Under-hood Fuse/Relay Box
| Socket | Ref | Terminal | Connects to | Notes |
|---|---|---|---|---|
| A (electrical load detector (ELD)) | 12 | 3 | Left engine compartment wire harness (Engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) | |
| Electrical load detector (ELD) | 11 | 3 | Connector A (3P) | |
| A/C compressor clutch relay B A/C condenser fan relay | 16 2 | 4 4 | ||
| B (relay circuit board) | 14 | 14 | Left engine compartment wire harness (Engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) | |
| Blower motor relay | 1 | 4 | ||
| C (relay circuit board) | 13 | 5 | Left engine compartment wire harness (Engine compartment branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (ENGINE COMPARTMENT BRANCH) ) | |
| Electronic throttle control system (ETCS) control relay | 6 | 4 | ||
| Ignition coil relay | 5 | 4 | ||
| PGM-FI main relay 1 (FI MAIN) | 3 | 4 | ||
| PGM-FI subrelay | 4 | 4 | ||
| A/C condenser fan relay | 2 | 4 | ||
| Rear window defogger relay | 8 | 4 | ||
| Relay circuit board | 15 | Connector B (14P) and C (5P) | ||
| Starter cut relay 2 | 7 | 4 | ||
| T101 | 9 | Starter cable, M/T (see STARTER CABLE (M/T) ), A/T (see STARTER CABLE (A/T) ) | ||
| T102 | 10 | Engine wire harness (Engine section) (see CONNECTOR TO HARNESS INDEX ) |
TERMINAL REFERENCE CHART
Scheme 30
Driver's Under-dash Fuse/Relay Box
| Socket | Ref | Terminal | Connects to | Notes |
|---|---|---|---|---|
| A | 1 | Not used | ||
| Accessory relay | 4 | 4 | (1) | |
| B | 2 | 2 | Dashboard wire harness (View of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| C | 3 | 5 | Dashboard wire harness (View of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| D | 11 | 16 | Left side wire harness Without SH-AWD (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) ) With SH-AWD (see LEFT SIDE WIRE HARNESS (WITH SH-AWD) ) | |
| E | 10 | 20 | Left side wire harness Without SH-AWD (see LEFT SIDE WIRE HARNESS (WITHOUT SH-AWD) ) With SH-AWD (see LEFT SIDE WIRE HARNESS (WITH SH-AWD) ) | |
| F | 9 | 33 | Left engine compartment wire harness (Dashboard branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| Front accessory power socket relay | 4 | 4 | (2) | |
| G | 8 | 13 | Left engine compartment wire harness (Dashboard branch) (see LEFT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH) ) | |
| H (optional connector) | 7 | 12 | ||
| K (MICU service check connector) | 6 | 3 | ||
| M | 13 | 4 | Dashboard wire harness (View of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| N | 14 | 16 | Dashboard wire harness (View of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| P | 15 | 20 | Dashboard wire harness (View of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| PGM-FI main relay 2 (FUEL PUMP) | 12 | 4 | ||
| Q | 17 | 20 | Dashboard wire harness (View of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| R | 16 | 24 | Dashboard wire harness (View of driver's side) (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| Starter cut relay 1 | 5 | 4 | ||
| (1) With keyless access system (2) Without keyless access system | ||||
| (1) | With keyless access system |
| (2) | Without keyless access system |
TERMINAL REFERENCE CHART
Scheme 31
Passenger's Under-dash Fuse/Relay Box
| Socket | Ref | Terminal | Connects to | Notes |
|---|---|---|---|---|
| A | 1 | 38 | Dashboard wire harness (View of middle to passenger's side) (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) ) | |
| B | 8 | 1 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) | |
| C | 7 | 12 | Not used | |
| D | 2 | 28 | Audio wire harness (see AUDIO WIRE HARNESS ) | |
| E | 6 | 18 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) | |
| F | 5 | 2 | Not used | |
| G | 3 | 16 | Right side wire harness (see RIGHT SIDE WIRE HARNESS (WITHOUT SH-AWD) ) | (1) |
| H | 4 | 38 | Right side wire harness (see RIGHT SIDE WIRE HARNESS (WITH SH-AWD) ) | (2) |
| (1) Without SH-AWD (2) With SH-AWD | ||||
| (1) | Without SH-AWD |
| (2) | With SH-AWD |
TERMINAL REFERENCE CHART
Scheme 32
