Signal specification, rear seat entertainment module (RSE)
| U= | DC voltage in volts (V) | U AC = | AC voltage in volts (V) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | T = | Time in seconds |
| PWM = | Pulse-width modulated signal in % |
Rear seat entertainment module (RSE)
Scheme 7
| Terminal | Signal type | Ignition on | Cable or signal information |
|---|---|---|---|
| #A1 | I2C data bus (SDA) | Data signal 0-5 V | #1-#10 left screen |
| #A2 | Synch clock signal I2C (SCL) | Data signal 0-5 V | |
| #A3 | Ground, screen | U=U low | Sheath to cable |
| #A4 | Infra red signal receiver (IR) | Remote control receiver | |
| #A5 | Supply to infra red receiver (IR) | 5 V | Remote control receiver |
| #A6 | Supply to screen (LCD) | U=U high | |
| #A7 | Image signal | Analog signal | |
| #A8 | Reference ground image signal and screen | U=U low | |
| #A9 | Ground for background lighting screen | U=U low | Lighting LCD screen |
| #A10 | Supply for background lighting screen | U=U high | Lighting LCD screen |
| #A11 | I2C data bus (SDA) | Data signal 0-5 V | #11-#20 right screen |
| #A12 | Synch clock signal I2C (SCL) | Data signal 0-5 V | |
| #A13 | Ground, screen | U=U low | Sheath to cable |
| #A14 | Infra red signal receiver (IR) | Remote control receiver | |
| #A15 | Supply to infra red receiver (IR) | 5 V | Remote control receiver |
| #A16 | Supply to screen (LCD) | U=U high | |
| #A17 | Image signal | Analog signal | |
| #A18 | Reference ground image signal and screen | U=U low | |
| #A19 | Ground for background lighting screen | U=U low | Lighting LCD screen |
| #A20 | Supply for background lighting screen | U=U low | Lighting LCD screen |
Signal table
| Terminal | Signal type | Ignition on | Cable or signal information |
|---|---|---|---|
| #B1 | 15 supply | U=U high | U=U low with ignition off |
| #B2 | Ground TV | U=U low | TV ground, port select |
| #B3 | |||
| #B4 | |||
| #B5 | |||
| #B6 | Supply | U=U high | |
| #B7 | Video signal (in) | Analog signal | TV image |
| #B8 | Video, signal ground | U=U low | TV image |
| #B9 | Right audio signal (in) | TV audio | |
| #B10 | Left audio signal (in) | TV audio | |
| #B11 | Audio ground | U=U low | TV audio |
| #B12 | Power ground | U=U low |
Signal table
| Terminal | Signal type | Ignition on | Cable or signal information |
|---|---|---|---|
| #C1 | Right audio (out), sound channel 1 | AC | Low level, signal to headsets via rear audio separation (RAS). Each headset pair has one audio channel |
| #C2 | Left audio (out), sound channel 1 | AC | Low level, signal to headsets via rear audio separation (RAS). Each headset pair has one audio channel |
| #C3 | |||
| #C4 | Right audio (out), sound channel 2 | AC | Low level, signal to headsets via rear audio separation (RAS). Each headset pair has one audio channel |
| #C5 | Left audio (out), sound channel 2 | AC | Low level, signal to headsets via rear audio separation (RAS). Each headset pair has one audio channel |
| #C6 | Channel selector audio | 0 V = no signal at all 5 V = sound for the left screen in the speaker (master) 7.5 V = sound for the right screen in the speaker (master) | The sound for the left-hand passenger position is always in the left-hand headset and vice-versa |
| #C7 | Video signal (in) | Analog signal | Wiring to AUX panel |
| #C8 | Video, signal ground | U=U low | Wiring to AUX panel |
| #C9 | Right audio signal (in) | Wiring to AUX panel | |
| #C10 | Left audio signal (in) | Wiring to AUX panel | |
| #C11 | Audio ground | Wiring to AUX panel | |
| #C12 | Audio ground | Low level, signal to headsets via rear audio separation (RAS) |
Signal table
| Terminal | Signal type | Ignition on | Cable information |
|---|---|---|---|
| #D1 | A and B regard the connectors on the digital versatile disc player | ||
| #D2 | IR reference signal ground for DVD | U=U low | #A2 DVD (IR GND) |
| #D3 | |||
| #D4 | 15-supply and lighting to DVD | U = U bat | #A6 DVD (Lighting) and #A7 (DVD 15-supply) |
| #D5 | IR control signal for DVD | U =5 V | #A1 DVD (IR in) |
| #D6 | Supply | U = U bat | #A4 DVD (Batt) |
| #D7 | Image signal | Analog signal | #B7 DVD (Video out) |
| #D8 | Image signal reference ground | U=U low | #B8 DVD (Video GND) |
| #D9 | Right audio channel | AC | #B6 DVD (Audio right) |
| #D10 | Left audio channel | AC | #B5 DVD (Audio left) |
| #D11 | Reference ground for audio channels | U=U low | #B4 DVD (Audio GND) |
| #D12 | Ground | U=U low | #A8 DVD (ground) |
| #D13 | |||
| #D14 | |||
| #D15 | |||
| #D16 |
Signal table
See Signal specification, rear seat entertainment module (RSE)
See Signal specification, rear seat entertainment module (RSE)
See Signal specification, rear seat entertainment module (RSE)
See Signal specification, rear seat entertainment module (RSE)
Signal specification, control module for rear audio separation (RAS)
| U= | DC voltage in volts (V) | U AC = | AC voltage in volts (V) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | T = | Time in seconds |
| PWM = | Pulse-width modulated signal in % |
Rear audio separation module (RAS).
Scheme 8
| Terminal | Signal type | Ignition on | Cable or signal information |
|---|---|---|---|
| #A1 | Battery voltage supply | U bat | |
| #A2 | Right audio (out), sound channel 2 | Headset signal channel 2, low level audio | |
| #A3 | Left audio (out), sound channel 2 | Headset signal channel 2, low level audio | |
| #A4 | 15-feed | U bat | |
| #A5 | Left audio (out), sound channel 1 | Headset signal channel 1, low level audio | |
| #A6 | Right audio (out), sound channel 1 | Headset signal channel 1, low level audio | |
| #A7 | |||
| #A8 | Loudspeaker signal left-hand (L-) | U=U low | Rear loudspeakers, high level audio |
| #A9 | Loudspeaker signal left-hand (R-) | Rear loudspeakers, high level audio | |
| #A10 | Loudspeaker signal left-hand (R+) | Rear loudspeakers, high level audio | |
| #A11 | Loudspeaker signal left-hand (L+) | Rear loudspeakers, high level audio | |
| #A12 | Incoming loudspeaker sound (L+) | The control module for audio separation (RAS) receives sound from the standard system and processes the sound. | |
| #A13 | Ground supply | U low | |
| #A14 | |||
| #A15 | Audio ground | ||
| #A16 | |||
| #A17 | |||
| #A18 | Channel selector ground | 0 V = no signal at all 5 V = sound for the left screen in the speaker (master) 7.5 V = sound for the right screen in the speaker (master) | The sound for the left-hand passenger position is always in the left-hand headset and vice-versa |
| #A19 | |||
| #A20 | |||
| #A21 | Incoming loudspeaker sound (R-) | Alternating voltage at sound in instrument panel speaker | The control module for rear audio separation (RAS) receives sound from the standard system and processes the sound. |
| #A22 | Incoming loudspeaker sound (R+) | The control module for rear audio separation (RAS) receives sound from the standard system and processes the sound. | |
| #A23 | Incoming loudspeaker sound (L-) | The control module for rear audio separation (RAS) receives sound from the standard system and processes the sound. | |
| #A24 |
Signal table
| Terminal | Signal type | Ignition on | Cable type or description |
|---|---|---|---|
| #B1 | Supply IR | 5 V | IR transmitter headset |
| #B2 | IR audio Hi | Low level | Twisted |
| #B3 | IR audio Lo | Low level | Twisted |
| #B4 | Ground | U low |
Signal table
See Signal specification, control module for rear audio separation (RAS)
See Signal specification, control module for rear audio separation (RAS)
See Signal specification, control module for rear audio separation (RAS)
Signal specification, TV Executive
| U= | DC voltage in volts (V) | U bat = | Battery voltage (V) |
|---|---|---|---|
| U low = | Voltage approximately 0 V |
| Terminal in control module connector N1 | Signal name | Signal type | Ignition on | Signal specification | ||
|---|---|---|---|---|---|---|
| N1-1 | VIDEO-in | Video signal TV | Analog signal | 1V p-p +-0.2V | ||
| N1-2 | C-SYNC-in | Composite synch, TV | Analog signal | 0-5V | ||
| N1-3 | ||||||
| N1-4 | ||||||
| N1-5 | ||||||
| N1-6 | +B-TV | 30-supply to the TV tuner | U bat | |||
| N1-7 | GND-TV | Signal ground TV | U low | |||
| N1-8 | SHIELD-GND | Screen ground | U low | |||
| N1-9 | +B | 30-supply to the M2D control module | U bat | |||
| N1-10 | RHEO+-in | Background lighting, TV | U low | U bat , when the BRIGHTNESS switch is pressed | ||
| N1-11 | REMOCON-out | Remote control TV | Digital signal | 33.3 kHz carrier wave when the remote control is pressed | ||
| N1-12 | ||||||
| N1-13 | GND | Ground | U low | |||
| N1-14 | ||||||
M2D control module (for the TV receiver)
| Terminal in control module connector N4 | Signal name | Signal type | Ignition on | Signal specification | ||
|---|---|---|---|---|---|---|
| N4-1 | MSCK | Clock signal | Digital signal | Melbus protocol | ||
| N4-2 | SIG-GND | Signal ground | U low | |||
| N4-3 | EXT-ACC | 15 supply | U bat | |||
| N4-4 | MDATA | Data signal | Digital signal | Melbus protocol | ||
| N4-5 | MBUSY | Busy signal | Digital signal | Melbus protocol | ||
| N4-6 | LCH-OUT | Left audio channel | Alternating current when there is sound to the loudspeaker | 150m Vrms +/- 38mV (1kHz 30% mod) | ||
| N4-7 | RCH-OUT | Right audio channel | Alternating current when there is sound to the loudspeaker | 150m Vrms +/- 38mV (1kHz 30% mod) | ||
| N4-8 | ||||||
| H | FG | Screen ground | U low | |||
M2D control module (to the audio unit)
| Terminal in control module connector N5 | Signal name | Signal type | Ignition on | Signal specification | ||
|---|---|---|---|---|---|---|
| N5-1 | SIG-GND | Signal ground | U low | |||
| N5-2 | LCH-IN | Left audio channel | Alternating current when there is sound to the loudspeaker | 150m Vrms +/- 38mV (1kHz 30% mod) | ||
| N5-3 | ||||||
| N5-4 | RCH-IN | Right audio channel | Alternating current when there is sound to the loudspeaker | 150m Vrms +/- 38mV (1kHz 30% mod) | ||
| N5-5 | ||||||
| N5-6 | ||||||
| N5-7 | ||||||
| N5-8 | ||||||
| N5-9 | ||||||
| N5-10 | EXT-ACC | 15 supply | U bat | |||
| N5-11 | MBUSY | Busy signal | Digital signal | Melbus protocol | ||
| N5-12 | MSCK | Clock signal | Digital signal | Melbus protocol | ||
| N5-13 | MDATA | Data signal | Digital signal | Melbus protocol | ||
| H | FG | Screen ground | U low | |||
M2D control module (to the audio unit)
Note. Before taking readings, the breakout box must be connected and the ground terminal must be checked. See Checking the ground terminals .
| DC voltage in volts (V) | Ulow = Voltage near V |
|---|---|
| Ubat = Battery voltage |
TV receiver terminals M1-M16 correspond to terminals #25-#40 on the breakout box.
| Control module terminal | Breakout box terminal | Signal type | Ignition on | Other |
|---|---|---|---|---|
| M1 | #25 | Video signal, TV | Analog signal | 1 V p-p +/- 0.2 V |
| M2 | #26 | Synchronizing signal, TV | Digital signal | 0-5 V |
| M3 | #27 | |||
| M4 | #28 | |||
| M5 | #29 | |||
| M6 | #30 | |||
| M7 | #31 | 30 supply | Ubat | |
| M8 | #32 | Signal ground, TV signals | Ulow | |
| M9 | #33 | Screen ground, TV signals | Ulow | |
| M10 | #34 | |||
| M11 | #35 | |||
| M12 | #36 | |||
| M13 | #37 | Signal, remote control TV | Digital signal | 33.3 kHz carrier wave when the remote control is pressed |
| M14 | #38 | |||
| M15 | #39 | Ground (Measured to battery negative terminal) | Ulow | |
| M16 | #40 |
See Signal specification, TV Executive
See Signal specification, TV Executive
See Signal specification, TV Executive
Capacity of the emergency battery (Volvo On Call/Volvo On Call Plus)
This parameter indicates the remaining capacity of the internal emergency battery. The emergency battery is only available for phone modules (PHM) with Volvo On Call/Volvo On Call Plus functionality.
The emergency battery is only used when activating the Volvo On Call/Volvo On Call Plus service and if there is no power supply.
The remaining capacity is calculated by the phone module (PHM).
Measurement range 0-100%.
100% is full capacity.
The diagnostic trouble code (DTC) stores a diagnostic trouble code (DTC) when the capacity drops to 30%.
- 0% corresponds to 0 minutes call time
- 10% corresponds to approximately 5 minutes call time
- 20% corresponds to approximately 10 minutes call time
- 30% corresponds to approximately 15 minutes call time
- 40-50% corresponds to approximately 20 minutes call time
- 60% corresponds to approximately 30 minutes call time
- 70-100% corresponds to more than 30 minutes call time.
Signal specification
General
All the values given below are between the terminals stated in column 1 and terminal #1 in column 2 (signal ground). This applies unless otherwise indicated in brackets.
Note. It is important to connect the breakout box and check the ground terminals before taking readings.
| U= | DC voltage in volts (V) | U AC = | AC voltage in volts (V) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | T = | Time in seconds |
| PWM = | Pulse width modulated signal as a % |
Scheme 9
| Control module terminal | Signal type | Ignition on |
|---|---|---|
| #1 | Ground | U low |
| #2 | 30 supply In the XC90 and S40 (04-) the handsfree box is powered via the infotainment relay. | U bat |
| #3 | ||
| #4 | Loudspeaker signal (+) | Alternating current when there is sound in the loudspeaker |
| #5 | 15 supply | U=12 V |
| #6 | Radio mute signal | During a call U=U low U=12 V otherwise |
| #7 | Loudspeaker signal (-) | Alternating current when there is sound in the loudspeaker |
| #8 |
Connector handsfree box
Scheme 10
| Control module terminal | Signal type | Ignition on |
|---|---|---|
| #1 | Handsfree antenna | Handsfree antenna signal |
| #2 | Antenna ground | U low |
Antenna connector
Scheme 11
| Control module terminal | Signal type | Ignition on |
|---|---|---|
| #1 | Microphone | Alternating current when there is sound in the microphone |
| #2 | Signal ground, microphone | U low |
Microphone connector
Signal specification, audio control module
See Signal specification, audio control module
See Signal specification, audio control module
Signal specification, RTI
See Signal specification, RTI
See also:
• Checking the ground terminals
