Suspension Module (Sum) - Diagnostic Trouble Codes: Other Volvo S60 I

Verification

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 19

Scheme 20

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the acceleration sensor. The value must be approximately 2.5 V Rock the car. Check that the value changes.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S28720733892011081500000)

Fault-tracing information

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal Too Low

See Signal Too Low

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the acceleration sensor. The value must be approximately 2.5 V Rock the car. Check that the value changes.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S36990210302011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal Too High

See Signal Too High

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 21

1. Ignition off
2. Reinstall the connectors, components etc.
3. Test drive the car. The driving mode must be changed during the test drive
4. Ignition on
5. Click on the VCT2000 symbol to read off the present value on the signal cable from the solenoids. The value must be approximately 0.5 A.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S07824810822011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Current Too Low

See Current Too Low

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Test drive the car. The driving mode must be changed during the test drive
4. Ignition on
5. Click on the VCT2000 symbol to read off the present value on the signal cable from the solenoids. The value must be approximately 0.5 A.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S05118077482011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Current Too High

See Current Too High

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Test drive the car. The driving mode must be changed during the test drive
4. Ignition on
5. Click on the VCT2000 symbol to read off the present value on the signal cable from the solenoids. The value must be approximately 0.5 A.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S16373607912011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Current Too High

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the acceleration sensor. The value must be approximately 2.5 V Rock the car. Check that the value changes.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S00140206832011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal Missing

See Signal Missing

See Signal Too Low

See Signal Too Low

See Signal Too High

See Signal Too High

See Signal Missing

See Signal Missing

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check the signal from the position sensor by clicking on the VCT2000 symbol. The value varies between 0.5-4.5 V depending on the degree of lean of the car.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S17339084242011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too Low

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check the signal from the position sensor by clicking on the VCT2000 symbol. The value varies between 0.5-4.5 V depending on the degree of lean of the car.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S12463999772011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check the signal from the position sensor by clicking on the VCT2000 symbol. The value varies between 0.5-4.5 V depending on the degree of lean of the car.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S34454656302011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Missing

See Signal Too Low

See Signal Too Low

See Signal Too High

See Signal Too High

See Signal Missing

See Signal Missing

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the acceleration sensors. The value must be approximately 2 V Rock the car. Check that the value changes.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S03699067212011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too Low

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the acceleration sensors. The value must be approximately 2 V Rock the car. Check that the value changes.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S36010401722011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too High

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the acceleration sensors. The value must be approximately 2 V Rock the car. Check that the value changes.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S12618168602011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Missing

See Signal too low

See Signal Too Low

See Signal Too High

See Signal Too High

See Signal Missing

See Signal Missing

See Signal Too Low

See Signal Too Low

See Signal Too High

See Signal Too High

See Signal Missing

See Signal Missing

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the power supply to the sensors. The value must be approximately 5 V

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S11722083942011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too Low

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the power supply to the sensors. The value must be approximately 5 V

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S29339028412011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too High

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the power supply to the sensors. The value must be approximately 5 V.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S25168899282011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too Low

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Click on the VCT2000 symbol to read off the present value of the power supply to the sensors. The value must be approximately 5 V

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S14198540412011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too High

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Test drive the car. The driving mode must be changed during the test drive
4. Ignition on
5. Click on the VCT2000 symbol to read off the present value on the signal cable from the solenoids. The value must be approximately 0.5 A.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S01674782982011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Test drive the car. The driving mode must be changed during the test drive
4. Ignition on
5. Click on the VCT2000 symbol to read off the present value on the signal cable from the solenoids. The value must be approximately 0.5 A.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S28688626722011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Test drive the car. The driving mode must be changed during the test drive
4. Ignition on
5. Click on the VCT2000 symbol to read off the present value on the signal cable from the solenoids. The value must be approximately 0.5 A.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S36509818742011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Current Too Low

See Current Too Low

See Current Too High

See current Too High

See Current Too High

See Current Too High

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Test drive the car. The driving mode must be changed during the test drive
4. Ignition on
5. Click on the VCT2000 symbol to read off the present value on the signal cable from the solenoids. The value must be approximately 0.5 A.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S10563508122011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal Too Low

See Signal Too High

See Signal Missing

Temperature Too High

See Temperature Too High

See Signal Too Low

See Signal too high

See Signal Missing

See Current Too Low

See Current Too Low

See Current Too High

See Current Too High

See Current Too High

See Current Too High

See Temperature Too High

See Signal Too Low

See Signal Too High

See Signal Missing

See Current Too Low

See Current Too Low

See Current Too High

See Current too high

See Current Too High

See Current Too High

See Temperature Too High

See Signal Too Low

See Signal Too High

See Signal Missing

See Signal Too Low

See Signal Too High

See Signal Too Low

See Signal Too Low

See Signal Too High

See Signal Too High

See Signal Too Low

See Signal Too Low

See Signal Too High

See Signal Too High

Checking the Supply Voltage To the System

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Read off the power supply to the Suspension Module (SUM).

The voltage must be normal system voltage.

1. OK OKAY: Troubleshooting has been completed.
2. NOT OK Refer to «Information»(ref-415373-S25844342612011081500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Read off the voltage to the Suspension Module (SUM).

The voltage should be battery voltage.

1. OK OKAY: Troubleshooting has been completed.
2. NOT OK Refer to «Information»(ref-415373-S25844342612011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Voltage Too Low

See Voltage Too Low

Voltage Too High

See Voltage Too High

Checking the Voltage

1. Ignition off
2. Disconnect the connector for the suspension module (SUM)
3. Disconnect the connector for the central electronic module (CEM)
4. Check these connectors. Check for contact resistance and oxidation
5. Reinstall the components, reconnect the connectors etc.
6. Ignition on
7. Read off the voltage for the suspension module (SUM) and the central electronic module (CEM). The voltage must be approximately 12 V. Other information: To disconnect the connector for the suspension module (SUM), see «Suspension Module (SUM), Replacing»(ref-415269-S39445909562011081500000) To disconnect the connector for the central electronic module (CEM), see «Central electronic module (CEM), replacing»(ref-415242-S13493029332011081500000) See «Contents»(ref-415229-S18832573702011081500000) .

Was the voltage OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking the wiring»(ref-415373-S12563303392011081500000)

Scheme 22

1. Ignition off
2. Suspension module (SUM) disconnected
3. Central electronic module (CEM) disconnected
4. Connect a breakout box to the suspension module (SUM) and a breakout box to the central electronic module (CEM). Check the cable for power supply between suspension module (SUM) terminal #C1 (31) and the system relay. Check the power supply wiring for the central electronic module (CEM). See the Service Information, Section 3, Wiring diagram. Remedy as necessary. Other information: To connect the breakout box to the suspension module (SUM), see «Connecting the Breakout Box»(ref-415268-S13497235102011081500000) To connect the breakout box to the central electronic module (CEM), see «Connecting the Breakout Box»(ref-415238-S18119942182011081500000) For information about signals for the suspension module (SUM), see «Signal Specification»(ref-415270-S01902851062011081500000) For information about signals for the central electronic module (CEM), see «Signal Specification»(ref-415241-S00055932492011081500000) See «Contents»(ref-415229-S18832573702011081500000) .

1. Continue Refer to «Verification»(ref-415373-S15132580802011081500000)

Note. After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Read off the voltage for the suspension module (SUM) and the central electronic module (CEM). The voltage must be approximately 12 V for both the suspension module (SUM) and the central electronic module (CEM)

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S14216607902011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty Signal

See Faulty Signal

Replacing the Control Module And Programming

1. Ignition off. The control module has registered an internal fault. CAUTION: A new control module is delivered without software. The control module must be programmed and calibrated in order to function after replacement. Other information: See «Suspension Module (SUM), Replacing»(ref-415269-S39445909562011081500000) .

1. Continue Refer to «Information»(ref-415373-S36985263562011081500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

Reloading Software

Check that the battery voltage is OK.

The suspension module (SUM) has registered an internal fault. If the fault is intermittent, the fault has been registered on a previous occasion. Intermittent faults can be caused by interference at start up of the control module or by the battery voltage being too low. As the suspension module (SUM) has registered this internal fault, the software must be reloaded. To reload software, see Suspension Module (SUM), Replacing .

Select "Continue" when the fault has been remedied.

1. Continue Refer to «Information»(ref-415373-S08059631542011081500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See Internal Fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the components, reconnect the connectors etc.
3. Ignition on. Read off the status of the diagnostic trouble code (DTC).

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S15200059342011081500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Internal Memory Fault

See Internal Memory Fault

The suspension module (SUM) has registered a fault in the software. If the fault is intermittent, the fault has been registered on a previous occasion. As the suspension module (SUM) has registered that the software is defective, the software must be reloaded. Intermittent faults may be caused by interference at start up of the control module. To reload software, see Suspension Module (SUM), Replacing .

Select "Continue" when the fault has been remedied.

1. Continue Refer to «Information»(ref-415373-S02384605462011081500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

Faulty Software

See Faulty Software

See Internal Fault

See Internal Fault

Checking the Control Module

HINT: Diagnostic trouble codes (DTC) SUM-0220 and SUM-0222 were stored after programming the Suspension Module (SUM) and are erased automatically after calibration.

Select "Continue" to calibrate the control module.

1. Continue Refer to «Calibrating the System»(ref-415373-S39145559742011081500000)

Communication Fault

Communication has been interrupted for one of the following reasons

1. The ignition is switched off
2. VCT2000 disconnected from the data link connector (DLC)
3. VCT2000 disconnected from the VIDA cart
4. Communication problems in VIDA application or in car.
5. No voltage in the data link connector (DLC).

Check therefore

1. That the control module power supply and ground terminal are fault-free.
2. That the fuse for the data link connector (DLC) is intact.
3. that the ignition is on
4. that the battery voltage (system voltage) is normal (approximately 12 V). If necessary a battery charger can be connected during the test. For information about charge currents and the battery, see «Battery, Charging»(ref-415474-S17299701082011081500000)
5. that VCT2000 is correctly connected to the VIDA cart and the data link connector (DLC)
6. that VCT2000 and the wiring is fault-free.

Other information

1. For information about fuse and terminal numbers, see the relevant Wiring Diagram.

Try to establish communication again or exit reading off diagnostic trouble codes (DTCs). Depending on the communication fault, select one of the following options.

1. Try again. Refer to «Calibration»(ref-415373-S13729855742011081500000) .
2. Fault-trace more comprehensively for the communication problem that has occurred. Refer to «Checking Communication Errors»(ref-415373-S18543539822011081500000) .
3. Exit fault-tracing/Read off from the next system.

Selecting Car Model

Select car model to obtain relevant troubleshooting information.

Select one of the following model alternatives

1. V70 (00-), V70 XC (01-)/XC70, S60, S80 and XC90. Refer to «Checking Communication Errors, Car Model V70 (00-), V70 XC (01-)/XC70, S60, S80 And XC90»(ref-415373-S23308911832011081500000) .

Checking Communication Errors, Car Model V70 (00-), V70 XC (01-) / XC70, S60, S80 and XC90

HINT: Test the communication with another corresponding vehicle to decide if the malfunction is in the vehicle or in VIDA/VCT/cable harness. If the communication works on another vehicle, the malfunction is in the vehicle.

HINT: For current information about each circuit and signals, see wiring diagram and signal description for each system.

Different speed on the CAN-communication can lead to problems

Volvo's vehicles have different speed of communication on the high-speed part of the CAN-network (HS-CAN), depending on model year.

1. Model year -2004 communicates with 250 kbit/s.
2. Model year 2005- communicates with 500 kbit/s.

Due to this, it is very important to specify correct vehicle profile before any communication is started with the vehicle's HS-CAN. This is normally done by pressing on " Retrieve VIN" or by manually specifying vehicle parameters under "Vehicle profile".

If the wrong model year has been selected, it may lead to blocking of the CAN-net, diagnostic trouble codes being stored in several control modules or missing response from control modules at continued communication. The following control modules may be affected by this problem

1. Brake control module (BCM)/(ABS)
2. Engine control module (ECM)
3. Electronic Throttle Module (ETM)
4. Suspension Module (SUM)
5. Central electronic module (CEM)
6. Transmission control module (TCM)
7. Steering wheel angle sensor module (SAS)
8. Steering Wheel Module (SWM)
9. Electrical Power Steering Module (EPS)

If this happens, take the following action

1. Turn off the ignition and remove the ignition key. Insert the key again in position II.
2. If the above does not work, remove the battery cable and connect it again after a minute to reset the control modules.
3. Select the correct vehicle profile in VIDA and erase the diagnostic trouble codes. Check that the symptoms have disappeared.

Diagnostic outlet

1. Check the voltage feed to diagnostic outlet #16. The voltage shall match battery voltage.
2. Check the cable for power ground and signal ground to diagnostic outlet #4 and #5.

HINT: When VCT2000 is connected to the diagnostic outlet (is supplied with voltage), the indicator diode shall be activated with a green light. Then the indicator diode flashes quickly when communication takes place with a control module. In case of certain internal malfunctions on VCT2000 the indicator diode is activated with a red light!

Communication cables

1. Check the communication cable (k-line) between diagnostic outlet #7 and central electronic module (CEM) #D6 and other connected control modules for open circuit, short-circuit to ground and short-circuit to voltage. CAUTION: In case of malfunction on this communication cable, communication cannot be established on either the low or high-speed network. First when communication takes place on this cable, the low and high-speed cables between the diagnostic outlet and central electronic module (CEM) are connected to the rest of the network in the vehicle. This is controlled via a relay in the central electronic module (CEM). This relay is only found on vehicles of model year -2004.
2. For communication problems with control units on the high-speed network , check communication cables between diagnostic outlet #6/ #14 and central electronic module (CEM) #B7/ #B8 for open circuit, short-circuit to ground and short-circuit to voltage according to references above.
3. For communication problems with control units on the low-speed network , check communication cables between diagnostic outlet #3/#11 and central electronic module (CEM) #B19/#B20 for open circuit, short-circuit to ground and short-circuit to voltage according to references above.
4. Also check the communication cables for the low and high-speed net between the central electronic module (CEM) and the other connected control modules according to troubleshooting above.

Control modules

1. Check that the control module's voltage feed and ground connection are trouble-free.

VCT2000 and cable harness

1. Connect VCT2000 to the vehicle so that it is supplied with voltage. Test VCT2000 by selecting the system's self-test and VCT Test in the VIDA main menu. If any malfunction is found according to the test, first replace the cable harness then the VCT2000, if the test still indicates a malfunction.
2. If no malfunctions were found after troubleshooting according to above, try with a new cable harness and/or new VCT2000.

VIDA

1. If no malfunctions were found after troubleshooting according to above, try performing a complete system reset of VIDA.

Other information

1. See «Contents»(ref-415229-S18832573702011081500000)

Scheme 23

1. Continue Refer to «Fault-Tracing Information»(ref-415373-S29776739632011081500000)

Fault-tracing communication problems is now finished.

Not Completed

See Not Completed

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the components, reconnect the connectors etc.
3. Ignition on. Read off the status of the diagnostic trouble code (DTC).

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S40654850862011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Not Completed

See Not Completed

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the components, reconnect the connectors etc.
3. Ignition on. Read off the status of the diagnostic trouble code (DTC).

Is the status of the diagnostic trouble code (DTC) intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-415373-S26556032992011081500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The suspension module (SUM) has registered an internal fault. If the fault is intermittent, the fault has been registered on a previous occasion. Intermittent faults may be caused by interference at start up of the control module.

The fault can occur on different occasions. The software may need to be reloaded. To reload software, see Suspension Module (SUM), Replacing .

Select "Continue" when the fault has been remedied.

1. Continue Refer to «Information»(ref-415373-S16492940662011081500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

The suspension module (SUM) has registered an internal fault. If the fault is intermittent, the fault has been registered on a previous occasion. Intermittent faults may be caused by interference at start up of the control module.

The fault can occur on different occasions. The software may need to be reloaded. To reload software, see Suspension Module (SUM), Replacing .

Select "Continue" when the fault has been remedied.

1. Continue Refer to «Information»(ref-415373-S34619220172011081500000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

See Internal Fault

Faulty Configuration

See Faulty Configuration

Downloading Software

1. Save a bookmark and cancel the fault-tracing. Then go to the software manager and download the correct software. Then resume the fault-tracing. NOTE: After downloading the software, the Suspension Module (SUM) must be calibrated according to VIDA vehicle communication.

1. Continue Refer to «Reading Off Diagnostic Trouble Codes (DTCs)»(ref-415373-S39211493792011081500000)

Configuration Fault

See Configuration Fault

Note. Diagnostic trouble code (DTC) SUM-0262 may be stored if the Suspension Module (SUM) has previously been installed in another car.

Was the Suspension Module (SUM) previously installed in another car?

1. YES Refer to «Checking the Control Module»(ref-415373-S14469148602011081500000)
2. NO Refer to «Downloading Software»(ref-415373-S16022587882011081500000)

1. Check that the P/N of the control module corresponds to the number in the replacement parts catalogue. If the P/N does not match the replacement parts catalogue, replace the control module. Download new software into the control module if the P/N matches the replacement parts catalogue. Select Pause. Save this as a bookmark and cancel the fault-tracing. Then go to the software manager and download the correct software. Then resume the fault-tracing.
2. Select an option: Incorrect control module P/N. OKAY: Troubleshooting has been completed. New software downloaded. Refer to «Reading Off Diagnostic Trouble Codes (DTCs)»(ref-415373-S35863128332011081500000) . NOTE: After downloading the software, the Suspension Module (SUM) must be calibrated according to VIDA vehicle communication.

1. Save a bookmark and cancel the fault-tracing. Then go to the software manager and download the correct software. Then resume the fault-tracing NOTE: After downloading the software, the Suspension Module (SUM) must be calibrated according to VIDA vehicle communication.

1. Continue Refer to «Reading Off Diagnostic Trouble Codes (DTCs)»(ref-415373-S35863128332011081500000)

See Configuration Fault

See Faulty Configuration

See Signal Missing

See Signal Missing

Acceleration sensor suspension front (Four-C), replacing

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Identifying Ignition In OFF Position. Scheme 24

Ignition off.

Raise the car.

Acceleration Sensor Hanging From Cable. Scheme 25

Remove the M6 screw.

Leave the acceleration sensor hanging from its cable.

Installing the acceleration sensor

Note. It is essential that the acceleration sensors are installed with the soft side facing downwards and are securely fixed in the vehicle. Otherwise movement may result in incorrect values being returned to the system, with poorer driving characteristics, when cornering for example, as a result.

Note. For tightening torques, see Tightening torque .

Align the new acceleration sensor.

Install the M6 screw.

Route and secure the cable for the new acceleration sensor following the old cable. Remove the old cable.

Connect the connector.

Test the function.

Position sensor suspension rear (Four-C), replacing

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Ignition off

Ignition off.

Raise the vehicle.

Removing Position Sensor Pressing In Catch Hook And Angle Bracket Downwards. Scheme 26

Remove

1. the nut for the linkage
2. the position sensor. Press in the catch hook and angle the bracket downwards
3. the connector
4. the bracket from the position sensor
5. the 2 screws.

Installing the position sensor

Install

1. the position sensor on the bracket
2. the 2 screws
3. the connector
4. the linkage
5. the nut.

Align the bracket which the position sensor is on. Press into position.

Acceleration sensor bodywork front (Four-C), replacing

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Identifying Front Acceleration Sensors. Scheme 27

The front acceleration sensors are under the headlamps. See the illustration.

Preparatory work

Ignition off.

Raise the car.

Removing the acceleration sensor

Remove the M10 nut.

Disconnect the connector.

Note. It is essential that the acceleration sensors are installed with the connector facing upwards and is secure in the vehicle. Otherwise movement may result in incorrect values being returned to the system, with poorer driving characteristics, when cornering for example, as a result.

Note. For tightening torques, see Tightening torque .

Install the M10 nut.

Connect the connector.

Test the function.

Acceleration sensor bodywork rear (Four-C), replacing

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Identifying Rear Acceleration Sensor. Scheme 28

The rear acceleration sensor is located behind the left-hand wheel arch in the cargo compartment, see the illustration.

Ignition off.

Remove the hatch in the rear side panel on the left-hand side of the cargo compartment.

Remove the M8 screw.

Disconnect the connector.

Install the M8 screw.

Connect the connector.

Finishing work

Install the hatch in the side panel.

Test the function.
