LUBRICANTS, ENGINE

Engine	Service interval (km/miles)	Volume (liters)	Grade	Viscosity	Part number
Gasoline	12.000/7.500	Approx. 5.8	ILSAC GF-4 API SL / ACEA A1/B1	SAE 5W-30	1161754, -755, -756

CLASSIFICATION OF MAIN BEARINGS

The marking is stamped in the engine block and crankshaft. The classification marking is in the engine block above the oil cooler and crankshaft. The classification shall be read from the digit 1 to 7.

The first letter after the digit 1 is the classification of main bearing 1. The bearing positions are numbered starting at the engine's leading edge.

	Class A block small diameter		Class B block average diameter		Class C block large diameter
	Block	Intermediate section	Block	Intermediate section	Block	Intermediate section
Class A crankshaft small	Yellow medium	Yellow medium	Yellow medium	Blue thick	Blue thick	Blue thick
Class B crankshaft medium	Red thin	Yellow medium	Yellow medium	Yellow medium	Yellow medium	Blue thick
Class C crankshaft large	Red thin	Red thin	Red thin	Yellow medium	Yellow medium	Yellow medium

Scheme 169

Scheme 169: CYLINDER BLOCK

CYLINDER BORE (SHOWN AS "D" IN THE ILLUSTRATION)

Standard
C-marked........ mm	83.000-83.010
D-marked........ mm	83.010-83.020
E-marked........ mm	83.020-83.030

CYLINDRICITY

Maximum deviation
Cylinder bore........ mm	0, 013

Scheme 170

Scheme 170: PISTONS

Standard	The diameter is measured 12 mm from the bottom of the piston
C-marked 1 ........ mm	82.950-82.960
D-marked 1 ........ mm	82.960-82.970
E-marked 1 ........ mm	82.970-82.980
1 Classification is marked on the top of the piston.

PISTON RUNNING CLEARANCE

Tolerance piston/cylinder - top........ mm

0.010 - 0.030

PISTON RINGS

Top ring........ mm	1.2 -0.01/-0.03
1st ring........ mm	1.5 -0.01/-0.03
Oil ring........ mm	2 -0.01/-0.136

PISTON PIN

Diameter........ mm	21.000 0.000/-0.004
Length........ mm	57.0 0.0/+0.2

Scheme 171

Scheme 171: VALVES

Intake
Length (A)........ mm	102.00 ±0.07
Diameter on crown (B)........ mm	31 ±0.15
Diameter on shaft (C)........ mm	5.94 ±0.07
Valve angle (D)........°	45.5 ±0.17
Clearance in guide........μm	50 - 70
Valve clearance........ mm	0.20 ±0.03
Exhaust
Length (A)........ mm	101.05 ±0.07
Diameter on crown (B)........ mm	27 ±0.15
Diameter on shaft (C)........ mm	5.94 ±0.07
Valve angle (D)........°	45.5 ±0.17
Clearance in guide........μm	50 - 70
Valve clearance........ mm	0.40 ±0.03

VALVE SEATS

Seat angle........°

45.5 ±0.17

TAPPETS

Diameter........ mm	32 -0.025/-0.040
Length........ mm	2, 950 - 3, 685 ±0, 01

CAMSHAFTS

Max. lift height inlet........ mm	8.68
Max. lift height exhaust........ mm	9.05

CYLINDER HEAD

Max. distortion........ mm	0.5
Max. distortion, transverse........ mm	0, 2
Height........ mm	149.4 ±0.15

CRANKSHAFT

Radial run-out main bearing journal........ mm	Max. 0.040
Axial play (Measured in the engine with the intermediate section tightened)........ mm	0.08-0.19
Main bearing journal, radial runout........ mm	0.020-0.043

BIG END JOURNALS

Diameter, standard 1 ........ mm	50.000 0.000/-0.016
Bearing recess width........ mm	26.0 ±0.1
Maximum out-of-round........ mm	0.004
Maximum taper........ mm	0.004
1 The variation in diameter for each bearing journal must not exceed 0.008 mm.

MAIN BEARING JOURNALS

Diameter, standard 1 ........ mm	65.000 +0.003/-0.016
Axial bearing width........ mm	26.00 0.00/-0.04
Maximum out-of-round........ mm	0.004
Maximum taper........ mm	0.004
1 The variation in diameter for each bearing journal must not exceed 0.008 mm.

CONNECTING RODS

Diameter, bearing recesses
Big end........ mm	53.000 0.000/+0.013
Small-end........ mm	21.000 +0.005/+0.011
Maximum ovality in the bearing recesses........ mm	0.006
Length
Big end - Small end........ mm	147

OIL PRESSURE

Oil pressure (min.)
13.3 r/s (800 RPM)........ Mpa 1	0.10
14.2 r/s (850 RPM)........ Mpa 1	0.10
66.7 r/s (4000 RPM)........ Mpa 1	0.35
Maximum oil pressure (the relief valve opens)........ Mpa 1	0.48
1 The oil pressure given is for an oil temperature of 100°C, which is reached after 10-15 minutes driving.

FUEL LINE PRESSURE

Desired value
Relative pressure	380 kPa
Absolute pressure	480 kPa

THERMOSTAT

Begins to open at	90°C
Fully open at	105°C

ENGINE MANUFACTURE NUMBER, ENGINE SERIAL NUMBER AND TYPE

The engine serial number and type are stamped on the left side of the cylinder block at the top of the mounting for the water pump.

There is also a decal on the timing casing with the engine type, manufacturing number, and serial number.
