Central Electronic Module (Cem) - Removal & Installation: Other Volvo C70 I

Note before connecting battery cables

Scheme 344

Note after connecting battery cables

Initiation of the Upper Electronic Module (UEM)

Initiate the central locking system, interior lighting and sunroof by unlocking the car with the remote control, key or VIDA vehicle communication.

Windows

Initiate window positions. See: VIDA Car communication, Initiating the window position.

Calibrating the passenger compartment fan.

1. If the car is equipped with Manual Climate Control (MCC) or Standard climate control system, fan speed must be recalibrated if the battery has been disconnected. Ignition on. Turn the fan control to max. Turn the fan control to min. The calibration is complete.

Calibrating the sunroof

1. For S80, S60, V70 (00-) and V70 XC (01-) / XC70 see «Sun roof module (SRM), calibrating»(ref-438270-S25746333322011120100000) .
2. For XC90 see: «Sun roof module (SRM), calibrating»(ref-438270-S16072511312011120100000) .

Engine

1. If the battery was disconnected, the engine may need to run for a few minutes before it runs smoothly.

Finishing

Note. Set the clock.

Central electronic module (CEM), replacing - B5244S 2000

S80

1. For -2004, see
2. For 2005-, see: «Central electronic module (CEM), replacing»(ref-438278-S00039636202011120100000) .

S60

1. For -2004, see
2. For 2005-, see: «Central electronic module (CEM), replacing»(ref-438278-S00984381762011120100000) .

V70 2000-, V70 XC 2001-/XC70

1. For -2004, see
2. For 2005-, see: «Central electronic module (CEM), replacing»(ref-438278-S18289197812011120100000) .

XC90

1. For -2004, see
2. For 2005-, see: «Central electronic module (CEM), replacing»(ref-438278-S35308413252011120100000) .

Central electronic module (CEM), replacing - S80 2005

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

For further information, see Downloading software and replacing the control module

Downloading software and replacing the control module

New software can be downloaded into the central electronic module (CEM). When ordering software, the hardware and the software in the car is compared to the information in the Volvo central database. If the comparison is OK the software is downloaded to the control module. The PINs for the existing remote controls are downloaded at the same time.

If the comparison between the car and Volvo central database is not OK, the database is updated with the car configuration. When this is complete the software is downloaded.

When installing a completely new central electronic module (CEM) in the vehicle, the PIN codes are downloaded into the control module (when downloading software) for the following

1. central electronic module (CEM)
2. immobilizer
3. transponder (key).

The PIN codes are loaded automatically during the ordering process in VIDA. The PIN codes are retrieved from the Volvo Central Database and sent with the software package when software is ordered for the new control module.

The central electronic module (CEM) is to the left of the steering column under the dashboard. The entire control module is removed from the car during replacement.

Because of the unique PIN codes, the central electronic module (CEM) cannot be moved between cars.

Five customer parameters (six for 5 door cars) can be programmed into the central electronic module (CEM). These customer parameters are stored in the control module but not in the Volvo central database. This means that the customer parameters must be reprogrammed when hardware is replaced.

The customer parameters which can be programmed are

1. Approach lights. The approach lights can be programmed to stay on for a longer or shorter time according to the wishes of the customer. The factory setting is 30 seconds. The time can be set to 0, 30, 60 or 90 seconds The tailgate wiper can only be activated manually The tailgate wiper can be activated automatically when back-up (reverse) gear is selected and the front wipers are activated.
2. Security lighting. The security lighting can be programmed to stay on for a longer or shorter time according to the wishes of the customer. The factory setting is 30 seconds. The time can be set to 0, 30, 60 or 90 seconds The tailgate wiper can only be activated manually The tailgate wiper can be activated automatically when back-up (reverse) gear is selected and the front wipers are activated.
3. Automatic locking. If this function is activated, the side doors lock when the speed exceeds 7 km/h (5 mph). Selectable values: On / off The tailgate wiper can only be activated manually The tailgate wiper can be activated automatically when back-up (reverse) gear is selected and the front wipers are activated.
4. Locking acknowledgment via the turn signal lamps. If this function is activated, the turn signal lamps flash when the car is locked and unlocked. Selectable values: On / Off The tailgate wiper can only be activated manually The tailgate wiper can be activated automatically when back-up (reverse) gear is selected and the front wipers are activated.
5. Tailgate wiper (certain models). The tailgate wiper function can be programmed in two ways: The tailgate wiper can only be activated manually The tailgate wiper can be activated automatically when back-up (reverse) gear is selected and the front wipers are activated.

Disconnecting the battery lead

Scheme 345

Ignition off

Disconnect the battery negative cable. See: Battery, disconnecting .

Note. For vehicles equipped with Volvo On Call Plus, the automatic alarm for the emergency services may deploy.

Note. The driver information module (DIM) must not be replaced at the same time. This would erase the mileage.

Scheme 346

Remove the wiper mechanism according to: Wiper mechanism and wiper motor, windshield, replacing

Scheme 347

Scheme 348

Remove the 2 screws.

HINT: The soundproofing panel sits in a groove at the pedal box.

Remove the soundproofing panel by pulling it straight down and back.

Scheme 349

Remove

1. the connectors
2. the control module by inserting a screwdriver up between the bracket and the control module. Twist the screwdriver so that the bracket opens out. At the same time, pull the control module out of the bracket towards the underside of the dashboard
3. the control module from the bracket and pull downwards under the dashboard.

Remove the fuses from the central electronic module (CEM).

HINT: For the location of the fuses, see

1. The wiring diagram for the relevant model year
2. The decals by the relevant fuse box in the vehicle
3. The Pocket Data booklet
4. The Owner's manual.

Installing the central electronic module (CEM)

Install

1. the control module on the bracket. Press the control module forward so that the catches enter the bracket
2. the connectors
3. the soundproofing panel on the driver's side
4. the 2 screws on top of the control module
5. the 2 connectors on top of the control module.

Note. Make sure that the rubber seal is correctly positioned in the groove.

Install

1. the cover
2. the wiper arm mechanism. See: «Wiper mechanism and wiper motor, windshield, replacing»(ref-438274-S42497984372011120100000)
3. the battery negative cable. See: «Battery, disconnecting»(ref-438278-S34403393232011120100000) .

Ordering software

Order software. See: 9438273 .

Programming data

Program in the data read off from the old control module (customer-programmed data for example). This is performed via VIDA vehicle communication.

Reset the service reminder indicator (SRI). Otherwise the lamp will receive incorrect reference data. (Global time is reset when the central electronic module (CEM) is replaced.) Reset the service reminder indicator (SRI). See: Resetting the service reminder indicator (SRI) .

Check that the CAN-communication is functioning. This is done by reading off the control module ID for the central electronic module (CEM), rear electronic module (REM) and engine control module (ECM) via VIDA vehicle communication.

Other information

For the location of other relay and fuse boxes, see: Relays, fuse boxes and wiring .

Central electronic module (CEM), replacing - S60 2005

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

For further information, see Downloading software and replacing the control module

Ignition off

Disconnect the battery negative cable. See: Battery, disconnecting .

Note. For vehicles equipped with Volvo On Call Plus, the automatic alarm for the emergency services may deploy.

Note. The driver information module (DIM) must not be replaced at the same time. This would erase the mileage.

Removing the wiper mechanism and cover

Remove the wiper mechanism according to: Wiper mechanism, windshield, replacing

Removing the soundproofing panel on the driver's side

Remove the 2 screws.

HINT: The soundproofing panel sits in a groove at the pedal box.

Remove the soundproofing panel by pulling it straight down and back.

Removing the central electronic module (CEM)

Remove

1. the connectors
2. the control module by inserting a screwdriver up between the bracket and the relay box. Turn the screwdriver so that the bracket opens out. At the same time, pull the relay box out of the bracket towards the underside of the dashboard
3. the control module from the bracket and pull downwards under the dashboard.

Remove the fuses from the central electronic module (CEM).

HINT: For the location of the fuses, see

1. The wiring diagram for the relevant model year
2. The decals by the relevant fuse box in the vehicle
3. The Pocket Data booklet
4. The Owner's manual.

Install

1. the control module on the bracket. Press the control module forward so that the catches enter the bracket
2. the connectors
3. the soundproofing panel on the driver's side
4. the 2 screws on top of the control module
5. the 2 connectors on top of the control module.

Note. Make sure that the rubber seal is correctly positioned in the groove.

Install

1. the cover
2. the wiper arm mechanism. See: «Wiper mechanism, windshield, replacing»(ref-438274-S31069508652011120100000)
3. the battery negative lead. See: «Battery, disconnecting»(ref-438278-S34403393232011120100000) .

Order software. See: 8645433 .

Program in the data read off from the old control module (customer-programmed data for example). This is performed via VIDA vehicle communication.

Reset the service reminder indicator (SRI). Otherwise the lamp will receive incorrect reference data. (Global time is reset when the central electronic module (CEM) is replaced.) Reset the service reminder indicator (SRI). See: Resetting the service reminder indicator (SRI) .

Check that the CAN-communication is functioning. This is done by reading off the control module ID for the central electronic module (CEM), rear electronic module (REM) and engine control module (ECM) via VIDA vehicle communication.

For the location of other relay and fuse boxes, see: Relays, fuse boxes and wiring .

Central electronic module (CEM), replacing - V70 2000-, V70 XC 2001-/XC70 2005

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

For further information, see Downloading software and replacing the control module

Ignition off

Disconnect the battery negative cable. See: Battery, disconnecting .

Note. For vehicles equipped with Volvo On Call Plus, the automatic alarm for the emergency services may deploy.

Note. The driver information module (DIM) must not be replaced at the same time. This would erase the mileage.

Remove the wiper mechanism according to: Wiper mechanism, windshield, replacing

Remove the 2 screws.

HINT: The soundproofing panel sits in a groove at the pedal box.

Remove the soundproofing panel by pulling it straight down and back.

Remove

1. the connectors
2. the control module by inserting a screwdriver up between the bracket and the relay box. Turn the screwdriver so that the bracket opens out. At the same time, pull the relay box out of the bracket towards the underside of the dashboard
3. the control module from the bracket and pull downwards under the dashboard.

Remove the fuses from the central electronic module (CEM).

HINT: For the location of the fuses, see

1. The wiring diagram for the relevant model year
2. The decals by the relevant fuse box in the vehicle
3. The Pocket Data booklet
4. The Owner's manual.

Install

1. the control module on the bracket. Press the control module forward so that the catches enter the bracket
2. the connectors
3. the soundproofing panel on the driver's side
4. the 2 screws on top of the control module
5. the 2 connectors on top of the control module.

Note. Make sure that the rubber seal is correctly positioned in the groove.

Install

1. the cover
2. the wiper arm mechanism. See: «Wiper mechanism, windshield, replacing»(ref-438274-S24634568572011120100000)
3. the battery negative lead. See: «Battery, disconnecting»(ref-438278-S34403393232011120100000) .

Order software. See: 9494722 .

Program in the data read off from the old control module (customer-programmed data for example). This is performed via VIDA vehicle communication.

Reset the service reminder indicator (SRI). Otherwise the lamp will receive incorrect reference data. (Global time is reset when the central electronic module (CEM) is replaced.) Reset the service reminder indicator (SRI). See: Resetting the service reminder indicator (SRI) .

Check that the CAN-communication is functioning. This is done by reading off the control module ID for the central electronic module (CEM), rear electronic module (REM) and engine control module (ECM) via VIDA vehicle communication.

For the location of other relay and fuse boxes, see: Relays, fuse boxes and wiring .

Central electronic module (CEM), replacing - XC90 2005

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

For further information, see Downloading software and replacing the control module

Ignition off

Disconnect the battery negative cable. See: Battery, disconnecting .

Note. For vehicles equipped with Volvo On Call Plus, the automatic alarm for the emergency services may deploy.

Note. The driver information module (DIM) must not be replaced at the same time. This would erase the mileage.

Remove the wiper mechanism according to: Wiper mechanism windshield, replacing

Remove the 2 screws.

HINT: The soundproofing panel sits in a groove at the pedal box.

Remove the soundproofing panel by pulling it straight down and back.

Remove

1. the connectors
2. the control module by inserting a screwdriver up between the bracket and the relay box. Twist the screwdriver so that the bracket opens out. At the same time, pull the control module out of the bracket towards the underside of the dashboard
3. the control module from the bracket and pull downwards under the dashboard.

Remove the fuses from the central electronic module (CEM).

HINT: For the location of the fuses, see

1. The wiring diagram for the relevant model year
2. The decals by the relevant fuse box in the vehicle
3. The Pocket Data booklet
4. The Owner's manual.

Install

1. the control module on the bracket. Press the control module forward so that the catches enter the bracket
2. the connectors
3. the soundproofing panel on the driver's side
4. the 2 screws on top of the control module
5. the 2 connectors on top of the control module.

Note. Make sure that the rubber seal is correctly positioned in the groove.

Install

1. the cover
2. the wiper arm mechanism. See: «Wiper mechanism windshield, replacing»(ref-438274-S10727288502011120100000)
3. the battery negative lead. See: «Battery, disconnecting»(ref-438278-S34403393232011120100000) .

Order software. See: 8691290 .

Program in the data read off from the old control module (customer-programmed data for example). This is performed via VIDA vehicle communication.

Reset the service reminder indicator (SRI). Otherwise the lamp will receive incorrect reference data. (Global time is reset when the central electronic module (CEM) is replaced.) Reset the service reminder indicator (SRI). See: Resetting the service reminder indicator (SRI) .

Check that the CAN-communication is functioning. This is done by reading off the control module ID for the central electronic module (CEM), rear electronic module (REM) and engine control module (ECM) via VIDA vehicle communication.

For the location of other relay and fuse boxes, see: Relays, fuse boxes and wiring .
