REMOVAL
Remove camshafts, see CAMSHAFTS
Scheme 194
Note. Note the position of each component before removal.
Scheme 195
Scheme 196
Scheme 197
Torque: M7
17 Nm
see 9995765
Scheme 198
Scheme 199
Torque: M6
10 Nm
Scheme 200
Measure and note the valve clearance values.
See information about specifications, see ENGINE - MECHANICAL AND TORQUE SPECIFICATIONS
Calculate the required thickness of the valve tappet with the following formula
Measurement of existing valve clearance (actual value) =
Required thickness of valve tappet =
Compare the measured valve clearance(s) with the specifications.
Measure the valve clearance and if necessary, adjust by installing new valve tappets.
Repeat the procedure as necessary until all valve clearances are within the specified tolerance.
Repeat the measurement for all cylinders.
Scheme 201
Install camshafts, see CAMSHAFTS
