INSTALLATION
Install cylinder head, see CYLINDER HEAD
REMOVAL
Remove the cylinder head, see CYLINDER HEAD
Install cylinder head, see CYLINDER HEAD
Remove the cylinder head, see CYLINDER HEAD
Install timing belt, see TIMING BELT (B5244S4; 2005) or TIMING BELT (B5244S4; B5244S7; 2007-2010)
Remove timing belt, see TIMING BELT (B5244S4; 2005) or TIMING BELT (B5244S4; B5244S7; 2007-2010)
Install timing belt, see TIMING BELT (B5244S4; 2005) or TIMING BELT (B5244S4; B5244S7; 2007-2010)
Remove timing belt, see TIMING BELT (B5244S4; 2005) or TIMING BELT (B5244S4; B5244S7; 2007-2010)
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: Piston cooling nozzle
32 Nm
Scheme 206
Note. Make sure that the classification of the components correspond with each other.
See information about engine, see ENGINE
Scheme 207
Note. Make sure that the classification of the components correspond with each other.
See information about engine, see ENGINE
Scheme 208
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Scheme 209
| CAUTION | Take extra care when handling the components. |
| CAUTION | Make sure that the crankshaft is not rotated. |
Scheme 210
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Scheme 211
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Scheme 212
Torque: Intermediate section for engine block step 1
20 Nm
Torque: Intermediate section for engine block step 2
40 Nm
Scheme 213
Torque: Intermediate section for engine block step 3
24 Nm
Scheme 214
Torque: Intermediate section for engine block step 4
17 Nm
Torque: Intermediate section for engine block step 5
90 degree
Scheme 215
Note. Make sure that the classification of the components correspond with each other.
See information about engine, see ENGINE
Scheme 216
Scheme 217
See information about engine, see ENGINE
Scheme 218
Scheme 219
Note. Make sure that the classification of the components correspond with each other.
Scheme 220
Scheme 221
see 9995746
Note. Make sure that the classification of the components correspond with each other.
Torque: Cap connecting rod
Stage 1: 30 Nm
Stage 2: 90 degree
Torque: M7
17 Nm
Scheme 222
see 9997273
Scheme 223
| CAUTION | Make sure that the gaskets are correctly located. |
Scheme 224
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Torque: M7
17 Nm
Torque: M7
17 Nm
Torque: M10
50 Nm
Scheme 225
see 9997174
| CAUTION | Take extra care not to damage the mating faces. |
see 9995651
| CAUTION | Note the position of the components before removal. |
| CAUTION | Take extra care when handling the components. |
see 9995746
| CAUTION | Take extra care not to damage the mating faces. |
| CAUTION | Take extra care when handling the components. |
Note. Only use moderate force.
| CAUTION | Take extra care when handling the components. |
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
Note. Make sure that the classification of the components correspond with each other.
See information about engine, see ENGINE
Note. Make sure that the classification of the components correspond with each other.
See information about engine, see ENGINE
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
| CAUTION | Take extra care when handling the components. |
| CAUTION | Make sure that the crankshaft is not rotated. |
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Torque: Intermediate section for engine block step 1
20 Nm
Torque: Intermediate section for engine block step 2
40 Nm
Torque: Intermediate section for engine block step 3
24 Nm
Torque: Intermediate section for engine block step 4
17 Nm
Torque: Intermediate section for engine block step 5
90 degree
Note. Make sure that the classification of the components correspond with each other.
See information about engine, see ENGINE
Scheme 226
See information about engine, see ENGINE
Note. Make sure that the classification of the components correspond with each other.
see 9995746
Note. Make sure that the classification of the components correspond with each other.
Torque: Cap connecting rod
Stage 1: 30 Nm
Stage 2: 90 degree
Torque: M7
17 Nm
see 9997273
| CAUTION | Make sure that the gaskets are correctly located. |
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Torque: M7
17 Nm
Torque: M7
17 Nm
Torque: M10
50 Nm
see 9997174
