Removing The Vibration Damper
Remove the 4 screws. Use the crankshaft center nut as a counterhold.
Install counterhold 9995433 and remove the center nut.
Remove counterhold 999 5433.
Work / pull the auxiliaries belt pulley loose.
Installing The Vibration Damper
Install
- the crankshaft pulley for the auxiliaries belt
- counterhold «9995433»(ref-403953-S41906385022011061000000) .
- the crankshaft center nut. Tighten to 300 Nm .
Remove counterhold 999 5433.
Install the vibration damper. Use new screws. Tighten to 35 Nm . Angle tighten 50° . Use the crankshaft center nut as a counterhold.
Remove the 4 screws. Use the crankshaft center nut as a counterhold.
Install counterhold 9995433 . Remove the center nut.
Remove counterhold 999 5433.
Work / pull the auxiliaries belt pulley loose.
Scheme 451
Slacken off the center screw for the belt tensioner slightly.
Hold the center screw in place. Turn the eccentric on the tensioner counter-clockwise to the 10 o'clock position using a 6mm Allen key.
Unhook and remove the timing belt.
| CAUTION | Do not turn the camshafts or the crankshaft when the timing belt has been removed. |
Install
- the crankshaft pulley for the auxiliaries belt
- counterhold «9995433»(ref-403953-S41906385022011061000000) .
- the crankshaft center nut. Tighten to 300 Nm .
Remove counterhold 999 5433.
Install the vibration damper. Use new screws. Tighten to 35 Nm . Angle tighten 50° . Use the crankshaft center nut as a counterhold.
Install
- the crankshaft pulley for the auxiliaries belt
- counterhold «9995433»(ref-403953-S41906385022011061000000) .
- the crankshaft center nut. Tighten to 300 Nm .
Remove counterhold 999 5433.
Install the vibration damper. Use new screws. Tighten to 35 Nm . Angle tighten 50° . Use the crankshaft center nut as a counterhold.
Remove the 4 screws. Use the crankshaft center nut as a counterhold.
Install counterhold 9995433 . Remove the center nut.
Remove counterhold 9995433 .
Work the vibration damper loose.
Scheme 452
Slacken off the center screw for the belt tensioner slightly.
Hold the center screw in place. Turn the belt tensioner eccentric clockwise to 10 o'clock using a 6mm Allen key.
Remove the timing belt from the timing gear pulley for the camshafts.
Remove the timing belt.
Scheme 453
| CAUTION | The crankshaft must not rotate. |
Use puller 9995304 and two 45 mm M8 screws with washers.
Pull off the timing gear pulley.
Scheme 454
Remove the belt tensioner and idler pulley.
Check the rolling surface and the bearings.
Check for any noise. Check for any play in the bearings.
Check that the rolling surfaces are smooth and clean.
Install the vibration damper. Use counterhold 9995433 .
Tighten the center nut to 180 Nm .
Remove counterhold 999 5433.
Tighten the four screws. Tighten to 25 Nm . Angle tighten 30° . Use the crankshaft center screw as a counterhold.
Remove the 4 screws. Use the crankshaft center nut as a counterhold.
Install the counterhold 9995433 and remove the center nut.
Remove counterhold 999 5433.
Work the vibration damper loose.
Scheme 455
Slacken off the center screw for the belt tensioner slightly.
Hold the center screw secure. Turn the belt tensioner eccentric clockwise with a 6mm Allen key to 10 o'clock.
Remove the timing belt from the timing gear pulley for the camshafts.
Remove the timing belt.
