Engine - Removal, Replacement and Installation (Coupe): Wiring Volvo C70 I

Mechanical 1 illustration ~166 words

Expose the engine cable harness

Disconnect all connectors and clamps from engine.

Note. Note all the cable harness mountings positions.

1. Thermostat

2. Generator (GEN)

3. Air conditioning (A/C) if installed

4. Ground terminal

5. Oil pressure switch

6. Oil level sensor

7. Starter motor (all)

8. Knock sensor (KS)

9. Ground terminal

10. Ground terminal

11. Throttle housing switch

12. Idle air trim

13. Flywheel sensor

14. Injectors

15. Camshaft position (CMP) sensor

16. Back-up (reversing) lamp switch

17. Mass air flow (MAF) sensor

18. Vehicle speed sensor (VSS)

19. Heated oxygen sensor (HO2S) (automatics x 2)

20. PTC element

Scheme 597

Scheme 597: Remove engine with transmission

Lift power steering pump and put it to one side.

Remove front engine pad when lifting.

Remove engine, use lift yokes 9992810 (in version with lifting arm 9995428 .

Adjust lifting angle during the lift (a relatively large angle is required).

Automatic: Remove turbocharger (TC) oil cooler hoses with valve, from oil pan right side.

CAUTIONCheck carefully that the driveline is clear of the bodywork and other optional extras.
