Oem Fuse/relay Boxes — Acura TL IV (2008-2011)

Fuse-to-Components Index

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
1			WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Not Used
2	SH-AWD	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	SH-AWD Control Unit	SH-AWD
3	WASHER	20A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Windshield Washer Relay
4	WIPER	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Windshield Wiper Relay
5	ODS	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Hazard Warning Switch (USA, Canada), ODS Unit, SRS Unit
6	ABS/VSA	7.5A	WITHOUT KEYLESS ACCESS	EPS Control Unit, Steering Angle Sensor (SH-AWD), VSA Modulator-Control Unit, Yaw Rate-Lateral Acceleration Sensor (without SH-AWD), Yaw Rate-Lateral/Longitudinal Acceleration Sensor (SH-AWD)
7			WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Not Used
8	STR LD	7.5A	ALL MODELS	ECM/PCM, Starter Cut Relay 2
9	FUEL PUMP	20A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	ECM/PCM, Electric Steering Lock Control Unit (Keyless Access), Fuel Pump Relay, Immobilizer-Keyless Control Unit (without Keyless Access), Keyless Access Control Unit (Keyless Access), Remote Slot Control Unit (Keyless Access)
10	VB SOL	10A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	ECM/PCM
11	SRS	10A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	SRS Unit
12	METER	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	AcuraLink Control Unit (XM Receiver) (AcuraLink), A/T Reverse Diode A (A/T), A/T Reverse Relay (A/T), A/T Shift Lock Solenoid/Park Pin Switch (A/T), Automatic Dimming Inside Mirror, Back-up Light Switch (M/T), Driver's MICU, Electrical Compass Unit (Electrical Compass), Gauge Control Module, Passenger's MICU, Power Mirror Control Unit, Power Seat Control Unit, Shift Lock Solenoid (A/T), TPMS Control Unit
13	ACG	15A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Alternator, Brake Pedal Position Switch, ECM/PCM, ELD Unit, Engine Mount Control Solenoid Valve, EVAP Canister Purge Valve (LEV2)
14			ALL MODELS	Not Used
15	DRL	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Driver's MICU
16	A/C	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	A/C Compressor Clutch Relay, A/C Condenser Fan Relay, A/C Diode A, Audio-HVAC Display Unit (without Navigation), Audio/Navigation Switch Panel (Navigation), Blower Motor Relay, Climate Control Unit, Driver's Climate Control Switch, Driver's Seat Heater Switch, Fan Control Relay, Front Passenger's Climate Control Switch, Front Passenger's Seat Heater Switch, Power Mirror Switch, Power Window Master Switch, Rear Window Defogger Relay

Driver's Under -Dash Fuse/Relay Box (6-1). Scheme 74

Scheme 74: Driver's Under -Dash Fuse/Relay Box (6-1)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected
17	ACC KEY LOCK	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	Driver's MICU (without Keyless Access)
18	ACCESSORY	7.5A	WITHOUT KEYLESS ACCESS , KEYLESS ACCESS	AcuraLink Control Unit (XM Receiver) (AcuraLink), Audio-Navigation Unit (Navigation), Audio Unit (without Navigation), Cigarette Lighter Socket Relay (Mexico), Console Accessory Power Socket Relay, Front Accessory Power Socket Relay (Keyless Access), HandsFreeLink Control Unit, HFL-Navigation Microphone (Navigation), Ignition Key Switch/Key Light (without Keyless Access), Interface Dial (Navigation), Keyless Access Control Unit (Keyless Access), Keyless Access Junction Box (Keyless Access), Navigation Display Unit (Navigation), Remote Slot Control Unit (Keyless Access)
19	DR P/SEAT (SLIDE)	20A	ALL MODELS	Power Seat Control Unit
20	MOON ROOF	20A	ALL MODELS	Moonroof Control Unit/Motor
21	DR P/SEAT (REC)	20A	ALL MODELS	Power Seat Control Unit
22	P/W L REAR	20A	ALL MODELS	Left Rear Power Window Relay
23	FR ACC SOCKET	15A	ALL MODELS	Cigarette Lighter Socket Relay (Mexico) (Keyless Access), Front Accessory Power Socket Relay (without Keyless Access)
24	P/WD R	20A	ALL MODELS	Power Window Master Switch
25	DOOR LOCK DR	15A	ALL MODELS	Driver's Door Unlock Relay, Door Lock Relay, Door Unlock Relay, Fuel Fill Door Opener Relay, Trunk Lid Opener Relay
26	FR FOG L	10A	ALL MODELS	Driver's MICU, Fog Light Control Circuit, Left Fog Light
27	SMALL (EXTR) L	10A	ALL MODELS	Driver's MICU, Left Front Side Marker Light, Left Front Turn Signal/Parking Light, Left Brake Light/Taillight, Right Brake Light/Taillight, Left Rear Side Marker Light, Left License Plate Light, Right License Plate Light, Right Rear Side Marker Light
28	H/L L HI	10A	ALL MODELS	Driver's MICU, Left Headlight (High Beam)
29	TPMS	7.5A	ALL MODELS	TPMS Control Unit
30	H/L L LO	15A	ALL MODELS	Driver's MICU, Left Headlight (Low Beam)
31			ALL MODELS	Not Used

Driver's Under -Dash Fuse/Relay Box (6-3). Scheme 75

Scheme 75: Driver's Under -Dash Fuse/Relay Box (6-3)

Connector-to-Fuse/Relay Box Index

Ref	Socket	Cavities	Connects to
1	A		Not Used
2	B	2	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
3	C	5	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
4	Front Accessory Power Socket Relay (without Keyless Access) Accessory Relay (Keyless Access)	4
5	Starter Cut Relay 1	4
6	K (MICU Service Check Connector)	3	Not Used
7	H (Option Connector)	12	Not Used
8	G	13	Left Engine Compartment Wire Harness (see CONNECTOR TERMINAL VIEWS )
9	F	33	Left Engine Compartment Wire Harness (see CONNECTOR TERMINAL VIEWS )
10	E	20	Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) )
11	D	16	Left Side Wire Harness (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) )
12	PGM-FI Main Relay 2 (Fuel Pump)	4
13	M	4	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
14	N	16	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
15	P	20	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
16	R (Driver's MICU)	24	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
17	Q (Driver's MICU)	20	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )

Driver's Under -Dash Fuse/Relay Box (6-5). Scheme 76

Scheme 76: Driver's Under -Dash Fuse/Relay Box (6-5)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected
1	H/L R HI	10A	ALL MODELS	Passenger's MICU, Right Headlight (High Beam)
2	SMALL (EXTR) R	10A	ALL MODELS	Passenger's MICU, Passenger's Under-dash Fuse/Relay Box Fuse 6, Right Front Side Marker Light, Right Front Turn Signal/Parking Light
3	FR FOG R	10A	ALL MODELS	Passenger's MICU, Right Fog Light
4	H/L R LO	15A	ALL MODELS	Passenger's MICU, Right Headlight (Low Beam)
5			ALL MODELS	Not Used
6	SMALL (INTR)	7.5A	ALL MODELS	A/T Gear Position Indicator Panel Light (A/T), Audio Remote Switch and HFL-Voice Control Switch, Audio Unit (without Navigation), Audio/Navigation Switch Panel (Navigation), Audio-HVAC Display Unit (without Navigation), Center Pocket Light, Cigarette Lighter Light (Mexico), Climate Control Unit, Cruise Control Combination/Select/Reset/Information Switch, Console Box Light, Dash Lights Brightness Controller, Driver's Climate Control Switch, Driver's Footwell Light, Driver's Seat Heater Switch, Front Passenger's Climate Control Switch, Front Passenger's Footwell Light, Front Passenger's Seat Heater Switch, Glove Box Light, Hazard Warning Switch, Headlight Washer Switch (Headlight Washer), HFL-Voice Control Switch (Navigation), Moonroof Switch, Rear Individual Map Lights, Roof Console, VSA OFF Switch
7			ALL MODELS	Not Used
8	AS P/SEAT (REC)	20A	ALL MODELS	Front Passenger's Power Seat Adjustment Switch
9	AS P/SEAT (SLIDE)	20A	ALL MODELS	Front Passenger's Power Seat Adjustment Switch
10	DOOR LOCK R	10A	ALL MODELS	Door Lock Relay, Door Unlock Relay
11	P/W R REAR	20A	ALL MODELS	Right Rear Power Window Relay
12	SMART	10A	ALL MODELS	Electric Steering Lock Control Unit (Keyless Access), Engine Start/Stop Switch (Keyless Access), Power Control Unit, (Keyless Access) Remote Slot (Keyless Access), Remote Slot Control Unit (Keyless Access)
13	P/W AS	20A	ALL MODELS	Front Passenger's Power Window Switch
14			ALL MODELS	Not Used
15	PREMIUM AMP	20A	ALL MODELS	Stereo Amplifier

Passenger's Under -Dash Fuse/Relay Box (6-7). Scheme 77

Scheme 77: Passenger's Under -Dash Fuse/Relay Box (6-7)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected
16	CTR ACC SOCKET	20A	ALL MODELS	Console Accessory Power Socket Relay
17			ALL MODELS	Not Used
18	LUMBAR SUPPORT	7.5A	ALL MODELS	Driver's Power Lumbar Support Switch
19	SEAT HEATER	20A	ALL MODELS	Driver's Seat Heater Relay (High), Driver's Seat Heater Relay (Low), Front Passenger's Seat Heater Relay (High), Front Passenger's Seat Heater Relay (Low)
20			ALL MODELS	Not Used
21			ALL MODELS	Not Used
22			ALL MODELS	Not Used

Passenger's Under -Dash Fuse/Relay Box (6-9). Scheme 78

Scheme 78: Passenger's Under -Dash Fuse/Relay Box (6-9)

Ref	Socket	Cavities	Connects to	Notes
1	A	38	Dashboard Wire Harness (see CONSOLE SUB-HARNESS )
2	D	28	Audio Wire Harness (see AUDIO WIRE HARNESS )
3	G	16	Right Side Wire Harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) )	Without SH-AWD
4	H	38	Right Side Wire Harness (see REAR WINDOW DEFOGGER GROUND WIRE (SH-AWD) )	SH-AWD
5	F	2	Not Used
6	E	18	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )
7	C	12	Not Used
8	B	1	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )

Passenger's Under -Dash Fuse/Relay Box (6-11). Scheme 79

Scheme 79: Passenger's Under -Dash Fuse/Relay Box (6-11)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
1	BATTERY (1-1)	120A	ALL MODELS	Alternator, ELD Unit, Fuses 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19 and 20 and Multi-fuse 3 in Under-hood Fuse/Relay Box
1	AS FUSE BOX (1-2)	40A	ALL MODELS	Fuses 7, 8, 9, 10, 11, 12, 13, 20 and 21 in Passenger's Under-dash Fuse/Relay Box
2	EPS (2-1)	70A	10	EPS Control Unit
	ABS/VSA MOTOR (2-2)	40A	10	VSA Modulator-Control Unit
	ABS/VSA (2-3)	30A	10	VSA Modulator-Control Unit
	AS FUSE BOX (2-4)	40A	10	Fuses 14, 15, 16, 17, 18, 19 and 22 in Passenger's Under-dash Fuse/Relay Box
	H/L WASHER (2-5)	30A	10	Headlight Washer Relay	Headlight Washer
	SH-AWD (2-6)	30A	10	SH-AWD Relay	SH-AWD
3	IG MAIN (3-1)	50A	ALL MODELS	ACC Cut Relay (without Keyless Access), Auxiliary Under-dash Fuse Holder, ECM/PCM, IG2 Cut Relay (without Keyless Access), Ignition Switch (without Keyless Access), Power Control Unit (Keyless Access), Remote Engine Start Connector (Option Connector), Starter Cut Relay 1, Starter Cut Relay 2
	SUB FAN MOTOR (3-2)	40A	ALL MODELS	A/C Condenser Fan Relay	160W Fans
	SUB FAN MOTOR (3-3)	30A	ALL MODELS	A/C Condenser Fan Relay	120W Fans
	DR FUSE BOX (3-4)	60A	ALL MODELS	Fuses 14, 19, 20, 21, 22, 23, 24 and 25 in Driver's Under-dash Fuse/Relay Box
	MAIN FAN MOTOR (3-5)	30A	ALL MODELS	Radiator Fan Relay	120W Fans
	MAIN FAN MOTOR (3-5)	40A	ALL MODELS	Radiator Fan Relay	160W Fans
	DR LIGHT MAIN (3-6)	30A	ALL MODELS	Fuses 26, 27, 28, 29, 30 and 31 in Driver's Under-dash Fuse/Relay Box
	WIPER MOTOR (3-7)	30A	ALL MODELS	Windshield Wiper Relay
	AS LIGHT MAIN (3-8)	30A	ALL MODELS	Fuses 1, 2, 3, 4 and 5 in Passenger's Under-dash Fuse/Relay Box
4	RR DEFROSTER	40A	ALL MODELS	Rear Window Defogger Relay
5			ALL MODELS	Not Used
6			ALL MODELS	Not Used
7			ALL MODELS	Not Used
8	HEATER MOTOR	40A	ALL MODELS	Blower Motor Relay
9	HAZARD	15A	ALL MODELS	Driver's MICU, Hazard Warning Switch
10	STOP & HORN	20A	ALL MODELS	Horn Relay, Brake Pedal Position Switch

Under-hood Fuse/Relay Box (6-13). Scheme 80

Scheme 80: Under-hood Fuse/Relay Box (6-13)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected
11	SMART ACC	7.5A	ALL MODELS	Accessory Relay Keyless Access
12			ALL MODELS	Not Used
13	IG COIL	15A	ALL MODELS	Ignition Coil Relay
14	FI SUB	15A	ALL MODELS	ECM/PCM, PGM-FI Sub-relay
15	BACK UP	10A	ALL MODELS	AcuraLink Control Unit (XM Receiver) (AcuraLink), AcuraLink Reprogramming Connector (AcuraLink), Audio-Navigation Unit (Navigation), Audio Unit (without Navigation), Audio/Navigation Switch Panel (Navigation), Audio-HVAC Display Unit (without Navigation), DLC, Driver's Door Courtesy Light, Driver's MICU, Front Passenger's Door Courtesy Light, Gauge Control Module, HandsFreeLink Control Unit, Immobilizer-Keyless Control Unit (without Keyless Access), HFL-Navigation Microphone (Navigation), Navigation Display Unit (Navigation), Passenger's MICU, Power Mirror Control Unit, Power Seat Control Unit, Power Window Master Switch
16	INTR LT	7.5A	ALL MODELS	Driver's Vanity Mirror Light, Front Passenger's Vanity Mirror Light, Ignition Key Switch/Key Light (without Keyless Access), Rear Individual Map Lights, Roof Console, Trunk Light
17	Fl MAIN	15A	ALL MODELS	PGM-FI Main Relay
18	DBW	15A	ALL MODELS	ETCS Control Relay
19	BACK UP	7.5A	ALL MODELS	ECM/PCM
20	MG CLUTCH	7.5A	ALL MODELS	A/C Compressor Clutch Relay
21	FAN RLY	7.5A	ALL MODELS	A/C Diode B, Radiator Fan Relay

Under-hood Fuse/Relay Box (6-15). Scheme 81

Scheme 81: Under-hood Fuse/Relay Box (6-15)

Ref	Socket	Cavities	Connects to
1	Blower Motor Relay	4
2	A/C Condenser Fan Relay	4
3	PGM-FI Main Relay	4
4	PGM-FI Sub-relay	4
5	Ignition Coil Relay	4
6	ETCS Control Relay	4
7	Starter Cut Relay 2	4
8	Rear Window Defogger Relay	4
9	T101		Starter Sub-harness (see CONNECTOR TO HARNESS INDEX or STARTER CABLE (M/T) )
10	T102		Engine Wire Harness (see ENGINE WIRE HARNESS (ENGINE SECTION) (A/T) or ENGINE WIRE HARNESS (ENGINE SECTION) (M/T) )
11	A (ELD Unit)	3	Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) )
12	A/C Compressor Clutch Relay	4
13	C	5	Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) )
14	B	14	Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) )

Under-hood Fuse/Relay Box (6-17). Scheme 82

Scheme 82: Under-hood Fuse/Relay Box (6-17)
