Radiator, Transmission Components - Removal & Installation: Specifications Volvo V70 II

Cooling System (Mechanical) 5 illustrations ~512 words

Removing the torque converter

Pull the torque converter straight out of the transmission. Check the torque converter throat for damage.

Scheme 72

Scheme 72: Removing the sealing ring from the oil pump

Use extractor 9995069 .

Scheme 73

Scheme 73: Installing a new sealing ring on the oil pump

Use drift 9995117 .

Note. Drift 9995117 modified according to the Workshop Guide.

Scheme 74

Scheme 74: Installing the torque converter

Lubricate the torque converter throat with ATF oil.

Note. Take care not to damage the oil pump during installation.

Make sure torque converter is as far into the transmission as possible. Check with a ruler. The distance between the cover and retaining tabs should be approximately approximately 14 mm .

Checking / replacing the torque converter

Ensure that the mating surfaces on the torque converter cover are clean.

Apply a light coating of grease to the torque converter guide studs and in the holes for the guide bushings on the torque converter cover.

Ensure that the torque converter is as far into the transmission as possible.

Check with a ruler that the distance between the cover and mounting lugs is approximately 14 mm .

Removing the upper torque rod

See Replacing the torque rod.

Scheme 75

Scheme 75: Continue removing engine compartment components

Remove the air hose for the turbocharger (TC)

Slacken off the hose clamp around the air hose down by the turbocharger (TC).

Remove the hose clamp around the rubber hose.

Separate the connector.

Remove the rubber hoses from their clips above the air hose.

Remove the air hose.

Remove the ventilation from the valve cover (slacken off the hose clamp).

Removing the torque control arm

See Replacing the torque control arm.

Installing and tightening the screws for the gearbox

Install the screws for the gearbox / engine. Tighten the two larger screws. Tighten to 50 Nm . Tighten the two smaller screws. Tighten to 25 Nm .

Remove the fixture from the gearbox.

Installing and tightening the screws for the front engine pad

See Installing and tightening the screw for the rear engine pad.

Installing the delivery line on the rubber hoses and torque rod screws

Install

  1. the turbo pipe on the rubber hoses. Tighten the hose clamps
  2. the screws for the clamps on the gearbox. Tighten to 10 Nm
  3. the torque rod and the screws. Tighten to 50 Nm .

Installing and tightening the screw for the rear engine pad

Pry up the anti-roll bar strut slightly using a crowbar. This makes it easier to insert the screws.

Tighten the screw to 50 Nm .

Installing and tightening the sub-frame screws

See Installing and tightening the sub-frame screws.

Installing and tightening front end components (both sides)

See Installing and tightening front end components (both sides).

Tightening the ball joint pinion

See Tightening the ball joint pinion.

Scheme 76

Scheme 76: Filling the gearbox with fluid

P/N: 1161423-7.

Correct volume: 2.1 liters

Tighten the plug to 35 Nm .

Installing the torque control arm

See Installing the torque control arm.

Installing the upper torque rod in the engine compartment

See Installing the upper torque rod in the engine compartment.
