Electrical System (Coupe): Overview Volvo C70 I

Body Electrical 7 illustrations ~136 words

Scheme 350

Scheme 350: Bulb For Automatic Transmission Position Indicator, Replacing

Pull down the bulb holder at the side of the gear selector and disconnect connectors.

Note. The bulb and holder are a unit and cannot be separated.

Replace the bulb.

Reinstall bulb holder.

Reinstall center console. Take care not to scratch interior.

Connect connectors.

  1. Check that bulb lights.

Screw center console into place and reinstall cover: Entire center console.

Scheme 351

Scheme 351: Fuel level sensor
Volume of fuelVolume : litersResistance ohms
Empty fuel tank0322 - 330
Full fuel tank, usable volume708 - 12

Scheme 352

Scheme 352: Fuel level sensor, AWD
Volume of fuelVolume : litersResistance ohms
Empty fuel tank0322.5 - 332.5
Full fuel tank, usable volume705 - 15
Volume : litersFuel pump (FP) unit sensor resistanceEjector unit sensor resistance
0157.5 - 162.5165 - 170
702.5 - 7.52.5 - 7.5

Scheme 353

Scheme 353: Windshield washer level switch

The windshield washer level switch closes when the fluid level is low.

Scheme 354

Scheme 354: Oil pressure switch

Oil pressure switch closes at an oil pressure of < 50 - 10 kPa.

Scheme 355

Scheme 355: Outside temperature sensor

The outside temperature sensor is located under the bumper on the left-hand side.

Temperature: °CResistance: ohms
01424
20610
40287
60146

Scheme 356

Scheme 356: Adapting Light Switch To Different Markets
  1. The light switch can be adapted to different markets using the selector.
