Installing the Lock Ring Volvo S60 I

Installing the Lock Ring

Install the lock ring.

Scheme 169

Install the shims.

Scheme 170

Install

1. the drive plate
2. the screw, 1 pc., using a counterhold: «9997193»(ref-403953-S07629342002011061500000) and tighten with 13 Nm.

Scheme 171

Check the clearance between the turning plate and the belt pulley with a feeler gauge.

The clearance should be 0.3-0.5 mm.

0.3 mm clearance all the way round

It must not be possible to insert 0.6 mm at any point.

If clearance is not within given values, replace the shims.

The following dimensions are available

0.2 mm

0.3 mm

1.0 mm.
