MONITOR STRATEGY
| Required Sensors/Components | Canister pump module |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P0452 and P0453 Within 2 minutes: P0451 (sensor fixed/flat) Less than 15 seconds: P0451 (sensor noise) |
| MIL Operation | Immediate: P0452 and P0453 2 driving cycles: P0451 |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not present | None |
| Atmospheric pressure (absolute pressure) | 70 to 110 kPa-a (525 to 825 mmHg-a) |
| Battery voltage | 10.5 V or more |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| Either of following conditions met | A or B |
| A. Engine condition | Running |
| B. Time after key-off | 5, 7 or 9.5 hours |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or more |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| Atmospheric pressure (absolute pressure) | 70 to 110 kPa-a (525 to 825 mmHg-a) |
| Time after key-off | 5, 7 or 9.5 hours |
P0451 (FIXED/FLAT MONITOR)
| Monitor runs whenever following DTCs not present | None |
| Either of following conditions met | (a) or (b) |
| (a) Ignition switch | ON |
| (b) Soak timer | ON |
TYPICAL MALFUNCTION THRESHOLDS
| Frequency that EVAP pressure changes 0.3 kPa-g (2.25 mmHg-g) or more | 10 times or more in 10 seconds |
P0451: CANISTER PRESSURE SENSOR SIGNAL NOISE
| EVAP pressure change during reference pressure measurement | Less than 0.65 kPa-g (4.87 mmHg-g) |
P0451: CANISTER PRESSURE SENSOR SIGNAL FIXED/FLAT
| EVAP pressure | Less than 42.1 kPa-a (315.9 mmHg-a) |
P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE
| EVAP pressure | More than 123.8 kPa-a (928.4 mmHg-a) |
P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE
Scheme 664
Scheme 664: CONFIRMATION DRIVING PATTERN
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menu items: Powertrain / Engine and ECT / Data List / Intake Air.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Enter the following menu items: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All readiness.
- Input the DTC: P0451, P0452 or P0453.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 665
Scheme 665: WIRING DIAGRAM
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 15 minutes (varies with amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Atmospheric pressure | 70 to 110 kPa-a (525 to 825 mmHg-a) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Below 4 km/h (2.5 mph) |
| Ignition switch | OFF |
| Time after key-off | 5, 7 or 9.5 hours |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key-off | Conditions 1 and 2 |
| 1. Duration that vehicle driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| ECT | 4.4 to 35°C (40 to 95°F) |
| IAT | 4.4 to 35°C (40 to 95°F) |
| EVAP pressure when vacuum introduction complete | Higher than reference pressure x 0.2 |
| EVAP pressure when vacuum introduction complete | Between reference pressure and reference pressure x 0.2 |
MONITOR RESULT
Refer to CHECKING MONITOR STATUS.Refer to CHECKING MONITOR STATUS .
CONFIRMATION DRIVING PATTERN
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Enter the following menu items: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0455 or P0456.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0500: Vehicle speed sensor "A" pulse input error |
| Required Sensors/Components (Main) | Vehicle Speed Sensor (VSS), Combination meter and Skid control ECU |
| Required Sensors/Components (Related) | Park/Neutral Position (PNP) switch, Engine Coolant Temperature (ECT) sensor, Crankshaft Position (CKP) sensor, Throttle Position (TP) sensor and Mass Air Flow (MAF) meter |
| Frequency of Operation | Continuous |
| Duration | 2 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) |
| Time after ignition switch turned from off to ON | 3 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Engine | Running |
| Transmission counter gear revolution | 300 rpm or more |
| When either condition below is met | Condition A or B |
| A. When both conditions below are met | |
| Engine coolant temperature | 20°C (68°F) or higher |
| Time after park/neutral position switch turned from on to off | 2 seconds or more |
| B. When both conditions below are met | |
| Engine coolant temperature | Below 20°C (68°F) |
| Time after park/neutral position switch turned from on to off | 30 seconds or more |
| Vehicle speed sensor signal | No pulse input |
Scheme 666
Scheme 666: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine.
- Drive the vehicle at 24 km/h (15 mph) or more for a total of 30 seconds or more [B].
- Stop the vehicle.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0500.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 667
Scheme 667: WIRING DIAGRAM
| Related DTCs | P0505: ISC function |
| Required Sensors/Components (Main) | ETCS |
| Required Sensors/Components (Related) | Crankshaft position sensor, Engine coolant temperature sensor, and Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT Oil Control Valve) P0011, P0021 (VVT System - Advance) P0012, P0022 (VVT System - Retard) P0016, P0018 (VVT System - Misalignment) P0013, P0023 (Exhaust VVT Oil Control Valve) P0014, P0024 (Exhaust VVT System - Advance) P0015, P0025 (Exhaust VVT System - Retard) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052 (Air Fuel Ratio Sensor Heater) P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256, P2A00, P2A03 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT Sensor) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT Sensor) P0351 - P0356 (Igniter) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0705 (Shift lever position switch) P0748, P0778, P0798 (Pressure Control Solenoid) P0982, P0983, P0985, P0986 (Shift Solenoid) |
| Engine | Running |
| Either condition 1 or 2 is met | |
| 1. Both of following conditions (a) and (b) met | |
| (a) Engine rpm - Target engine speed | Less than -100 rpm, or more than 200 rpm (A/C ON or Shift position is Neutral) Less than -100 rpm, or more than 150 rpm (A/C OFF and Shift position is not Neutral) |
| (b) IAC flow rate learning value | 1.3 L/sec. or less, or 8.5 L/sec. or more for 5 second |
| 2. Both of following conditions (c) and (d) met | |
| (c) Frequency that both of following conditions (1) and (2) | 5 times or more |
| (1) Engine rpm - Target engine rpm | Less than -100 rpm, or more than 200 rpm (A/C ON or Shift position is Neutral) Less than -100 rpm, or more than 150 rpm (A/C OFF and Shift position is not Neutral) |
| (2) Vehicle condition | Stop after vehicle was driven by 6.25 mph (10 km/h) or more |
| (d) Either condition is met | (3) or (4) |
| (3) Amount of change of IAC flow rate learned value | +2.3 L/sec. or more or -4 L/sec. or less |
| (4) IAC flow rate learned value | 1.3 L/sec. or less, or 8.5 L/sec. or more |
Scheme 668
Scheme 668: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or more) with all the accessories switched OFF [B].
- Idle the engine for 10 minute or more [C].
- Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine [D].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result [E]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, repeat step [D] 4 times, allowing 20 seconds or more between each repetition, and then check the DTC judgment result [F].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P0505 A P0505 and other DTCs B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
- CHECK THROTTLE VALVE Check the throttle valve condition. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 6 OK --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
- REPLACE THROTTLE BODY ASSEMBLY. Refer to «REMOVAL»(ref-493466-S05114120172012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P050A: Idle speed control problem at cold |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Engine Coolant Temperature (ECT) sensor, Throttle position sensor, Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT Oil Control Valve) P0011, P0021 (VVT System - Advance) P0012, P0022 (VVT System - Retard) P0016, P0018 (VVT System - Misalignment) P0013, P0023 (Exhaust VVT Oil Control Valve) P0014, P0024 (Exhaust VVT System - Advance) P0015, P0025 (Exhaust VVT System - Retard) P0017, P0019 (Exhaust VVT System - Misalignment) P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256, P2A00, P2A03 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT Sensor) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT Sensor) P0351 - P0356 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) |
| Battery voltage | 8 V or more |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| ECT at engine start | 10°C (14°F) or more |
| ECT | 10 to 50°C (14 to 122°F) |
| Engine idling time | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Time after shift position changed | 1 second or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Accumulated air flow amount | Less than 18 g (varies with engine coolant temperature) |
Scheme 669
Scheme 669: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the tester on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Enter the following menu items: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List are within the range of -10 to 50°C.
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050A.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P050B: Idle ignition timing problem at cold |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Engine Coolant Temperature (ECT) sensor, Throttle position sensor, Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010, P0020 (VVT Oil Control Valve) P0011, P0021 (VVT System - Advance) P0012, P0022 (VVT System - Retard) P0016, P0018 (VVT System - Misalignment) P0013, P0023 (Exhaust VVT Oil Control Valve) P0014, P0024 (Exhaust VVT System - Advance) P0015, P0025 (Exhaust VVT System - Retard) P0017, P0019 (Exhaust VVT System - Misalignment) P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256, P2A00, P2A03 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT Sensor) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT Sensor) P0351 - P0356 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) |
| Battery voltage | 8 V or more |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| ECT at engine start | 10°C (14°F) or more |
| ECT | 10 to 50°C (14 to 122°F) |
| Engine idling time | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 3 km/h (1.875 mph) |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Accumulated time when ignition timing retard is cut off | 5 seconds or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the tester on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Enter the following menu items: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List are within the range of -10 to 50°C.
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050B.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P050B A P050B and other DTCs B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. NG --> See step 20 OK: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Select the following menu items: Powertrain / Engine and ECT / Data List / A/F Control System / Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2. Read the values displayed on the Techstream when the engine is idling. Add together the Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values to obtain the total Fuel Trim. OK Total of Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
- CHECK THROTTLE VALVE Check for deposits around the throttle valve, and the throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. OK --> See step 14 NG --> See step 4
- REPAIR OR REPLACE THROTTLE BODY ASSEMBLY Repair or replace the throttle body assembly.Refer to «REMOVAL»(ref-493466-S05114120172012081000000) . NEXT --> See step 14
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> See step 10 OK: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. OK No leaks in the air induction system. NG --> See step 11 OK: Go to next step
- CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK Air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OCV) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Select the following menu items: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1) or Control the VVT System (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Tester Operation Specified Condition OCV OFF Normal engine speed OCV ON Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 13 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 11.00 gm/s. and 16.00 gm/s. (shift lever: N; A/C: Off). OK --> See step 14 NG --> See step 15
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 14
- REPAIR OR REPLACE AIR INDUCTION SYSTEM Repair or replace the air induction system. NEXT --> See step 14
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
- CHECK AND REPAIR VVT SENSOR Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> See step 15 A --> See step 22
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM.Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-493289-S18206983812012081000000) . Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the B1 mass air flow meter connector. Disconnect the B30 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B1-5 (VG) - B30-74 (VG) Always Below 1 ohms B1-4 (E2G) - B30-75 (E2G) Always Below 1 ohms B1-5 (VG) or B30-7 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter.Refer to «REMOVAL»(ref-493466-S37228417242012081000000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 21 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
- CHECK INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
| Related DTCs | P0560: ECM system voltage |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate (MIL illuminated after next engine start) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| ECM power source | Less than 3.5 V |
Scheme 670
Scheme 670: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0560.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 671
Scheme 671: WIRING DIAGRAM
| Related DTCs | P0604: ECM RAM error |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 6 times |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
Scheme 672
Scheme 672: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0604.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK WHETHER DTC OUTPUT RECURS (P0604) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P0604 A No output B B --> See step 2 A --> See step 3
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTC | P0606: ECM CPU range check |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Either condition A or B is met | |
| A. DMA communication | No response |
| B. Watchdog from Monitoring Processor | Not toggle |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0606.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK WHETHER DTC OUTPUT RECURS (P0606) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Turn the ignition switch off. Disconnect the cable from the negative battery terminal and wait for 1 minute. Connect the cable to the negative battery terminal. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC output) Proceed to P0606 A No DTC output B B --> See step 2 A --> See step 3
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTC | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | APP sensor, TP sensor, Brake switch, Cruise control, HO2 sensor |
| Frequency of Operation | Continuous |
| Duration | 60 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not present | None |
| Engine | Running |
| Estimated HO2S temperature | 450 to 800°C (842 to 1, 472°F) |
Scheme 673
Scheme 673: CONFIRMATION DRIVING PATTERN
- Stop the engine for 30 minutes or more [A].
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [B].
- Start the engine, and wait 2 minutes [C].
- Warm up the engine until the engine coolant temperature is 75°C (167°F) or more [D].
- Idle the engine for 1 minute [E].
- Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [F].
- Drive the vehicle at 56 to 80 km/h (35 to 50 mph) for 5 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0607, P0136, P0137, P0138, P0156, P0157 or P0158.
- Check the DTC judgment result [H]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] through [H].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 674
- CHECK ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . RESULT Result Proceed to P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A Only P0607 is output B B --> See step 3 A: Go to next step
- INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Refer to P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-493462-S08923911752012081000000) . Then proceed to "INSPECT ECM". If P0137 or P0157 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-493462-S08923911752012081000000) . Then proceed to "INSPECT ECM". If P0138 or P0158 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-493462-S08923911752012081000000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT --> See step 6
- CHECK FOR EXHAUST GAS LEAK Allow the engine to idle, and then rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "PERFORM CONFIRMATION DRIVING PATTERN". If no exhaust gas leaks are present, proceed to "PERFORM CONFIRMATION DRIVING PATTERN". HINT: If no exhaust gas leaks are present, a malfunction in the heated oxygen sensor circuit can be suspected. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or more. Perform the driving pattern. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle. Drive the vehicle between 56 and 80 km/h (35 and 50 mph) for 5 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A Only P0607 is output B No DTC is output C B --> See step 7 C --> See step 6 A: Go to next step
- INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Refer to P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-493462-S08923911752012081000000) . Then proceed to "INSPECT ECM". If P0137 or P0157 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-493462-S08923911752012081000000) . Then proceed to "INSPECT ECM". If P0138 or P0158 is output, troubleshoot for that DTC first.Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2); DTC P0156: Oxygen Sensor Circuit Malfunction (Bank 2 Sensor 2); DTC P0157: Oxygen Sensor Circuit Low Voltage (Bank 2 Sensor 2); DTC P0158: Oxygen Sensor Circuit High Voltage (Bank 2 Sensor 2); DTC P0159: Oxygen Sensor Circuit Slow Response (Bank 2 Sensor 2)»(ref-493462-S08923911752012081000000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT: Go to next step
- INSPECT ECM Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check the DTCs. RESULT Result Proceed to DTC is not output A P0607 is output B B --> See step 8 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 16 seconds |
| MIL operation | Immediate |
| Sequence of operation | None |
| When either condition below is met | Condition 1 or 2 |
| 1. When all conditions below are met | |
| CPU reset | 1 time or more |
| Learned TP - Learned APP | 0.4 V or more |
| Electronic throttle actuator | OFF |
| 2. CPU reset | 2 times or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060A.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Check for DTCs. OK P060A is not present. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 10 times: Internal control module is fail 2 times: AD converter is fail 30 times: Knock sensor circuit is fail |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| When one of following conditions is met | Condition 1, 2, 3 or 4 |
| 1. Internal control module serial communication | Fail |
| 2. AD converter | Fail |
| 3. Knock sensor circuit | Fail |
| 4. Knock sensor signal communication | Fail |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060B.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Check for DTCs. OK P060B is not present. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| Difference of main APP and sub APP | 0.3 V or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060D.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Check for DTCs. OK P060D is not present. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | None |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second: Throttle sensor fail 13 times: Brake switch signal fail |
| MIL operation | Immediate |
| Sequence of operation | None |
| DMA communication error | Not detected |
| When one of following conditions is met | Condition 1 or 2 |
| 1. Difference of main TP and sub TP | 0.3 V or more |
| 2. Difference of main brake switch signal and sub brake switch signal | Different |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060E.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Check for DTCs. OK P060E is not present. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P0617: Starter signal |
| Required Sensors/Components (Main) | STARTER relay, PNP switch and Ignition switch |
| Required Sensors/Components (Related) | Vehicle Speed Sensor (VSS), Crankshaft Position (CKP) sensor |
| Frequency of Operation | Continuous |
| Duration | 20 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or more |
| Vehicle speed | 20 km/h (12.43 mph) or more |
| Engine speed | 1, 000 rpm or more |
Scheme 675
Scheme 675: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Idle the engine for 5 minutes or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0617.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
- Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [D].
- Check the DTC judgment result [E].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 676
Scheme 676: WIRING DIAGRAM
Scheme 677
| Related DTCs | P062F: Internal control module EEPROM error |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 3 times |
| MIL operation | Immediate |
| Sequence of operation | None |
| Monitor runs whenever following DTCs not present | None |
| Time after starter on to off | 0.5 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Permanent fault code data | Mismatch (3 times or more) |
Scheme 678
Scheme 678: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 30 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P062F.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No output A P062F B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P0630: VIN not programmed |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.325 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
COMPONENT OPERATING RANGE
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0630.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ CURRENT DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P0630 A P0630 and other DTCs B If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is set, the VIN must be input to the ECM using the Techstream. However, DTCs are cleared automatically by the Techstream when the VIN is input. If DTCs other than P0630 are set, check them first. B --> See step 3 A: Go to next step
- INPUT VIN WITH TECHSTREAM Refer to REGISTRATION.Refer to «REGISTRATION»(ref-493460-S26481541872012081000000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
| Related DTC | P0657: ETCS power supply |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Throttle actuator |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor will run whenever this DTC is not present | None |
| Throttle actuator power supply voltage | 7 V or more |
| Ignition switch | From ON to off (Temporary Fail ON) |
| Throttle actuator power supply | ON |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0657.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK WHETHER DTC OUTPUT RECURS (P0657) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Turn the ignition switch off. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON for 10 seconds. Turn the ignition switch off. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC output) Proceed to P0657 A No DTC output B B --> See step 2 A --> See step 3
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P0724: Stop light switch/Range check/Rationality |
| Required sensors/Components | Stop light switch, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| The monitor will run whenever this DTC is not present. | None |
| Battery voltage | 8 V or more |
| Starter | OFF |
| Ignition switch | ON |
| GO (Vehicle speed is 30 km/h (18.65 mph) or more) | Once |
| STOP (Vehicle speed is less than 3 km/h (1.86 mph)) | Once |
Scheme 679
Scheme 679: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 5 seconds after clear DTCs.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0724.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] through [E].
- Start the engine [C].
- Accelerate the vehicle to 30 km/h (18.65 mph) or more, depress the brake pedal and decelerate the vehicle to 3 km/h (1.86 mph) or less [D]. Repeat step [D] 5 times.
- Check the DTC judgment result [E].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTC | P1607: Internal control module range check |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Cruise control |
| Frequency of Operation | Continuous |
| Duration | 0.3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not present | None |
| DMA communication error | Not detection |
| Cruise control | Prohibited |
| When either condition below is met | A or b |
| A. Cruise control | Operating |
| B. Low speed control | Operating |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P1607.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR DTC Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Check for DTCs. OK P1607 is not present. NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P2102: Throttle actuator current (low current) P2103: Throttle actuator current (high current) |
| Required Sensors/Components (Main) | Throttle actuator (throttle body) |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P2102 25 times: P2103 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Throttle actuator | ON |
| Duty cycle to open throttle actuator | 80% or more |
| Throttle actuator power supply | 8 V or more |
| Motor current change during last 0.016 seconds | Below 0.2 A |
| Throttle actuator | ON |
| Either of the following conditions 1 or 2 is met | |
| 1. Throttle actuator power supply | 8 V or more |
| 2. Throttle actuator power | ON |
| Throttle actuator current | Less than 0.5 A |
| Either of the following conditions is met | Condition 1 or 2 |
| 1. Hybrid IC diagnosis signal | Fail |
| 2. Hybrid IC current limiter monitor | Fail |
Scheme 680
Scheme 680: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine.
- With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
- Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2102 or P2103.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [C] again.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When either of these DTCs or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected and the ignition switch is turned off.
Scheme 681
Scheme 681: WIRING DIAGRAM
| Related DTCs | P2111: Throttle actuator stuck open P2112: Throttle actuator stuck closed |
| Required Sensors/Components (Main) | Throttle actuator |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of following conditions are met | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or higher |
| Duty-cycle to close throttle | 80% or more |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| All of following conditions are met | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or higher |
| Duty-cycle to open throttle | 80% or more |
| *: System guard set when following conditions are met | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or higher |
| Throttle actuator fail | Not detected |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
| Throttle position sensor voltage change | No change |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| Throttle position sensor voltage change | No change |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
Scheme 682
Scheme 682: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2111 or P2112.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When either of these DTCs or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected and the ignition switch is turned off.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P2111 or P2112 A P2111 or P2112 and other DTCs B HINT: If any DTCs other than P2111 or P2112 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle body and check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 4 OK: Go to next step
- READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Check the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output* A Other than above B *: As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector.Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-493289-S18206983812012081000000) . B --> See step 5 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR
- REPLACE THROTTLE BODY ASSEMBLY Replace the throttle body assembly.Refer to «REMOVAL»(ref-493466-S05114120172012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Start the engine, and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve). Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No DTC is output A P2111 or P2112 is output B B --> See step 7 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P2118: Throttle actuator power supply |
| Required Sensors/Components (Main) | Throttle actuator, throttle valve, ETCS fuse |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | 0.8 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 8 V or more |
| Electronic throttle actuator power | ON |
| Throttle actuator power supply voltage (+BM) | Less than 4 V |
| Throttle actuator power supply voltage (+BM) | 11 to 14 V |
Scheme 683
Scheme 683: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the tester on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine.
- Slowly depress the accelerator pedal, raise the engine speed to approximately 3000 rpm for approximately 5 seconds, and then idle the engine [B].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2118.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected and the ignition switch is turned off.
Scheme 684
Scheme 684: WIRING DIAGRAM
| Related DTCs | P2119: ETCS malfunction |
| Required Sensors/Components (Main) | Throttle actuator |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Closed: 1 second Open: 0.6 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| System guard* judge condition | ON |
| *: System guard set when following conditions are met | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or higher |
| Throttle actuator fail | Not detected |
| Either of following conditions A or B met | |
| A. Difference between commanded closed throttle position and current closed throttle position | 0.3 V or more |
| B. Difference between commanded open throttle position and current open throttle position | 0.3 V or more |
Scheme 685
Scheme 685: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine.
- Idle the engine for 20 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2119.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, fully depress and release the accelerator pedal 3 times, and then check the DTC judgment result at step [C].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° opening angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing in accordance with the accelerator pedal position to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected and the ignition switch is turned off.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. Result Display (DTC Output) Proceed to P2119 A P2119 and other DTCs B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Throttle Position No. 1 and Throttle Position Command. Check the values displayed on the Techstream while fully depressing and releasing the accelerator pedal quickly. RESULT Result Proceed to Throttle Position No. 1 does not change A Throttle Position No. 1 changes even a little B HINT: When a DTC is output, the system changes to fail-safe mode. Therefore, only use the data up until the time the DTC is stored for confirmation. B --> See step 4 A: Go to next step
- INSPECT THROTTLE BODY (RESISTANCE OF THROTTLE ACTUATOR) Inspect the throttle body assembly.Refer to «INSPECTION»(ref-493466-S25320506932012081000000) . NG --> See step 6 OK: Go to next step
- INSPECT THROTTLE BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and housing. If necessary, clean the throttle body. Also, check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 6 OK: Go to next step
- READ VALUE USING TECHSTREAM (THROTTLE POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Throttle Position No. 1, Throttle Position No. 2 and Throttle Position Command. Check the values displayed on the Techstream while wiggling the ECM wire harness. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check for DTCs. RESULT Result Proceed to Value in Data List changes when wire harness is wiggled, or DTC is output* A Other than above B *: As the DTC was stored due to a change in the contact resistance of the connector, repair or replace the wire harness or connector.Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-493289-S18206983812012081000000) . B --> See step 7 A --> REPAIR OR REPLACE HARNESS OR CONNECTOR
- REPLACE THROTTLE BODY Replace the throttle body assembly.Refer to «REMOVAL»(ref-493466-S05114120172012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Allow the engine to idle for 15 seconds or more. Fully depress and release the accelerator pedal several times quickly. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to No DTC is output A P2119 is output B B --> See step 9 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P2120: APP sensor 1 range check (fluctuating) P2122: APP sensor 1 range check (low voltage) P2123: APP sensor 1 range check (high voltage) P2125: APP sensor 2 range check (fluctuating) P2127: APP sensor 2 range check (low voltage) P2128: APP sensor 2 range check (high voltage) P2138: APP sensor range check (correlation) |
| Required Sensors/Components (Main) | APP sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P2120, P2122, P2125 and P2127 2.0 seconds: P2123, P2128 and P2138 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Either of following conditions 1 or 2 met | |
| 1. Ignition switch | ON (0.012 seconds or more) |
| 2. Throttle actuator power | ON |
| Either of following conditions met | 1 or 2 |
| 1. All of following conditions met | (a) and (b) |
| (a) VPA voltage | 0.4 V or less |
| (b) VPA2 voltage - Learned VPA2 accelerator off position voltage | 0.04 V or higher |
| 2. VPA voltage | 4.8 V or higher |
| All of following conditions met | (a) and (b) |
| (a) VPA voltage | 0.4 V or less |
| (b) VPA2 voltage - Learned VPA2 accelerator off position voltage | 0.04 V or higher |
| VPA voltage | 4.8 V or higher |
| Either of following conditions met | 1 or 2 |
| 1. All of following conditions met | (a) and (b) |
| (a) VPA2 voltage | 1.2 V or less |
| (b) VPA voltage - Learned VPA accelerator off position voltage | 0.04 V or higher |
| 2. VPA2 voltage when VPA voltage 0.4 to 3.45 V | 4.8 V or higher |
| All of following conditions met | (a) and (b) |
| (a) VPA2 voltage | 1.2 V or less |
| (b) VPA voltage - Learned VPA accelerator off position voltage | 0.04 V or higher |
| VPA2 voltage when VPA voltage 0.4 to 3.45 V | 4.8 V or higher |
| Either of following conditions met | Condition A or B |
| Condition A | |
| Difference between VPA and VPA 2 voltages | 0.02 V or less |
| Condition B | |
| VPA voltage | 0.4 V or less |
| VPA2 voltage | 1.2 V or less |
| VPA voltage | 0.4 to 4.8 V |
| VPA2 voltage | 1.2 to 4.8 V |
| Difference between VPA and VPA2 voltages | More than 0.02 V |
Scheme 686
Scheme 686: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Fully depress and release the accelerator pedal [B].
- Check that 5 seconds or more have elapsed since the DTCs were cleared.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2120, P2122, P2123, P2125, P2127, P2128 or P2138.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When DTC P2120, P2121, P2122, P2123, P2125, P2127, P2128 or P2138 is set, the ECM enters fail-safe mode. If either of the 2 sensor circuits malfunctions, the ECM uses the remaining circuit to calculate the accelerator pedal position to allow the vehicle to continue driving. If both of the circuits malfunction, the ECM regards the accelerator pedal as being released. As a result, the throttle valve is closed and the engine idles.
Fail-safe mode continues until a pass condition is detected and the ignition switch is turned off.
Scheme 687
Scheme 687: WIRING DIAGRAM
| Related DTCs | P2121: Accelerator Pedal Position Sensor Rationality |
| Required Sensors/Components (Main) | Accelerator pedal sensor assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions met | 1 or 2 |
| 1. Ignition switch | ON |
| 2. Throttle actuator power | ON |
| Accelerator pedal position sensor circuit fail (P2120, P2122, P2123, P2125, P2127, P2128, P2138) | Not detected |
| VPA2 voltage | Less than 4.84 V |
| Either of following conditions met | A or b |
| A) VPA voltage - Learned VPA accelerator off position voltage | 0.04 V or more |
| B) VPA2 voltage - Learned VPA2 accelerator off position voltage | 0.04 V or more |
| Difference between VPA voltage and VPA2 voltage (learned value of accelerator off position) | Less than 0.4 V, or more than 1.2 V |
| (VPA voltage - Learned VPA accelerator off position voltage) - (VPA2 voltage - Learned VPA2 accelerator off position voltage) | 0.165 V or more (varies with accelerator position) |
Scheme 688
Scheme 688: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait for 5 seconds after turning the ignition switch to ON.
- Operate the accelerator pedal in accordance with the following procedure [B]. Enter the following menus: Powertrain / Engine and ECT / Data List / Gas Throttle / Accel Sens. No. 1 Volt %, and Accel Sens. No. 2 Volt %. Slowly depress the accelerator pedal until Accel Sens. No. 1 Volt % is approximately 30% and Accel Sens. No. 2 Volt % is approximately 46%, then slowly release the accelerator pedal.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2121.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
The APP sensor has two (main and sub) sensor circuits. If a malfunction occurs in either of the sensor circuits, the ECM detects the abnormal signal voltage difference between the two sensor circuits and switches to limp mode. In limp mode, the functioning circuit is used to calculate the accelerator pedal position to allow the vehicle to continue driving. If both circuits malfunction, the ECM regards the accelerator pedal as being fully released. In this case, the throttle valve remains closed as if the engine is idling.
If a pass condition is detected and the ignition switch is turned off, the fail-safe operation stops and the system returns to normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P2121 A P2121 and other DTCs B HINT: If any DTCs other than P2121 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- READ VALUE USING TECHSTREAM (ACCEL SENSOR OUT No. 1 AND ACCEL SENSOR OUT No. 2) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Data List / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the values displayed on the Techstream. Standard voltage Accelerator Pedal Operations Accel Sensor Out No. 1 Accel Sensor Out No. 2 Released 0.5 to 1.1 V 1.2 to 2.0 V Depressed 2.6 to 4.5 V 3.4 to 4.98 V OK --> See step 6 NG: Go to next step
- REPLACE ACCELERATOR PEDAL ASSEMBLY Replace the accelerator pedal assembly.Refer to «REMOVAL»(ref-493466-S03195754632012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream ON. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Start the engine. Allow the engine to idle for 15 seconds. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P2121 A No output B B --> SYSTEM OK A --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Related DTCs | P2195: A/F sensor signal stuck lean (bank 1) P2196: A/F sensor signal stuck rich (bank 1) P2197: A/F sensor signal stuck lean (bank 2) P2198: A/F sensor signal stuck rich (bank 2) |
| Required Sensors/Components (Main) | A/F sensor |
| Required Sensors/Components (Related) | HO2 sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds: Sensor voltage detection monitor 3 seconds: Sensor current detection monitor |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT System - Misalignment) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052 (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (VVT Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0505 (IAC valve) |
| Time after engine start | 30 seconds or more |
| Fuel system status | Closed-loop |
SENSOR VOLTAGE DETECTION MONITOR
| Battery voltage | 11 V or more |
| ECT | 75°C (167°F) or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| A/F sensor status | Activated |
| Continuous time of fuel cut | 3 to 10 seconds |
SENSOR CURRENT DETECTION MONITOR P2195, P2196, P2197 AND P2198
| Rear heated oxygen sensor voltage | 0.21 V or higher |
| A/F sensor voltage | Higher than 3.8 V |
SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195 AND P2197)
| Rear heated oxygen sensor voltage | Below 0.59 V |
| A/F sensor voltage | Less than 2.8 V |
SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196 AND P2198)
| A/F sensor current during fuel cut | 3.6 mA or more |
SENSOR CURRENT DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195 AND P2197)
| A/F sensor current during fuel cut | Less than 1.4 mA |
SENSOR CURRENT DETECTION MONITOR (RICH SIDE MALFUNCTION P2196 AND P2198)
This confirmation driving pattern is used in the "PERFORM CONFIRMATION DRIVING PATTERN" procedure of the following diagnostic troubleshooting procedure.
Scheme 689
Scheme 689: CONFIRMATION DRIVING PATTERN
Scheme 690
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Start the engine, and warm it up until the ECT reaches 75°C (167°F) or higher [A].
- On the Techstream, select the following menu items to check the fuel-cut status: Powertrain / Engine and ECT / Data List / Idle Fuel Cut.
- Drive the vehicle at between 60 km/h (38 mph) and 120 km/h (75 mph) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Shift the transmission to 2nd gear [C].
- Accelerate the vehicle to 64 km/h (40 mph) or more by depressing the accelerator pedal for at least 10 seconds [D].
- Soon after performing step [D] above, release the accelerator pedal for at least 4 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 2, 500 rpm or more (fuel injection returns at 1, 000 rpm).
- Allow the vehicle to decelerate until the vehicle speed decreases to less than 10 km/h (6 mph).
- Repeat steps [C] through [E] above at least 3 times in one driving cycle.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2195, P2196, P2197 or P2198.
- Check the DTC judgment result [F]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [F].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Refer to CHECKING MONITOR STATUS.Refer to CHECKING MONITOR STATUS .
Scheme 691
Scheme 691: WIRING DIAGRAM
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P2195, P2196, P2197 OR P2198) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P2195, P2196, P2197 or P2198 A "P2195, P2196, P2197 or P2198" and "P0136, P0137, P0138, P0156, P0157 or P0158" are output A P2195, P2196, P2197 or P2198 and other DTCs B HINT: If any DTCs relating to the A/F sensor (DTCs for the A/F sensor heater or A/F sensor admittance) are output, troubleshoot those DTCs first. B --> See step 17 A: Go to next step
- CONFIRM IF VEHICLE HAS RUN OUT OF FUEL IN PAST Has the vehicle run out of fuel in the past? NO --> See step 4 YES: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195, P2196, P2197 or P2198. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195, P2196, P2197 or P2198 is output) B B --> See step 4 A --> DTC CAUSED BY RUNNING OUT OF FUEL
- READ VALUE USING TECHSTREAM (TEST VALVE OF A/F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Monitor / O2 Sensor / Current. Check that the status of O2 Sensor is Complete. If the status is still Incomplete, drive the vehicle according to the driving pattern again. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RANGE B1 S1 or RANGE B2 S1. Check the test value of the A/F sensor output current during fuel-cut. RESULT Result Proceed to Within normal range (1.4 mA or higher, and below 3.6 mA) A Outside normal range (Below 1.4 mA, or 3.6 mA or higher) B B --> See step 14 A: Go to next step
- READ VALUE USING TECHSTREAM (OUTPUT VOLTAGE OF A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the air fuel ratio sensor at an engine speed of 2500 rpm for 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.5% to +12.5%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +12.5% Rich Below 3.1 V AFS Voltage B1S1 (Air fuel ratio) -12.5% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) +12.5% Rich Higher than 0.55 V O2S B1S2 (Heated oxygen) -12.5% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Suspected Trouble Area Proceed to Lean Lean Actual air fuel ratio lean PCV valve and hose PCV hose connections Fuel injector blockage Gas leaks from exhaust system Intake system Fuel pressure Mass air flow meter assembly Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich Fuel injector leakage or blockage Gas leaks from exhaust system Ignition system Fuel pressure Mass air flow meter assembly Engine coolant temperature sensor A Lean Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction Air fuel ratio sensor B Lean/Rich Lean/Rich Normal - B Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the heated oxygen sensor alternates correctly. B --> See step 14 A: Go to next step
- CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leaks. OK No leaks in air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
- CHECK EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure.Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-493470-S04487971902012081000000) . NG --> See step 16 OK: Go to next step
- INSPECT FUEL INJECTOR Check the fuel injector (whether fuel volume is high or low, and whether injector pattern is poor).Refer to «INSPECTION»(ref-493467-S30494626252012081000000) . NG --> See step 18 OK: Go to next step
- REPLACE AIR-FUEL RATIO SENSOR Replace the air fuel ratio sensor.Refer to «REMOVAL»(ref-493427-S03761156882012081000000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195, P2196, P2197 or P2198. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P2195, P2196, P2197 or P2198 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- REPLACE ECM Replace the ECM.Refer to «REMOVAL»(ref-493466-S41904497902012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2195, P2196, P2197 OR P2198) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195, P2196, P2197 or P2198. Check the DTC judgment result. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
- REPLACE AIR-FUEL RATIO SENSOR Replace the air fuel ratio sensor.Refer to «REMOVAL»(ref-493427-S03761156882012081000000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN (DTC P2195, P2196, P2197 OR P2198) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P2195, P2196, P2197 or P2198. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2195, P2196, P2197 or P2198 is output) B B --> See step 19 A --> END
- CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 20
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
- REPLACE FUEL INJECTOR. Refer to «REMOVAL»(ref-493467-S37933332382012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
- REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-493467-S31356503202012081000000)
| Related DTCs | P2237: A/F sensor (bank 1) open circuit between A1A+ and A1A- P2238: A/F sensor (bank 1) short circuit between A1A+ and A1A- P2238: A/F sensor (bank 1) short circuit between A1A+ and GND P2239: A/F sensor (bank 1) short circuit between A1A+ and +B P2252: A/F sensor (bank 1) short circuit between A1A- and GND P2253: A/F sensor (bank 1) short circuit between A1A- and +B P2241: A/F sensor (bank 2) open circuit between A2A+ and A2A- P2241: A/F sensor (bank 2) short circuit between A2A+ and A2A- P2241: A/F sensor (bank 2) short circuit between A2A+ and GND P2242: A/F sensor (bank 2) short circuit between A2A+ and +B P2255: A/F sensor (bank 2) short circuit between A2A- and GND P2256: A/F sensor (bank 2) short circuit between A2A- and +B |
| Required Sensors/Components (Main) | A/F sensor |
| Required Sensors/Components (Related) | Engine Coolant Temperature (ECT) sensor, Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 seconds: A/F sensor open circuit between A1A+/A2A+ and A1A-/A2A- and low impedance 5 seconds: Other |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT System - Misalignment) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052 (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (VVT Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0505 (IAC valve) |
| Estimated sensor temperature | 450 to 550°C (842 to 1022°F) |
| Engine | Running |
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after Ignition switch is OFF to ON | 5 seconds or more |
P2237 AND P2240 (OPEN CIRCUIT BETWEEN A1A+/A2A+ AND A1A-/A2A-)
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT System - Misalignment) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052 (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (VVT Sensor) P0500 (Vehicle Speed Sensor) P0505 (IAC valve) |
| Estimated sensor temperature | 700 to 800°C (1292 to 1472°F) |
| Engine coolant temperature | 5°C (41°F) or higher (varies with ECT at engine start) |
| Fuel cut | Not executed |
P2238 AND P2241 (OPEN CIRCUIT BETWEEN A1A+/A2A+ AND A1A-/A2A-)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2238 AND P2241 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND GND)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2238 AND P2241 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND A1A-/A2A-)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2239 AND P2242 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND +B)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2239 AND P2242 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND VCC)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2252 AND P2255 (SHORT CIRCUIT BETWEEN A1A-/A2A- AND GND)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2253 AND P2256 (SHORT CIRCUIT BETWEEN A1A-/A2A- AND +B)
| Battery voltage | 11 V or more |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2253 AND P2256 (SHORT CIRCUIT BETWEEN A1A-/A2A- AND VCC)
| A/F sensor admittance | Below 0.002 1/ohms |
P2237 AND P2240 (OPEN CIRCUIT BETWEEN A1A+/A2A+ AND A1A-/A2A-)
| A/F sensor admittance | Below 0.015 1/ohms |
P2238 AND P2241 (OPEN CIRCUIT BETWEEN A1A+/A2A+ AND A1A-/A2A-)
| A1A+/A2A+ terminal voltage | 0.5 V or less |
P2238 AND P2241 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND GND)
| Difference between A1A+/A2A+ and A1A-/A2A- terminal voltages | 0.1 V or less |
P2238 AND P2241 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND A1A-/A2A-)
| A1A+/A2A+ terminal voltage | More than 4.5 V |
P2239 AND P2242 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND +B)
| A1A+/A2A+ terminal voltage | More than 4.5 V |
P2239 AND P2242 (SHORT CIRCUIT BETWEEN A1A+/A2A+ AND VCC)
| A1A-/A2A- terminal voltage | 0.5 V or less |
P2252 AND P2255 (SHORT CIRCUIT BETWEEN A1A-/A2A- AND GND)
| A1A-/A2A- terminal voltage | More than 4.5 V |
P2253 AND P2256 (SHORT CIRCUIT BETWEEN A1A-/A2A- AND +B)
| A1A-/A2A- terminal voltage | More than 4.5 V |
P2253 AND P2256 (SHORT CIRCUIT BETWEEN A1A-/A2A- AND VCC)
Scheme 692
Scheme 692: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine and wait 2 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255 or P2256.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes and check the DTC judgment result again [C].
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- INSPECT AIR-FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-493462-S00240019282012081000000) NG --> See step 7 OK: Go to next step
- INSPECT INTEGRATION NO. 1 RELAY (A/F RELAY). Refer to «PROCEDURE - Step 3»(ref-493462-S00240019282012081000000) NG --> REPLACE INTEGRATION NO. 1 RELAY OK: Go to next step
- CHECK WIRE HARNESS (AIR FUEL RATIO SENSOR - ECM) Disconnect the B48 or B33 air fuel ratio sensor connector. Disconnect the B30 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B48-1 (HA1A) - B30-22 (HA1A) Always Below 1 ohms B48-3 (A1A+) - B30-126 (A1A+) Always Below 1 ohms B48-4 (A1A-) - B30-125 (A1A-) Always Below 1 ohms B33-1 (HA2A) - B30-20 (HA2A) Always Below 1 ohms B33-3 (A2A+) - B30-103 (A2A+) Always Below 1 ohms B33-4 (A2A-) - B30-102 (A2A-) Always Below 1 ohms B48-1 (HA1A) or B30-22 (HA1A) - Body ground Always 10 kohms or higher B48-3 (A1A+) or B30-126 (A1A+) - Body ground Always 10 kohms or higher B48-4 (A1A-) or B30-125 (A1A-) - Body ground Always 10 kohms or higher B33-1 (HA2A) or B30-20 (HA2A) - Body ground Always 10 kohms or higher B33-3 (A2A+) or B30-103 (A2A+) - Body ground Always 10 kohms or higher B33-4 (A2A-) or B30-102 (A2A-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR-FUEL RATIO SENSOR Replace the air fuel ratio sensor.Refer to «REMOVAL»(ref-493427-S03761156882012081000000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle referring to the Confirmation Driving Pattern of DTC P2195.Refer to «CONFIRMATION DRIVING PATTERN»(ref-493463-S36187940752012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream ON. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Select the following menu items: Powertrain / Engine and ECT / Trouble Code / Pending. Read pending DTCs. Result Display (DTC Output) Proceed to No output A P2238, P2239, P2252, P2253, P2241, P2242, P2255 or P2256 B B --> See step 8 A --> END
- REPLACE AIR-FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-493427-S03761156882012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 3 minutes (varies with amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Atmospheric pressure | 70 to 110 kPa-a (525 to 825 mmHg-a) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Below 4 km/h (2.5 mph) |
| Ignition switch | OFF |
| Time after key-off | 5, 7 or 9.5 hours |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key-off | Conditions 1 and 2 |
| 1. Duration that vehicle driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| ECT | 4.4 to 35°C (40 to 95°F) |
| IAT | 4.4 to 35°C (40 to 95°F) |
| EVAP pressure change after EVAP canister vent valve ON | Less than 0.3 kPa-g (2.25 mmHg-g) |
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Enter the following menu items: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2420.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Refer to CHECKING MONITOR STATUS.Refer to CHECKING MONITOR STATUS .
| Required Sensors/Components | ECM |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes: Timer malfunction Within 9.5 hours: Timer start-up malfunction |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTC not present | None |
| Ignition switch | ON |
| Engine | Running |
| Battery voltage | 8 V or more |
| Starter | OFF |
| Monitor runs whenever following DTC not present | None |
| Elapsed time from engine stop | Less than 1800 seconds |
| Ignition switch | ON |
| Battery voltage | 8 V or more |
| Starter | OFF |
TIMER START-UP MALFUNCTION (CASE 1)
| Monitor runs whenever following DTC not present | None |
| Elapsed time from engine stop | 2400 seconds or more |
| Ignition switch | ON |
| Battery voltage | 8 V or more |
| Starter | OFF |
TIMER START-UP MALFUNCTION (CASE 2)
| Soak timer measurement when ECM CPU clock counts 10 minutes | Less than 7 minutes, or more than 13 minutes |
| ECM had the started record | Yes |
TIMER START-UP MALFUNCTION (CASE 1)
| ECM had the started record | No |
TIMER START-UP MALFUNCTION (CASE 2)
Scheme 693
Scheme 693: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Start the engine.
- Idle the engine for 10 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2610.
- Check the DTC judgment result [B]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- REPLACE ECM Replace the ECM.Refer to «REMOVAL»(ref-493466-S41904497902012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream ON. Clear DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . Start the engine and wait for 10 minutes or more. On the Techstream, select the following menu items: Powertrain / Engine and ECT / Trouble Code / Pending. If no pending DTC is displayed, the repair has been successfully completed. NEXT --> END
Performing this confirmation pattern will activate the A/F sensor response monitor.
Scheme 694
Scheme 694: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream ON.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Select the following menu items: Powertrain / Engine and ECT / Monitor / O2 Sensor / Details.
- Check that RES RATE B1S1 and RES RATE B2S1 are Incomplete.
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or more) [A].
- Drive the vehicle at a constant speed of between 75 km/h and 100 km/h (47 mph and 62 mph) for 10 minutes [B].
- Check the monitor result values on the Techstream by selecting the following menu items: Powertrain / Engine and ECT / Monitor / O2 Sensor / Details / RES RATE B1S1 and B2S1.
- If the values indicated on the Techstream do not change, perform READINESS MONITOR DRIVE PATTERN for the A/F sensor and heated oxygen sensor.Refer to «READINESS MONITOR DRIVE PATTERN»(ref-493460-S13314905742012081000000) .
- Note the value of the Monitor Result.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P2A00 or P2A03.
- Check the DTC judgment result [C]. Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is N/A, enter the following menus: Powertrain / Engine and ECT / Trouble Code / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs.Refer to «DTC CHECK / CLEAR»(ref-493460-S06003279822012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P2A00: Air-Fuel Ratio (A/F) sensor slow response (bank 1) P2A03: Air-Fuel Ratio (A/F) sensor slow response (bank 2) |
| Required Sensors/Components (Main) | A/F sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor, Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016, P0018 (VVT System - Misalignment) P0017, P0019 (Exhaust VVT System - Misalignment) P0031, P0032, P0051, P0052 (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel System) P0301 - P0306 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (VVT Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0505 (IAC valve) |
| Active A/F control | Performing |
| Active A/F control performed when following conditions met | |
| Engine coolant temperature | 75°C (167°F) or more |
| Battery voltage | 11 V or more |
| Idle | OFF |
| Engine RPM | Less than 4, 000 rpm |
| A/F sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 2nd or higher |
| Catalyst monitor | Not yet |
| Intake air amount | 2.5 to 15 g/sec. |
| Response rate deterioration level | Less than 0.18 V |
Refer to CHECKING MONITOR STATUS.Refer to CHECKING MONITOR STATUS .
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2A00 AND/OR P2A03) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the tester ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read DTCs. Result Display (DTC Output) Proceed to P2A00 and/or P2A03 A P2A00 and/or P2A03 and other DTCs B HINT: If any DTCs relating to the A/F sensor (DTCs for the A/F sensor heater or A/F sensor admittance) are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- INSPECT AIR-FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-493462-S00240019282012081000000) NG --> See step 10 OK: Go to next step
- CHECK WIRE HARNESS (AIR FUEL RATIO SENSOR - ECM) See step 3 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00 AND/OR P2A03) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the tester ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code / Pending. Read pending DTCs. Result Display (DTC Output) Proceed to P2A00 and/or P2A03 A No output B B --> See step 11 A: Go to next step
- REPLACE AIR-FUEL RATIO SENSOR Replace the air fuel ratio sensor.Refer to «REMOVAL»(ref-493427-S03761156882012081000000) NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00 AND/OR P2A03) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream ON. Select the following menu items: Powertrain / Engine and ECT / Trouble Code / Pending. Read pending DTCs. Result Display (DTC Output) Proceed to No output A P2A00 and/or P2A03 B B --> See step 12 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
- REPLACE AIR-FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-493427-S03761156882012081000000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493460-S14877818602012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493466-S41904497902012081000000)
RELATED DTCS
| DTC No. | Monitoring Item | See |
| P043E | Reference orifice clogged (built into canister pump module) | Refer to DTC P043E: Evaporative Emission System Reference Orifice Clog Up; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P043F | Reference orifice high-flow (built into canister pump module) |
| P0441 | Purge VSV (Vacuum Switching Valve) stuck closed Purge VSV stuck open Purge flow | Refer to DTC P0441: Evaporative Emission Control System Incorrect Purge Flow |
| P0451 | Canister pressure sensor (built into canister pump module) signal noise Canister pressure sensor (built into canister pump module) signal becomes fixed/flat | Refer to DTC P0451: Evaporative Emission Control System Pressure Sensor Range / Performance; DTC P0452: Evaporative Emission Control System Pressure Sensor / Switch Low Input; DTC P0453: Evaporative Emission Control System Pressure Sensor / Switch High Input |
| P0452 | Canister pressure sensor (built into canister pump module) voltage low |
| P0453 | Canister pressure sensor (built into canister pump module) voltage high |
| P0455 | EVAP gross leak | Refer to DTC P0455: Evaporative Emission Control System Leak Detected (Gross Leak); DTC P0456: Evaporative Emission Control System Leak Detected (Very Small Leak) |
| P0456 | EVAP small leak |
| P2401 | Leak detection pump stuck OFF (built into canister pump module) | Refer to DTC P043E: Evaporative Emission System Reference Orifice Clog Up; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P2402 | Leak detection pump stuck ON (built into canister pump module) |
| P2419 | Vent valve stuck closed (built into canister pump module) |
| P2420 | Vent valve stuck open (vent) (built into canister pump module) | Refer to DTC P2420: Evaporative Emission System Switching Valve Control Circuit High |
| P2610 | Soak timer (built into ECM) | Refer to DTC P2610: ECM / PCM Internal Engine Off Timer Performance |
If any EVAP system DTCs are stored, the malfunctioning area can be determined using the table below.
Scheme 695
Note. If the reference pressure difference between the first and second checks is more than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P0441, P0455, P0456, P2401, P2420) will all be stored.
Scheme 696
The canister pressure sensor, the leak detection pump and the vent valve are built into the canister pump module.
Scheme 697
Note. In the EVAP system of this vehicle, turning ON the vent valve does not seal off the EVAP system. To check for leaks in the EVAP system, disconnect the air inlet vent hose and apply pressure from atmospheric side of the canister.
While the engine is running, if a predetermined condition (closed-loop, etc.) is met, the purge VSV is opened by the ECM and fuel vapors stored in the canister are purged to the intake manifold. The ECM changes the duty cycle ratio of the purge VSV to control purge flow volume.
The purge flow volume is also determined by the intake manifold pressure. Atmospheric pressure is allowed into the canister through the vent valve to ensure that the purge flow is maintained when negative pressure (vacuum) is applied to the canister.
The following two monitors run to confirm appropriate EVAP system operation.
Scheme 698
Scheme 699
Scheme 700
Scheme 701
- Key-off monitor This monitor checks for EVAP (evaporative emission) system leaks and canister pump module malfunctions. The monitor starts 5 hours* after the ignition switch is turned off. At least 5 hours are required for the fuel to cool down to stabilize the EVAP pressure, thus making the EVAP system monitor more accurate. The leak detection pump creates negative pressure (vacuum) in the EVAP system and the pressure is measured. Finally, the ECM monitors for leaks from the EVAP system, and malfunctions in both the canister pump module and purge VSV based on the EVAP pressure. HINT: *: If the engine coolant temperature is not below 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not below 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.
- Purge flow monitor The purge flow monitor consists of the 2 monitors. The 1st monitor is conducted every time and the 2nd monitor is activated if necessary. The 1st monitor While the engine is running and the purge VSV (Vacuum Switching Valve) is on (open), the ECM monitors the purge flow by measuring the EVAP pressure change. If negative pressure is not created, the ECM begins the 2nd monitor. The 2nd monitor The vent valve is turned ON (closed) and the EVAP pressure is then measured. If the variation in the pressure is less than 0.4 kPa-g (3 mmHg-g), the ECM interprets this as the purge VSV being stuck closed, and illuminates the MIL and stores DTC P0441 (2 trip detection logic). Atmospheric pressure check: In order to ensure reliable malfunction detection, the variation between the atmospheric pressures, before and after of the purge flow monitor, is measured by the ECM. Component Operation Canister Contains activated charcoal to absorb EVAP (Evaporative Emissions) generated in fuel tank. Cut-off valve Located in fuel tank. Valve floats and closes when fuel tank is 100% full. Purge VSV (Vacuum Switching Valve) Opens or closes line between canister and intake manifold. ECM uses purge VSV to control EVAP purge flow. In order to discharge EVAP absorbed by canister to intake manifold, ECM opens purge VSV. EVAP discharge volume to intake manifold controlled by purge VSV duty cycle (current-carrying time). (Open: on, Close: off) Roll-over valve Located in fuel tank. Valve closes by its own weight when vehicle overturns to prevent fuel from spilling out. Soak timer Built into ECM. To ensure accurate EVAP monitor, measures 5 hours (+/-15 min) after ignition switch is turned off. This allows fuel to cool down, stabilizing EVAP pressure. When approximately 5 hours elapsed, ECM activates (Scheme 665) Canister pump module Consists of (a) to (d) below. Canister pump module cannot be disassembled. (a) Vent valve Vents and closes EVAP system. When ECM turns valve on, EVAP system is closed. When ECM turns valve off, EVAP system is vented. Negative pressure (vacuum) is created in EVAP system to check for EVAP leaks by closing purge VSV, turning on vent valve (closing it) and operating leak detection pump see scheme 1 (b) Canister pressure sensor Indicates pressure as voltages. ECM supplies regulated 5 V to pressure sensor, and uses feedback from sensor to monitor EVAP system pressure (Scheme 664) (c) Leak detection pump Creates negative pressure (vacuum) in EVAP system for leak check. (d) Reference orifice Has opening with 0.02 inch diameter. Vacuum is produced through orifice by closing purge VSV, turning off vent valve and operating leak detection pump, to monitor reference pressure. Reference pressure indicates a small leak of EVAP.
After a repair, check Monitor Status by performing the Key-Off Monitor Confirmation and Purge Flow Monitor Confirmation described below.
- KEY-OFF MONITOR CONFIRMATION Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The fuel tank is less than 90% full. The altitude is less than 7875 ft. (2400 m). The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). The vehicle remains stationary (the vehicle speed is 0 km/h [0 mph]). Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the ignition switch off and wait for 6 hours (8 or 10.5 hours). HINT: Do not start the engine until checking Monitor Status. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
- PURGE FLOW MONITOR CONFIRMATION (P0441) HINT: Perform this monitor confirmation after the Key-Off Monitor Confirmation shows Complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The engine coolant temperature is 4.4°C (40°F) or higher. The intake air temperature is 4.4°C (40°F) or higher. Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel cap. Warm the engine up until the engine coolant temperature reaches more than 75°C (167°F). Increase the engine speed to 3000 rpm once. Allow the engine to idle and turn the A/C switch on for 1 minute. Monitor Status Turn the ignition switch off (if ON or if the engine is running). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor did not complete. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
Refer to Checking Monitor Status.Refer to CHECKING MONITOR STATUS .
- CHECK DTC OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: System Select / Health Check. Check DTCs. RESULT Result Proceed to No DTC output A DTC output B B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (STOP LIGHT SWITCH AND ST1) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Stop Light Switch and ST1. Check the Data List indication when the brake pedal is depressed and released. OK Techstream Display Condition Specified Condition Stop Light Switch Brake pedal released OFF Brake pedal depressed ON ST1 Brake pedal released OFF Brake pedal depressed ON NG --> See step 10 OK: Go to next step
- INSPECT BRAKE PEDAL Inspect and adjust the brake pedal.Refer to «ADJUSTMENT»(ref-493389-S18672917172012081000000) . HINT: If the stop light switch turns ON too late, the start of brake override system control may be delayed; if it turns ON too soon, brake override system control may begin too early, so conduct inspection of the brake pedal and stop light switch assembly. NG --> See step 9 OK: Go to next step
- READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %. Read the value displayed on the Techstream. OK Techstream Display Condition Specified Condition Accel Sens. No. 1 Volt % Accelerator Pedal Released --> Depressed --> Released Values smoothly change following accelerator pedal operation Accel Sens. No. 2 Volt % HINT: For numerical values of Accel Sens. No. 1 Volt % and Accel Sens. No. 2 Volt %, refer to the Data List.Refer to «DATA LIST / ACTIVE TEST»(ref-493460-S25626451972012081000000) . NG --> See step 8 OK: Go to next step
- READ VALUE USING TECHSTREAM (VEHICLE SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / Vehicle Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition Vehicle Speed Vehicle stopped, engine running 0 km/h (0 mph) Vehicle running at constant speed between 16.1 to 64.4 km/h (10 to 40 mph) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the drive test. NG --> See step 7 OK: Go to next step
- READ VALUE USING TECHSTREAM (FR, FL, RR, RL WHEEL SPEED) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Chassis / ABS/VSC/TRAC / Data List / FR Wheel Speed, FL Wheel Speed, RR Wheel Speed and RL Wheel Speed. Read the value displayed on the Techstream. Standard Techstream Display Condition Specified Condition FR Wheel Speed FL Wheel Speed RR Wheel Speed RL Wheel Speed Vehicle stopped, engine running 0 km/h (0 mph) Vehicle running at constant speed between 16.1 to 64.4 km/h (10 to 40 mph) No large fluctuations when driving at a constant speed WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Confirm the data after performing the drive test. NG --> INSPECT FRONT OR REAR SPEED SENSOR OK --> END
- GO TO VEHICLE SPEED SENSOR "A". Refer to «DTC P0500: Vehicle Speed Sensor "A"»(ref-493463-S32600470702012081000000)
- REPLACE ACCELERATOR PEDAL SENSOR ASSEMBLY. Refer to «REMOVAL»(ref-493466-S03195754632012081000000)
- REPAIR OR REPLACE BRAKE PEDAL. Refer to «REMOVAL»(ref-493389-S18828803562012081000000)
- INSPECT STOP LIGHT SWITCH ASSEMBLY. Refer to «INSPECTION»(ref-493389-S31837385932012081000000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493460-S19564278272012081000000)
