Engine - Removal, Replacement and Installation: Overview Volvo V50 I рестайлинг

Scheme 1

Install the following items

1. Engine support insulator, left, see «ENGINE SUPPORT INSULATOR, LEFT»(ref-466659-S38747202142012042500000)
2. Engine support insulator, right, see «ENGINE SUPPORT INSULATOR, RIGHT»(ref-466659-S38257567102012042500000)

Scheme 2

Torque: M8

24 Nm

Scheme 3

1. Torque: M10 50 Nm
2. Torque: Pressure line to power steering pump 30 Nm

Scheme 4

Torque: M6

10 Nm

Scheme 5

Scheme 6

Scheme 7

Torque: M6

10 Nm

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Torque: M6

10 Nm

Scheme 13

Scheme 14

Torque: M6

10 Nm

Scheme 15

1. Torque: M8 24 Nm
2. Torque: M6 10 Nm

Scheme 16

1. Torque: M8 24 Nm
2. Torque: M6 10 Nm

Scheme 17

Scheme 18

Scheme 19

Torque: M6

10 Nm

Install the following items

1. Driveshaft left, see «DRIVESHAFT LEFT»(ref-466740-S05875829252012042500000)
2. Drive shaft right, see «DRIVE SHAFT RIGHT»(ref-466740-S14159912262012042500000)
3. the catalytic converter, see «CATALYTIC CONVERTER»(ref-466651-S09894321312012042500000)
4. Front subframe
5. Bracket lower torque rod, see «BRACKET LOWER TORQUE ROD»(ref-466659-S36531864382012042500000)
6. Tensioner accessory drive belt, see «ACCESSORY DRIVE BELT TENSIONER»(ref-466659-S19986261482012042500000)
7. air cleaner (ACL) housing, see «AIR CLEANER HOUSING»(ref-466651-S39773552372012042500000)
8. battery, see «BATTERY»(ref-466696-S07629326482012042500000)

Fill cooling system, draining, filling, and bleeding, see COOLING SYSTEM - DRAINING, CHARGING AND BLEEDING

Perform oil level power steering, check, see OIL LEVEL, POWER STEERING, CHECKING

Top up the engine oil, see ENGINE OIL
