Engine - Removal, Replacement and Installation (Convertible): Wiring Volvo C70 I

Mechanical 2 illustrations ~178 words

Removing the screws from the cable harness clamps

Remove the 2 screws from the clamps holding the cable harness.

Scheme 93

Scheme 93: Removing the torque control arm

Remove

  1. screws 1-4
  2. the upper screw (5) for the starter motor.

Expose the engine cable harness

Disconnect all connectors and clamps from engine.

Note. Note all the cable harness mountings positions.

  1. Thermostat
  2. Generator (GEN)
  3. Air conditioning (A/C) if installed
  4. Ground terminal
  5. Oil pressure switch
  6. Oil level sensor
  7. Starter motor (all)
  8. Knock sensor (KS)
  9. Ground terminal
  10. Ground terminal
  11. Throttle housing switch
  12. Idle air trim
  13. Flywheel sensor
  14. Injectors
  15. Camshaft position (CMP) sensor
  16. Back-up (reversing) lamp switch
  17. Mass air flow (MAF) sensor
  18. Vehicle speed sensor (VSS)
  19. Heated oxygen sensor (HO2S) (automatics x 2)
  20. PTC element

Scheme 94

Scheme 94: Remove engine with transmission

Lift power steering pump and put it to one side.

Remove front engine pad when lifting.

Remove engine, use lift yokes 9992810 (in version with lifting arm 9995428 .

Adjust lifting angle during the lift (a relatively large angle is required).

Automatic: Remove turbocharger (TC) oil cooler hoses with valve, from oil pan right side.

CAUTIONCheck carefully that the driveline is clear of the bodywork and other optional extras.
