Threads - Overhaul Instructions: Overview Volvo S80 I

Mechanical 7 illustrations ~471 words

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 380

Scheme 380: Thread inserts, general

Damaged threads can in most cases be reconditioned using HELI-COIL thread inserts.

Thread inserts are available in a variety of sizes, pitches and lengths. A correctly reconditioned thread will generally increase the strength of a joint.

Scheme 381

Scheme 381: Designation of thread insert

Measure the old threads and thread length in the hole.

A: Thread.

B: Thread length.

Scheme 382

Scheme 382: Drilling and tapping new thread in the hole

Drill out the old threads using the correct diameter drill bit. Blow the hole clean.

Tap the new thread using the correct tap.

Note. The thread taps referred to in the text are specially made for use with the HELI-COIL system.

Use methylated spirit or similar to lubricate the threading operation in aluminum. Thread longer threads in stages, backing out the tap and blowing the tap and the hole clean in between.

Thread the hole to the proper depth (or through if it is to be threaded throughout).

C: drill depth.

D: cutting phase.

Scheme 383

Scheme 383: Tools required for installation

The installation tool (illustrated) is used for threads M6 - M14 . During some operations the tool must be disassembled by removing the locking ring, for example with countersunk threads.

For threads M16 and larger the specific tool for each thread size must be used The guide and mandrel are included.

Scheme 384

Scheme 384: Installing the thread insert in the installation tool

Locate the thread insert with the tang facing down in the tool.

Turn the spindle until the tang engages in the recess.

Screw the thread insert into the guide, do not apply pressure, until the first turn of the thread insert is flush with the guide opening.

A: Tang.

B: Guide.

C: Mandrel.

Scheme 385

Scheme 385: Installation of thread insert

Hold the installation tool straight above and centered over the hole. Screw in the insert without applying pressure on the spindle handle. Screw in until the end of the insert reaches at least half a thread revolution into the thread.

The insert must not touch the bottom of the hole or stick out of the other side if it is a through hole.

Break off the tang with the proper tang breaker. For M14 threads and coarser, use a pair of flat-nosed pliers or similar and break downwards.

Scheme 386

Scheme 386: Extraction of damaged thread insert

Alternative 1

File a notch in the thread insert, about a quarter turn in from the end. Do not file through the insert.

Note. Do not damage the thread in the material.

Use a triangular scraper or similar to extract the insert by rotating it.

Alternative 2

Carefully expose the end of the thread insert. Use flat-nose pliers to pull the thread insert out.

Clean out the threads in the hole using the thread tap and blow clean.

Install a new thread insert.
