Media, Communication and Navigation - Design and Function: Overview Volvo S80 I

Entertainment Systems 2 illustrations ~1288 words

Scheme 77

Scheme 77: Audio System
Scheme 77: Audio System

System Overview

The components included in the audio system depend on the market and equipment level selected

  1. Radio antenna integrated in the rear windshield
  2. Antenna amplifier FM+AM
  3. Loudspeakers located in the parcel shelf
  4. Keypad in the steering wheel for audio and telephone systems
  5. Center loudspeaker with RTI display
  6. Center loudspeaker
  7. Radio head unit
  8. Front door-mounted loudspeakers (treble)
  9. Front door-mounted loudspeakers (bass/mid-range)
  10. Amplifier located under right front seat
  11. Rear door-mounted loudspeakers
  12. Antenna amplifier for sub-antenna
  13. Sub antenna integrated in the bumper
  14. CD changer - audio

Panel Overview

  1. Traffic information
  2. Station setting/fast forward/reverse
  3. Tape eject
  4. Preset/Programming stations
  5. Cassette opening
  6. Cassette direction selector
  7. On/off switch/volume control
  8. Adjusting bass/treble/balance
  9. Selecting bass/treble/balance
  1. CD random (HU-601)
  2. CD opening (HU-601)
  3. CD eject (HU-601)
  4. Frequency setting
  5. Station search
  6. Adjusting fader/balance
  7. Selecting radio/cassette/CD/CD changer
  8. Tape eject
  9. Preset radio stations/CD disc
  10. Cassette opening
  11. Cassette direction selector
  12. On/off switch/volume control
  13. Adjusting bass/treble
  14. Automatic pre-setting of radio stations
  15. Traffic information
  16. Program type
  17. News
  18. Volume control in Steering wheel hub
  1. CD random (HU-611)
  2. CD opening (HU-611)
  3. CD eject (HU-611)
  4. Frequency setting
  5. Station search
  6. Adjusting fader/balance
  7. Selecting radio/cassette/CD
  8. Tape eject
  9. Preset radio stations/CD disc
  10. Cassette opening
  11. Cassette direction selector
  12. On/off switch/volume control
  13. Adjusting bass/treble
  14. Automatic pre-setting of radio stations
  15. Dolby B
  16. RND -CD random/ASC - automatic volume control
  17. Stations search
  18. Volume control in Steering wheel hub
  1. CD random
  2. CD opening
  3. CD eject
  4. Frequency setting
  5. Station search
  6. Adjusting fader/balance
  7. Selecting radio/cassette/CD
  8. Tape eject/MD eject
  9. Preset radio stations/CD disc
  10. Cassette opening/MD opening
  11. Volume center loudspeaker/Volume output
  12. 3-CH/OFF/Dolby Pro Logic 5-CH (HU-831)
  13. Cassette tape direction selector/MD random
  14. On/off switch/volume control
  15. Adjusting bass/treble
  16. Automatic pre-setting of radio stations
  17. Traffic information
  18. Automatic volume control
  19. Station search
  20. Volume control in Steering wheel hub
  1. CD opening for changer (4 discs)
  2. 3-CH/OFF/ Dolby Pro Logic 5-CH
  3. CD eject
  4. Frequency setting
  5. Station search
  6. Selecting radio/CD/CD changer
  7. Preset radio stations/CD disc
  8. Volume center loudspeaker/Volume output
  9. Adjusting fader/balance
  10. Adjusting bass/treble
  11. On/off switch/volume control
  12. Automatic pre-setting of radio stations
  13. Traffic information
  14. Program type
  15. News
  16. CD random
  17. Volume control in Steering wheel hub
  1. Rheostat
  2. LSM
  3. Sensor back-up (reverse) gear
  4. Ignition switch
  5. Data link connector (DLC)
  6. Handsfree loudspeaker
  7. Handset
  8. Telephone antenna
  9. Handsfree microphone
  10. Carphone module
  11. Carphone box
  12. CCM
  13. Sun sensor
  14. Parking brake sensor
  15. DIM
  16. Display
  17. Keypad in the steering wheel
  18. steering wheel module
  19. RTI control
  20. Loudspeakers
  21. Separate amplifier
  22. CD changer Audio
  23. Audio control module
  24. TV receiver
  25. Sub-antenna in bumper
  26. Antenna in rear windshield
  27. CD ROM changer
  28. GPS antenna
  29. Display
  30. RTI unit
  31. ABS
  32. Vehicle speed sensor (VSS)
  33. Sensor back-up (reverse) gear
  34. TCM
  35. Central electronic module
  1. On/off button (not in Steering wheel hub)
  2. End call
  3. Arrow keys
  4. Number keys (not in Steering wheel hub)
  5. Erase button (not in Steering wheel hub)
  6. Start call
  7. Volume buttons (not in keypad)

Operation

The telephone is operated from the keypad beside the audio head unit or the keypad in the steering wheel. The telephone can only be switched on/off at the keypad beside the audio head unit.

Emergency calls to the emergency services can be made without the ignition key or SIM card.

The first time a SIM card is used the PIN code must be entered. The code can be stored and will not then need to be keyed in. When using several SIM cards, only one PIN code can be stored.

To make it as easy as possible to use the keypad without looking at it all the keys have individual tones when pressed (this function can be switched off via the telephone menu function).

To simplify volume settings a tone at the current setting sounds when the resetting is carried out. The tone is not heard during a call.

For safety reasons certain functions cannot be used at speeds above 8 km/h (5 mph) (can be disconnected). Unfinished functions cannot be finished.

Scheme 78

Scheme 78: Road Traffic Information (RTI)
Scheme 78: Road Traffic Information (RTI)
  1. CD ROM changer
  2. RTI unit with integrated GPS receiver and receiver for TMC or FM-MPX
  3. TV antenna amplifier
  4. RTI control on steering wheel right reverse side
  5. Display
  6. Antenna amplifier TV/TV+FM-MPX
  7. Antenna amplifier TMC/FM-MPX
  8. Sub-antenna TMC/FM-MPX
  9. GPS antenna and amplifier
  10. TV receiver as option
  11. Antenna TV/TV+FM-MPX

The RTI system guides the driver to a given destination and uses and taking into account information about situations that may make the journey more difficult. The RTI system guides the driver using voice and visual signals. Depending on the function selected, the display screen can display information about the quickest route to a destination, distance, direction, junctions, road works, traffic queues, parking etc. It is possible to adapt the information displayed on the screen as required by using the on-screen menus. The RTI system is an option depending on the market. The system is also available as an accessory.

The RTI system has a new user interface.

On the condition that traffic messages are sent they are displayed with symbols on the display. Backup text information can be obtained by selecting with the RTI controls.

The RTI functions can be operated from the controls mounted on the right side of the steering wheel. There is also a remote control (optional) so that a front seat passenger can operate the RTI system.

  1. Telephone antenna mounted in front windshield
  2. Telephone keypad in the steering wheel
  3. Combined instrument panel display
  4. Keypad beside audio system head unit
  5. Handsfree microphone mounted in rear-view mirror
  6. Telephone box located on car parcel shelf
  7. Handsfree loudspeaker mounted in drivers head rest
  8. Handset in front seat armrest

As an option the car is available with a complete telephone system (handset optional). The alternative is also available for aftermarket installation. The telephone system is available for all markets which use GSM - 900MHz.

The Phone Module (PHM) with keypad is located beside the audio system head unit.

When a call is made or when using the telephones other functions the keypad in the steering wheel hub controls the telephone system. All functions except for switching on and off can be controlled by the telephone keypad on the steering wheel hub.

Information from the telephone system is displayed in the combined instrument panel display.

If the car is equipped with the telephone the storage compartment beside the audio unit is replaced by a keypad and the telephone keypad is installed in the steering wheel. The design allows after market installation.

The telephone box is installed under the parcel shelf. The telephone box is designed for the large SIM card which is inserted into the box. If the customer wishes to use the small SIM card from a mobile phone an adapter/holder should be used.

The language choice for the phone system does not affect the cars global language selection (in the central electrical module (CEM)) while a change in the global language selection controls the telephone system.

The handsfree microphone is integrated into the rear view mirror and the loudspeakers into the driver's seat head restraint. This also applies to aftermarket installation.

The telephone system is equipped with Active Sound Control (ASC) which means that the handsfree loudspeaker sound level is automatically adjusted to the car speed to compensate for noise. Active Sound Control (ASC) can be disconnected using the telephone system menu function.

The antenna is mounted against the windshield (in front of the rear view mirror).

The handset is optional (not available as single accessory). It is used for private conversations when the handsfree function is not desired.

The telephone has an power handling capacity of 8W (compared to a mobile phone approximately 2W) which gives longer range and high conversational quality.
