-Pillar | | |
| 32 | G801 | Right C-Pillar | Body Ground via Rear Window Defogger Ground |
Identifying Right Side Wire Harness And Rear Window Defogger Ground Wire (Page 203-53). Scheme 535
Scheme 535: Identifying Right Side Wire Harness And Rear Window Defogger Ground Wire (Page 203-53)
Roof Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Automatic Dimming Inside Mirror | 7-BLK | Behind Rearview Mirror | | |
| 2 | Front Passenger's Vanity Mirror Light | 2-WHT | Front Passenger's Sunvisor Mount |
| 3 | Roof Console | 20-BLK/WHT | Front of Roof |
| 4 | C451 (Female) | 23-WHT | Front of Roof | MOONROOF SUB-HARNESS |
| 5 | Moonroof Switch | 7-GRN | Front of Roof |
| 6 | HFL-Navigation Microphone | 7-GRY | Front of Roof | Navigation |
| 7 | Driver's Vanity Mirror Light | 2-WHT | Driver's Sunvisor Mount |
| 11 | C402 (Male) | 23-WHT | Left A-Pillar | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| 12 | Left Tweeter | 2-BLK | Left A-Pillar |
Moonroof Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 4 | C451 (Male) | 23-WHT | Front of Roof | ROOF WIRE HARNESS | |
| 8 | Rear Individual Map Lights | 10-GRN | Middle of Roof |
| 9 | High Mount Brake Light | 2-WHT/GRY | Rear of Roof |
| 10 | Moonroof Control Unit/Motor | 14-GRY | Middle of Roof |
Identifying Roof Wire Harness And Moonroof Sub-Harness (Page 203-55). Scheme 536
Scheme 536: Identifying Roof Wire Harness And Moonroof Sub-Harness (Page 203-55)
Driver's Door Wire Harness
Driver's Door Switch Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 2 | Power Window Master Switch | 37-GRY | Driver's Door | | |
| 3 | Driving Position Memory Switch | 7-WHT | Driver's Door |
| 4 | C756 (Junction Connector) | 12-BLU | Driver's Door |
| 5 | Power Mirror Switch | 13-WHT | Driver's Door |
| 6 | C753 (Male) | 28-WHT | Driver's Door | DRIVER'S DOOR WIRE HARNESS |
| 7 | C754 (Male) | 16-WHT | Driver's Door | DRIVER'S DOOR WIRE HARNESS |
| 10 | Power Mirror Control Unit | 24-GRY | Driver's Door |
| 13 | Trunk Lid Opener/Fuel Fill Door Opener Switch | 6-GRN | Driver's Door |
| 16 | Driver's Door Courtesy Light | 2-WHT | Driver's Door |
Identifying Driver's Door Switch Sub-Harness And Driver's Door Wire Harness (Page 203-57). Scheme 537
Scheme 537: Identifying Driver's Door Switch Sub-Harness And Driver's Door Wire Harness (Page 203-57)
Front Passenger's Door Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Right Power Mirror | 16-WHT | Front Passenger's Door | | |
| 2 | C762 (Junction Connector) | 12-GRY | Front Passenger's Door |
| 3 | Front Passenger's Power Window Switch | 37-GRY | Front Passenger's Door |
| 4 | Front Passenger's Door Outer Handle Light/Lock Switch/Touch Sensor/LF Antenna | 8-BLK | Front Passenger's Door | Keyless Access |
| 5 | Front Passenger's Door Lock Actuator/Knob Switch | 10-WHT | Front Passenger's Door |
| 6 | Front Passenger's Door Courtesy Light | 2-WHT | Front Passenger's Door |
| 7 | Front Passenger's Power Window Motor | 6-BLK | Front Passenger's Door |
| 8 | Front Passenger's Door Speaker | 2-GRY | Front Passenger's Door |
| 9 | C761 (Male) | 28-WHT | Right A-Pillar | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
Identifying Front Passenger's Door Wire Harness (Page 203-58). Scheme 538
Scheme 538: Identifying Front Passenger's Door Wire Harness (Page 203-58)
Left Rear Door Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Left Rear Door Lock Actuator/Knob Switch | 10-WHT | Left Rear Door | | |
| 2 | Left Rear Power Window Switch | 14-GRY | Left Rear Door |
| 3 | Left Rear Door Speaker | 2-GRY | Left Rear Door | Navigation |
| 4 | C771 (Male) | 13-WHT | Left B-Pillar | Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (SH-AWD) or LEFT SIDE WIRE HARNESS (SH-AWD) ) |
| 5 | Left Rear Power Window Motor | 2-GRY | Left Rear Door |
Identifying Left Rear Door Wire Harness (Page 203-59). Scheme 539
Scheme 539: Identifying Left Rear Door Wire Harness (Page 203-59)
Right Rear Door Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Right Rear Door Speaker | 2-GRY | Right Rear Door | | Navigation |
| 2 | Right Rear Power Window Switch | 14-GRY | Right Rear Door |
| 3 | Right Rear Door Lock Actuator/Knob Switch | 10-WHT | Right Rear Door |
| 4 | Right Rear Power Window Motor | 2-GRY | Right Rear Door |
| 5 | C781 (Male) | 13-WHT | Right B-Pillar | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) or RIGHT SIDE WIRE HARNESS (SH-AWD) ) |
Identifying Right Rear Door Wire Harness (Page 203-60). Scheme 540
Scheme 540: Identifying Right Rear Door Wire Harness (Page 203-60)
Cable Reel Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Audio Remote Switch, HFL Voice Control Switch | 12-WHT | Steering Wheel | | Without Navigation |
| 1 | Audio Remote Switch, HFL-Navigation Voice Control Switch | 12-WHT | Steering Wheel | Navigation |
| 2 | Paddle Shifter - (Downshift Switch) | 4-WHT | Steering Wheel | A/T |
| 3 | Cable Reel Connector C | 20-WHT | Steering Wheel | Cable Reel Connector B (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 4 | T9 | Steering Wheel | Steering Wheel |
| 5 | Paddle Shifter + (Upshift Switch) | 4-WHT | Steering Wheel | A/T |
| 6 | Cruise Control Combination/Select/Reset/ Information Switch | 12-WHT | Steering Wheel |
| 7 | Horn Switch | 1-BLK | Steering Wheel |
Identifying Cable Reel Sub-Harness (Page 203-61). Scheme 541
Scheme 541: Identifying Cable Reel Sub-Harness (Page 203-61)
Driver's Seat Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Driver's Seat Back Heater | 2-WHT | Driver's Seat Back | | |
| 2 | Driver's Power Seat Recline Motor/Position Sensor | 5-WHT | Driver's Seat Back |
| 3 | Driver's Power Seat Rear Up-down Motor/Position Sensor | 5-WHT | Under Driver's Seat |
| 4 | Driver's Seat Position Sensor | 2-BLK | Under Driver's Seat | USA, Canada |
| 5 | Driver's Power Lumbar Support Switch | 5-NAT | Left Side of Driver's Seat |
| 6 | Driver's Power Seat Adjustment Switch | 12-GRY | Left Side of Driver's Seat |
| 7 | C701 (Male) | 23-WHT | Under Driver's Seat | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) |
| 8 | Power Seat Control Unit Connector A | 18-GRY/WHT | Under Driver's Seat |
| 9 | Driver's Power Seat Slide Motor/Position Sensor | 5-GRY | Under Driver's Seat |
| 10 | Power Seat Control Unit Connector B | 40-GRY | Under Driver's Seat |
| 11 | Driver's Seat Cushion Heater | 3-WHT | Under Driver's Seat |
| 12 | Driver's Seat Belt Buckle Switch | 2-WHT | Under Driver's Seat |
| 13 | Driver's Seat Heater Relay (Low) | 5-BLU | Under Driver's Seat |
| 14 | Driver's Seat Heater Relay (High) | 4-BLU | Under Driver's Seat |
| 15 | Driver's Power Seat Front Up-down Motor/Position Sensor | 5-WHT | Under Driver's Seat |
| 16 | Driver's Power Lumbar Support Motor | 2-WHT | Right Side of Driver's Seat Back |
Identifying Driver's Seat Wire Harness (Page 203-63). Scheme 542
Scheme 542: Identifying Driver's Seat Wire Harness (Page 203-63)
Front Passenger's Seat Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | ODS Unit Connector D | 18-BLK | Left Side of Front Passenger's Seat Back | | |
| 2 | Front Passenger's Power Seat Front Up-down Motor | 2-WHT | Under Front Passenger's Seat |
| 3 | Inner Side Front Passenger's Seat Weight Sensor | 2-GRY | Under Front Passenger's Seat | USA, Canada |
| 4 | Front Passenger's Seat Heater Relay (Low) | 5-BLU | Under Front Passenger's Seat |
| 5 | Front Passenger's Seat Heater Relay (High) | 4-BLU | Under Front Passenger's Seat |
| 6 | Front Passenger's Seat Heater | 4-WHT | Under Front Passenger's Seat |
| 7 | Front Passenger's Seat Belt Buckle Switch | 2-BLU/WHT | Under Front Passenger's Seat |
| 8 | C702 (Male) | 18-WHT | Under Front Passenger's Seat | SRS Floor Wire Harness (see SRS FLOOR WIRE HARNESS ) |
| 9 | Front Passenger's Power Seat Slide Motor | 5-GRY | Under Front Passenger's Seat |
| 10 | Front Passenger's Power Seat Adjustment Switch | 12-GRY | Right Side of Front Passenger's Seat |
| 11 | Front Passengers Power Seat Rear Up-down Motor | 2-WHT | Under Front Passenger's Seat |
| 12 | Outer Side Front Passenger's Weight Sensor | 3-GRY | Under Front Passenger's Seat | USA, Canada |
| 13 | Front Passenger's Power Seat Recline Motor | 2-WHT | Front Passenger's Seat Back |
Identifying Front Passenger's Seat Wire Harness (Page 203-65). Scheme 543
Scheme 543: Identifying Front Passenger's Seat Wire Harness (Page 203-65)
A/C Wire Harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C301 (Male) | 2-WHT | Under Left Side of Dash | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| 2 | C302 (Male) | 2-WHT | Under Left Side of Dash | Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) |
| 3 | Blower Power Transistor | 5-NAT | Under Right Side of Dash |
| 4 | Recirculation Control Motor | 7-GRN | Behind Glove Box |
| 5 | Front Passenger's Mode Control Motor | 7-GRN | Under Right Side of Dash |
| 6 | C205 (Male) | 2-WHT | Under Right Side of Dash | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| 7 | Blower Motor | 2-WHT | Under Right Side of Dash |
| 8 | Front Passenger's Footwell Light | 2-GRY | Under Right Side of Dash |
| 9 | Climate Control Unit Connector C | 20-GRY | Under Right Side of Dash |
| 10 | C501 (Male) | 20-WHT | Under Middle of Dash | Audio Wire Harness (see AUDIO WIRE HARNESS ) |
| 11 | Climate Control Unit Connector B | 24-GRY | Under Right Side of Dash |
| 12 | Climate Control Unit Connector A | 32-GRY | Under Right Side of Dash |
| 13 | Front Passenger's Air Mix Control Motor | 7-GRN | Under Right Side of Dash |
| 14 | C403 (Female) | 20-WHT | Under Middle of Dash | Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) |
| 15 | Driver's Air Mix Control Motor | 7-GRN | Under Left Side of Dash |
| 16 | Driver's Mode Control Motor | 7-GRN | Under Left Side of Dash |
| 17 | Evaporator Temperature Sensor | 2-WHT/GRY | Under Left Side of Dash |
Identifying A/C Wire Harness (Page 203-67). Scheme 544
Scheme 544: Identifying A/C Wire Harness (Page 203-67)
EPS Sub-harness
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | C202 (Male) | 3-BLK/WHT | Right Rear of Engine Compartment | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) | |
| 2 | C203 (Male) | 12-BLK | Right Rear of Engine Compartment | Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| 3 | EPS Motor Angle Sensor | 6-BLK | Right Rear of Engine Compartment |
| 4 | EPS Torque Sensor | 3-GRY | Under Left Rear of Engine Compartment |
| 5 | T6 | Under Left Rear of Engine Compartment | Steering Gearbox |
| 6 | T7 | Right Rear of Engine Compartment | Steering Gearbox |
| 7 | T8 | Right Rear of Engine Compartment | Steering Gearbox |
| 8 | EPS Motor | 3-BLK | Right Rear of Engine Compartment |
Identifying EPS Sub-Harness (Page 203-68). Scheme 545
Scheme 545: Identifying EPS Sub-Harness (Page 203-68)
Rear Differential Sub-harness (SH-AWD)
| Ref | Connector or Terminal | Cavities/Color | Location | Connects to | Notes |
|---|
| 1 | Left Clutch Electromagnetic Coil/Search Coil | 4-GRY | Left Side of Rear Differential | | |
| 2 | T10 | Left Side of Rear Differential |
| 3 | Right Clutch Electromagnetic Coil/Search Coil | 4-GRY | Right Side of Rear Differential |
| 4 | C653 (Male) | 6-BLK | Middle of Rear Differential | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (SH-AWD) ) |
| 5 | C652 (Male) | 6-GRY | Middle of Rear Differential | Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (SH-AWD) ) |
| 6 | Differential Fluid Temperature Sensor | 2-GRY | Middle of Rear Differential |
Identifying Rear Differential Sub-Harness (Page 203-69). Scheme 546
Scheme 546: Identifying Rear Differential Sub-Harness (Page 203-69)
